Elo touchsystems Mx925 User manual

E352169 EMV-SELF-SERV-VF-MX925

FOR USE ON:

E796965 ELO-STAND-SELF-SERVICE-15-22-FLOOR-TOP

E796783 ELO-STAND-SELF-SERVICE-15-22-COUNTERTOP

ASSEMBLY INSTRUCTIONS, ELO MX925 EMV BRACKET KIT

Contents for Kit: E352169, EMV-SELF-SERV-VF-MX925

Screws

Bag CQty.2 SCREW, M3X8, PAN-HEAD,

CROSS-RECESS

Bag PQty.4 SCREW, M4X5, PAN-HEAD,

CROSS-RECESS

Bag RQty.4 SCREW, M4X6, FLAT-HEAD,

CROSS-RECESS

Bag QQty.3 SCREW, M3X5, PAN-HEAD,

CROSS-RECESS

EMV Arm Assembly

Qty. 1

EMV Mount Plate, Long

Qty. 1

EMV Edge Bracket, 15 Android

(bag label “15 A”)

Qty. 1

EMV Edge Bracket, 22 Android

(bag label “22 A”)

Qty. 1

EMV Edge Bracket, 15

Windows

(bag label “15 W”)

Qty. 1

EMV Edge Bracket, 22

Windows

(bag label “22 W”)

Qty. 1

Tie-wrap

Qty. 2 EMV Edge Bracket, 22 Android 4.0

(bag label “22 A4”)

Qty. 1

Remove Fill Plate on Display Bracket.

Add the EMV Mount Plate to the

Display Bracket using (4) screws from

bag “R”.

Add (2) screws to EMV Mount Plate from bag “P”

at position 1, 2,3 or 4. Leave ~3mm (1/8”) gap

(for

EMV Arm).

Position “1” for 15” in portrait.

Position “2” for 22” in portrait.

Position “3” for 15” in landscape.

Position “4” for 22” in landscape.

Assemble EMV Arm to Display Bracket. Add

(2) screws from bag “P” at right most position

“A” to secure EMV Arm to Display Bracket.

1234

Remove Fill Plate on Display Bracket.

Remove and save EMV Cover Plate and screws.

Add (3) screws for mounting EMV terminal

from bag “Q”.

Attach EMV terminal cable to terminal and slide

terminal onto (3) Arm Assembly screws.

Route EMV terminal cable and tie-wrap.

For portrait installations, setup is

complete.

For landscape installations, proceed to

step 7.

Cover Plate Attach Cover Plate and

screws.

Remove plastic cover from right edge of display.

Add Edge Bracket using (2) screws from bag “C”.

Use Edge Bracket “15 A” for Android 15”

Use Edge Bracket “22 A” for Android 22” 2.0/3.0

Use Edge Bracket “22 A4” for Android 22” 4.0

Use Edge Bracket “15 W” for Windows 15”

Use Edge Bracket “22 W” for Windows 22”

Return to Wallaby™assembly instructions

(QIG600073/QIG600074) to complete installation.
