ELRO SF40GA11 User manual

English 02 - 14
Deutsch 16 - 29
Nederlands 31 - 44
Français 46 - 59
Hereby, ELRO Europe declares that the radio equipment type SF40GA11
is in compliance with Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the following internet address:
www.elro.eu/compliance
K1 CONNECTOR
ELRO CONNECTS
SF40GA11 Home is not a place, it’s a feeling

-2-
EXPLANATION
The ELRO K1 Connector is the heart of your ELRO Connects system. It
connects all your ELRO Connects products to the free ELRO Connects
App. With the ELRO Connects App you gain full control of your home,
making it a more comfortable and safe environment for you and your
family. ELRO Connects is a plug & play system, developed for anyone to
use and enjoy. 3 step installation
1. Download the ELRO Connects App
Download the “ELRO Connects” app from
the Apple App Store or Google Play Store.
To enjoy all the functions of the ELRO
Connects system, make sure to allow the
app to send push notifications and use
your current location.
2. Register an Account
When opening the app for the first time,
the login screen will pop-up. Please press
‘Create an account’ (1) on the bottom
right corner of the app.

-3-
Enter your e-mail address (2). To verify
your e-mail address, please press ‘Get
code’ (3). Now a pop-up will appear in
which you need to fill in a graphic
verification code (4). (Be aware of capital
and lower case letters!)
After you've entered the graphic's
verification code, you'll receive an e-mail
from the ELRO Connects App.
The verification code you received in your
e-mail needs to be filled in left to the
“Get code” button (3).
Next, type in the password (5) you need
to use at least 8 digits, a mix of
upper/lower case letters and numbers
and/or special characters. Re-enter the
password in the field underneath and
press ‘Create an account’. You can check
the password by pressing on the eye
symbol! The login screen will appear and
you can login to the app by using your
email and created password.

-4-
3. Connect the K1 Connector to theapp
Once you have logged into the app, you
are taken to the network configuration.
Plug in the K1 connector into a power
outlet and wait for the LED indicator to
turn green.
Next, press the K1 Connector's button (1)
for at least 3 seconds until the LED
flashes blue. (2) Press ‘Next’.
In the next screen, type in your Wi-Fi
network password (3) and press
‘Configure’. The connector will now
connect with your Wi-Fi network. This
will take approximately 1 minute. You’ll
be informed whether the connection was
successful or not.
Make sure that you use a 2.4GHz Wi-Fi
signal. This means that this cannot be a
Wi-Fi signal that exists of both 2.4GHz
and 5GHz signals. We recommend that
you turn of the 5GHz signal when
installing the K1. After the installation
you can turn this signal back on again.

-5-
Connect ELRO Connects products to the app
Connecting the different ELRO Connects products to your app is very
easy and will take you very little time. First, go to the Device List by
tapping the ‘Devices’ (1) at the bottom right corner of your Home
screen. Next, tap the ‘+’ in the upper right corner (2).

-6-
Quickly press the button on your ELRO
Connects device 3 times (3). When the
connection with the ELRO Connects
device is successful the LED of the K1
Connector will quickly blink 10 times and
you'll receive a notice in the app.
Please note! The ELRO Connects Water
Detector (FW3801R) doesn't have a
button, use a screwdriver to touch both
sensors 3 times in success.
Congratulations!
You successfully connected an ELRO
Connects product to your app. You can
now name the product and use it in your
app to control with your smartphone, use
in scenes etc.
Scenes
Your ELRO Connects app has 3 pre-installed
operation modes “Home, “Away” and
“Sleep”. You can switch between these
operation modes by tapping the button in
the middle of your Home screen and select
the desired mode.
Creating scenes
Press the "Scenes" button at the bottom of the start screen. Here you
can set up various scenes for your ELRO Connects system. It is possible
to add various automatic actions to these scenes to automate
everything. To create a scene, simply press the "+" (1) in the scene
overview. A screen will appear where you can add conditions and link
them to an action that needs to be executed (2). You can also use the
following menu items to set up your own automatic actions. It is
possible to modify a scene by pressing one of the scenes.

-7-
Automatic actions
So it is possible to set an automatic action on a scene. You can assign
one or more conditions to an automatic action. If one or more of these
conditions are met, the automatic action will be executed. For example,
it is possible to have a plug switch on when a door is opened. By
following the steps below you can easily create automatic actions
yourself. In the scene overview, press the plus sign to create an
automatic actions (1). You can then give a name to the automatic action
(2).Add the conditions that will trigger the automatic action (3). This
can be a timer or a button press, for example (4). Then determine which
action should be performed when one or more of the conditions are
met (5). The list of actions will grow as different products are added to
your system (6).
Please note! When only using fire protection products, it is not necessary
to create automatic actions. There are also a number of standard
automatic actions for intrusion protection. You therefore do not need to
set these up yourself either.

-8-

-9-
Timers
On the home screen, press the "Scenes" button at the bottom of the
home screen. To set a timer, press the clock in the top left corner of
your screen. You will then see an overview of all your set timers. By
pressing the plus sign you can set a time when a scene will start
automatically. For example, you can set the "Sleep mode" to be
activated at 23:00 every day.

-10-
Explanation of the app
Below is an overview of all the app's
functions with explanations.
1. Connector list: Here you can find
all the connectors which are
connected to the account. You can
also delete a connector and change
the name of one.
2. Scene switching: Switch between
the different scenes of the system.
3. Alarm history: previous alarms are
stored here.
4. Home page, scene overview and
device list. Home page, scene
overview and device list.
5. Change Password: Change the
password for the account.
6. Configure your connector: add a
second connector to the app.
7. Location settings: here you can
turn the location facilities on or off.
8. Emergency number: Add an
emergency number. This can be
used as a shortcut. Simply call this
number in case of emergency. This
number is not automatically called
by the app.

-11-
9. Frequently asked questions:
navigate to our FAQ page.
10. About: here you will find the app
version, the connector version, the
customer service details and the
privacy terms.
11. Synchronize: Synchronize the
device list to get the latest status
of the devices.
12. Standby : The device is online and
working.
13. Trigger : The device is activated.
14. Offline : The device is offline.
Forgot your password?
If you have forgotten your password you can set a new one by pressing
'Forgot password' at the bottom left of the login screen. Then follow the
same steps as when creating an account. At email address, enter the
email address of your current account.
Reset
You can reset the connector by following the steps below:
1. Remove the K1 Connector from your app by going to the connector
list at the top of the home screen.
a. For iPhone, drag the connector line to the left and press delete.
b. For Android, press the booklet and then press delete.
2. Plug the connector into the wall outlet and wait 5 seconds.
3. Press the K1 button 3 times.

-12-
4. Hold down the button on the connector until you see a purple light.
5. The connector will briefly alarm.
6. The connector is now reset.
Troubleshooting
If the installation fails or you encounter some other problem, please
refer to this troubleshooting. It contains a number of tips and tricks that
might help you further.
Installation K1
When installing the K1 system, we recommend that you pay attention to
the following points.
• Make sure your phone is connected to the 2.4GHz Wi-Fi signal.
• Make sure your Wi-Fi password/name does not contain any
spaces.
• The Wi-Fi name should be entered automatically during the
network configuration. Is this not the case? Then you need to
enable the location services on your phone and in the app's
settings. Also, all permissions need to be accepted.
• Are you sure that the password for the Wi-Fi is correct? By clicking
on the eye on the right, you can see the password you have
entered.
• Make sure the connector flashes blue when you go through the
network configuration.
• If all of the above does not appear to be the cause of the problem,
then you are probably dealing with a combined WiFi band. In
other words, a WiFi band that offers both 2.4Ghz and 5Ghz (in
some cases, a combined WiFi band is still displayed as a 2.4Ghz
WiFi). We recommend that you check the router settings to see
which frequencies are offered for the relevant SSID. Before
installing the system, temporarily disable the 5GHz signal and go
through the installation. After installing the K1 connector, you can
turn the 5GHz signal on again. If that doesn't work, you can also
create a separate wifi band with a unique name and password on

-13-
2.4Ghz only. I can imagine that this is complex, we therefore
advise you to contact your telecom provider for the correct
settings to set up a separate 2.4Ghz WiFi band in this case, they
will be able to help you the quickest and best.
FAQ
Q Can I connect a second device to my system?
A It is possible to link several phones to one connector. You can do
this simply by logging in with your account on multiple devices.
Q How many devices can be connected to the connector?
A Up to 127 devices can be connected to the connector.
Q Can I add multiple connectors to one account?
A This is certainly possible. You can add various connectors by
pressing the top right of the home screen. Then you have to press
'Configure your connector’. Each connector has its own set of
scenes and devices and are therefore not connected to each
other.
Q What is the wireless range of the system?
A All components have a range of 100m in an open space without
any obstacles or interfering signals. All accessories should be
located within reach of each other, as the system is not a mesh
network.

-14-
Store these instructions in a safe place for future usage
Disposal of the device The adjacent symbol of a crossed-out wheelie bin
means that this device is subject to Directive 2012/19/EU. This directive
states that this device may not be disposed of in normal household
waste at the end of its usable life, but must be handed over to specially
set-up collection locations, recycling depots or disposal companies. This
disposal is free of charge for the user. Protect the environment and
dispose of this device properly. You can obtain further information from
your local disposal company or the city or local authority.
SPECIFICATIONS SF40GA11 K1 Connector
Power Input : AC 240V, 50/60Hz
Power consumption : ≤ 1W (Standby)
Max. transmission power : 10dBm
Networking : WiFi | 802.11n/g/b,WPA/WPA2
: RF | 868MHz
Wireless distance : WiFi | Refer to Router for instructions
: RF | ≥ 100 m
Environment : -10°C ~ +50°C <95% RH (Non-condensate)
ELRO Europe | www.elro.eu
Postbus 9607 –Box E800
1006 GC Amsterdam - The Netherlands
V3

-15-
English 02 - 14
Deutsch 16 - 29
Nederlands 31 - 44
Français 46 - 59
Hiermit erklärt ELRO Europe, dass der Funkanlagentyp SF40GA11 der
Richtlinie 2014/53/EU entspricht. Der vollständige Text der
EU-Konformitätserklärung ist unter der folgenden Internetadresse
verfügbar: www.elro.eu/compliance
K1 CONNECTOR
ELRO CONNECTS
SF40GA11 Home is not a place, it’s a feeling

-16-
ERKLÄRUNG
Der ELRO K1-Connector ist das Zentrum Ihres ELRO Connects- Systems.
Er verbindet all Ihre ELRO Connects-Produkte mit der kostenlosen ELRO
Connects App. Mit der ELRO Connects-App übernehmen Sie die volle
Kontrolle über Ihr Zuhause und machen es zu einer sicheren und
komfortablen Umgebung für Sie und Ihre Familie. ELRO Connects ist ein
Plug & Play- System, entwickelt für eine einfache Bedienung und um
Freude zu bereiten.
Installation in drei Schritten
1. Die ELRO Connects-App herunterladen
Laden Sie die "ELRO Connects"-App aus
dem Apple App Store oder Google Play
Store herunter. Um alle Funktionen des
ELRO Connects-Systems zu erleben,
erlauben Sie der App, Ihnen Push-
Benachrichtigungen zu senden und Ihren
derzeitigen Standort verwenden zu
dürfen.
2. Ein Benutzerkonto erstellen
Wenn Sie die App zum ersten Mal
öffnen, wird die Anmeldeseite gezeigt.
Bitte drücken Sie den "Registrieren"-
Button (1) in der unteren rechten Ecke
der App. Geben Sie auf der nächsten
Seite Ihre E-Mail-Adresse ein (2). Um
Ihre E- Mail-Adresse zu bestätigen,
drücken Sie bitte den "Erhalten"- Button
(3). Nun erscheint ein Fenster, in welches Sie Ihren angezeigten
grafischen Bestätigungscode eingeben müssen (4). (Geben Sie dabei auf

-17-
die Groß- und Kleinschreibung acht!)
Nachdem Sie den grafischen
Bestätigungscode eingegeben haben,
erhalten Sie eine E-Mail von der ELRO
Connects App.
Wenn Sie die E-Mail auf Ihrem Telefon
abrufen, werden Sie die ELRO Connects-
App erneut öffnen und die E-Mail-
Adresse erneut eingeben müssen; den
Bestätigungscode, den Sie in der E-Mail
erhalten haben, können Sie dann in der
App links neben dem "Erhalten"- Button
(3) einfügen.
Geben Sie als nächstes das Kennwort (5),
dass Sie verwenden möchten
(mindestens 8 Zeichen, eine
Kombination aus Groß- und
Kleinbuchstaben, Zahlen und/oder
Zeichen). Geben Sie Ihr Kennwort in dem
Feld darunter erneut ein und drücken Sie
auf "Registrieren". Sie können das
Kennwort überprüfen, indem Sie auf das
Augensymbol drücken. Zum Bestätigen
drücken Sie "Registrieren". Der
Anmeldebildschirm wird erscheinen. Nun
können Sie sich mit Ihrer E-Mail-Adresse
und Ihrem Kennwort in der App
anmelden.

-18-
3. Den K1-Connector mit der App
verbinden
Nun werden Sie zur "Verbindung
hinzufügen"-Seite weitergeleitet. Bitte
verbinden Sie den K1 Connector mit
einer Steckdose und warten Sie bis die
LED-Anzeige grün zeigt.
Drücken Sie dann den Schalter des K1
Connector (1) für mindestens drei
Sekunden bis die blaue LED-Anzeige
langsam blinkt. Drücken Sie danach den
"WEITER"-Button (2). Geben Sie auf der
nächsten Seite das Kennwort (3) zu
Ihrem W-LAN- Netzwerk ein und drücken
Sie "VERBINDEN". Nun sucht die App
nach Ihrem Netzwerk, um den K1
Connector mit der App zu verbinden. Der
Vorgang dauert ungefähr eine Minute. In
Folge werden Sie informiert, dass die
Verbindung erfolgreich hergestellt
wurde.
Stellen Sie sicher, dass Sie ein reines 2,4-
GHz-WLAN-Signal verwenden. Das
bedeutet, dass es sich nicht um ein
kombiniertes WLAN-Band mit sowohl
einem 2,4-GHz- als auch einem 5-GHz-
Signal handeln kann. Vor der Installation
des Systems müssen Sie daher das 5GHz-
Signal vorübergehend deaktivieren. Nach
der Installation kann dieses Signal wieder
eingeschaltet werden.

-19-
ELRO Connects-Produkte mit der App verbinden
Verschiedene ELRO Connects-Produkte mit der App zu verbinden ist
sehr einfach und beansprucht sehr wenig Zeit. Gehen Sie zuerst in die
Geräteliste, indem Sie den "Geräte"- Button (1) in der unteren rechten
Ecke der Startseite drücken. Drücken Sie danach das "+"-Symbol in der
oberen rechten Ecke (2).

-20-
Nun drücken Sie rasch den Schalter Ihres
ELRO Connects- Gerätes dreimal. (3).
Wenn die Verbindung mit dem ELRO
Connects-Gerät erfolgreich hergestellt
wurde, blinkt die LED- Anzeige des K1-
Connector zehnmal in Folge schnell und
Sie erhalten eine Benachrichtigung in der
App.
Bitte beachten Sie:
Der ELRO Connects Water Detector
(FW3801R) besitzt keinen Schalter.
Verwenden Sie hier einen
Schraubenzieher, um beide Sensoren
dreimal während dem Verbindungs-
prozess zu berühren.
Gratulation!
Sie haben ein ELRO Connects- Produkt erfolgreich mit Ihrer App
verbunden. Nun können Sie das Produkt benennen und es mit Ihrer App
verwenden, um es vom Smartphone aus zu kontrollieren, Szenen zu
erstellen, usw.
Szenen
Ihre ELRO Connects-App hat drei
vorinstallierte Betriebsmodi: "Zuhause",
"Weg" und "Schlafen". Sie können zwischen
diesen Betriebsmodi wechseln, indem Sie
den Button in der Mitte auf der Startseite
drücken und dann den gewünschten Modus
wählen.
