Elm Plus EPL1020 Installation instructions

Elm Plus LLC
2704 Handley Ederville Rd Richland Hills, TX76118
www.elmplus.com
E-mail: [email protected]
US Toll Free: 888 - 357 - 7263

Read this manual before installing and operating this appliance.
Failure to follow these instructions may result in electric
shock, fire property, or personal injury. Do not store or use gasoline or other
flammable liquids in vicinity of this appliance.
Product has been CSA tested and certified.
48"W 30000-BTU Aluminum
Propane Fire Pit with Cover

User Instruction 1
FIRE OR EXPLOSION HAZARD
If you smeII gas:
• Shut off gas to the appliance.
• Extinguish any open flame.
• If odor continues, Ieave the area immediateIy.
• After Ieaving the area, caII your gas supplier or fire department.
FaiIure to foIIow these instructions couId resuIt in fire or
explosion, which could cause property damage, personal injury
or death.
Do not store or use gasoline, or other flammable vapors
and liquids, in the vicinity of this or any other appliance.
An LP-cylinder not connected for use shall not be stored
in the vicinity of this or any other appliance.
For outdoor use only. lnstallation and service must be
performed by a qualified installer, service agency or the
gas supplier.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
DANGER
WARNING
WARNING
WARNING
IMPORTANT, FAILURE TO CAREFULLY READ, UNDERSTAND AND FOLLOW EVERY PART OF
THIS DOCUMENT MAY RESULT IN PROPERTY DAMAGE, SERIOUS BODILY INJURY OR DEATH.
IMPORTANT SAFETY INFORMATION!

User Instruction
2
Improper installation, adjustment, alteration, service or
maintenance may cause property damage, serious bodily injury or
death. Read instructions completely before proceeding with
installation, service or maintenance.
Turn off gas supply when the appliance is not in use.
If the appliance is stored indoors, detach and leave LP-Gas
cylinder outdoors.
This appliance must be attended at all times!
Battery may contain mercury. Do not deposit in fire or put in trash.
Recycle the battery as hazardous waste.
The minimum inlet gas supply pressure for the purpose of input
adjustment: 25psi.
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide which has
no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a
camper, tent, car or home.
DANGER
WARNING
WARNING
WARNING
WARNING

User Instruction 3
Failure to position the parts in accordance with these diagrams or
failure to use only parts specifically approved with this appliance
may result in property damage or personal injury.
lf the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury,
or loss of life.
WARNING
WARNING
WARNING
DANGER
Failure to follow the Dangers, Warnings and Cautions contained in
this Owner’s Manual may result in serious bodily injury or death, or
in a fire or an explosion causing damage to property. During
ignition procedure, one should NEVER get his/her face close to
and/or above the burner in a case an unnoticed flame were to
suddenly light up and cause injury.
• Do not use this appliance for cooking.
• Remove the PVC Cover from the appliance before operating the
appliance.
• Do not lay the PVC Cover over the appliance until it is turned off
and completely cooled down.
• Do not burn any other materials than are supplied with and
intended for use in this appliance.
• Do not pour water into appliance.
• The use and installation of this product must conform with local
codes or, in the absence of local codes, use the National Fuel Gas
Code, ANSI Z223.1 / NFPA5A. Natural Gas and Propane Installation
code CSA Bl49.1 or Propane Storage and Handling codeB149.2.

User Instruction
4
• Do not use this appliance if any part has been under water.
• Remove the battery when not using the appliance for an extended
length of time.
• Do not store a spare or disconnected liquid propane cylinder under
or near this appliance.
• After a period of storage, and/or non use, the propane appliance
should be checked for gas leaks and burner obstructions before use.
• This propane appliance must be used ONLY in a well ventilated
space and shall not be used inside a building or garage.
• Do not operate the propane appliance if there is a gas leak present.
• Do not use this outdoor gas appliance for indoor heating. TOXIC
carbon monoxide fumes can accumulate and cause asphyxiation.
• Never use a flame to check for gas leaks.
• Do not locate this appliance under any overhead enclosure. Avoid
using near or under overhanging trees and shrubs.
• Combustible materials should never be within 10 feet of the top,
back or sides of your propane appliance.
• The propane appliance should never be operated by children.
Children must be supervised and kept at a safe distance while the
appliance is in use.
• Children and adults should be alerted to the hazards of high
surface temperatures and keep a safe distance to avoid burns or
clothing ignition.
• Do NOT use in windy conditions.
• Pay attention when operating the appliance. It is hot in use and
should never be left unattended. Do not attempt to transport it while
in operation.
• Do not attempt to transport this appliance until all parts are cooled
or while it is in operation.
• Should the fire go out while burning, turn the control knob to "off".
Follow the instruction and wait five minutes before attempting to
relight.
• Never use charcoal or any other solid fuel in the appliance. Never
hang clothing or other flammable materials on or near the appliance.

User Instruction 5
• Never lean over the open appliance or place hands or fingers on
the upper portion of an operational unit.
• Do not rest feet on the appliance.
Do not enlarge valve orifices or burner ports when cleaning the
valve or burner.
• Liquid propane gas is not natural gas. This appliance is
manufactured and preset for use with propane gas ONLY.
• The conversion or attempted use of natural gas in a liquid propane
unit or liquid propane gas in a natural gas unit is dangerous.
• Do not use this appliance on vehicles or boats. Always operate the
appliance on flat ground outdoors.
• Keep any electrical supply cord and the fuel supply hose away from
any heated surfaces.
• Do not use this appliance unless all parts are in place.
• Any guard or other protective device removed for servicing this
appliance must be replaced prior to operating this appliance.
• This appliance is designed for use with a 20 lb. liquid propane gas
(LP) tank, not included with this appliance. Never connect your
appliance to an LP gas tank that exceeds this capacity.
• Storage of this outdoor appliance indoors is permissible only if the
tank is disconnected and properly stored outdoors.
• Do not store or use gasoline or other flammable vapors and liquids
within 25 feet (7.62m) of this or any other appliance.
• Cylinders must be stored outdoors in a well-ventilated area out of
the reach of children. The max. inlet supply pressure: 250psi.
• The use of alcohol, prescription or non-prescription drugs may
impair an individual’s ability to properly assemble or safely operate
this outdoor appliance.
• Do not use in an explosive atmosphere. Keep gas appliance area
clear and free from combustible materials, gasoline and other
flammable vapors and liquids.
• This outdoor appliance is NOT to be operated by children. Young
children should be closely supervised when in the vicinity of this
outdoor appliance.

User Instruction
6
• This outdoor appliance is not to be installed or used in or on
recreation vehicles and/or boats.
• Always use in accordance with all applicable local, state and
national codes. Contact your local fire department for details on
outdoor burning.
• Use the same precautions you would with any open fire when using
this outdoor appliance.
• Do not use this outdoor appliance until it is COMPLETELY assem-
bled and all parts are securely fastened and tightened.
• Do not store another LP gas tank within 10 feet (3.05 m) of this
outdoor appliance while it is in operation.
• Do not use this outdoor appliance near automobiles, trucks, vans or
recreational vehicles.
• Certain areas of this outdoor appliance when in use will become too
hot to touch. Do not touch hot surfaces until the unit has cooled
unless you are wearing protective gear such as insulated pot holders
or heat resistant gloves or mittens to avoid burns.
• Keep all electrical cords away from a hot outdoor appliance.
• Do not sit on the mantle when the unit is in operation.
• Do not throw anything onto the fire when the unit is in operation.
• Glass beads are very hot; please keep the children or pets away at
a safe distance.
• Place the hose out of pathways where someone might trip over it or
it where it may be subjected to accidental damage.
FOR LIQUID PROPANE GAS UNITS
WARNING
This outdoor appliance is for use with liquid propane (LP) gas only.
The conversion to or attempted use of natural gas in this outdoor
appliance is dangerous and will void your warranty.
• LP gas is flammable and hazardous if handled improperly. Become
aware of the characteristics before using any LP gas product.

User Instruction 7
Propane Characteristics:
- Flammable, explosive under pressure, heavier than air and settles
in pools in low areas.
- In its natural state, propane has no odor. For your safety, an
odorant has been added.
- Contact with propane could burn the skin.
• A dented or rusty liquid propane cylinder may be hazardous and
should be checked by your gas supplier prior to use.
• Do not use a liquid propane cylinder with a damaged valve and any
other worn out parts.
• Transport and store the empty gas cylinders carefully and properly.
Cylinders must be stored outdoors in a well-ventilated area out of the
reach of children.
• Young children should be carefully supervised when they are in the
area of the appliance.
• Disconnected cylinders must have threaded valve plugs tightly
installed and must not be stored in a building, garage or any other
enclosed area.
• Never use a propane cylinder with a damaged body, valve, collar
or footing.
• If you see, smell or hear the hiss of gas escaping from the
propane cylinder:
1. Turn off the gas supply and get away from the gas cylinder at
once.
2. Do not attempt to correct the problem yourself.
3. Contact your gas supplier and/or fire departement for help.
• The LP gas supply tank constructed and marked in accordance
with the U.S. Department of Transportation (D.O.T.)Specificat ions
for LP-Gas Cylinders, or the Standard for Cylinders, Transportation
of Dangerous Goods and Commission, CAN/CSA-B339.
• LP gas tank must be arranged for vapor withdrawal.
• It is essential to keep the outdoor appliance’s valve compartment,
burners, and circulating air passages clean. Inspect outdoor
appliance before each use. This outdoor appliance should be

User Instruction
8
thoroughly cleaned and inspected on a regular basis. Clean and
inspect the hose before each use of the appliance. If there is
evidence of abrasion, wear, cuts, or leaks, the hose must be
replaced prior to the appliance being put into operation.
• LP Tank used must include a collar to protect the cylinder valve.
• The LP gas tank must have a listed overfilling prevention device
(OPD) and a QCCI or Type I (CGA791) LP gas tank connection.
• The LP gas tank should not be dropped or handled roughly.
• Tanks must be stored outdoors out of the reach of children. Do NOT
store in a building, garage, or any other enclosed area.
• Never store your LP gas tank where temperatures can reach over
125°F.
• Never keep a filled LP gas tank in a hot car or car trunk. Heat will
cause the gas pressure to increase, which may open the relief valve
and allow gas to escape.
• Place dust cap on valve outlet whenever the LP gas tank is not in
use. Only install the type of dust cap on the LP gas tank valve outlet
that is provided with the LP gas tank valve. Other types of caps or
plugs may result in leakage of propane.
• Do not store a spare LP gas tank under or near this gas appliance.
• Never fill the tank beyond 80 percent full.
• LP gas cylinders should only be filled by a certified LP gas dealer.
• The pressure regulator is set for 11 inches of water column
(pressure).
• Any guard or other protective device removed for servicing the
appliance must be replaced prior to operating the appliance.
• Installation and repair should be done by a qualified service person.
The appliance should be inspected before use and at least annually
by a qualified service person. More frequent cleaning may be
required as necessary. It is imperative that control compartment,
burners and circulating air passageways of the appliance be kept
clean.
• Do not attempt to disconnect the gas regulator from the tank or any
gas fitting while the outdoor appliance is in use.

User Instruction 9
• Keep gas appliance away from location where it can get
excessively wet. Do not use gas appliance if any part has been
underwater. Immediately call a qualified service technician to inspect
the appliance and to replace any part of the control system and any
gas control which has been under water.
• This appliance shall be used only outdoors in a well-ventilated
space and shall not be used in a building, garage or any other
enclosed area.
• The LP-gas supply cylinder must be disconnected when this
appliance is not in use.
• Only cylinder marked “propane” shall be used.
• Be sure to use only one 20 lb (9.1 kg) LP gas cylinder with a Type
1 valve with this appliance as required by the American National
Standards Institute (ANSI) and the Canadian Standards Steering
Committee.
• Never attempt to attach this appliance to the self-contained LP gas
system of a camper trailer, motor home or house.
• Hand turn the manual gas control valve. Never use tools. If the
valve will not turn by hand, do not try to repair it. Call a Certified Gas
Technician. The use of force or any self attempted repair may result
in a fire or explosion.
• WARNING: Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage. Refer to the
owner’s information manual provided with this appliance. For
assistance or additional information consult a qualified installer,
service agency or the gas supplier.
LP HOSE AND REGULATOR ASSEMBLY AND REPLACEMENT
1. This appliance comes equipped with a standard LP gas hose and regulator including the
appliance side connection for a CGA No 791 Cylinder Connection Device. The LP gas hose
and regulator supplied with this appliance must be used. Only a hose and regulator
specified by manufacturer can be used for replacement.
a) The CGA No791 connection incorporates an excess flow limiting device that acts to limit
the flow of gas if a leak is detected between the regulator and the burner valve.

User Instruction
10
b) If the burner valve is open prior to the LP gas cylinder service valve being opened, the
connection will interpret this free flow of gas to be a leak.
c) The connection safety feature will reduce gas flow from the regulator to the appliance to
a minimal level.
d) Be sure that the burner control valve is closed prior to opening the LP gas cylinder
service valve to ensure that the connection flow limiting device is not triggered mistakenly.
e) If the connection flow limiting device is triggered mistakenly, close the LP gas cylinder
service valve and the burner valve, wait 10 seconds to allow the device to reset, open the
cylinder service valve, then open the burner valve and light the appliance as per lighting
instructions.
2. Be sure to protect the hose from any hot surfaces. Serious danger may result if the hose
contacts any hot surface.
3. Regular maintenance of the hose and regulator:
a) Inspect the hose before each use of the appliance. If the hose shows signs of cracks,
abrasions, cuts or damage of any kind, do not operate the appliance. Fix or replace the
hose as required before using the appliance. For assistance with repair or replace
replacement of the hose, please contact the supplier. Use only replacement parts from the
manufacturer.
b) Inspect the seal inside the CGA No 791 service valve on the LP gas cylinder when replac-
ing the cylinder or at least once per year. If there is any indication of damage, have the seal
replaced by a certified gas dealer before operating the appliance.
4. Do not use tools to tighten the CGA No 791 connection nut onto the LP gas cylinder
service valve. Hand tighten only.
5. Be careful to not cross the threads on the connection when tightening the CGA No 791
connection on to the LP gas cylinder service valve.
6. “Leak Test” should always be performed after attaching the connection to the LP gas
cylinder service valve. (See “Leak Test” section of this manual)
7. For the connection of the hose and regulator to the LP tank, refer to the “Connection”
section of the LP gas cylinder section above.
WARNING
GLASS BEADS USE
1. Do not light or use gas unit if glass beads are wet. Ensure glass
beads are completely dry before lighting as intense heat could cause
the glass beads to crack.
2. Glass beads could hit somebody's face or eyes during the initial
start of this unit, so please keep away from the appliance for the first
20 minutes.

User Instruction 11
CSA (Canadian Standards Association) certified to ANSI
Z21.97-2017•CSA 2.41-2017 “Outdoor Decorative Gas Appliances”.
Do not connect to a remote gas supply.
EXPLOSIVE VIEW
SPECIFICATIONSFigure 1
Sides: 72in. /
182.9cm
Top: 48 in. /
121.9 cm
50,000 Btu/hr
11 inches water
column
INPUT
Propane Regulator
Pressure
Clearances to
combustible
surfaces

User Instruction
12
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
Lid
Table Top
Control Knob (Preassmbled)
Left Side Panel
Back Side Panel
Right Side Panel
Door Frame
Door
Metal Stand
M6X35mm Bolt
M6X25mm Bolt
M6 Flat Washer
M6 Spring Washer
Wrench
Glass Beads
Battery (AAA) (Not included)
PVC Cover
Door Knob
M4X25mm Screw
M4 Flat Washer
1
1
1
1
1
1
1
1
1
4
12
16
16
1
1
1
1
1
1
1
Item Description Qty

User Instruction 13
STEP 1
Check that the Control Knob (C)
for the gas supply system is
turned to the "OFF" position
before starting any assembly.
STEP 2
Attach the Door Frame (G), Left
Side Panel (D), Back Side Panel
(E) and Right Side Panel (F)
together by using 8pcs
M6X25mm Bolts (K), 8pcs M6
Flat Washer (L) and 8pcs M6
Spring Washer (M).
STEP 3
Attach the Metel Stand (I) with
Left Side Panel (D) and Right
Side Panel (F) together by using
4pcs M6X25mm Bolts (K), 4pcs
M6 Flat Washer (L) and 4pcs M6
Spring Washer (M).
ASSEMBLY INSTRUCTIONS
* Please keep this owner's manual for future reference.
* Please unpack and identify all parts using the parts list provided.
* Note: DO NOT tighten any bolts until all bolts have been started.
Philips screw driver NOT included

User Instruction
14
STEP 4
Attach the steel base to the
bottom part of the Table Top (B)
by using 4pcs M6X35mm Bolts
(J), 4pcs M6 Flat Washer (L)
and 4pcs M6 Spring Washer
(M).
STEP 5
Insert the Door (H) to Right
Front Panel (F) and attach Door
Knob (R) to the door by using
M4X25mm screw (S) and M4
Flat Washer(T).
STEP 6
Place propane gas tank (not
included) into the Metal Stand
(I). Make sure the gas tank sits
on the metal stand completely.
Turn the preassembled wing
screw on the outer part of metal
stand clockwise to secure the
propane gas tank tightly.
STEP 7
Remove the rubber cap on the
electronic ignitor by unscrewing
and slide Battery (P) (not
included) into the battery slot.
Make sure the positive side of
the battery faces outwards.
Screw the electronic ignitor cap
over the battery tightly.

User Instruction 15
STEP 8
Pour the box of glass beads (O) into
the fire pit around Table Top (B).
STEP 9
Close the door, put the Burner
Cover (A) on the fire pit Table Top
(C), then cover the fire pit with PVC
Cover (Q) when not in use to protect
it from the elements or when fire pit
is cool COMPLETELY after the use.
See "LP (Liquid Propane) gas
supply connection" for tank
connection.
** DO NOT COVER THE IGNITION
SCREEN when placing the glass
beads into the fire bowl. Always
keep Ignition Screen visible. This
screen must be clear and free of
obstructions at all times to insure
proper operation.
The burner of the fire bowl must be
covered by glass beads completely.
Otherwise the flame may be
extinguished occasionally. See the
Figure CORRECT and
INCORRECT for reference.
CORRECT INCORRECT
DANGER WARNING:
To ensure proper function, the
guard on this burner should be
free of glass beads at all times.
WARNING
Screen
Do not place lava
on screen.
Keep screen clear

User Instruction
16
LP (LIQUID PROPANE) GAS SUPPLY CONNECTION
SELECTING A LOCATION
• Always confirm that the burner control knob is in the OFF
position before connecting the gas supply.
• Do not obstruct the flow of combustion air and ventilation air to
the appliance.
To Connect:
1. Ensure that there is no debris caught in the head of gas
cylinder, head of the regulator valve.
2. Insert the nipple of the valve coupling into the cylinder valve
and tighten the black coupling nut by turning it
clockwise with one hand while holding the regulator
with the other hand. (See diagram.)
Hand tighten only.
To Disconnect:
1. Always confirm that the cylinder valve is in the
OFF position before disconnecting the gas supply.
2. Hold the regulator with the one hand and loosen
the black coupling nut by turning it counter-clockwise
with the other hand. (See diagram.)
IMPORTANT
Disconnect the propane cylinder from the regulator
valve when the appliance is not in use.
Always place this outdoor appliance on a hard, level non-combustible surface such a
concrete, rock or stone.
Minimum clearance from unit to combustible materials: 48"(121.9cm) from the top,
72"(182.9cm) from all sides. Do not locate this appliance under any overhead enclosure.
Position the appliance so that you have easy access to the control knob.
Min. Clearance
72in.(182.9 cm)
Min. Clearance
48in.(121.9 cm)
Min. Clearance
48in.(121.9 cm)

User Instruction 17
TIPS: Before Beginning
● Read and understand the instructions thoroughly.
● Check and make sure that all parts are present.
● For future reference, save this instruction sheet.
1. Locate the burner control knob and make sure it is in the "OFF" position.
2. Connect propane (LP) cylinder. (See above pages).
3. Open LP tank valve slowly.
4. Push in igniter button to create sparks at the electrode and hold.
5. Push and turn burner control knob to the "LOW" position. Continue to push the control
knob for 15 seconds after ignition.
6. If ignition does not occur within few seconds, turn the burner control knob to "OFF", wait
5 minutes for gas to clear and repeat the lighting procedure. If burner still will not light, refer
to the Troubleshooting Section.
VISUAL CHECK
LEAK TEST
TO LIGHT
Prior to each use, check the hose and valve for excessive wear or abrasions.
1. Perform a leak test in a well ventilated area outside.
2. Make sure any open flames or cigarettes are extinguished.
3. Remove the battery.
4. Ensure the burner control knob is in the "OFF" position.
5. In a bowl, create a soap solution using 1 part water and 1 part liquid detergent.
6. Apply the soapy water solution to all connections.
7. Open LP tank valve.
8. A gas leak will be detected by expanding bubbles originating from the point of the leak.
9. If a leak is found at any connection point or if you smell gas, close the tank valve, disconnect
the tank and do not use the appliance until repairs can be made.
