USER MANUAL
OIL FILLED RADIATOR
DragonPlus7-1.5W
DragonPlus7-1.5WB
DragonPlus9-2.0W
DragonPlus9-2.0WB
DragonPlus11-2.5W
DragonPlus11-2.5WB
Thank you for choosing electriQ
Please read the manual before using this heater
and keep it safe for future reference.
Visit our page www.electriQ.co.uk for our entire product range
THIS PRODUCT IS ONLY SUITABLE FOR WELL INSULATED SPACES OR
OCCASIONAL USE.

2
CONTENTS
SAFETY INSTRUCTIONS
3
PRODUCT OVERVIEW
5
DISPLAY
6
CONTROL PANEL
7
REMOTE CONTROL
7
OPERATION
8
CONNECTING THE APPLIANCE TO WIFI
9
CONTROLLING YOUR APPLIANCE THROUGH THE APP
15
MAINTENANCE
20
TROUBLESHOOTING
20
TECHNICAL DATA
21
SUPPORT
21
PRODUCT FICHE
22

3
SAFETY INSTRUCTIONS
IMPORTANT
Carefully read the instructions before operating the unit
This appliance is for indoor use only.
Rating: This unit must be only connected to a 220-240 V / 50 Hz earthed outlet.
Installation must be in accordance with regulations of the country where the
unit is used.
If you are in any doubt about the suitability of your electrical supply have it
checked and, if necessary, modified by a qualified electrician.
This heater has been tested and is safe to use. However, as with any electrical
appliance use it with care.
Disconnect the power from the unit before dismantling, assembling or
cleaning.
Avoid touching any moving parts within the appliance.
Never insert fingers, pencils or any other objects though the guard.
This appliance can be used by Children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be carried out by children.
Children aged from 3 years and less than 8 years shall only switch on/off the
appliance provided that it has been placed or installed in its intended normal
operating position and they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
Children aged from 3 years and less than 8 years shall not plug in, regulate,
or clean the appliance or perform user maintenance.
Children under 3 years should be kept away unless continuously supervised.
Some parts of this product can become very hot and cause burns. Particular
attention has to be given where children and vulnerable people are present.
Do not clean the unit by spraying it or immersing it in water.
Never connect the unit to an electrical outlet using an extension cord. If an
outlet is not available, one should be installed by a qualified electrician.
Never operate this appliance if the unit, cord or plug is damaged. Ensure the
power cord is not stretched, exposed to sharp object/edges, or routed under
the unit.
Any service other than regular cleaning should be performed by an authorised
service representative. Failure to comply could result in a voided warranty.
Never use the plug as a switch to start and turn off the heater. Use the
provided power button located on the control panel.

4
Do not use an external timer.
Do not cover the appliance, or place items close to the unit which may restrict
airflow, as this may present a fire risk.
The heater must not be located immediately below a socket outlet.
Always place the unit on a dry and stable surface. Do not move or tilt the unit.
Avoid keeping the unit in direct sunlight for a long period of time.
The heater is designed to be used at temperatures above -20°C. If it is
exposed to temperatures below this, it must be allowed to warm above this
level before operation.
Do not attempt to repair, disassemble or modify the appliance. This unit
contains no user-serviceable parts.
Always unplug or disconnect the appliance from the mains power supply when
not in use, or when moving or cleaning it. Do not pull the cord to unplug the
heater.
Keep the heater clean. Do not allow any object to enter the ventilation or
exhaust opening as this may cause electric shock, fire, or damage to the
heater.
Do not use the appliance for anything other than its intended use. It is
designed for domestic indoor use only.
There may be a trace of odour during the first few minutes of initial use, or
after a period of storage. This is normal and will quickly disappear.
This appliance has hot and arching or sparking parts inside. Do not use it in
areas where gasoline, paint, or any flammable liquids are used or stored.
This appliance is not intended for use in bathrooms, laundry areas and similar
humid locations. Never locate this appliance where it may fall into a bathtub
or otherwise become exposed to water.
The remote contains a lithium battery, keep out of reach of small children.
Seek Medical advice if swallowed.
To prevent battery leakage: Remove the battery from the remote if exhausted
or before long periods of storage.
WARNING: To reduce the risk of fire or electrical shock, DO NOT use this
appliance with any solid-state Speed Control Device or any variable speed
controllers.
ENERGY SAVING AND UNIT SAFETY PROTECTION TIPS
Do not cover or restrict the airflow. Do not use in dusty environment.
For safety and maximum performance, the minimum distance from a wall or
objects should be 50cm.

5
PRODUCT OVERVIEW
1.Handle
2.Digital display screen
3.Control panel
4.Power switch
5.Cord storage with hook
6.2 x mounting plates U
ACCESSORIES
Remote Control
x1
Mounting Plates
x2
Castors
x4
U-Shaped Bolts
x2
Butterfly Screws
x4

6
ASSEMBLY INSTRUCTIONS
•The castors must be attached before the heater is operated.
•Castors are supplied with the device. You must mount them on the
supplied mounting plates and then attach these to the unit before
use.
WARNING: Do not operate without the castors. Only operate the
heater in an upright position.
POSITIONING THE HEATER
•Place the unit in an upright position on a flat, stable and heat-resistant surface.
•Ensure that there are no flammable or heat-sensitive materials or substances
within one metre of the front and 50 cm of the rear and sides of the unit.
•Do not cover the heater.
CONNECTING THE HEATER
•Before inserting the plug into a suitable socket, make sure that the unit is intact,
properly assembled and that there is no signs of damage to the appliance or its
power cable.
•To avoid overloading a circuit, connect the unit only to a circuit where no other
equipment is connected.
•When the power switch is in the OFF position, insert the plug into an earthed
socket and turn on the power.
DISPLAY SCREEN
LOW
MEDIUM
HIGH
TIMER
POWER
HEAT
LEVEL

7
CONTROL PANEL
The unit can be operated using the remote control or the control panel on the side of
the unit.
Please note the unit must be turned on using the power switch before use
REMOTE CONTROL
The buttons on the remote allow the access to the same settings as the main control
panel.
Change the heat
level between Low,
Medium and High
Set the Standby /
Start Timer
On / Off Button
Increase
desired
Temperature
Decrease desired
Temperature
Decrease desired
Temperature
Increase
desired
Temperature
Change the heat
level between Low,
Medium and High
Set the Standby /
Start Timer
On / Off Button

8
OPERATION
Turning ON/OFF
•Press the power switch on the side of the unit to the "ON" position to power the unit.
The power symbol will illuminate on the display.
•Press the "ON/OFF" button on the control panel or remote control. The unit will start
to operate at the High heat setting.
•Press the "ON/OFF" button to stop operation and put the unit into standby mode.
•Press the power switch to the OFF position to turn off the power to the appliance.
SELECTING A POWER LEVEL
Press the “HEAT” button repeatedly to select a Heat level between Low, Medium and
High. The display will show the currently selected Heat level
SETTING THE TEMPERATURE
The desired temperature can be set between 15°C and 35°C. Once the desired
temperature has been reached the unit will stop the heating function.
With the unit operating at the desired heat level use the + and - buttons to set the
desired temperature.
While the unit is heating, the thermometer symbol will flash.
When the room temperature is above the desired temperature the thermometer
symbol will be illuminated constantly.
TIMER BUTTON
The in-built timer will allow you to set the unit to turn on or turn off after a set period
of time, Please note only one timer can be used at any time.
ON TIMER –The timer will turn on the unit automatically after the time set has
elapsed.
1. With the unit turned off, press the TIMER button, then set the number of
hours’ time you desire the unit to start by repeatedly pressing the TIMER
button.
2. Once the set time has elapsed, the unit will turn on automatically.
3. Press the POWER button before the time has elapsed and the unit will turn on
as normal and the timer will be cancelled
OFF TIMER –The timer will turn off the unit automatically after the time set has
elapsed.
1. While the unit is operating, press the TIMER button then set the number of
hours’ time you desire the unit to stop by repeatedly pressing the TIMER
button.
2. Once the set time has elapsed, the unit will enter standby automatically.
3. Press the POWER button before the time has elapsed, the timer will be
cancelled and the unit will turn off.

9
MODES AVAILABLE FOR SETUP
The heater has two different setup modes, Quick Connection and AP (Access Point).
The quick connection is a quick and simple way to set the unit up. The AP connection
uses a direct local Wi-Fi connection between your phone and the heater to upload the
network details.
When first turned on using the switch on the rear of the unit, the power indicator will
flash rapidly, showing that the unit is in Quick connection mode, and ready to set up.
Please ensure your device is in the correct Wi-Fi connection mode for the connection
type you are attempting, the flashing of the power indicator on your heater will indicate
this.
Connection Type
Frequency of Flashes
Quick Connection
Flashes twice per second
AP (Access Point)
Flashes once per second
CHANGING BETWEEN CONNECTION TYPES
To change the unit into AP mode, with the appliance in standby (Power switch on and
unit turned off), press and hold the HEAT button for 5 Seconds.
To change back to Quick connection mode, turn the appliance off using the switch on
the rear. Leave turned off for 10 seconds before returning the switch to the on position.
After a few seconds the Power indicator will start to quickly flash to indicate the unit is
in Quick connection mode.
TURNING WIFI OFF
With the appliance in standby mode (Power switch on, but turned off), Press and hold
the On Off Button for 3 seconds. The unit will bleep and the Light button will go out.
TURNING WIFI ON
Turn the appliance off using the switch. Leave turned off for 10 seconds before
returning the switch to the on position. After a few seconds the Power indicator will
start to quickly flash to indicate the unit is in Quick connection mode.

10
CONNECTING THE APPLIANCE TO WIFI
DOWNLOAD THE APP TO YOUR PHONE
Download the” TUYA SMART” app, from your chosen app store, using the QR codes
below, or by searching for the app in your chosen store.
Android

11
REGISTER THE APP
2. Read the Privacy policy and
press the Agree Button.
3. Enter your email address or
phone number and press
continue to register.
4. A verification code will be
sent by the method selected
in step 3. Enter the code into
the app.
2. The app is now registered.
It will automatically log you
in following registration.
5. Type in the password you
would like to create. This
needs to be 6-20 characters,
with letters and numbers.
1. Press on the register button
at the bottom of the screen.

12
SETTING UP YOUR HOME WITHIN THE APP
TUYA is designed so it can work with a large number of compatible smart devices
within your home. It can also be set up to work with multiple devices within different
houses as such during the setup process, the app requires that different areas are
created and named to allow easy management of all your devices. When new devices
are added, they are assigned to one of the rooms you have created.
CREATING ROOMS
1. Press on the ADD HOME
button.
3. Type in a name for your
home,
4. Press on the location button
to select the location of your
home. (See SETTING
YOUR LOCATION below)
5. New rooms can be added
by pressing the ADD
ANOTHER ROOM option at
the bottom. (See ADD
ANOTHER ROOM below)
6. Untick any rooms that are
not required on the app.
7. Press DONE in the top right
corner.
SETTING YOUR LOCATION
Use your finger to
move the orange
HOME symbol.
When the symbol is
in the approximate
location of your
home, press the
confirm button in
the top right corner.
Location details
allows the app to
be set up later to
respond to weather
conditions in your
area.
ADD ANOTHER ROOM
Type in the
name of the
room, and
press Done in
the top right
corner

13
CONNECTING USING THE QUICK CONNECTION METHOD
Before initiating the connection, make sure the unit is in standby mode (Power switch
ON, but unit turned off), with the power indicator flashing twice per second. If not follow
the instructions for changing the connection mode. Also ensure your phone is
connected to the Wi-Fi network. (We advise turning mobile data off during setup)
2. Select the type of device
as “Heater”within the Home
Appliance tab.
3. Ensure the Ambient Light
indicator on the heater is
flashing twice per second
then press on the orange
button at the bottom of the
screen.
4. Enter your Wi-Fi password
and press confirm.
5. This will then transfer the
settings to the heater. Wait for
this to complete. If this fails,
retry. If still unsuccessful
please review the
troubleshooting section for
further help.
1. Open app and press “+” to
add device, or use the add
device button

14
CONNECTING USING APP MODE ALTERNATIVE METHOD
Before initiating the connection, make sure the unit is in standby mode, with the power
Indicator flashing once per second. If not follow the instructions for changing the Wi-
Fi connection mode. Also ensure your phone is connected to the Wi-Fi network. (We
advise turning mobile data off during setup)
1. Open app and press “+” to
add device, or use the add
device button
2. Select the type of device
as “Heater”within the Home
Appliance tab.
3. Press on the AP mode
button in the top right of the
screen.
4. Ensure the Ambient Light
indicator on the heater is
slowly flashing (once per
second), then press on the
orange button at the bottom
of the screen to confirm
5. Enter your Wi-Fi password
and press confirm.
6. Go to network settings in your
phone and connect to the
“SmartLife xxx” connection.
There is no password to
enter. Then return back to the
app to complete setup.
This will then transfer the settings to the heater.
Once the connection process has completed, go back to the network settings on your phone to ensure
your phone has reconnected to your Wi-Fi router.

15
CONTROLLING YOUR APPLIANCE THROUGH THE APP
THE HOME SCREEN
Each device has its own entry on the home screen to allow the user to either quickly turn the unit on or
off, or to enter the device screen to make other changes.
Smart Scene: Allows you
to program intelligent
behaviour based on the
internal and external
environment
Add Device: Add a
device to the app, and go
through the setup
process.
Profile: Provides the
option for changing
settings,
Name of Heater: Press to
enter the Device Screen
Home: Return to home
screen from the Smart
Scene and Profile
screens
Voice Control: Press to
give verbal instructions for
operation.

16
DEVICE SCREEN
The device screen is the main control screen for the heater, providing access to the controls to amend
the functions and settings.
NOTE: Due to continuous development of the app, the layout and available features
may be subject to change.
Edit Name: Use to
change the name of the
heater
Back: Returns to the
Home Screen
Power: Use to turn the unit on
or off.
HEAT:
Use to change between Auto,
Low Heat, High Heat, and
Cooling Fan.
COUNTDOWN
TIMER:
Use to add an off
timer while the unit is
running, or an on
timer while the unit is
turned off
Device Name
Current Mode: Shows
the mode the heater is
currently working in.
Desired
Temperature:
Displays what has
been set as the
target room
temperature.
Decrease desired
Temperature
Temperature
range 15-35C
Increase desired
Temperature
Temperature
range 15-35C

17
SMART SCENES
Smart Scenes is a powerful tool providing the option to customize the operation of the air heater
based both on conditions within the room and outside influences. This gives the user the option of
specifying much more intelligent actions. These are split into two categories Scene and Automation.
SCENE
Scene allows for a one touch button to be added to the Home Screen. The button can be used to
change a number of settings in one go, and can change all the settings within the unit. A number
of scenes can easily be setup, allowing the user to easily change between a number of preset
configurations.
Below is an example of how to set up a scene:
3. Press the Pen next to
“Please Enter Scene Name” to
input the name for your Scene
Show on Dashboard: Leave
this on if you require the scene
to be displayed as a button on
the Home Screen
Press the Red Plus to add the
action required. Then select
the heater from the list of
devices.
4. Chose the function, set the
value for the function, and
then press the back button in
the top right corner, to return
to the previous screen.
6. Once all the functions required have been added, press the Save button in the top right corner to
finalize and save your new Scene. It will then be saved to the home screen
1. Press on the
Smart tab at the
bottom of the
Home screen
2. Press on the Plus in the top right corner or
on Add Scenario to add a smart scene.

18
AUTOMATION
Automation allows an automatic action to be set up for the device. This can be triggered by the
Time, and a range of other influences, depending what other TUYA enabled devices you have on
the network.
1. Press on the Scene tab at
the bottom of the Home
screen
2. Press on the Automation
tab at the top of the screen.
3. Press on the + at the top of
the screen or press on Add
Automatic Action
4. Setup is very similar to the scene
setup on the previous page, and
includes an extra section for
specifying a trigger for the scene to
start.
Press the Pen next to “Please Enter
Scene Name” to input the name for
your Scene
Press the Red Plus next to “When
any condition is satisfied” to add the
trigger
Press the Red Plus next to “Execute
following actions” to add the action
required. Then select the heater
from the list of devices.
6. Chose the function,
set the value for the
function, and then press
the back button in the
top right corner, to
return to the previous
screen.
5. Select the condition when the
automation should start. A
number of triggers can be
combined.
7. Once all the functions required have been
added, press the Save button in the top right
corner to finalize and save your new scene.
The automation is now set up, it can be turned on
and off using the toggle on the home page.

19
PROFILE TAB
The profile tab gives you the option to edit both your
detail, and use the added features of the unit.
HOME MANAGEMENT
Home Management proves options for managing your
TUYA account, giving options such as adding a home,
adding and removing rooms, and sharing devices with
family.
MESSAGE CENTRE
View notifications from devices, if alarms are set up
(dependent on device)
HELP CENTRE
Provides assistance using the features provided within
the app
MORE SERVICES
This allows the unit to be integrated with your favorite
home automation hardware such as Google Home and
the Amazon Echo.
CONNECTION TROUBLESHOOTING
1. Check whether the device is powered on and is in the correct Wi-Fi connection
mode, if not please refer to the CHANGING BETWEEN CONNECTION MODES
section.
2. Ensure the Wi-Fi password has been entered into the app correctly (Case
sensitive)
3. Check that the phone is connected to the Wi-Fi you are connecting the device to.
4. Ensure the network you are connecting it to is 2.4Ghz (5Ghz Wi-Fi networks are
not supported), and that there is a strong Wi-Fi signal to the item.
5. If your router is dual band, ensure that the 2.4ghz network has a different network
name (SSID). Further advice on changing router settings will be available from
your Internet service provider / Router manufacturer.
6. Check the settings on the router. Encryption should be WPA2-PSK and
authorisation type should be set to AES
7. Try using the alternative connection method. i.e. If connection is failing when
attempting to connect through CF mode, try AP mode.

20
MAINTENANCE
CLEANING AND STORAGE
ATTENTION: Please shut off the unit and unplug from the mains before
cleaning or performing any maintenance.
CLEANING THE SURFACE
Clean the heater with a duster or a soft wet cloth.
Do not use chemical solvents (such as benzene, alcohol or gasoline) as they
may cause irreversible damage. Make sure no water enters the control panel or
gaps in the casing.
Do not run the unit until completely dry.
Place the heater in its original box or cover to protect it from dust when not in
use.
Store it in a cool dry place.
TROUBLESHOOTING
Do not repair or disassemble the unit by yourself, unauthorized repair attempts will
invalidate the warranty and may cause bodily harm.
Issue
Possible Reason
Solution
No power
1. Power cord is unconnected
2. There is no power from socket
3. The power switch on the rear of the unit
is turned off.
1. Connect the power cord
2. Check socket is turned on
3. Ensure the power switch on
the rear of the unit is in the on
position
Odour
emission
from unit
1. New unit. When the unit is used for the
first time the fan motor may produce and
odour which will dissipate within a week of
use
1. No action required
Strong
vibrations
and noise
1. Unit is not placed on a flat surface
2. Unit may be damaged
1. Place on a flat surface. May
put an anti-vibration mat
underneath
2. If the heater is damaged
discontinue use and contact the
service centre.
If the above solutions do not resolve the problem please contact the service centre.
Disposal: Do not dispose this product as unsorted municipal waste. Collection of such
waste must be handled separately as special treatment is necessary.
Recycling facilities are now available for all customers at which you can
deposit your old electrical products. Customers will be able to take any
old electrical equipment to participating civic amenity sites run by their
local councils. Please remember that this equipment will be further
handled during the recycling process, so please be considerate when
depositing your equipment. Please contact the local council for details of
your local household waste recycling centres.
