Elko Lara radio User manual

1/8

5132, 5133, 5134, 5135, 5136, 5137 02-60/2016 rev.:4

LARA Radio

LARA

LAN

LARA

www.elkoep.com

INTERNET RADIO

Supported data transfer formats:

CONTROL / SETTINGS

Front panel:

Remote control:

Communication Ethernet:

Button RESET:

INTERFACE ETHERNET

Communications interface:

Connector:

Max. cable length UTP with power:

DISPLAY

Type:

Resolution:

Visible surface:

POWER SUPPLY PARAMETERS

Supply:

Min. input:

Max. input:

AMPLIFIER PARAMETERS

Ampliﬁer:

Max. ampliﬁer output

INPUTS / OUTPUTS

Audio input:

Audio output 1:

Audio output 2:

CONNECTION

Terminal block:

OTHER DATA

Working temperature:

Protection:

Overvoltage category:

Pollution degree:

Installation:

Dimensions: Frame - plastic:

Frame - metal, glass, wood, granite:

Weight - plastic:

mp3, ogg, acc

touchscreen buttons

IR remote control (part of supply)

via PC setting up and communicating SW LARA conﬁgurator

restart product / reset product to factory settings

10/100 Mbps

RJ45

50m

color OLED

128x128 pixels

26 x 26 mm

PoE 24 V DC (max. 27 V DC) / 1.25 A

1.4 W

26W (peak at maximum playback performance)

stereophonic class D with digital output control

2 x10 W/8 Ω

3.5 stereo jack

terminals LINE OUT (used for external ampliﬁer)*

terminals OUT L/OUT R (speaker output from int. ampliﬁer)

0.5 - 1 mm2(audio outputs)

0 .. + 55 °C

IP20

II.

in an installation box

85 x 85 x 46 mm

94 x 94 x 46 mm

87 g (plastic frame)

Congratulations on purchasing your LARA Radio device (Internet radio in a switch).

The instruction manual provides information on installing and operating the device. The instruction manual is always a part of the supply.

Only perform installation after becoming thoroughly familiar with this User Guide and device functions. Problem-free function of the device

also depends on the way it was shipped, stored and handled. If you notice any signs of damage, deformation, malfunction or a missing part,

do not install this product and return it to the point of sale. At the end of its service life, the product and its parts must be treated as electronic

waste. Before starting the installation, make sure that all wires and connected parts are not under voltage. When assembling and performing

maintenance, you must uphold safety regulations, standards, directives and special provisions for working with electrical equipment.

For successful installation, you will need: LARA Radio, a set of speakers, PoE power source, UTP cable with RJ45 connector, cable for speakers, PC

with the application LARA Configurator.

To protect yourself from electrical shock, connect only safety extra-low voltage (SELV) circuits. For example power supplies PoE (SELV) or LAN

circuits (SELV circuits). Other power supplies (ELV) and WAN circuits (TNV circuits) should not be connected directly to product.

Warning: some LAN and WAN ports use the same connectors RJ-45 so be careful when connecting a product.

Before you begin

Charakteristic

1. Connect LARA and switch

3. Setting of LARA through LARA congurator

2. Connect speakers to LARA

Easy installation in 3 steps

* The cable from the LINE OUT terminals must be shielded, max. length should not exceed 5m.

Technical parametres

Speaker

(8, 16, 32 )

Speaker in design

LOGUS90 21581

External

music

source

WiFi router with PoE

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ...

MP3

128

• A music and Internet radio player - all in the dimension of a switch and a luxurious LOGUS90 design.

• LARA Radio - when connected to the Internet, it can play streaming radio stations and you can store up to 40 of them. But you can also select from thousands of radio stations from across the

globe, which provide data for correct connection.

• LARA Radio can play content from an external music source, which can be an smart phone or e.g. an MP3 player. These devices are connected to a 3.5mm stereo jack audio input, located

underneath the front panel.

• LARA Radio can also play audio files from central data storage, onto which Logitech Media Server is installed. This LARA function can therefore be used within the complex iNELS system or as an

entirely independent home automation device. When used within iNELS, control is a part of the complex application iHC. If using with NAS data storage, the application LARA NAS App is available.

• Touch control is performed on the device front panel (six capacity buttons available), or by infrared remote control, which is included in the product packaging. The basic device settings

(network connection, language, audio input) are performed via the display and a simple menu controlled from capacity buttons on the device front cover. Further settings (selection of

stations, connection with the server, updating firmware, etc.) are configured via computer and the software LARA Configurator.

• LARA Radio is equipped with an OLED colored display with the size of 1.5“. The display also shows basic information about playing music, which also serves the orientation in the menu settings,

etc.

• LARA Radio has an integrated amplifier with 2 x 10 W output, thus greatly facilitating device installation in places where such output suffices. LARA is used e.g. to provide premium sound to

the kitchen, waiting rooms, offices, reception desks, entrance halls, operating rooms or wellness facilities.

• LARA is powered by PoE with maximum voltage level 27 V DC / 1000mA. So connecting and communicating with just one cable (UTP) is a major advantage.

• For LARA, an entire series of accessories is ready for connection (PoE adapters, PoE switches), speakers (in a frame, walls or ceilings) and installation (cables, box, etc.).

• Complies with standards IEEE 802.3u (100BASE-Tx).

• Automatic cable crossing detection of Ethernet cable - MDIX.

Notebook / PC

2/8

5132, 5133, 5134, 5135, 5136, 5137 02-60/2016 rev.:4

LARA Radio

LARA Intercom

www.elkoep.com

External amplier

Output of speakers, audio cables

speaker output (W)

2 x 4 Ω 2 x 20W

2 x 8 Ω 2 x 10W

2 x 16 Ω 2 x 5W

2 x 32 Ω 2 x 2.5W

When installing the speakers, use quality audio cables with

minimum diameter 0.5 mm, with maximum length of 30 m. It is

best to have the same cable length for the right and left channels.

left speaker right speaker

Hardware installation

Requirements for installation environment:

- The product cannot be placed where it is exposed to moisture or excessive heat.

- Place the product at a spot where it can be connected to the Ethernet network. The Ethernet cable with PoE

supply should have a short a distance as possible between the player and PoE source due to voltage drop

occurring as the distance grows. Also use quality cables and connectors of a renowned brand for installation.

- Never install the player without its installation box, and it is prohibited to mount it directly into the wall, e.g. into

drywall partitions, where the device chassis would be directly wrapped in insulation material.

- Distributing individual elements of the installation must be dened prior to actual installation, prior to

interference (cutting) into walls or installation of boxes.

PoE (Power over Ethernet) is fed along a data network cable, without the need to provide power to the

machine by another separate cable.

Description of installation:

Install the bottom part of the LARA player into the box KU, we recommend a box that enables mounting

devices with greater depth.Connect the speaker cables into the terminals OUT L +/- OUT R +/-. You can

connect the input to an external amplifier into the terminals LINE OUT L, LINE OUT R, GND. Snap the Ethernet

cable into the RJ45 connector. Secure the device using the installation box screws. Snap the upper part of

the player into the design frame LOGUS90. Snap the upper part of the player with the frame to the lower part

of the player.

Connection of these two parts must be performed with care to avoid damaging the connectors. Connect

the other end of the Ethernet cable to the PoE switch or via the PoE adapter to the Wi-Fi router, switch. After

providing power, the display shows the system information, then after around five seconds the main display

of the player.

Options of design of the LARA player Radio Music Videophone Intercom Audio zone

In-wall speaker

Installation box

Ceiling speaker

Box for surface mounting

Surface

mounting

Flush mounting

(adapted to be

mounted

inside the wall)

•

ARA - can be mounted inside

our wall (installation box) or oers a surface mounting option.

Connection

3/8

5132, 5133, 5134, 5135, 5136, 5137 02-60/2016 rev.:4

LARA Radio

















- -

 







www.elkoep.com

A long press of both arrows locks the touchpad buttons.

Locking is signaled by a symbol on the display.

The device is unlocked by the same process.

Description and control of player

Long press

Short press

Repeated pressing

Description of display in basic display

Date

Display of actual station

name

Display of station name as

it is listed on the Internet

Bit Rate*

Time

Volume

Performed action

Graphic equalizer

Hidden button RESET

- In the opening (in the upper part of the cover), for pressing use a thin object, i.e. a paper clip

Short press

- navigating in the list of assigned Radios

- switching songs in the Audio Zone

Short press - switching between the Radio, AUX Input and Audio Zone

Long press - switches o the device

Short press - PLAY / PAUSE

Long press - input to menu

Short press

- volume up

- move up between rows

Short press

- volume down

- move down between rows

IR sensor of remote control

Connector for audio input of external music source for AUX Input

* Displaying the transmission quality (transmission speed tells what volume of

information is being transferred per unit of time. The basic unit of the displayed

transmission speed is a kilobit per second).

Control

Playback

Switching between the Radio, AUX Input and

Audio Zone:

Radio: Input AUX:

The input AUX IN is used to connect external

audio devices such as a mobile phone, mp3

player and others.

A 3.5 mm jack provides connection. In this

mode, the player functions as an audio

amplier.

When activating the input, the volume on

the player is set (xed) at 100%.

You can control only on a connected

external audio device.

External

source

music

Switching between modes is performed by a

short touch.

Audio zone:

PLAY / PAUSE

Switching between songs

PLAY / PAUSE

Navigating in the list of assigned

Radios

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ....

MP3

128

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ...

MP3

128

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ...

MP3

128

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ...

MP3

128

01.01.2013 12:54

AUX IN

100%

01.01.2013 12:54

Audio zone

ALBUM

TRACK TITLE

WAITING ...

Button lock

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ...

MP3

128

MP3

128

4/8

5132, 5133, 5134, 5135, 5136, 5137 02-60/2016 rev.:4

LARA Radio















 

www.elkoep.com

Configuration, putting into operation

01.01.2013 12:54

Alarm

01.01.2013 12:54

SET TIME:

00:00

Station:

Alarm

VOLUME: 30%

STATUS: OFF

01.01.2013 12:54

SET TIME:

07:00

Station:

Alarm

VOLUME: 30%

STATUS: OFF

01.01.2013 12:54

SET TIME:

07:00

Station:

Alarm

VOLUME: 30%

STATUS: OFF

01.01.2013 12:54

SET TIME:

07:00

Station:

Alarm

VOLUME: 30%

STATUS: REPEAT

01.01.2013 12:54

SET TIME:

07:00

Station:

Alarm

VOLUME: 30%

STATUS: REPEAT

Opening change.

Setting the value hours / minutes.

Switching hours / minutes.

Saving set time.

Move down one row.

Selection alarm clock / radio station.

/ Increasing/decreasing volume.

/ On 1x / Repeat (every day) / Off.

One press - one level up, multiple presses - return to basic display

Display of alarm

clock settings 01.01.2013 12:54

Alarm

WAITING ..

The alarm stops ringing

by touching any

button.

1. Alarm setting

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ....

N 45

MP3

128

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ....

MP3

128

2. Selecting a language

01.01.2013 12:54

Language

01.01.2013 12:54

Čeština

01.01.2013 12:54

English

01.01.2013 12:54

English

01.01.2013 12:54

Alarm

3. Audio output settings

- Selection of the PA

output to speakers connected to terminals OUT L, OUT R

01.01.2013 12:54

Alarm

01.01.2013 12:54

Audio OUT

01.01.2013 12:54

PA+Line

01.01.2013 12:54

Line

- Selection Output link

to terminals Line OUT L, Line OUT R designed for an external amplier

- Selection PA+Link

output to both terminals

simultaneously

The PA output is set as the default audio.

01.01.2013 12:54

PA+Line

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ....

MP3

128

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ....

MP3

128

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ....

N 45

MP3

128

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ....

MP3

128

5/8

5132, 5133, 5134, 5135, 5136, 5137 02-60/2016 rev.:4

LARA Radio











Factory rst

…

>10s



www.elkoep.com

Opening a change

Move in row

Change to numerical value to +/-

Locking the change

Move to next line - modification see points - 

Move to next line - modification see points - 

* LARA won‘t display the date or time and won‘t play the radio until a new IP address is set and Internet connection

is established.

01.01.2013 12:54

Alarm

01.01.2013 12:54

LAN

01.01.2013 12:54

IP ADRESS:

192.168.0.103

SUBNET MASK:

255.255.255.0

GETEWAY:

192.168.0.1

ASSIGNMENT OF IP:

DHCP

01.01.2013 12:54

IP ADRESS:

---.---.---.---

SUBNET MASK:

---.---.---.---

GETEWAY:

---.---.---.---

ASSIGNMENT OF IP:

STATIC IP

01.01.2013 12:54

Save all

changes?

<< NO >>

01.01.2013 12:54

Save all

changes?

<< YES >>

LARA comes equipped with DHCP, meaning that it assigns the IP address itself automatically from the network range of your DHCP server.

If you select „Static IP“, LARA Intercom automatically restarts and displays the start screen.* Then in LAN you can manually set in the relevant positions:

- IP address - Enter a new address in decimal format separated by periods (default setting: 192.168.1.10).

- Subnet mask - Determines the size of the network: The value 255.255.255.0 is commonly used for the network mask.

- Gateway - Setting the default gate of the local network.

After setting, LARA Radio automatically restarts and displays the start screen.

Nastavení Statické IP aresy:

--.--.---- --:--

IP ADRESS:

192.168.1.10

SUBNET MASK:

255.255.255.0

GETEWAY:

192.168.1.1

ASSIGNMENT OF IP:

STATIC IP

--.--.---- --:--

LAN

--.--.---- --:--

Alarm

--.--.---- --:--

IP ADRESS:

192.168.1.10

SUBNET MASK:

255.255.255.0

GETEWAY:

192.168.1.1

ASSIGNMENT OF IP:

STATIC IP

--.--.---- --:--

IP ADRESS:

192.168.1.11

SUBNET MASK:

255.255.255.0

GETEWAY:

192.168.1.1

ASSIGNMENT OF IP:

STATIC IP

--.--.---- --:--

IP ADRESS:

192.168.1.11

SUBNET MASK:

255.255.255.1

GETEWAY:

192.168.1.1

ASSIGNMENT OF IP:

STATIC IP

--.--.---- --:--

Save all

changes?

<< NO >>

--.--.---- --:--

Save all

changes?

<< YES >>

--.--.---- --:--

STATION:

Radio

NOW PLAYING:

PLAYING ....

MP3

128

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ....

MP3

128

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ....

MP3

128

4. Setting up a network

This concerns how long the display stays lit (10s, 20s, 30s, 1min, 2min, 5min). After this time expires the display goes out. It is activated by touching any button.

5. Settings of the active illumination time of the display

01.01.2013 12:54

Alarm

01.01.2013 12:54

Display

01.01.2013 12:54

DISPLAY OFF:

2 minutes

<< >>

01.01.2013 12:54

DISPLAY OFF:

5 minutes

<< >>

01.01.2013 12:54

DISPLAY OFF:

5 minutes

<< >>

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ....

MP3

128

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ....

MP3

128

Through the settings menu, select „Factory rst“ - returns the product to its factory settings, i.e. the IP address is set to 192.168.1.10, and stored stations are erased.

Reset to factory settings occurs after pressing and holding the hidden button for 10s (reset won‘t occur if the hidden button is released too quickly).

6. Device reset

01.01.2013 12:54

Reset all

setting?

<< NO >>

01.01.2013 12:54

Reset all

setting?

<< YES >>

01.01.2013 12:54

Alarm

01.01.2013 12:54

Factory rst

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ....

MP3

128

01.01.2013 12:54

STATION:

Radio

NOW PLAYING:

Radio

PLAYING ....

MP3

128

6/8

5132, 5133, 5134, 5135, 5136, 5137 02-60/2016 rev.:4

LARA Radio

www.elkoep.com

Configuring the device LARA Radio

Conguring the LARA network music player is performed using the software („SW“) LARA Congurator via Ethernet connection.

SW enables setting the basic network parameters, a change in login data, update of rmware („FW“) of the device, and editing the list of web radios.

Start the LARA Configurator on the PC, which is signed in to the same network as LARA Radio. Then

click on:

Administrator login: In the login window dialog box, enter the set administrator login data. The

factory settings of this data are the user: „admin“ and the password: „elkoep“. If the entered data is

invalid, it will not possible to continue in reading the LARA Radio device settings.

LAN parameters: The IP address of the connected LARA Radio device must be entered in the dialog

window. IP address of the connected device can also be obtained by using the function „Search device“.

In a few seconds, the function „Search device“ searches for all connected LARA devices in the network.

In the dialog window „Searching for device in the LAN network“, a list of all discovered devices is displayed.

By marking the required device and consequent pressing of the button „Select“, the congurator is ready

to read the settings of the device with the selected IP address.

About the device: The window „About the device“ indicates the connection status, login and version

of SW and HW in the LARA Radio device. The connection status is not dependent on successful

„Successful!“ occurs after login data is correctly entered.

About the device: Information about the device and program including hypertext links to the

product manual and catalog list.

Read settings: The button „Read settings“ serves to read all settings stored in the device LARA Radio.

Reading occurs only in the event of successful connection and login.

Save settings: The button „Save settings“ is used to save the complete settings stored to the LARA

Radio.

Remote control: By using the remote control in the LARA Congurator program, you can simply and

quickly check the function of your congured device.

Conguring the device LARA Radio using SW LARA Congurator:

The conguration SW can be freely downloaded from the website http://www.elkoep.

com/products/audiovideo/lara/radio/lara-radio-radio-mounted-in-the-wall-8295/

Using the conguration SW (LARA Congurator), you can:

- set the login data

- set the network connection parameters

- set the parameters for automatic synchronization of time

- edit the Internet radios list

- set the IMM audio zone parameters

- update FW of the LARA Radio device

- remotely control the LARA Radio device

The conguration SW communicates with the LARA Radio device by means of the

Ethernet network. This SW can be run simply without installation in operating systems

Microsoft Windows XP, Windows 7, Windows 8 and Windows 10. A condition to running

the application is support of Microsoft .NET Framework 4 or its possible installation.

Device settings / Network settings

Administrator login: To change the login data, enter the new login name and password into the

text elds. You must conrm the password.

LAN parameters: To change network connection parameters, select the option „DHCP“ (automatic

assignment of an IP address by the DHCP server) or „Static IP address“. If you want to use the device

Intercom, you have to have a static IP address set.

- To change the network connection parameters of the LARA device, enter in the text elds the new IP

address, subnet mask and Epsnet port.

- IP address- Enter a newdevice IP address in decimalformat separated by periods (default setting: 192.168.1.10).

- Subnet mask: Default value 255.255.255.0.

- Firewall: Local network rewall settings.

Port: use the factory preset port 61695. In case of problems with the rewall, we recommend choosing

ports in a range of 49152 to 65535.

Date and time: The IP address of the time server is factory preset.

- SNTP server: If needed, enter the IP address of another time server supporting the SNTP protocol.

(addresses of SNTP servers can be copied from http://www.timetools.co.uk/2013/07/25/ntp-server-uk/)

- Time zone: Select the time zone in the place of installation of the LARA Radio device for correct

display of time.

- You can switch from winter to summer time using the control element „Summer time“

 











 



7/8

5132, 5133, 5134, 5135, 5136, 5137 02-60/2016 rev.:4

LARA Radio

www.elkoep.com

The tab „List of stations“ is used for complete management of the list of Internet radio

stations stored in the LARA device. In LARA Radio, several stations are preset, which you

can change or modify in any way.

Edit stations*: In the section Edit stations, you can use the buttons to add new or modify existing

stations in the list.

List of stations: It is possible to store up to 40 presets into the list for music network streams. LARA

Radio in its current version supports streams in the formats SHOUTcast and Icecast with audio for-

mats MP3, AAC and OGG, which are used in most cases of Internet broadcasting.

Control elements: After successful reading of stations along with overall device settings, you can

browse the list of streams and change their order. For sorting and removing items from the list, use

the relevant control elements on the right side of the list.

* To add a new station, you must know its source address, which is usually given in a variety of forms:

- http://www.servername.com:portnumber/filename

- http://135.111.258.333:8000/filename

- http://www.servername.com:8000/filename

- http://www.servername.com:8000

- http://135.111.258.333:8000

- http://www.servername.com/filename

Import list / Export list: Using these functions, it is possible simply to store a list of set stations by

storing in the le.

Device settings / List of stations

Device settings / Functions

To update the FW in the LARA Radio device, it is rst necessary to download the update le

with the extension „*.lfw“ from the address http://www.elkoep.com/products/audiovideo/

lara/radio/lara-radio-radio-mounted-in-the-wall-8295/

Device settings / Updating FW

Select le: Pressing „Select le“ brings up a dialog window for searching and selecting the update

le. After opening the selected le, its contents are checked, and the user is then informed of the

result. If the correct le has been selected, the FW version number is displayed.

Updating FW: Pressing the button starts the update, the progress of which is illustrated graphically.

Reading a damaged or invalid le prevents the following updating steps, and it is necessary to repe-

at the process with the correct update le.

Adding new radio stations: after pressing the „add“ button, you begin entering the stream parameters into the relevant elds.

Manual completion:

- Name of station: name of preselection displayed on the OLED display.

- IP address: Server address where the stream is being broadcast. The server address must

be entered in decimal format separated by periods. If it is an address with a domain

name (www.servername.com), use the automatic completion option, see below.

- Port number: This is entered as a number in decimal format. (example 1: www.

servername.com:8000/hudba.mp3 - port number = 8000) If this port number is not

listed in the address, enter port number 80 (example 2: www.servername.com/hudba.

mp3 - port no. = 80).

- File name: Not always used and not a required parameter for storing the station.

(example 3: www.servername.com:8000/hudba.mp3 - le name = hudba.mp3)

(example 4: www.servername.com:8000 - do not enter le name).

- After entering all necessary data, store the station in the list by pressing „Save“.

Note: If the le name has the extension *.m3u, it is not the music stream address , but a

playlist address containing the address (or multiple addresses) in the music stream. In

this case, use the option of automatic completion.

Automatic completion:

For most addresses, it is possible to use the function of automatic completion by the

following steps:

- Enter any name of a station.

- Click the option „Automatic completion“ and after entering the address, conrm by

pressing „OK“.

- An information message will inform you of the result of the automatic processing of

the link.

- Enter the station in the list by pressing „Save“.

Note: The automatic completion function requires an active Internet connection.

Important note: Store the prepared list of stations into the device along with settings by pressing „Save“. Until you do so, the list is elaborated and stored only in the SW memory!

Function iMM Audio Zones: used for already installed iNELS system, where the LARA

payer is a fully functional Audio Zone.

Note: the iMM Server is designed to connect nearly all technologies in the home with the intelligent

electrical installation iNELS BUS System.

Function of the iMM Audio Zone The iMM Audio Zone function can be activated and deactivated

by control unit.

IP address: Enter the IP address of the iMM server in decimal format separated by periods.

Name of equipment: This is displayed in the iMM environment and when searching for the device

in the network.

Restart the device after each change in settings of the function.

Note: To set LARA device after FW update it is necessary to use the same version of LARA

Congurator as the FW version.















8/8

5132, 5133, 5134, 5135, 5136, 5137 02-60/2016 rev.:4

LARA Radio

www.elkoep.com

The company ELKO EP, as the manufacturer, is entitled to make technical modications to the product, in the technical specication and product manual, without prior notication. ELKO EP bears no liability for possible incompleteness and mistakes in this document.

Speaker 2“ 32 Ω

- with mounting into an

installation box

Order Code: 21581

Speaker 5“ 32 Ω

Speaker 5“ 16 Ω

Speaker 5“ 8 Ω

- with ceiling mounted

2 way speaker 32 Ω

2 way speaker 16 Ω

2 way speaker 8 Ω

- mounting on a wall or ceiling

- dimension (mm): 270 x 183 x 37

Square 2-way speaker 32 Ω

Square 2-way speaker16 Ω

Square 2-way speaker 8 Ω

- with ceiling mounting

- dimension (mm): 204 x 204 x 92

NAS

Synology DiskStation DS213j

- the storage of data (music, movies, photos) connected

to the LAN

- 2.000 gigabytes storage size

- enables intelligent management and backup

Order Code: 7212

Accessories

PoE switch with5 ports

(to power 5x LARA)

Order Code: 6605

Power / network elements Speakers

White 90710 TBR

Ivory 90710 TMF

Ice 90710 TGE

Pearl 90710 TPE

Grey 90710 TIS

Alluminium 90710 TAL

White 75023 CBR

Ivory 75023 CMF

White 75022 CBR

Ivory 75022 CMF

White 75021 CBR

Ivory 75021 CMF

White 75106 CBR

White 75105 CBR

White 75104 CBR

White 75083 CBR

Ivory 75083 CMF

White 75082 CBR

Ivory 75082 CMF

White 75081 CBR

Ivory 75081 CMF

Cover colors: Order Code:

Power supply PoE

(PoE injector, for powering by

UTP cable, connector 2x RJ45)

Order Code: 5225

Power supply PoE + WiFi

(complete for wireless connection

of LARA into hollow walls)

Order Code: 5227

Power supply of PoE + WiFi into an

installation box

(complete for wireless connection of

LARA into installation boxes)

Order Code: 5224

•The product is not communicating, the display is not illuminated

Solution: Check the power supply. Check to see if the product is connected to the power supply and if the RJ45 connector is connected to the product. Check if the power source PoE

is connected to the network.

•The product is illuminated but the radio does not play.

Solution: Check the IP address of the radio server, or its new settings.

Check the Ethernet network connection. Disconnect and reconnect the RJ45 Ethernet connector. After repeated connection, the product displays system information; if

within ve seconds the player display does not appear,there must be some network connection issues, check the network settings.

•Interrupted playing, frequent reading of the radio.

Probably insucient Internet connection speed.

•Restart the product.

Device restart is used to restart without deleting the set data. Do this by a short press (+/- 1 sec) of the RESET button located on the device cover in the state where the product is
