KNX AQS/TH
Indoor Sensor

1 Content
Elsner Elektronik GmbH • Herdweg 7 • D-75391 Gechingen • Germany
Indoor Sensor KNX AQS/TH • from software version 0.1.0, ETS programme version 1.0
Subject to technical changes. Errors excepted.
1. Description ........................................................................................... 3
1.0.1. Measurement of carbon dioxide in the air ................................................. 3
1.1. Technical specifications ........................................................................................... 4
1.1.1. Accuracy of the measurement ..................................................................... 5
2. Installation and commissioning ........................................................... 5
2.1. Notes on installation ................................................................................................ 5
2.2. Installation position .................................................................................................. 6
2.3. Delivery scope and assembly .................................................................................. 7
2.3.1. Front view sensor board .............................................................................. 7
2.3.2. Rear view sensor board ................................................................................ 8
2.4. Installation ................................................................................................................ 8
2.5. Notes on assembly and operation .......................................................................... 9
3. Transmission protokoll ...................................................................... 10
3.1. List of all Communication objects ........................................................................ 10
4. Setting of parameters ........................................................................ 19
4.1. General settings ..................................................................................................... 19
4.2. Temperature measured value ............................................................................... 19
4.3. Temperature threshold values .............................................................................. 20
4.3.1. Threshold values 1 / 2 / 3 / 4 ....................................................................... 20
4.4. Temperature PI control .......................................................................................... 22
4.5. Humidity measured value ..................................................................................... 26
4.6. Humidity threshold values .................................................................................... 27
4.6.1. Humidity threshold values 1 / 2 ................................................................. 27
4.7. Humidity PI control ................................................................................................ 29
4.8. Dewpoint temperature ........................................................................................... 30
4.8.1. Monitoring of the cooling medium temperature ..................................... 31
4.9. Absolute humidity .................................................................................................. 32
4.10.Comfort field .......................................................................................................... 33
4.11.CO2 measured value ............................................................................................. 33
4.12.CO2 threshold values ............................................................................................ 34
4.12.1. Threshold value 1 / 2 / 3 / 4 ........................................................................ 34
4.13.CO2 PI control ........................................................................................................ 36
4.14.Actuating variable comparator ............................................................................. 37
4.14.1. Actuating variable comparator 1 / 2 .......................................................... 38
4.15.Logic ........................................................................................................................ 38
4.15.1. AND Logic 1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 .............................................................. 38
4.15.2. Linkage inputs for AND Logik .................................................................... 40
4.15.3. OR Logic 1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 ................................................................ 42
4.15.4. Linkage inputs of OR Logik ........................................................................ 43

2 Explanation of symbols
Explanation of the symbols used in this manual
Danger of death by electrocution!
Advice on dangers concerning work on electrical terminals, components etc.
Safety measures to protect the life and health of relevant personnel.
Safety instruction!
Instructions that must strictly be observed to ensure the safe operation.
Safety measures to protect against damage to persons or property.

3 Description
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
1. Description
The Indoor Sensor KNX AQS/TH measures the room CO2concentration, the tempe-
rature und air humidity and calculates the dew point. The sensor can receive external
values for temperture, humidity and CO2via the bus and process them with the own
data to overall values (mixed values, e. g. room average).
The KNX AQS/TH provides eleven switching outputs with adjustable threshold valu-
es. The switching outputs and further communication objects can be linked by AND
and OR logic gates. Additionally, an integrated actuating variable comparator can com-
pare and output values that are received via communication objects.
Integrated PI controllers allows for control of a ventilation (depending on CO2concen-
tration and air humidity) and a heating/cooling system (depending on temperature).
The sensor can can emit a warning to the bus as soon as the area of optimum comfort
(according to DIN 1946) is left.
Functions:
• Measurement of CO2concentration of the air, of temperature and air
humidity (absolute, relative), calculation of the dew point
•Mixed values from own measured values and external values (proportions
can be set in percentage)
•PI controller for heating (one or two step) and cooling (one or two step)
depending on temperature
•PI controller for ventilation depending on humidity and CO2 concentration:
dehumidification/humidification (one step) or dehumidification (one or two
step)
•11 switching outputs with adjustable threshold values (Threshold values
can be set by parameter or via communication objects)
•8 AND and 8 OR logic gates with each 4 inputs. Every switching incident as
well as 8 logic inputs (in the form of communication objects) may be used as
inputs for the logic gates. The output of each gate may optionally be configured
as 1 bit or 2 x 8 bits
•2 actuating variable comparators for output of minimum, maximum or
avarage values. Each with 5 inputs (for values received via communication
objects)
Configuration is made using the KNX software ETS. The programme file (format VD),
the data sheet and the manual can be downloaded from the Elsner Elektronik home-
page on www.elsner-elektronik.de in the “Service” menu.
1.0.1. Measurement of carbon dioxide in the air
The CO2concentration in the air is indicated in parts per million (ppm). 1000ppm cor-
respond to 0.1%. From this value on humans perceive the room air as „used“.

4 Description
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
1.1. Technical specifications
CO2concentration (ppm)
200.000 Humans are not capable to survive (fatal concentration)
100.000 Candle will go out
40.000 bis 50.000 Exhaled air
5.000 Maximum admissible value at work place (MAC value)
4.000 Insufficiently ventilated room
1.000 “Bad air“ is perceived
330 bis 350 Outside air
Housing Plastic material
Colour White matt
Mounting In-wall (in junction box Ø 70 mm, 36 mm deep,
box is included in scope of delivery)
Protection category IP 50
Dimensions Cover approx. 94 × 94 (W × H, mm),
mounting depth approx. 8 mm
Weight approx. 105 g (including box and cover)
Ambient temperature Operation -10…+50°C, Storage -20…+60°C
Ambient air humidity approx. 95% rF, avoid bedewing
Operating voltage KNX bus voltage
Bus current max. 10 mA
Data output KNX +/- Bus terminal plug
BCU type own micro controller
PEI type 0
Group addresses max. 254
Allocations max. 254
Communication objects 227
Measurement range CO20…2000 ppm
Resolution (CO2) 1 ppm
Accuracy *(CO2) ± 50 ppm ± 3% of the measured value±
Measurement range
temperature
-10…+50°C
Resolution (temperature) 0.1°C
Accuracy* (temperature) ± 0.4°C at 25°C
Measurement range
humidity
0…95%
Resolution (humidity) 0.1%
Accuracy* (humidity) ± 5% R. H.

5 Installation and commissioning
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
* Please consider the notes on Accuracy of the measurement, Seite 5
The following standards have been considered for the evaluation of the product in
terms of electro magnetic compatibility:
• EN 50090-2-2: 1996/A2:2007
• EN 61000-6-1: 2007
• EN 61000-6-3: 2007
The product has been tested for the above mentioned standards by an accredited EMV
laboratory.
1.1.1. Accuracy of the measurement
Measurement variations from sources of interference (see chapter Installation positi-
on) must be corrected in the ETS in order to ensure the specified accuracy of the sensor
(offset). To ensure a correct CO2measurement, the device must be installed in a wind-
proof socket.
The indiceted accuracy of the CO2measurement will be achieved after a run-in period
of 24 hours (without interruption of the bus voltage) if the sensor has been in contact
with fresh air (350…450 ppm) at least once in this period.
After this, the CO2sensor will recalibrate every two weeks by defining the lowest mea-
sured value captured during that period (without interruption of the bus voltage) as a
reference for fresh air.
The guarantee the accuracy on a sustained basis, the sensor should be provided with
fresh air at least once in two weeks. This occurs normally during room ventilation.
2. Installation and commissioning
2.1. Notes on installation
Installation, inspection, commissioning and troubleshooting of
the device must only be carried out by a competent electrician.
Disconnect all lines to be assembled, and take safety precautions against accidental
switch-on.
The device is exclusively intended for appropriate use. With each inappropriate change
or non-observance of the instructions for use, any warranty or guarantee claim will be
void.
After unpacking the device, check immediately for any mechanical damages. In case of
transport damage, this must immediately notified to the supplier.
If damaged, the device must not be put into operation.
If an operation without risk may supposedly not be guaranteed, the device must be put
out of operation and be secured against accidental operation.

6 Installation and commissioning
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
The device must only be operated as stationary system, i.e. only in a fitted state and
after completion of all installation and start-up works, and only in the environment in-
tended for this purpose.
Elsner Elektronik does not assume any liability for changes in standards after publica-
tion of this instruction manual.
2.2. Installation position
The KNX AQS/TH is flush mounted in a distribution box (Ø 70 mm, 36 mm deep) and
covered. Box and cover are supplied.
May be installed and operated in dry interior rooms only.
Avoid condensation.
For monitoring of the CO2content of the room air choose an installation position in
height of head (standing or sitting, according to utilization of room). The CO2concen-
tration in indoor rooms is highest near the floor and decreases towards the ceiling.
When selecting an installation location, please ensure that the measurement results
are affected as little as possible by external influences. Possible sources of interference
include:
• Direct sunlight
• Drafts from windows and doors
• Draft from ducts which lead from other rooms or from the outside to the
junction box in which the sensor is mounted
• Warming or cooling of the building structure on which the sensor is mounted,
e.g. due to sunlight, heating or cold water pipes
• Connection lines and ducts which lead from warmer or colder areas to the
sensor
Measurement variations from such sources of interference must be corrected in the
ETS in order to ensure the specified accuracy of the sensor (offset).
To ensure a correct CO2measurement, the device must be installed in a windproof so-
cket.

7 Installation and commissioning
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
2.3. Delivery scope and assembly
2.3.1. Front view sensor board
2x Device screw Ø 3,2 mm × 15 mm
1x Cover with punches
1x Board with sensor electronic and
connection plugs (bus black-red,
axiliary voltage white-yellow)
1x Distribution box Ø 70 mm, 36 mm
deep
1 Grooves for attachment of cover
2 Oblong holes for fastening with distribution box
3 Programming button for teaching the device,
can also be operated when cover is clamped on (see right)
4 Programming LED
3
2
1
434

8 Installation and commissioning
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
2.3.2. Rear view sensor board
2.4. Installation
The future orientation is determined by fitting the box:
First, mount the box and connection lead
Subsequently, connect the bus +/- (connector black-red) to the intended terminal of the
sensor board.
Screw the sensor board in the box. Now clamp the cover with the snap taps in the
grooves of the board.
Screw holes on left and
right
Logo on top of board Logo on top of cover
1 Grooves for attachment of cover
2 Oblong holes for fastening with distribution box
3 KNX terminal BUS +/-
3
21

9 Installation and commissioning
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
2.5. Notes on assembly and operation
Sensor must not be exposed to water (rain) or dust. This could result in the electronic
being damaged. A relative air humidity of 95% must not be exceeded. Avoid bedewing.

10 Transmission protokoll
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
3. Transmission protokoll
3.1. List of all Communication objects
Abbreviations Flags:
C Communication
R Read
WWrite
T Transmit
UUpdate
No Name Function DPT Flags
0 Software version readable 217.001 C R T
1 Malfunction temperature/humidity
sensor
Output 1.001 C R T
2 CO2 sensor malfunction Output 1.001 C R T
3 External measured value for tem-
perature
Input 9.001 C W
4 Internal measured value for tem-
perature
Output 9.001 C R T
5 Total measured value for temperature Output 9.001 C R T
6 Request min./max. temperature mea-
sured value
Input 1.017 C W
7 Minimum measured value for tem-
perature
Output 9.001 C R T
8 Maximum measured value for tem-
perature
Output 9.001 C R T
9 Reset min./max. measured value for
temperature
Input 1.017 C W
10 Temp. threshold value 1: Absolute
value
Input / output 9.001 C R W T U
11 Temp. threshold value 1: (1:+ | 0:-) Input 1.002 C W
12 Temp. threshold value 1: Switching
delay from 0 to 1
Input 7.005 C W
13 Temp. threshold value 1: Switching
delay from 1 to 0
Input 7.005 C W
14 Temp. threshold value 1: Switching
output
Output 1.001 C R T
15 Temp. threshold value 1: Switching
output block
Input 1.002 C W
16 Temp. threshold value 2: Absolute
value
Input / output 9.001 C R W T U

11 Transmission protokoll
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
17 Temp. threshold value 2: (1:+ | 0:-) Input 1.002 C W
18 Temp. threshold value 2: Switching
delay from 0 to 1
Input 7.005 C W
19 Temp. threshold value 2: Switching
delay from 1 to 0
Input 7.005 C W
20 Temp. threshold value 2: Switching
output
Output 1.001 C R T
21 Temp. threshold value 2: Switching
output block
Input 1.002 C W
22 Temp. threshold value 3: Absolute
value
Input / output 9.001 C R W T U
23 Temp. threshold value 3: (1:+ | 0:-) Input 1.002 C W
24 Temp. threshold value 3: Switching
delay from 0 to 1
Input 7.005 C W
25 Temp. threshold value 3: Switching
delay from 1 to 0
Input 7.005 C W
26 Temp. threshold value 3: Switching
output
Output 1.001 C R T
27 Temp. threshold value 3: Switching
output block
Input 1.002 C W
28 Temp. threshold value 4: Absolute
value
Input / output 9.001 C R W T U
29 Temp. threshold value 4: (1:+ | 0:-) Input 1.002 C W
30 Temp. threshold value 4: Switching
delay from 0 to 1
Input 7.005 C W
31 Temp. threshold value 4: Switching
delay from 1 to 0
Input 7.005 C W
32 Temp. threshold value 4: Switching
output
Output 1.001 C R T
33 Temp. threshold value 4: Switching
output block
Input 1.002 C W
34 Temp. control: Switching object
(0:Heating | 1:Cooling)
Input 1.002 C W
35 Temp. control: Target value current Output 9.001 C R T
36 Temp. control: Blocking object Input 1.002 C W
37 Temp. control: Target value, Heating
day
Input / output 9.001 C R W T U
38 Temp. control: Target value, Heating
day (1:+ | 0:-)
Input 1.002 C W
39 Temp. control: Target value, Cooling
day
Input / output 9.001 C R W T U
40 Temp. control: Target value, Cooling
day (1:+ | 0:-)
Input 1.002 C W
No Name Function DPT Flags

12 Transmission protokoll
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
41 Temp. control: Actuating variable hea-
ting (1.stage)
Output 5.001 C R T
42 Temp. control: Actuating variable hea-
ting 2.stage
Output 5.001 C R T
43 Temp. control: Actuating variable hea-
ting 2.stage
Output 1.001 C R T
44 Temp. control: Actuating variable Coo-
ling (1. stage)
Output 5.001 C R T
45 Temp. control: Actuating variable Coo-
ling 2.stage
Output 5.001 C R T
46 Temp. control: Actuating variable Coo-
ling 2.stage
Output 1.001 C R T
47 Temp. control: Night reduction activa-
tion
Input 1.003 C W
48 Temp. control: Target value heating,
night
Input / output 9.001 C R W T U
49 Temp. control: Target value heating,
night (1:+ | 0:-)
Input 1.002 C W
50 Temp. control: Target value Cooling,
night
Input / output 9.001 C R W T U
51 Temp. control: Target value Cooling,
night (1:+ | 0:-)
Input 1.002 C W
52 Temp. control: Status heating 1 (1=ON
| 0=OFF)
Output 1.001 C R T
53 Temp. control: Status heating 2 (1=ON
| 0=OFF)
Output 1.001 C R T
54 Temp. control: Status Cooling 1 (1=ON
| 0=OFF)
Output 1.001 C R T
55 Temp. control: Status Cooling 2 (1=ON
| 0=OFF)
Output 1.001 C R T
56 Temp. control: Window status
(0: CLOSED | 1: OPEN)
Input 1.019 C W
57 External measured value for humidity Input 9.007 C W
58 Internal measured value for humidity Output 9.007 C R T
59 Total measured value for humidity Output 9.007 C R T
60 Request min./max. humidity measured
value
Input 1.017 C W
61 Minimum measured value for
humidity
Output 9.007 C R T
62 Maximum measured value for
humidity
Output 9.007 C R T
63 Reset min./max. measured value for
humidity
Input 1.017 C W
No Name Function DPT Flags

13 Transmission protokoll
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
64 Humidity threshold value 1: Absolute
value
Input / output 9.007 C R W T U
65 Humidity threshold value 1: (1:+ | 0:-) Input 1.002 C W
66 Humidity threshold value 1: Switching
delay from 0 to 1
Input 7.005 C W
67 Humidity threshold value 1: Switching
delay from 1 to 0
Input 7.005 C W
68 Humidity threshold value 1: Switching
output
Output 1.001 C R T
69 Humidity threshold value 1: Switching
output block
Input 1.002 C W
70 Humidity threshold value 2: Absolute
value
Input / output 9.007 C R W T U
71 Humidity threshold value 2: (1:+ | 0:-) Input 1.002 C W
72 Humidity threshold value 2: Switching
delay from 0 to 1
Input 7.005 C W
73 Humidity threshold value 2: Switching
delay from 1 to 0
Input 7.005 C W
74 Humidity threshold value 2: Switching
output
Output 1.001 C R T
75 Humidity threshold value 2: Switching
output block
Input 1.002 C W
76 Humidity control: Blocking object Input 1.006 C W
77 Humidity control: Target value Input / output 9.007 C R W T
78 Humidity control: Target value (1:+ | 0:-
)
Input 1.002 C W
79 Humidity control: Actuating variable
Dehumidification (1.stage)
Output 5.001 C R T
80 Humidity control: Actuating variable
Dehumidification 2.stage
Output 5.001 C R T
81 Humidity control: Actuating variable
Humidification
Output 5.001 C R T
82 Humidity control: Status
Dehumidification1(1=ON | 0=OFF)
Output 1.001 C R T
83 Humidity control: Status
Dehumidification2(1=ON | 0=OFF)
Output 1.001 C R T
84 Humidity control: Status Humidifica-
tion (1=ON | 0=OFF)
Output 1.001 C R T
85 Dew point temperature Output 9.001 C R T
86 Cooling medium temp.: Threshold
value
Output 9.001 C R T
No Name Function DPT Flags

14 Transmission protokoll
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
87 Cooling medium temp.: Actual value Input 9.001 C W
88 Cooling medium temp.: Offset change
(1:+ | 0:-)
Input 1.002 C W
89 Cooling medium temp.: Switching
delay from 0 to 1
Input 7.005 C W
90 Cooling medium temp.: Switching
delay from 1 to 0
Input 7.005 C W
91 Cooling medium temp.: Switching out-
put
Output 1.001 C R T
92 Cooling medium temp.: Switching out-
put block
Input 1.002 C W
93 Absolute Humidity [g/kg] Output 14.005 C R T
94 Absolute Humidity [g/m³] Output 14.005 C R T
95 Ambient climate Status: 1 =
comfortable | 0 = uncomfortable
Output 1.002 C R T
96 External measured value for humidity Input 9.001 C W
97 Internal measured value for CO2 Output 9.001 C R T
98 Total measured value for CO2 Output 9.001 C R T
99 Request min./max. CO2 value Input 1.017 C W
100 Maximum measured value for CO2 Output 9.001 C R T
101 Reset min./max. measured value for
CO2
Input 1.017 C W
102 CO2 threshold value 1: Absolute value Input / output 9.001 C R W T U
103 CO2 threshold value 1: (1:+ | 0:-) Input 1.002 C W
104 CO2 threshold value 1: Switching
delay from 0 to 1
Input 7.005 C W
105 CO2 threshold value 1: Switching
delay from 1 to 0
Input 7.005 C W
106 CO2 threshold value 1: Switching out-
put
Output 1.001 C R T
107 CO2 threshold value 1: Switching out-
put block
Input 1.002 C W
108 CO2 threshold value 2: Absolute value Input / output 9.001 C R W T U
109 CO2 threshold value 2: (1:+ | 0:-) Input 1.002 C W
110 CO2 threshold value 2: Switching
delay from 0 to 1
Input 7.005 C W
111 CO2 threshold value 2: Switching
delay from 1 to 0
Input 7.005 C W
112 CO2 threshold value 2: Switching out-
put
Output 1.001 C R T
No Name Function DPT Flags

15 Transmission protokoll
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
113 CO2 threshold value 2: Switching out-
put block
Input 1.002 C W
114 CO2 threshold value 3: Absolute value Input / output 9.001 C R W T U
115 CO2 threshold value 3: (1:+ | 0:-) Input 1.002 C W
116 CO2 threshold value 3: Switching
delay from 0 to 1
Input 7.005 C W
117 CO2 threshold value 3: Switching
delay from 1 to 0
Input 7.005 C W
118 CO2 threshold value 3: Switching out-
put
Output 1.001 C R T
119 CO2 threshold value 3: Switching out-
put block
Input 1.002 C W
120 CO2 threshold value 4: Absolute value Input / output 9.001 C R W T U
121 CO2 threshold value 4: (1:+ | 0:-) Input 1.002 C W
122 CO2 threshold value 4: Switching
delay from 0 to 1
Input 7.005 C W
123 CO2 threshold value 4: Switching
delay from 1 to 0
Input 7.005 C W
124 CO2 threshold value 4: Switching out-
put
Output 1.001 C R T
125 CO2 threshold value 4: Switching out-
put block
Input 1.002 C W
126 CO2 control: Blocking object Input 1.006 C W
127 CO2 control: Target value Input / output 9.007 C R W T
128 CO2 control: Target value (1:+ | 0:-) Input 1.002 C W
129 CO2 control: Actuating variable ven-
tilation (1.stage)
Output 5.001 C R T
130 CO2 control: Actuating variable ven-
tilation (2.stage)
Output 5.001 C R T
131 CO2 control: Status ventilation 1
(1=ON | 0=OFF)
Output 1.001 C R T
132 CO2 control: Status ventilation 2
(1=ON | 0=OFF)
Output 1.001 C R T
133 Actuating variable comparator 1:
Input 1
Input 5.010 C W
134 Actuating variable comparator 1:
Input 2
Input 5.010 C W
135 Actuating variable comparator 1:
Input 3
Input 5.010 C W
136 Actuating variable comparator 1:
Input 4
Input 5.010 C W
No Name Function DPT Flags

16 Transmission protokoll
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
137 Actuating variable comparator 1:
Input 5
Input 5.010 C W
138 Actuating variable comparator 1:
Output
Output 1.001 C R T
139 Actuating variable comparator 1: Block Input 1.002 C W
140 Actuating variable comparator 2:
Input 1
Input 5.010 C W
141 Actuating variable comparator 2:
Input 2
Input 5.010 C W
142 Actuating variable comparator 2:
Input 3
Input 5.010 C W
143 Actuating variable comparator 2:
Input 4
Input 5.010 C W
144 Actuating variable comparator 2:
Input 5
Input 5.010 C W
145 Actuating variable comparator 2:
Output
Output 1.001 C R T
146 Actuating variable comparator 2: Block Input 1.002 C W
147 AND Logic 1: 1 Bit Switching output Output 1.002 C R T
148 AND Logic 1: 8 Bit Output A Output 5.010 C R T
149 AND Logic 1: 8 Bit Output B Output 5.010 C R T
150 AND Logic 1: Blocking Input 1.002 C W
151 AND Logic 2: 1 Bit Switching output Output 1.002 C R T
152 AND Logic 2: 8 Bit Output A Output 5.010 C R T
153 AND Logic 2: 8 Bit Output B Output 5.010 C R T
154 AND Logic 2: Blocking Input 1.002 C W
155 AND Logic 3: 1 Bit Switching output Output 1.002 C R T
156 AND Logic 3: 8 Bit Output A Output 5.010 C R T
157 AND Logic 3: 8 Bit Output B Output 5.010 C R T
158 AND Logic 3: Blocking Input 1.002 C W
159 AND Logic 4: 1 Bit Switching output Output 1.002 C R T
160 AND Logic 4: 8 Bit Output A Output 5.010 C R T
161 AND Logic 4: 8 Bit Output B Output 5.010 C R T
162 AND Logic 4: Blocking Input 1.002 C W
163 AND Logic 5: 1 Bit Switching output Output 1.002 C R T
164 AND Logic 5: 8 Bit Output A Output 5.010 C R T
165 AND Logic 5: 8 Bit Output B Output 5.010 C R T
166 AND Logic 5: Blocking Input 1.002 C W
167 AND Logic 6: 1 Bit Switching output Output 1.002 C R T
168 AND Logic 6: 8 Bit Output A Output 5.010 C R T
169 AND Logic 6: 8 Bit Output B Output 5.010 C R T
No Name Function DPT Flags

17 Transmission protokoll
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
170 AND Logic 6: Blocking Input 1.002 C W
171 AND Logic 7: 1 Bit Switching output Output 1.002 C R T
172 AND Logic 7: 8 Bit Output A Output 5.010 C R T
173 AND Logic 7: 8 Bit Output B Output 5.010 C R T
174 AND Logic 7: Blocking Input 1.002 C W
175 AND Logic 8: 1 Bit Switching output Output 1.002 C R T
176 AND Logic 8: 8 Bit Output A Output 5.010 C R T
177 AND Logic 8: 8 Bit Output B Output 5.010 C R T
178 AND Logic 8: Blocking Input 1.002 C W
179 OR Logic 1: 1 Bit Switching output Output 1.002 C R T
180 OR Logic 1: 8 Bit Output A Output 5.010 C R T
181 OR Logic 1: 8 Bit Output B Output 5.010 C R T
182 OR Logic 1: Blocking Input 1.002 C W
183 OR Logic 2: 1 Bit Switching output Output 1.002 C R T
184 OR Logic 2: 8 Bit Output A Output 5.010 C R T
185 OR Logic 2: 8 Bit Output B Output 5.010 C R T
186 OR Logic 2: Blocking Input 1.002 C W
187 OR Logic 3: 1 Bit Switching output Output 1.002 C R T
188 OR Logic 3: 8 Bit Output A Output 5.010 C R T
189 OR Logic 3: 8 Bit Output B Output 5.010 C R T
190 OR Logic 3: Blocking Input 1.002 C W
191 OR Logic 4: 1 Bit Switching output Output 1.002 C R T
192 OR Logic 4: 8 Bit Output A Output 5.010 C R T
193 OR Logic 4: 8 Bit Output B Output 5.010 C R T
194 OR Logic 4: Blocking Input 1.002 C W
195 OR Logic 5: 1 Bit Switching output Output 1.002 C R T
196 OR Logic 5: 8 Bit Output A Output 5.010 C R T
197 OR Logic 5: 8 Bit Output B Output 5.010 C R T
198 OR Logic 5: Blocking Input 1.002 C W
199 OR Logic 6: 1 Bit Switching output Output 1.002 C R T
200 OR Logic 6: 8 Bit Output A Output 5.010 C R T
201 OR Logic 6: 8 Bit Output B Output 5.010 C R T
202 OR Logic 6: Blocking Input 1.002 C W
203 OR Logic 7: 1 Bit Switching output Output 1.002 C R T
204 OR Logic 7: 8 Bit Output A Output 5.010 C R T
205 OR Logic 7: 8 Bit Output B Output 5.010 C R T
206 OR Logic 7: Blocking Input 1.002 C W
207 OR Logic 8: 1 Bit Switching output Output 1.002 C R T
208 OR Logic 8: 8 Bit Output A Output 5.010 C R T
209 OR Logic 8: 8 Bit Output B Output 5.010 C R T
No Name Function DPT Flags

18 Transmission protokoll
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
210 OR Logic 8: Blocking Input 1.002 C W
211 Logic input 1 Input 1.002 C W
212 Logic input 2 Input 1.002 C W
213 Logic input 3 Input 1.002 C W
214 Logic input 4 Input 1.002 C W
215 Logic input 5 Input 1.002 C W
216 Logic input 6 Input 1.002 C W
217 Logic input 7 Input 1.002 C W
218 Logic input 8 Input 1.002 C W
219 Logic input 9 Input 1.002 C W
220 Logic input 10 Input 1.002 C W
221 Logic input 11 Input 1.002 C W
222 Logic input 12 Input 1.002 C W
223 Logic input 13 Input 1.002 C W
224 Logic input 14 Input 1.002 C W
225 Logic input 15 Input 1.002 C W
226 Logic input 16 Input 1.002 C W
No Name Function DPT Flags

19 Setting of parameters
Indoor Sensor KNX AQS/TH • Date of issue: 13.10.2011 • Subject to technical changes. Errors excepted.
4. Setting of parameters
4.1. General settings
4.2. Temperature measured value
If no external measured value is used:
Transmission delays after power-up and programming for:
Measured values 5 s • 10 s • 30 s • 1 min • … • 2 h
Threshold values and switching outputs 5 s • 10 s • 30 s • 1 min • … • 2 h
Controller objects 5 s • 10 s • 30 s • 1 min • … • 2 h
Logic outputs 5 s • 10 s • 30 s • 1 min • … • 2 h
Maximum telegram quota 1 • 2 • 3 • 5 • 10 • 20 Telegrams per second
Use temperature/humidity malfunction
object
No • Yes
Use CO2 malfunction object No • Yes
Offset in 0,1°C -50 … +50
Use external measured value No • Yes
