Duronic HV220 User manual

Creative Consumer Electronics
Mica Heater - HV220
PLEASE READ ALL THE INSTRUCTIONS BEFORE USE

2

3
English Manual
Manuel d’utilisation en français
Gebrauchsanleitung auf Deutsch
Manual de Instrucciones en Español
Manuale D’istruzioni In Italiano
5
21
34
53
64
Contents
Instrukcja obsługi. Polski 84

4

5
English Manual

6

7
Contents
Features & Specications
Introduction
Remove Packaging
Installation of Wheels
Operation
Important Safeguards
Clearning, Storage & Warning
Trouble-shooting
8
9
10
11
12
14
16
17

8
Features & Specications
The Duronic HV220 uses a “Mica Heating Element” which is a leading
technology in heating. Our mode is not only oil free, but offers more than a
standard heater. It heats up within a minute, making it a very cost effective
heater. All our Mica heaters have wheels, making them fantastic portable
heaters.
Full heat in 1 Minute
Two Power settings
Covering sensor (overheat protection) and Tip over protection
Anti - frost
Light weight
Quiet operation
No oil =No leakage
No dehumidifying
Power cord storage on front
Oil-Free Column Heater
Special Features
Specication
Item Power Voltage Rating Unit Size Unit Weight
HV220 2000W 220-240V,
50/60Hz
580(L)*130(W)*690(H)mm 4.6kg

9
Unit Layout
1. Top cover
2. Power switch knob
3. Temperature control knob
4. Cable storage
5. The power cord
6. Left Plastic Cover
7. Footbase
8. Wheels

10
Removing Packaging
1. Take the heater and the
packaging out of the box.
2. Remove foam from both ends
of the heater. Remove the polybag
which is covering the heater and
store away. Keep any bags and
foam away from children.
3. Remove the front foot and
wheels from the foam
packaging
4. Keep your packaging safe,
as this is part of the
guarantee. It is also useful for
storing the heater when not in
use.

11
Assembly Instructions
1. Position the heater carefully upside
down.
2. Place screws in center round hole
of foot base and screw in tightly with a
screwdriver.
3. Repeat for other leg
4. Turn the heater the right way up.

12
- Turn the Power Switch Knob
to [OFF] position (Fig. 1 ).
- Turn the Temperature
Control Knob to [OFF] position
(Fig. 2).
2. Then plug in power cord to a
suitable electrical outlet.
(Rated not less than 1 O AMP)
At this moment, the light
indicator should be on.
3. Turn the Temperature
control knob clockwise to turn
the heater on. The heater will
heat the room to the chosen
temperature and then
automatically turn off. When
the indoor temperature drops,
the heater will operate again
and emit heat until the
temperature of the indoor
temperature reaches the
desired temperature. This
cycle will repeat to maintain
your chosen temperature. The
temperature can be altered by
turning the temperature control
knob.
Operation
PLEASE READ THE INSTRUCTIONS IN FULL BEFORE USING THIS
HEATER.

13
4. Then switch the heater ON by selecting
as below:
[I] Heating power setting I
[ || ] Heating power setting ||
[|]1000W
[II] 2000W
5. Anti-Frost Function
This function will keep the surrounding
temperature above freezing point. To do
this, simply plug in the power cord, and
turn the Temperature control Knob to
the “Snowake” position.
6. Covering Sensors
Even though a warning label “DO NOT
COVER” has been placed on the unit,
some users may accidentally cover the
unit with a towel or blanket etc. Therefore,
a safety device known has been installed
within the heater to protect against
overheating. If the unit overheats, the
power will be cut off. When the unit
temperature falls again, power will be
resumed.
7. Tip over protection
If the heater is accidentally knocked over,
it will switch off automatically .

14
Important Safeguards
The heater is hot when in use. To
avoid burns, do not let bare skin
touch the hot surface, please use
the handles to move the heater.
Keep combustible materials, such
as curtains etc at least 3 feet (0.9m)
radius from the heater to avoid a re
hazard. Extreme caution is
necessary when any heater is used
near childre. Do not leave children
unattended when this heater is ON.
The heater is not a toy.
Do not use the heater outdoors. This
heater is not intended for use in
bathrooms, laundry areas and near
water.
Do not use the heater in areas
where gasoline, paint or ammable
liquids are used or stored.
Do not insert or allow any objects to
enter any ventilation or exhaust
opening as this may cause an
electric shock or re, or damage the
heater.
To prevent a possible re, do not
block air intakes or exhaust in
any manner. Do not operate this
appliance on a soft or uneven
surface as it may block the air inlets.

15
Always unplug heater when not in
use. To disconnect heater, remove
plug from outlet.
Please avoid using an extension lead
with this heater. All extension leads
have a maximum wattage allowance,
by using this heater with other
appliances the wattage allowance
may be exceeded and may overheat
the plug and extension socket and
result in a re risk.
Do not run cord under carpeting. Do
not cover cord with throw rugs,
runners, or the like. Arrange cord
tidily where it cannot be tripped over.
Do not operate any heater with a
damaged cord or plug. If the supply
cord is damaged, it must be replaced
by a qualied person in order to avoid
hazard. Connect to properly
grounded outlets only.
Use this heater only described in this
manual. Any other use not
recommended by the manufacturer
may cause re, electric shock, or
injury to persons. Do not use this
heater with a programmer, timer or
any other device that switches the
heater on automatically, as a re risk
exists if the heater is covered or
positioned incorrectly.

16
Cleaning
Storage
Warning
1. Before cleaning, turn off the heater, unplug the power cord and allow the
heater to cool.
2. Do not immerse power cord, plug or heater in water or other liquid, or pour
water or other liquids over the heater.
3. Use a vacuum cleaner to remove dust and lint at the metal grill of the
heater. Wipe the heater with a dry cloth to remove dust and a damp cloth (not
wet) to clean off stains.
4. Do not use detergents, abrasive cleaning products or any kind of polishing
material on the body of the heater, as these can damage the nish.
Do not use this heater in the immediate
surroundings of a bath, a shower or a
swimming pool
The heater must not be located
immediately below a socket-outlet.
1. Store the heater in a cool dry location, preferably covered to present dust
and dirt. Use old packaging to repack the unit.
2. Unplug the heater and store the mains lead in the storage tidy at the front of
the heater. Ensure that the plug does not trail before cleaning.
Any other servicing should be performed by an authorized service
representative.

17
Troubleshooting
Heater is not warm
1. Check the heater is
operating
3. Check the heater
is not covered
2. Check the
temperature setting is
in the right position
4. On low temperature settings
not all panels heat up. This
does not mean that the
heater is not working.
1. Check the power
cord plug in the
electrical outlet
2. Check whether the
electricity or the main
fuse is working
4. Check the heater if
it is on the thermostat
control condition.
After storage/restarting the heater, a slight smell may be released
from the heater. This is because the heater absorbs the air in the
room, which may contains cigarette smoke, cosmetic fumes, and
smells from the furniture and walls. When the heater starts up
again, it will emit those smells. This is normal, and after a short
period of time the smell will start to disappear.
3. Make sure the
power switch is
at the [ON]
position.
Heater is not operating
There is a smell coming from the heater
Keep these instructions safe

18
Warranty
1 Year Guarantee from Shine-Mart Ltd, Trademark owners of Duronic Products.
NOTE: THESE STATEMENTS DO NOT AFFECT YOUR STATUTORY RIGHTS AS A
CONSUMER
This product has been manufactured under the strictest or quality control procedures, and
using the highest quality of materials, to ensure excellent performance and reliability. It will
give very good and long lasting service, provided it is properly used and maintained. The
product is guaranteed for 1 years from the date of original purchase. If any defect arises due
to a faulty materials or poor workmanship, the faulty product must be returned to the original
place of purchase. Refund or replacement is at the discretion of that company.
Duronic Products are offered with a 1 year guarantee under the following conditions:
1. The product must be returned to the retailer with original proof of purchase.
2. The product must be installed and used in accordance with the instructions contained in
this operating manual.
3. It must be used only for domestic purposes.
4. It does not cover wear and tear, malicious damage, misuse, neglect, inexpert repairs or
consumable parts.
5. Shine-Mart Ltd has no responsibilities for accidental or consequential loss or damage.
6. Shine-Mart Ltd are not liable to carry out any type of servicing work, under the guarantee
7. Valid in the UK only
This product is tted with BS:1363 plug and fuse
Imported by Shine-Mart Ltd, RM3 8SB
Information on waste Disposal for Consumers of
Electrical & Electronic Equipment.
This mark on a product and/or accompanying documents indicates that when it
is to be disposed of, it must be treated as Waste
Electrical & Electronic Equipment, (WEEE).
Any WEEE marked products must not be mixed with general household waste,
but kept separate for the treatment, recovery and recycling of the materials used.
For proper treatment, recovery and recycling; please take all WEEE marked
waste to your Local Authority Civic waste site,
where it will be accepted free of charge.
If customers dispose of Waste Electrical & Electronic Equipment correctly, they
will be helping to save valuable resources and preventing any potential negative
effects upon human health and the environment, of any hazardous materials that
the waste may contain.

19
