Elmira Stove Works 1954 Configuration guide

NORTHSTAR™RANGE FEATURES AND SPECIFICATIONS
Specifications subject to change without notice.
Electric Range
1954
Dual-Fuel Range
1955
All Gas Range
1956
RANGE WIDTH 30" 30" 30"
RANGE DEPTH (Plus 2" Handle) 28 ½" 28 ½" 28 ½"
Self-Cleaning Electric Oven (4.3 cu. ft.)
Oven Size: 25"Wx 16"H x17 1/2"D
 
Self-Cleaning Electric Convection Oven (4.0 cu. ft.)
Oven Size: 25"Wx 16"H x16 1/2"Doptional optional
Gas Self-Cleaning Oven with Top Broiler (4.0 cu. ft.)
Oven Size: 25"Wx 15 1/2"H x17 1/2"D

Delayed Start Baking/Cleaning 
Variable Temperature Broil 
Door-Activated Oven Light with manual over-ride 
Heavy Duty, Plated Oven Racks 
Porcelain Enamel Broiler Pan 
RANGE TOP
Electric High-Speed Radiant Elements under glass 
Gas: Sealed Surface Burners with cast grates  
Converts to L.P. (Propane)  
Electronic Spark with Re-ignition  
Chrome frame around range top 
POWER RATINGS
Power Source (208 to 250V) appliance rating 220V-40A 220V-25A 110V-10A
Radiant Elements, 1,500 watts (Rear Elements) 2
Radiant Elements, 2,000 watts (Front Left) 1
Radiant Elements, 2,500 watts (Front Right) 1
Gas Top Burners, 8,000*BTU NG (Rear Burners) 2 2
Gas Top Burners, 12,000*BTU NG (Front Right) 1 1
Superburner, 15,000*BTU NG (Front Left) 1 1
*Ratings for Liquid Propane approx. 10% lower
Power Ratings NG (BTUs) 43,000 58,000
Power Ratings LP (BTUs) 38,700 52,200
Power Ratings – Oven burner NG (BTUs) 16,000
Shipping Weight 275 lbs. 285 lbs. 295 lbs.
RANGE OVERALL DIMENSIONS
30"Wx 49"H x28 ½"D(Plus 2"Handle) – Height to cooking surface is 36".
All 220V ranges come with standard four wire range cords attached. NOTE: The new electrical standard (Jan. 98) requires that a four wire range
cord be used in all new construction. Please advise if a three wire range cord is required (used only in existing construction). Electrical receptacle
and gas piping should be installed in approximately the center of opening, 6 inches off the floor.
STAINLESS STEEL WARMER (Becomes lower storage drawer when warmer option not chosen)
Located behind the drawer face. Heat settings from proofing (80˚) to 225 degrees (F). optional optional not available
Dimensions: 26 ¾ "Wx 22 ½ "Dx 5 3/8"H
