Elnur Gabarron ECOMBI SSH Series User manual

User Guide
ECOMBI SSH
Digital Smart Storage Heaters
ECOSSH158 | ECOSSH208 | ECOSSH308 | ECOSSH408
Please read these instructions carefully before
installing or using this appliance for the first time.

Elnur powered by Gabarrón | ECOMBI SSH | User Guide 2
WARNING: Please read all instructions before installing
or using this heater for the first time.
• This heater is hot when in use. To avoid burns,
do not let bare skin touch hot surfaces.
• Keep combustible materials, such as furniture, pillows,
bedding, papers, clothes, and curtains etc at least
10 Inches (25cm) from the front, sides and rear of the
heater.
• It is essential that the indicated minimum clearances
are maintained.
• CAUTION — Some parts of this product can become
very hot and cause burns. Particular attention
must be given where children and vulnerable
people are present.
• Children should be supervised to ensure they do
not play with the heater.
• Extreme caution is necessary when any heater is
used by or near children or invalids and whenever
the heater is left operating unattended.
• This appliance can be used by children aged 8 years
and above, persons with reduced physical, sensory
or mental capabilities or lack of experience and
knowledge, if they have been given supervision or
instruction concerning the use of the appliance in
a safe way and understand the hazards involved.
Children must not play with the appliance. Cleaning
and user maintenance must not be made by children
without supervision.
• Children aged from 3 years and less than 8 years
shall only switch on/off the appliance provided
that it has been placed or installed in its intended
normal operating position and they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children aged from 3 years and less than
8 years shall not plug in, regulate and clean the
appliance or perform user maintenance.
• Children of less than 3 years should be kept
away unless continuously supervised.
• Do not operate any heater after it malfunctions.
Disconnect the power at the service panel and
have the heater inspected by a reputable electrician
before reusing.
• Do not use the heater outdoors.
• To disconnect the heater, turn controls to off, and turn
off power to heater circuit at main disconnect panel.
• Do not insert or allow foreign objects to enter any
ventilation or exhaust opening as this may cause
an electric shock, fire or damage to the heater.
• Do not use this heater to dry clothes. To prevent
a possible fire, do not block air intakes or exhaust
in any way.
• Air inlets and outlets provide proper operation
of the appliance and prevent it overheating.
DO NOT cover air inlet and outlet grills.
• A heater has hot and arcing or sparking parts inside.
Do not use in areas where gasoline, paint, flammable
vapours or liquids are used or stored. The use of these
heaters is forbidden in any area where there is a
presence of gases, explosives or inflammable objects.
• Use this heater only as described in this manual.
Any other use not recommended by the manufacturer
may cause fire, electric shock, or injury to persons.
• The warranty of the heater will not cover any
damage caused by non observance of any of these
instructions.
• Neither the connecting cable nor any other object
must come into contact with the hot unit.
• This heater should be switched off at the circuit
breaker before any repair work is carried out.
This should also be done during times of the year
when heat is not required.
• The nominal charging period of this heater is indicated
in the rating label.
• Never open a charged heater.
• To maintain stability, it is essential that the heater is
placed on a level surface and care should be taken
to avoid irregular surfaces, such as may result from
carpets or tiled surrounds partially protruding under
the heater.
• The presence of air particles of smoke, dust and
other pollutants could, in time, discolour the walls
and surfaces around the heater.
• Incorrect time settings, erroneous programming
of the reduced rate time and too high temperature
settings may result in a high cost of your
electricity bill.
• SAVE THESE INSTRUCTIONS. This guide must be
kept and given to any new user.
IMPORTANT INFORMATION
When using electrical appliances, basic precautions should always be followed
to reduce the risk of fire, electric shock, and injury, including the following:
WARNING: In order to avoid overheating do not cover the heater.
!

Elnur powered by Gabarrón | ECOMBI SSH | User Guide 3
IMPORTANT INFORMATION
On/Off
Once the heater is connected to a mains supply you can turn the heater ON by
switching the main ON/OFF switch positioned on the rear of the right hand side
of the heater as shown above.
Backlight
Press any button and the display will illuminate with a soft white colour.
The display back light will turn off after time if no buttons are pressed.
Programming Buttons will only respond when the back light is on.
Keyboard Lock
During any operation mode, it is possible to lock the keyboard.
You can do this by holding both the and buttons simultaneously
until the padlock indicator is displayed on the screen.
G-Control Hub
connection indicator
Daily Programming:
Temperature level for
each time interval (1h)
of the day
Button “+” Press
the key to increase
different values or
scroll through menus
Button “-” Press the
key to decrease
different values or
scroll through menus
“Config/Prog” Button
Press the button to access
the advanced configuration
and exit menu items
Open Windows
detection indicator
Keyboard lock indicator
Programme mode
indicator
“OK” Button
Press the button to check and set the time. Press
the button to confirm values in the different menus
Current charge level
Current set point in
Programme Mode
To unlock the keyboard, press the and simultaneously until the
padlock indicator disappears from the screen.
General information
Connection/Disconnection
Power switch. All models are equipped with a switch on the
back side panel. It is used to Turn On and Turn Off the ECOMBI SSH.
Keyboard:
CAUTION: DO NOT USE THIS HEATER TO DRY CLOTHES.
Do not cover this heater at any time.
!

Elnur powered by Gabarrón | ECOMBI SSH | User Guide 4
The default temperature set points are:
• Comfort Temperature or “ ” is set at 21°C
• Economy Temperature or “ ” is set at 18°C
• Frost Protection Temperature or “ ” is set at 3°C
• To amend the default temperature set points view page 6
The defaults off peak charge times are between UP02 00:00, UP03 07:00, UP04 00:00 & UP05 00:00
• If you have different times or have an additional charging period view page 8.
Default programming is:
Comfort: from 07:00 until 22:00 with a default temperature of 21°C.
Economy: from 00:00 until 07:00 & 22:00 to 00:00 with a default temperature of 18°C.
To change the programming please see page 7
*We only recommend using the frost protection in programming for days that you require not stored heat
as the heater does not take charge during frost protection.
For more advanced programming defaults please see page 11.
DEFAULT SETTINGS FOR YOUR ECOSSH
When you first switch your ECOSSH smart storage heater on or do a manual
reset, it will have the following settings.

Elnur powered by Gabarrón | ECOMBI SSH | User Guide 5
QUICK USER GUIDE - SETTING OR CHANGING THE TIME
1. Press any button to get the backlight on.
2. Hold the button until “Func” is displayed Blinking
3. Using or buttons scroll until the time is displayed and press button
4. Again using the and buttons you can modify the hour and press button to
confirm and move to minutes.
5. Repeat step 4 but for the minutes and again press the button confirm and move to setting the day.
6. Using the and buttons modify the days. Monday = Day 1 & Sunday = Day 7.
Once on the correct day press the button to confirm.
The Heater will exit automatically and return to the home screen.

Elnur powered by Gabarrón | ECOMBI SSH | User Guide 6
QUICK USER GUIDE - SETTING OPERATION MODE
1. Press any button to get the backlight on.
2. Hold the button until “Func” is displayed Blinking then press
3. Using or buttons you can select one of the 3 Modes.
4. Once your desired mode is selected press the button to confirm
Frost Protection Manual Control

Elnur powered by Gabarrón | ECOMBI SSH | User Guide 7
QUICK USER GUIDE - SETTING THE SET POINT TEMPERATURES
1. Press any button to get the backlight on.
2. Hold the button until “Func” is displayed Blinking.
3. Using or buttons scroll through the menu until you see all three temp icons then press
4. Again using or buttons set your desired temperatures and press the button to confirm to go to the
next temperature setting and repeat the process.
5. Once you have set all 3 temperatures press the to exit.

Elnur powered by Gabarrón | ECOMBI SSH | User Guide 8
QUICK USER GUIDE - PROGRAMMING YOUR SSH
1. Press any button to get the backlight on.
2. Hold the button until “Func” is displayed Blinking.
3. Using or buttons scroll through the menu until you see the bar diagrams at the top of the display,
icons then press
4. The bar diagram at the top of the display represents every hour of the day you will be programming.
The first segment will begin to flash. To change the temperature mode setting, press the
button and once on the desired setting. Press the button to go to the next hour interval.
2 bars represent the hour is programmed to your Comfort ( ) temperature
1 bar represents the hour is programmed to your Economy ( ) temperature
No bar represents the hour is programmed to your Frost protection ( ) temperature
Please note the heater will not charge during frost protection time intervals.
5. Once you have programmed all the time intervals for the first day, it will automatically go to the next day.
Repeat the process until you have programmed all 7 days.
If you do not wish to edit the current day, press the button to skip to the next day.
Copy Function
You can copy the programming of a current day to the next day or to all the days.
To copy the current day to the next day – Whilst on the day you want to copy, hold until “CP12” is displayed,
this will then copy the current day to the next day. To copy day 2-3 it will show CP23 and so on.
To copy the current day to all the days – Whilst on the day you want to copy, hold until “CPALL” is displayed,
this will then copy the current day to all the other days.

Elnur powered by Gabarrón | ECOMBI SSH | User Guide 9
QUICK USER GUIDE – SETTING THE CHARGE PERIOD TIMES
1. Press any button to get the backlight on.
2. Hold the button until “Func” is displayed Blinking.
3. Using or buttons scroll through the menu until “PArA” is displayed on the screen and press
4. Press the button until “UP02” is displayed then press the button.
5. Using the “ ” and “ ” buttons set the end time of your Off Peak charging period then press the button
6. Press the button until “UP03” is displayed then press the button.
7. Using the “ ” and “ ” buttons set the end time of your off Peak charging period then press the button
8. Repeat the above steps for “UP04” and “UP05” if you have two off
peak charge periods.
9. Once all charge times have been set press button to exit.

Elnur powered by Gabarrón | ECOMBI SSH | User Guide 10
Smart charging control
Ecombi SSH optimizes the energy management and consumption using the current % of the storage heater charge.
It uses this information to charge only the heat required to meet the daily heat demand and avoid unnecessary
energy consumption.
The charge level is monitored by the electronic control and represented in the display by the dots at the bottom of
the display. 5 dots represents a full storage heater charge level. (If not fully charged after a charging period, please
note this is the optimisation working.)
SMART STORAGE HEATER:
Ecombi SSH optimises the energy consumption and ensures the heat demand requested by the
user is met. It does this using a smart energy management system which meets the desired
comfort levels whilst using the least energy.
Current Charge Level
While Ecombi SSH is charging, the last dot is flashing at the top right part of the display.
!
Protection to Avoid excess temperature in a room
In order to achieve maximum savings and avoid
unnecessary energy consumption during the charging
period, the Ecombi SSH monitors the temperature in
the room. If it exceeds the temperature set up in the
heater, then the charging will be interrupted until the
temperature in the room decreases.
Charge correction
The % of the storage heater charge is corrected
automatically by Ecombi SSH software. If the working
hours of the balancing element is higher than a certain
value, the storage heater charge will be increased by a
relevant %. On the other hand, if the balancing element
working hours does not exceed this value, the storage
heater charge level is reduced in the same way.
This behaviour adapts the consumption to the real
thermal needs, allowing the maximum level of energy
savings at the required comfort. The set-up temperature
is independent of the Storage Heater level of charge.
Initial setting for charge is 100%. This value can be
modified by entering the “General Settings” menu to
modify the initial % of storage charge according to the
UP01 setting.
Balancing Heating Element
If the energy discharged with natural convection is
not enough to meet the heat demand of the room, the
Ecombi SSH will use it’s balancing heating element
incorporated to provide additional heat. The maximum
working period of the balancing heating element during
on-peak electric periods can be adjusted by modifying
UP08 parameter. By adjusting the balancing element
you are at risk of the heater not being able to perform
as efficiently as possible.
Balancing Element ON
Storage Heater and Balancing Heating Element will never work at the same time.
!
Adaptive Start Control
With adaptive start control activated, Ecombi SSH electronic control analyses the heating requirements of the room
where it is installed using this information to turn on the balancing heating element in advance in order to reach the
set point temperature at the desired time.
When Adaptive Start Control function is working, the icon ASC is displayed.
!
Open Window Detection
With open window detection activated, the balancing element operation will be disconnected automatically when
a sharp decrease in temperature in the room is detected avoiding energy wastage.
When Open Windows Detection function is working, the icon is displayed.
!

Elnur powered by Gabarrón | ECOMBI SSH | User Guide 11
GENERAL OPERATION MENU
Accessing the general operation menu
It is possible to modify the general operation parameters,
such as charging configuration, temperature units and more.
During any operation mode from the main screen,
you can access the settings.
Hold the button until “Func” is displayed press
the button until
“PArA.” is displayed. Press to access the
general parameters menu. UP01 will be displayed.
Access to the parameter value
Change value: Decrease
Confirm value
Use and to move on through the different parameters.
Use to access the parameter you want to modify. Change
the value using the navigation keys and . Confirm the
new value with .
It is possible to save the changes and exit at any moment by
pressing . Ecombi SSH general parameters that can be
modified by the user are.
- UP01: Initial % of storage charge.
- UP02: Starting time of reduced (off-peak) rate electric period.
- UP03: Ending time of reduced rate electric period.
- UP04: Starting time of the second reduced rate electric period.
(if not available set up 00:00).
- UP05: Ending time of the second reduced rate electric period.
(if not available set up 00:00).
- UP06: Charging days during the week.
- UP07: Temperature ambient sensor correction
(values from -5ºC to5ºC).
- UP08: Maximum working period of the balancing heating
element in on peak electric period.
- UP09: Excess of temperature protection during the charge,
Degrees higher than the comfort set point temperature
(Auto Mode) or the manual set point temperature
(Manual Mode) when the charge is interrupted.
(Values 1,2,3,4 & 5).
- UP10: Degrees Celsius or Fahrenheit. (Values: ºC – F).
- UP11: Open Window Detection Activation. (On/Off).
- UP12: Adaptive Start Control Activation (On/Off)
- UP13: Kind of temperature control. Recommended &
default PID.
ECOMBI SSH does not change automatically
from summer time to winter time or vice
versa when not connected to the internet.
Depending on the tariff it may be necessary
to change the clock settings to fit these
two timings.
i

Elnur powered by Gabarrón | ECOMBI SSH | User Guide 12
REMOTE OPERATION USING THE WIFI G-CONTROL HUB
It is possible to control the full operation of the Ecombi
SSH remotely with the Elnur-Gabarron app or web-app.
The unit must be connected to a G-Control Hub
connected to the Internet to use this feature.
(Wifi is needed for this feature)
To associate the unit to the G-Control Hub, the discovery
mode must be activated. Press the associate button at
the back of the hub for 3 seconds. An orange flashing
light every second indicates association mode.
With the hub in association mode, press on the
storage heater for 3 seconds until is shown.
You can control and adjust the programming
and temperatures on the Ecombi SSH via the
Gabarron-Elnur app.
Download the Elnur app or go online
Scan the QR Code or visit the App store
from your Android or Apple device.
If you don’t have one of these devices simply log on to:
https://remotecontrol.elnur.es/#/signin

Elnur powered by Gabarrón | ECOMBI SSH | User Guide 13
DEFAULT SETTINGS & RESET
To reset the unit to factory default settings, hold and simultaneously until the message “SrES” is displayed.
Confirm the reset with
5s
Default Values
Sun: Comfort temperature 21ºC
Moon: Economic temperature 18ºC
Frost: protection temperature 3ºC
UP01: Initial % of storage charge 100%
UP02: Starting time off peak period 1 00:00
UP03: Ending time off peak period 1 07:00
UP04: Starting time off peak period 2 00:00
UP05: Ending time off peak period 2 00:00
UP06: Charging days of the week Default -> Charging 7 days of the week.
UP07: Ambient sensor Offset 0ºC
UP08: Max. Balancing element – working period 16 hours
UP09: Overtemperature protection 2ºC
UP10: Temperature Unit ºC
UP11: Open Window Detection Function Off
UP12: Adaptive Start Control Off
UP13: Kind of temperature control PID
Default Programming Comfort: 07:00 to 22:00.
Eco: 00:00 to 07:00 & 22:00 to 00:00.

Elnur powered by Gabarrón | ECOMBI SSH | User Guide 14
CLEANING MAINTENANCE
INSTRUCTIONS
TECHNICAL FEATURES
MAIN COMPONENTS LIST
Before cleaning, make sure the power has been
turned off at the circuit breaker panel and that
the heating element of the heater is cool.
Occasionally, clean dust with a dry, soft cloth.
Do not use any solvent or abrasive product
for cleaning.
When the Heating season is finished, please
disconnect the device by turning off the power
switch located at the right side on the back
of the unit or at the circuit breaker.
Any other servicing should be performed by
an authorised technician.
ECOMBI SSH has been manufactured
under a fully assured quality system
and using environmentally friendly
processes. Once its useful life is
finished please take the device
to a recycling depot so that its
components can be recycled in
an appropriate way.
Storage Heating Element
(All except ECOSSH158) Ref. 15190091
Storage Heating Element (ECOSSH158) Ref. 15190875
450W Balancing Heating Element
(ECOSSHI58) Ref. 15190105
600W Balancing Heating Element
(ECOSSH208) Ref. 15190110
900W Balancing Heating Element
(ECOSSH308) Ref. 15190120
1200W Balancing Heating Element
(ECOSSH408) Ref. 15190130
Switch Ref. 46100530
Power PCB & Fixing Bracket Ref. 15191890
Keyboard PCB ECO SSH Ref. 15191873
Core Sensor Ref. 15192140
Room Sensor Ref. 46102195
110ºC Balancing Element Limiter Ref. 15190725
135ºC Cut Out Manually Limiter Ref. 10190460
Model ECOSSH158 ECOSSH208 ECOSSH308 ECOSSH408
Connection 220 - 240V ~ 220 - 240V ~ 220 - 240V ~ 220 - 240V ~
Balancing Element Output 450/490W 600/653W 900/980W 1200/1307W
Storage Heater Output 975/1062W 1300/1415W 1950/2123W 2600/2831W
Charge Period 7.6 – 7h 7.6 – 7h 7.6 – 7h 7.6 – 7h
Charging 7.4 kWh 9.9 kWh 14.9 kWh 19.8 kWh
Insulation Class I Class I Class I Class I
Length 55cm 66cm 89cm 111cm
Height 73cm 73cm 73cm 73cm
Depth 18cm 18cm 18cm 18cm
Weight 59kg 77kg 112kg 147kg
Num. Of Bricks 7,5kg - 8 12 16
Num. Of Bricks 11,5kg 4 - - -
Brick Type 11072 11016 11016 11016
i
Storage heater elements and balancing heating element will never operate at the same time.
!

Elnur powered by Gabarrón | ECOMBI SSH | User Guide 15
ECOSSH TROUBLESHOOTING, ERROR CODES AND WHAT TO DO:
Error Error Reason Resolution
ECOSSH Does not heat 1. Check everything is connected
and the switch is on at the back
right hand side.
2. Make sure heater is not in frost mode
3. Ensure nothing is covering the
inlets or outlets.
4. If all above checked call
Technical line
ECOSSH does not reach set up
temperature
1. Make sure that the adequate
temperature is set up.
2. Check that the balancing
element is not turned off in UP08
Keyboard does not respond If the lock symbol is displayed, the
keyboard is locked. Hold “+” and “-”
buttons simultaneously for 3 seconds
to unlock the keyboard. (See Keyboard
Lock Section).
ECOMBI SSH does not communicate
with the G Control Hub
Check the unit is associated. The “Link”
symbol must be shown on the display
LCD. For distances greater than 30
metres and 2-3 walls, associate first
the closest unit. Each unit can work as
signal extender.
If the “Link” symbol is flashing check
G-control connection to the network.
Err1 90°C Registered at the main PCB Call fitter and get him to check that the
microtherm panel is fitted correctly. If
still not fixed please get fitter to call us.
Err2 180°C Registered in the Core Call fitter and get him to check that the
microtherm panel is fitted correctly. If
still not fixed check then possible safety
cut out has been triggered. If still not
working then please get fitter to call us.
SC – OC Core Sensor Error Please call our technical line
SA - OA Room Sensor Error Please call our technical line

Elnur powered by Gabarrón | ECOMBI SSH | User Guide 16
CHECKING THE VERSION OF YOUR SSH
Press any button to get the back light on.
Press and hold the “ ” and the “ ” button until “Accu” is displayed on the screen
Press the “ ” button twice and the version of your ECOSSH will be shown on the display.
- F1.2
- F1.4
- F2.0
To exit Press the “ ” button until you return to the main menu.
Having the version of SSH before calling us can help us speed up the processing of your request.
By performing this simple check we can ensure we give you all the right information for your heater.

Supplier:
ELNUR UK Ltd.
Unit 1, Brown Street North
Leigh, Lancashire, WN7 1BU.
[phone]
[e-mail]
15190020 R2 | EN
Manufactured by:
ELNUR S.A.
Travesía de Villa Esther, 11 28110, Algete
Madrid Telephone: [phone]
© All rights reserved. As part of the continuous improvement
policy, ELNUR, S.A. reserves the right to alter or modify any
specifications without notice.
The symbol on the product or in its packaging indicates that this
product may not be treated as household waste. Instead it shall
be handed over to the applicable collection point for the recycling
of electrical and electronic equipment. By ensuring this product
is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which
could otherwise be caused by inappropriate waste handling of
this product. For more detailed information about recycling of this
product, please contact your local council office, your household
waste disposal service or the shop where you purchased the
product. These instructions are only valid in the EU member states.
www.elnur.co.uk
