Ellington SUA62BNK5 User manual

For Models:
SUA62BNK5
SUA62WW5
net weight of fan: 33.15 lb. (15.04 kg) PRINTED IN CHINA
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE
Table of Contents:
Safety Tips. pg. 1
Unpacking Your Fan. pg. 2
Parts Inventory. pg. 2
Installation Preparation. pg. 3
Hanging Bracket Installation. pg. 3
Fan Assembly. pgs. 4 - 5
Wiring. pg. 6
Canopy Assembly. pg. 6
Blade Assembly. pg. 7
Switch Housing Assembly. pg. 7
Testing Your Fan. pg. 8
Troubleshooting. pg. 9
Parts Replacement. pg. 9
Warranty. pg. 9
Installation Guide
E192641

SAFETY TIPS.
page 1
WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit
panel before you begin the fan installation or before servicing the fan or installing accessories.
1. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN
AND SAVE THESE INSTRUCTIONS.
CAUTION: To avoid personal injury, the use of gloves may be necessary while handling fan parts with sharp edges.
2. Make sure all electrical connections comply with Local Codes or Ordinances, the National Electrical Code, and
ANSI/NFPA 70-1999. If you are unfamiliar with electrical wiring or if the house/building wires are different
colors than those referred to in the instructions, please use a qualified electrician.
3. Make sure you have a location selected for your fan that allows clear space for the blades to rotate, and at
least seven (7) feet (2.13 meters) of clearance between the floor and the fan blade tips. The fan should be
mounted so that the tips of the blades are at least thirty (30) inches (76 centimeters) from walls or other
upright structures.
4. The outlet box and ceiling support joist used must be securely mounted, and capable of supporting at least
35 pounds (16 kilograms). The box must be supported directly by the building structure. Use only UL
listed outlet boxes marked "FOR FAN SUPPORT."
WARNING: To reduce the risk of fire, electrical shock, or personal injury, mount to the outlet box marked
"Acceptable for Fan Support of 15.9 kg (35 lbs) or less" and use the mounting screws provided with the outlet box.
Most outlet boxes commonly used for the support of lighting fixtures are not acceptable for fan support and may
need to be replaced. Consult a qualified electrician if in doubt.
WARNING: To reduce the risk of fire, electrical shock, or personal injury, wire connectors provided with this fan are
designed to accept only one12 gauge house wire and two lead wires from the fan. If your house wire is larger than
12 gauge or there is more than one house wire to connect to the corresponding fan lead wires, consult an
electrician for the proper size wire connectors to use.
5. Electrical diagrams are for reference only. Light kits that are not packed with the fan must be UL listed and
marked suitable for use with the model fan you are installing. Switches must be UL general use switches.
Refer to the instructions packaged with the light kits and switches for proper assembly.
6. After installation is complete, check that all connections are absolutely secure.
7. After making electrical connections, spliced conductors should be turned upward and pushed carefully up
into the outlet box. The wires should be spread apart with the grounded conductor and the
equipment-grounding conductor on opposite sides of the outlet box.
WARNING: To reduce the risk of fire or electrical shock, do not use this fan with any solid state speed control device
or control fan speed with a full range dimmer switch. [Using a full range dimmer switch to control fan speed will
cause a loud humming noise from fan.] (Note:This fan is suitable for use with remote control.)
8. Do not operate the reverse switch until fan has come to a complete stop.
9. Do not insert anything between the fan blades while they are rotating.
WARNING: To reduce the risk of personal injury, do not bend the blade arms during assembly or after installation.
Do not insert objects into the path of the blades.
WARNING: To avoid personal injury or damage to the fan and other items, be cautious when working around or
cleaning the fan.
10. Do not use water or detergents when cleaning the fan or fan blades.A dry dust cloth or lightly dampened
cloth will be suitable for most cleaning.
WARNING: To reduce the risk of personal injury, use only parts provided with this fan. The use of parts OTHER
than those provided with this fan will void the warranty.
NOTE: The important safety precautions and instructions appearing in the manual are not meant to cover all
possible conditions and situations that may occur. It must be understood that common sense and caution are
necessary factors in the installation and operation of this fan.

page 2
2. Parts Inventory.
a. canopy. 1 piece
b. hanging bracket. 1 piece
c. 6in. downrod and hanging ball. 1 piece
d. motor housing. 1 piece
e. switch housing plate. 1 piece
f. switch housing. 1 piece
g. blade arm. 5 pieces
h. blade. 5 pieces
i. yoke cover. 1 piece
j. safety cable (already attached to motor).
1 piece
k. canopy cover (in hardware pack). 1 piece
l. hardware packs
a
e
bc
d
f
h
1. Unpacking Your Fan.
Carefully open the packaging. Remove items
from Styrofoam inserts. Remove motor housing
and place on carpet or Styrofoam to avoid
damage to finish. Do not discard fan carton or
Styrofoam inserts should this fan need to be
returned for repairs.
Check against parts inventory that all parts have
been included.
IMPORTANT REMINDER: You must
use the parts provided with this fan for
proper installation and safety.
g
j
i
l
k

4. Hanging Bracket Installation.
page 3
ON
OFF
ON
OFF
3. Installation Preparation.
Vaulted ceiling
angle is not to
exceed 25 degrees.
downrod
installation flushmount
installation
hanging bracket
7 feet
(2.13m) (76cm)
30
inches
12ft. - 20ft.
12ft. - 20ft.
(3.66m - 6.1m)
(3.66m - 6.1m)
blade edge
Turn off circuit breakers to current fixture from breaker panel
and be sure operating light switch is turned to the OFF
position.
WARNING: Failure to disconnect power supply prior to
installation may result in serious injury.
Remove existing fixture.
WARNING: When using an existing outlet box, be sure the outlet
box is securely attached to the building structure and can
support the full weight of the fan. Ensure outlet box is clearly
marked "Suitable for Fan Support." If not, it must be replaced
with an approved outlet box. Failure to do so can result in serious
injury.
CAUTION: Be sure outlet box is grounded properly and that a
ground wire (green or bare) is present.
Install hanging bracket to outlet box using original screws,
spring washers and flat washers provided with new or
original outlet box.* If installing on a vaulted ceiling, face
opening of hanging bracket towards high point of ceiling.
Arrange electrical wiring around the back of the hanging
bracket and away from the hanging bracket opening.
*Note: It is very important that you use the proper hardware
when installing the hanging bracket as this will support the fan.
To prevent personal injury and damage, ensure
that the hanging location allows the blades a
clearance of 7 feet (2.13m) from the floor and
30in. (76 cm) from any wall or obstruction.
This fan is suitable for room sizes up to 400 square
feet (37.2 square meters).
Installation requires these tools:
Phillips screwdriver, flathead screwdriver,
adjustable pliers or wrench, stepladder, wire
cutters, and rated electrical tape.
This fan can be mounted with a downrod
on a regular (no-slope) or vaulted ceiling. The
hanging length can be extended by purchasing
a longer downrod (0.5in./1.27cm diameter).
Other installation, such as flushmount, is not
available for this fan.
spring washers
outlet box screws
flat washers

page 4
5. Fan Assembly.
If you wish to extend the hanging length of your fan, you
must remove the hanging ball from the 6in. downrod
provided to use with an extended downrod (sold
separately). [If you wish to use the 6in.downrod, please
proceed to instructions following the dotted line below.]
To remove hanging ball, loosen set screw on hanging ball,
lower hanging ball and remove stop pin. Slide hanging
ball off the original downrod, A, and slide it down the
longer downrod, B (the top of the downrod should be
noted as having a set screw hole; use this hole when
setting the set screw). Insert stop pin into top of extended
downrod and raise hanging ball. Be sure stop pin aligns
with slots on the inside of the hanging ball.Tighten set
screw securely.
Remove blade arm screws and lock washers from
underside of motor in order to remove blue motor
stabilization plate. (Blue motor stabilization plate may be
discarded once removed but save blade arm screws and
lock washers to secure blade arms).
Tip: To prepare for threading electrical wires through
downrod, apply a small piece of electrical tape to the ends
of the electrical wires--this will keep the wires together
when threading them through the downrod.
Locate canopy cover in hardware pack. Loosen yoke set
screws and nuts in motor housing yoke and remove pin
and clip from motor housing yoke. Slide downrod through
canopy, canopy cover and yoke cover. [Note: Canopy cover
must be turned with shiny side toward the motor
housing.]
Thread safety cable and electrical wires through downrod
and pull extra wire slack from the upper end of the
downrod.
Place downrod into the motor housing yoke and re-insert
pin and clip. Securely tighten yoke set screws and nuts.
Lower yoke cover to motor housing.
["Fan Assembly" continued on next page.]
NOTE: The important safety precautions and instructions
appearing in the manual are not meant to cover all possible
conditions and situations that may occur. It must be
understood that common sense and caution are necessary
factors in the installation and operation of this fan.
set screw hole
set screw
hanging ball
stop pin
A
B
stabilization
plate
safety cable
downrod
electrical wiring
pin
clip
canopy
motor housing
yoke set screw
and nut
yoke cover
canopy cover

page 5
wood
ceiling
joist
5. Fan Assembly. (cont.)
hanging ball slot
hanging bracket tab
motor housing
safety cable
wood screw
and washer
safety cable loop
canopy
With the hanging bracket secured to the
outlet box and able to support the fan, you are
now ready to hang your fan. Grab the fan
firmly with two hands. Slide downrod through
opening in hanging bracket and let hanging
ball rest on the hanging bracket.Turn the
hanging ball slot until it lines up with the
hanging bracket tab.
Tip: Seek the help of another person to hold
the stepladder in place and to help lift the fan
up to you once you are set on the ladder.
Find a secure attachment point (wood ceiling
joist highly recommended) and secure safety
cable. It will be necessary to use a heavy duty
wood screw, washer and lock washer (not
supplied) with the safety cable loop. If
necessary, adjust the loop at the end of the
safety cable.The loop at the end of the safety
cable should just fit over the threads on the
wood screw. Extra cable slack can be left in
ceiling area.

page 6
7. Canopy Assembly.
screw
canopy
hanging bracket
screw
Locate 2 screws on underside of hanging bracket and
remove screw closest to the open end of the hanging
bracket. Partially loosen the other screw. Lift canopy to
hanging bracket. Place rounded part of slotted hole in
canopy over loosened screw in hanging bracket and
push up.Twist canopy to lock. Re-insert screw that was
removed and then tighten both screws securely. Slide
canopy cover up to canopy, aligning rounded part of
slotted holes in canopy cover with screwheads in
bottom of canopy.Turn canopy cover to the right
(clockwise) until it stops. canopy cover
6.Wiring.
CAUTION: Be sure outlet box is properly grounded
and that a ground wire (GREEN or Bare) is present.
Make sure all electrical connections comply with
Local Codes or Ordinances and the National Electrical
Code.If you are unfamiliar with electrical wiring or if
the house/building wires are different colors than
those referred to below, please use a qualified
electrician.
Note: Excess lead wire length from the fan can be cut
to the desired length and then stripped.
When downrod is secured in place on the hanging
bracket, electrical wiring can be made as follows:
Connect BLACK wire from fan to BLACK wire from
ceiling with wire connector provided.
Connect WHITE wire from fan to WHITE wire from
ceiling with wire connector provided.
Connect all GROUND (GREEN) wires together from
fan to BARE/GREEN wire from ceiling with wire
connector provided.
Since this fan does not come with a light kit, you
will need to cap off the BLUE wire with a wire
connector (as shown with arrow in diagram).
[Note: If you elect to purchase a light kit for the fan,
the BLUE wire from the fan must be connected to
the BLACK wire from the ceiling instead.]
* Wrap each wire connector separately with
electrical tape as an extra safety measure.
wire
connector
This fan is remote control adaptable (remote
control sold separately).
black
black
white
white
blue
black supply wire
ground
(green
or bare)
white supply wire
from ceiling
from fan
ground
(green or bare)
*

8. Blade Assembly. motor housing
blade arm
blade
blade attachment
screws and washers
9. Switch Housing Assembly.
switch housing plate
fitter
plate
motor
housing
lock
washers blade arm screws
page 7
Time Saver: Washers for blade screws can be
set on each blade screw prior to installing
blades.
Locate 15 blade attachment screws and
washers in hardware pack. Hold blade arm up
to blade and align holes. Insert 3 blade
attachment screws (along with washers) with
fingers first and then tighten screws securely
with Phillips screwdriver. Repeat procedure for
the remaining blades.
Locate blade arm screws and lock washers that
were previously removed on page 4.
Align
blade arm holes with motor screw holes and
attach one blade arm with lock washers and
blade arm screws. Before securing screws
permanently, repeat procedure with remaining
blade arms. Securely tighten all screws.
Note:Tighten blade arm screws twice a year.
Remove 3 screws from outer edge of switch
housing plate (save screws for later use).
Remove 1 screw from fitter plate on underside
of motor and partially loosen the other 2
screws. Align slotted holes in center of switch
housing plate with loosened screws in fitter
plate, allowing male plug from motor housing
to come through hole in middle of switch
housing plate.Twist switch housing plate to
lock. Re-insert screw that was removed and
secure all screws.
Connect male plug from motor housing to
female plug from switch housing. Make sure
plugs connect tightly.
Align holes in switch housing with holes in
switch housing plate. Re-insert screws that
were previously removed and use a Phillips
screwdriver to secure all screws.
switch housing
male plug
female plug

10.Testing Your Fan.
It is recommended that you test fan before
finalizing installation. Restore power from circuit
box and light switch (if applicable). Test fan
speeds with the pull chain. Start at the OFF
position (no blade movement). First pull will set
the fan to HI. Second pull will set the fan to
MEDIUM-HI.Third pull will set the fan to
MEDIUM-LOW. Fourth pull will the fan to LOW.
Fifth pull will again set the fan to OFF setting.
(diagram 1) If fan does not function, please refer
to "Troubleshooting" section to solve any issues
before contacting Customer Service.
Turn fan completely off before moving the
reverse switch. Set reverse switch to recirculate
air depending on the season:
- LEFT position in summer (diagram 2)
- RIGHT position in winter (diagram 3)
A ceiling fan will allow you to raise your
thermostat setting in summer and lower your
thermostat setting in winter without feeling a
difference in your comfort.
Important: Reverse switch must be set either
completely to the LEFT or completely to the RIGHT
for fan to function. If the reverse switch is set in
the middle position (diagram 4), fan will not
operate.
Attach pull chain extension supplied or custom
pull chain extension (sold separately) to the end
of the pull chain.
page 8
diagram 2 diagram 3 diagram 4
pull chain
extension
reverse
switch
diagram 1
motor housing
switch housing

page 9
Warranty.
Parts Replacement.
For parts and information, please refer to
"Parts Inventory" on page 2.
Craftmade/Ellington Customer Support:
1-800-486-4892
www.ellingtonfans.com
Troubleshooting.
Problem: Fan fails to operate.
Solutions:
1. Check wall switch to fan.
2.Verify that reverse switch is set completely in
either direction.
3. Check to be sure fan is wired properly.
4.Verify that male plug and female plugs are
connected properly in switch housing.
Problem: Fan wobbles.
Solutions:
1. Use the balancing kit in one of the hardware
packs. If no blade balancing kit is provided, please
call Customer Support, 1-800-486-4892, to request
one.
2. Check to be sure set screw(s) on motor
housing yoke is (are) tightened securely.
3. Check to be sure set screw on hanging ball is
tightened securely.
CRAFTMADE/ELLINGTON LIFETIME WARRANTY:
CRAFTMADE/ELLINGTON warrants this fan to the original
household purchaser for indoor use under the following
provisions:
1-YEAR WARRANTY: CRAFTMADE/ELLINGTON will replace
or repair any fan which has faulty performance due to a
defect in material or workmanship.Contact
Craftmade/Ellington Customer Service at 1-800-486-4892
to arrange for return of fan. Return fan, shipping prepaid, to
Craftmade/Ellington.We will repair or ship you a
replacement fan, and we will pay the return shipping cost.
5-YEAR WARRANTY: CRAFTMADE/ELLINGTON will repair or
replace at no charge to the original purchaser any fan
motor that fails to operate satisfactorily when failure
results from normal use.
RETURN FAN MOTOR ONLY, shipping prepaid, to
Craftmade/Ellington.We will repair or ship purchaser a
replacement motor and Craftmade/Ellington will pay the
return shipping cost.
6-YEAR to LIFETIME LIMITED WARRANTY:
CRAFTMADE/ELLINGTON will repair the fan, at no charge
for labor only to the original purchaser, if the fan motor
fails to operate satisfactorily when failure results from
normal use. Parts used in the repair will be billed to the
purchaser at prevailing prices at time of repair.
The purchaser shall be responsible for all costs incurred
in the removal, reinstallation and shipping of the product
for repairs.
This warranty does not apply when damage from
mechanical, physical, electrical or water abuse results in
causing the malfunction. Deterioration of finishes or other
parts due to time or exposure to salt air is specifically
exempted under this warranty.
Neither Craftmade/Ellington nor the manufacturer will
assume any liability resulting from improper installation or
use of this product. In no case shall the company be liable
for any consequential damages for breach of this, or any
other warranty expressed or implied whatsoever.This
limitation as to consequential damages shall not apply in
states where prohibited.
