LST HT-11005 User manual

© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL [phone] • FAX [phone]
[email protected] • WWW.LST.AT • ALL RIGHTS RESERVED
HT-11005_DBL_LST_EN_0804.PDF • PAGE 1
ABuilding Safety. Building Security.
Thermal ROR Detector
HT-11005
• Addressable conventional technology
• Maximum temperature 90°C
• Individual detector addressing by
means of optional address module
• Optional connection of remote
indicator
• Extremely fl at design
• Sealed electronics
Description
The Thermal ROR Detector HT-11005 reacts to tempe-
rature changes within defi ned periods of time, up to a
maximum temperature of 90°C. The intelligent evaluati-
on of these data allows the early detection of spreading
fi res. The detector complies with Class CR and can be
used up to a room height of 6m.
Addressable conventional technology is used for alarm
transmission to the fi re detection control panel. By
means of the optional Address Module NG60-1, each
detector can be addressed individually, thus allowing to
display the detector address, as well as an assigned
element text, on a suitable fi re detection control panel.
A detector fault is indicated by a yellow fl ashing of the
multicoloured status LED.
The detector can be attached to various bases and it
can be protected against theft.
Specifi cations
Operating voltage Supply through the detector line voltage
Current consumption typ. 65µA (quiescent)
Alarm temperature 90°C (maximum-heat component)
Operating temperature max. +80°C
Ambient temperature - 40°C to +90°C (no condensation or icing)
Relative humidity 0 – 98% (no condensation)
Dimensions ø × H 100 × 36 (mm)
Colour white
Weight 70g
Approval VdS G204037
Order number 242034
Order name Thermal ROR Detector/Conv./ORBIS/Apo HT-11005
