S&P PCLP50 User manual

WARNING
READ AND SAVE THESE INSTRUCTIONS
Installer: Leave this manual with the homeowner.
CAUTION
CLEANING & MAINTENANCE
OPERATION
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
1. For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors.
2. This product is designed for installation in ceilings up to a 12/12 pitch (45 degree angle). Duct connector must point up.
3. To avoid motor bearing damage and noisy and/or unbalanced impellers, keep drywall spray, construction dust, etc. off
power unit.
4. Please read specification label on product for further information and requirements.
For quiet and efficient operation, long life, and attractive appearance - lower or remove grille and vacuum interior of unit
with the dust brush attachment.
The motor is permanently lubricated and never needs oiling. If the motor bearings are making excessive or unusual noi-
ses, replace the motor with the exact service motor. The impeller should also be replaced.
Use an on/off switch to operate this fan. See “Connect Wiring” for details.
PLAN THE INSTALLATION
1. Do not use in a cooking area.
2. Two ways to connect ductwork to a factory-shipped unit.
1
VENTILATION FAN
MODEL: PCLP50 PCLP80
PCLP100
a). Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer.
b). Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting means to prevent
power from being switching on accidentally. When the service disconnecting means cannot be locked, securely fasten a
prominent warning device, such as a tag, to the service panel.
c). Installation work and electrical wiring must be done by a qualified person(s) in accordance with all applicable codes and
standards, including fire-rated construction codes and standards.
d). Sufficient air is needed for proper combustion and exhausting of gases through the flue (chimney) of fuel burning
equipment to prevent backdrafting.Follow the heating equipment manufacturer’s guideline and safety standards such as
those published by the National Fire Protection Association (NFPA),and the American Society for Heating, Refrigeration
and Air Conditioning Engineers (ASHRAE), and the local code authorities.
e). When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities.
f). Ducted fans must always be vented to the outdoors.
g). Acceptable for use over a tub or shower when connected to a GFCI (Ground Fault Circuit Interrupter) - protected branch
circuit (ceiling installation only).
h). This unit must be grounded.
i). Not for Use in Kitchens.
j). To reduce risk of fire and to properly exhaust air, be sure to duct air outside – Do not vent exhaust air into spaces within
walls or ceilings or into attics,crawl spaces, or garages.
k). WARNING: To Reduce The Risk Of Fire Or Electric Shock, Do Not Use This Fan With Any Solid-State Speed Control
Device.
l). The fan must not be installed in a ceiling thermally insulated to a value greater R40.
ROOF CAP*
(with built-in
damper)
ROUND
DUCT* WALL CAP*
(with built-in
damper)
*Purchase
separately
POWER
CABLE*
INSULATION*
(Place around and
over Fan Housing.)
Seal gaps
around
Housing.
FAN
HOUSING
ROUND
ELBOW(S) *
Seal duct
joints with
tape.
Keep duct
runs short

a. Mount with mounting holes and hanger bar(Ⅰ)
Slide one hanger bar into the channel on the housing and adjust as
needed to fit between framing. Hold housing in place so that the housing
contacts the bottom of the joist, Screw housing to joist through the hole A
and hole B. Screw the hanger bar onto the other side of joist through the
hole (refer to the right diagram).
Screw hanger bar to housing with screw A.
ASSEMBLY INSTRUCTIONS
Distance A
JOIST
1. Before installation, you need to know:
Hole A
Hole B
Hole A
Hole B
Distance A
13 3/4 in to 15 15/16 in (350mm-405mm)
19 11/16 in to 21 7/8 in (500mm-555mm)
13 3/8 in to 19 11/16 in (340mm-500mm)
Hanger Bar Channel
Channel A (Fig. 3)
Channel A (Fig. 3)
Channel B (Fig. 4)
Hanger bar (short)
Hanger bar (long)
Hanger bar (long)
The choice of Hanger Bar
Channel A
Channel B
ST4.2*13mm
Screw A
Screw B
Hanger bar
(short)
Hanger bar
(long)
ST4.2*25mm
7 1/2 in (190mm)
13 3/8 in (340mm)
Note: Hanger bar (short) only can slide into channel A.
Channel B
Hanger bar (long)
c. Mount with hanger bars only
Slide hanger bars onto housing and adjust as needed to fit between
framing. Extend the hanger bars to the width of the framing. Position the
ventilator with the housing tabs wrapped around the bottom edge of
the framing, holding the ventilator in place.
Secure hanger bars to framing using one screw on each end of hanger
bar (refer to the right diagram).
Screw hanger bar to housing with screw A.
Distance A
14 in to 23 1/2 in (356mm-597mm)
19 11/16 in to 23 1/2 in (500mm-597mm)
Hanger Bar A
Hanger bar (short)
Hanger bar A
Hanger bar (long)
The choice of Hanger Bar A
Screw A
Screw B
Screw B
d. Mount to I-joist
Slide one hanger bar (long) into channel B on the housing and adjust as
needed to fit between framing. Hold housing in place so that the housing
contacts the bottom of the joist. Screw housing to joist through the hole A
and hole B. Screw the hanger bar onto the other side of joist through the
hole (refer to the right diagram).
Screw hanger bar to housing with screw A.
Fig. 4
Fig. 2
2
Screw B
Screw A
Channel A
Fig. 3
Fig. 6Fig. 5
Fig. 7
Fig. 8
Fig. 1
Screw B
Screw B
Screw B
Screw B
Distance A
13 3/4 in to 15 15/16 in (350mm-405mm)
19 11/16 in to 21 7/8 in (500mm-555mm)
Hanger Bar A
Hanger Bar A
Hanger bar (short)
Hanger bar (long)
The choice of Hanger Bar
b.
Disconnect plug connector from receptacle and remove adaptor from
housing before starting installation. Slide one hanger bar into the channel A
on the housing and adjust as needed to fit between framing.Insert the
housing into joists make sure that adaptor claws are properly inserted into
housing slots. Secure the housing to adaptor by using screw .
Screw housing to joist through the hole A and hole B Screw B
Screw B
Screw B
Screw
Screw hanger bar to housing with screw A.
Tap
Mount with mounting holes and hanger bar(Ⅱ)

Fig. 10
ductwork
Squeeze
lead wires connectors
Note:
Fig. 9
Ensure the tap (Fig.2) in vertical position before installation.
Slide hanger bars onto housing and adjust as needed to fit between
framing. Extend the hanger bars to the width of the framing. Holding the
ventilator in place.Secure hanger bars to framing using one screw on each
end of hanger bar (refer to the right diagram).
Screw hanger bar to housing with screw A.
Distance A
14 in to 23 1/2 in (356mm-597mm)
19 11/16 in to 23 1/2 in (500mm-597mm)
Hanger Bar A
Hanger bar (short)
Hanger bar (long)
The choice of Hanger Bar A
Hanger bar A
ASSEMBLY INSTRUCTIONS
e. Wall installation with hanger bars only
Run 120V AC house wiring to the location of the fan. Use only UL-approved connectors (not included) to attach the house wiring to the
wiring plate. Refer to the wiring diagram, and connect the wires as shown.
CONNECT ELECTRICAL WIRING
FAN
WIRE
PANEL
UNIT
BLACK (BLK)
SWITCH BOX
FAN
POWER SUPPLY
120V AC
GROUND (GRD)
WHITE(WHT)
FAN
RECEPTACLE
2. Install ductwork and junction box
Remove junction box cover and secure conduit or stress relief to
junction box knock-out hole.Using connectors ,connect house power wires to
ventilating fan wires (refer to wiring diagram) replace the junction box cover.
Squeeze the ductwork to fit the adaptor then slip onto the adapter and
secure it with duct tape (not included) ,secure all the ductwork connections
so that they are air tight.
When the product is installed on the wall,the adaptor shall be faced upward.
3
WIRE
PANEL
UNIT
BLACK(BLK)
SWITCH BOX
FAN
POWER SUPPLY
120V AC
GROUND (GRD)
BROWN(BRN)
WHITE(WHT)
FAN
RECEPTACLE
FAN
SWITCH B
SWITCH
OX
HUMIDITY SENSOR /
HUMIDITY SENSOR /
SPEED CONTROLLER
HUMIDITY SENSOR /
SPEED CONTROLLER
HUMIDITY SENSOR /
SPEED CONTROLLER
SWITCH
CONTROLLER RECEPTACLE
For model: PCLP50 , PCLP80 and PCLP100
For humitidy sensor and speed controller function

Install ceiling material to complete the ceiling construction. Then, cut around
the fan housing.
To attach the grille assembly to the fan housing, pinch the grille springs on
the sides of the grille assembly, and position the grille into the housing with
the grille springs in the appropriate slots. Push the grille assembly towards
the ceiling to secure.
INSTALL GRILLE
SERVICE PARTS
PART PART NAME Qty.
1
2
3
4
5
6
7
8
9
10
a
d
b
c
Housing
Screw
Screw
Screw
Blower Wheel
Motor
1
2
1
1
1
1
1
4
1
1
3
3
3
4
Nut, Hex Lock
Grille Assembly (includes part 2)
Grille Spring
Hanger Bar Kit
* Blower Assembly includes part 4, 3, 9, a, b, c.
WARNING: Before replacing, be sure to turn off power at power source.
WARRANTY
4
1
2
3
4
b
c
a
5
6
7
8
9
10
d
d
Junction box cover
Adaptor
Wire Panel / Harness Assembly
Blower
S&P USA Ventilation Systems, LLC. & S&P Canada Ventilation Products, Inc. warrants to the original end user of its
products that our exhaust fans will be free from defects in materials and workmanship for a period of Five (5) years from
the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING BUT
NOT LIMITED TO IMPLIED WARRANTIES OF SUITABILITY FOR A PARTICULAR PURPOSE.
During this five year period, S&P will, at its option, repair returned products or parts, or provide replacement products or
parts, without charge, for any product or part which is found to be defective under normal use.
This warranty does not cover normal maintenance and service or any parts that have been subject to misuse, negligence,
accident, improper maintenance or repair, faulty installation or installation contrary to recommended installation instructions.
S&P’s obligation to repair or replace, at S&P’s option, shall be the purchaser’s sole and exclusive remedy under this
warranty. No labor or materials are covered by this warranty. S&P shall not be liable for incidental damages arising out of
or in connection with product use or performance.
This warranty gives you specific legal rights. You may also have other rights which vary from state to state.
To qualify for warranty service, you must notify S&P at the address or telephone number stated below, provide the model
number and part identification, and describe the nature of any defect in product or part. You may be required to ship a
defective part to S&P. There will be no charge for shipping repaired or replacement parts from S&P to you if your address
is in the United States or Canada. At the time of requesting warranty service, you must present evidence of the original
purchase date.
S&P USA Ventilation Systems,LLC.
6393 Powers Avenue Jacksonville, FL 32217
P. 904-731-4711
F. 904-731-8322
www.spvg-northamerica.com
S&P Canada Ventilation Products, Inc.
5600 Ambler Drive Mississauga, ON L4W 2K9
P. 866-733-0233
F. 866-358-5346
www.solerpalaucanada.com
OPTION FUNCTION
If need to add option function (humitidy sensor, speed controller ect.),
put relevant power box in the place showed right, fixed it with screws,
and insert the plug from the box into the suitable wire panel.
Connect electrical wiring refer to “CONNECT ELECTRICAL WIRING” .
Screw
