Emax PDRCF1150029 User manual

Emax Air Dryer
R E F R I G E R A T E D T Y P E C O M P R E S S E D A I R D R Y E R S
EDRCF1150029 –EDRCF4602000
Instructions Manual

TABLE OF CONTENTS
1. Important safety notes - Please read..........................1
1.1. Transportation...............................................................1
1.2 Positioning.....................................................................1
1.3 Installation......................................................................1
1.4 Before operating............................................................1
1.5 Maintenance by an engineer.........................................1
1.6 Maintenance by the user............................................. 1
2.Introduction.....................................................................2
3.Operation.........................................................................4
4.Technical specifications ................................................7
5.Diagrams.............................................................................8
6.General Arrangements...................................................18
7. Main Settings................................................................18
8.Drawings........................................................................19
9.Components location...................................................60
10.Troubleshooting............................................................61
11. Warranty.........................................................................63

1
A) When operating the air dryer the operator must apply safe working methods and observe all local safety
instructions and relevant regulations.
B) Prior to installation, the dryer and the compressed air system are to be depressurized and disconnected
from the electrical main supply.
C) The user is responsible for safe operating conditions. Parts and accessories must be replaced if inspection
showsthat safe operation cannot be assured.
D) Installation, operation, maintenance and repair are only to be authorized, trained and skilled engineers.
E) The minimum and maximum values stated must be observed, as well as all of the safety precautions described
in this manual.
F) If any statement in this manual does not comply with the local legislation, the strongest standard is to be applied.
1.1. Transportation
A) Use care and caution when transporting the dryer. Avoid dropping and other physical abuse.
B) A forklift can be used to transport the dryers provided the forks are long enough to support its full width or
length and caution is used throughout themove.
1.2. Positioning
A) The dryer must be installed horizontally. A minimum of 20” clearance around the dryer is necessary to
allowa good ventilation and easy access for servicing.
B) The ambient temperature in the room should not exceed 122°F and should not be below 39°F, taking the heat
radiatedby the dryer into account.
C) (40 watt for each liter/sec under ISO 7183-A condition or 18 watts for each SCFM under ISO 7183-B condition).
1.3. Installation
A) In addition to the general mechanical construction procedures and local regulations, the following instructions
need to be emphasized:
1) Onlyauthorized, trained and skilled engineers should installthe compressed air dryer.
2) Safety devices, protecting covers or insulation in the dryers never to be dismantled or modified.
Each pressure vessel or accessory installed outside the dryer with air above atmospheric pressure must be fitted
with the required pressurereliefsafety valves.
1.4. Before Operating
A) Review all safetyprecautions.
B) The piping must have the correct diameter and be adapted to the operating pressure (see technical specification).
C) Never operate the dryer at pressure above the maximum specified on the dryer label (check the technical specs too).
1.5. Maintenanceby an Engineer
A) Maintenance and repairs should only be performed when the air dryer is shut down and depressurized and when
the main power switch is turned off.
B) Use only the appropriate toolsfor maintenance and repair.
C) Before dismantling a part under pressure, disconnect the pressure sources and depressurize the system.
D) Proceed carefully during maintenance and repair. Prevent dirt from entering by covering parts and orifices with
a clean cloth, paper or tape.Areceiver should never be welded or modified inany way.
E) Never leave tools, loose parts or cleaning rags inor on the air dryer.
F) Before returning the dryer into service, check the setting of the control and safety devices as well as the pressure
and the temperature of the compressed air circuit.
1.6. Maintenanceby the user
A) Keepthe dryerclean.
B) Regularly check thecorrect operationof the condensate drain trap.
C) Every six months, check and clean the drain strainer by undoing the access screw and rinsing the filter with tap
waterto remove the trapped dirt from the inside.
I. IMPORTANT SAFETY NOTES –Please READ

2
D) For air cooled dryers, clean the air condenser as soon as it’s dirtyor clogged.
E) For optional water-cooled condensers, use only clean water and install a water filter if needed.
Use water counter flow to clean condenser if need.
F) Check the trouble-shooting list in case of maintenance troubles.
G) Check operating pressures, temperatures and time settings after maintenance. If operating and safety devices
function properly, the air dryer may be used.
A) Manufacturer:
B) Purpose of this dryer
1) This refrigerated compressed air dryer has been designed to remove water vapor from industrial compressed air.
2) This dryer has been designed for indoor operation.
3) The minimum and maximum values stated must be observed, as well as the safety precautions described
in this manual.
C) Dryer label
The following label is affixed on the cabinet
of the refrigerant compressed air dryer.
D) Working details
1) Refrigerant circuit:
The refrigerant circuit can be divided in 3 parts:
a) Low pressure section with an evaporator (heat exchanger)
b) High-pressure section including: Condenser, liquid receiver, (if installed) and the filter dryer.
c) Control circuit including: Compressor, Expansion valve, by-pass valve (if installed),
Fan pressure switch (if installed)
2) For water - cooled dryers:
a) Water valve
b) Safety high pressure switch (if installed)
3) The Refrigerant circuit operates as follows:
a) The compressor compresses gaseous refrigerant to a high temperature.
b) The hot refrigerant condenses in the condenser. Being liquefied it is stored in the liquid receiver (if installed).
c) The liquid is taken out the storage vessel and injected in the evaporator (heat exchanger) by an expansion valve.
This expansion valve is protected by a filter, which removes particles and humidity that could be in the circuit.
d) The injected liquid fills in the refrigerant section of the air / refrigerant heat exchanger and evaporates by taking
out the calories from the compressed air. The gaseous refrigerant is sucked in the compressor and the cycle
carries on.
e) In order to keep the evaporation pressure steady, and thus the refrigerant temperature in the heat exchanger,
a by-pass valve is injecting hot gaseous refrigerant in the circuit. On certain dryers, an automatic expansion valve
regulates this.
4) Compressed air circuit
a) The saturated hot compressed air flows into the Economiser where it is pre-cooled by the out flowing dry chilled
air. In the cold zone of the air refrigerant section it continues to cool
2. INTRODUCTION TO THE DRYER

3
down to dew point and enters the separator where condensates are collected. The outgoing chilled air is then
warmed up in the economizer by the hot incoming air.
b) The condensates are collected after centrifugal separation and drained out through the automatic trap.
c) As long as the compressed air temperature does not drop below dew point, there will be no condensation
in the air circuit.
5) Refrigerant compressor
Being of the hermetic type, it requires no servicing.
6) Condenser
a) The air condensers are equipped with a helecoidal at the condenser refrigerant level.
On certain type of dryers, a water-cooled condenser can be fitted.
b) In this case, a water valve being driven by the refrigerant circuit is taking care of its regulation.
7) Refrigerant circuit protection
a) Klixon: The single phase compressors are equipped with a klixon which is a thermal sensitive switch
controlling the temperature of the compressor and possible over intensity.
In case of malfunction, the klixon trips but switches on again automatically as soon as the compressor has
cooled down.
b) High Pressure Security Switch: Refrigerant line is considered as a pressure vessel. That is why it is
protected against bursts by the help of manually reset switch. It is set to 362.5 psi for dryers working with
R134a
c) Filter dryer: A refrigerant circuit is a closed circuit and total water removal in the refrigerant circuit is
paramount in order to obtain a correct functioning.
d) To avoid problems, the refrigerant circuit must be vacuumed before loading the refrigerant.
It is equipped with a filter dryer, which also traps any solid particles, which may have migrated into the circuit
during assembly.
e) Water-cooled dryers have a safety high-pressure switch.
In case of cooling water failure, the safety switch stops the dryer. When the safety switch has tripped out,
it has to be manually resettled before switching on the dryer.
8) Refrigerant circuit controls
a) Liquid refrigerant injection: The liquid refrigerant is into the evaporator by a control valve. This valve is a
thermostatic or pressostatic one maintaining a constant overheats of the refrigerant in the evaporator(s).
b) Constant evaporating pressure: In the dryers equipped with a by-pass valve, the evaporating pressure is kept
constant by a controlled injection of hot gas from the high-pressure side into the low-pressure section of the circuit.
9) Condensate drain - trap assembly
Dismantling the drain is easy because it can be isolated from the air circuit under pressure with a ball valve.
The drain has to be depressurized before being dismantled.
10) Heat Exchanger Modular design
a) The dryers are equipped with a compact Mono Bloc Heat Exchanger
module. This assembly has been specially designed to dry compressed air and is
made of:
1) An Economiser which pre-cools the entering hot air with the out flowing cold air.
2) An air/refrigerant exchanger cooling down the compressed air.
3) Acentrifugal separator concentrating all condensates and requiring no maintenance.
11) Accessories
a) Dew point indicator: Located on the control panel, it displays the value of the pressure dew point.
b) Temperature switch: Located inside the dryer, this temperature switch is adjustable from 32 °F up to 95 °F
c) Energy Saving Device: (ESD) This device helps dryer save energy when there is not any compressed air flow
in the dryer. (Please see the models have standart and optional in next page)
d) Filter change alarm on the front panel

4
3.1. Operation
A)
Control panels: The control panel of the dryer includes the following elements:
1) Dewpoint indicator (Standard)
2) Filter change Alarm**
3) Start / Stop Button 1) Dewpoint indicator (Standard)
2) Start Light
3) N/A
4) Filter change Alarm**
5) Main Switch
Triphase
ESD3
PDRCF4600575 - PDRCF4601200
1) ESD3 (Standard)
5) EMERGENCY STOP
ATTENTION : DN-US range dryers have low pressure drop according its competitors.
Do not use DN-US range dryers together with other dryers which have higher
pressure drop without getting the confirmation from our technical team.
** IMPORTANT NOTE: The Dryer has two Compressed Air Filter inside.
It is better to change filter element for the best efficiency when the alarm light is active.
It is recommended to keep replacement filter elements in your stock
in order to replace them when needed.
1
5
1
2 3
Monophase
Dew point
indicator
DN120-US - DN130-US
Monophase
Dew point
indicator
PDRCF1150029 - PDRCF2300288
3. OPERATION
2 3
1
4
5

5
3.2. During Operation
Regularly check the digital temperature controller ESD3 or dew point indicator on dryer.
B) Start up and shut-down
Warning: Avoid leaving the dryer off when compressed air is still flowing through it.
C) Starting for the first time or after a long stop
1) Set the rotary switch to “I” This preheats the dryer and turns the drain system on.
It is recommended to leave the dryer power on permanently so the crankcase heater runs continuously.
3) Follow the daily starting and shut down procedure.
D) Daily starting and shut-down
1) Push on the green button to start the dryer.
2) The start light will indicate that the dryer is running.
3) To stop the dryer, first stop the airflow (either shut-down the air compressor or close the inlet/outlet or
by-pass valve) When the air flow is stopped set the rotary switch on “0 “Set it again on “I “in order to keep the
preheating on.
4) IMPORTANT NOTE!
Avoid leaving the dryer stopped when compressed air is still flowing through it.
5) To switch the already preheated dryer on again, simply push the green start button.
E) Digital Temperature Control technical features (ESD3)
ESD3: PLC clear text multilingual indication of alarms, maintenance and running hours
+ Energy Saving Device automatic switching OFF at no load and ON when warm compressed air is entering.
(Please see the ESD3 manual which is given with Dryer)
2) IMPORTANT NOTE!
After a long stop of the dryer it is MANDATORY to allow a preheating period of minimum 4 hours
before starting again, to avoid any compressed air flow during preheating.

Emax Air Dryer
REFRIGERATED TYPE COMPRESSED AIR DRYERS
Technical Specifications
& Diagram

7
Model
Capacity
(CFM)
Connection
Size
Voltage
Total
Electric
Power
Refrigerant
Type
Pressure
Drop
Max Work
pressure
(bars)
Max
Ambient
Temperatu
Max inlet
Temp.
PDRCF1150029 29 1/2" 115 0.42 R134a <3 232 122 140
PDRCF1150058 58 3/4" 115 0.68 R134a <3 232 122 140
PDRCF1150115 115 1 1/2" 115 0.93 R134a <3 232 122 140
PDRCF1150144 144 1 1/2" 115 1.28 R134a <3 232 122 140
PDRCF2300288 288 2" 230 1.94 R134a <3 232 122 140
PDRCF4600288 288 2" 460 1.94 R134a <3 232 122 140
PDRCF4600575 575 3" 460 3.01 R134a <3 232 122 140
PDRCF2300575 575 3" 230 3.01 R134a <3 232 122 140
PDRCF4600850 850 3" 460 4.31 R134a <3 232 122 140
PDRCF4601200 1200 3" 460 5.68 R134a <3 232 122 140
PDRCF4601600 1600 3" 460 R134a <3 232 122 140
PDRCF4602000 2000 3" 460 R134a <3 232 122 140
For All Models
Maximum Pressure 232 PSI
Maximum Ambient Temperature 122 F
Minimum Ambient Temperature 40F
Maximum Inlet Temperature 140 F

8
5.1 AIR FLOW DIAGRAMS
EDRCF1150029 - EDRCFR1150144
M
IMPORTANT NOTICE:
5: Only From Dryer PDRCF1150115 to PDRCF1150144
9: Only from Dryer PDRCF1150115 to PDRCF1150144

9

10
5.2 ELECTRICAL DIAGRAMS Dryair DN10-US - Dryair DN30-US
ElectricalCircuit

12
Dryair DN40-US - Dryair DN80-
US
Electrical Circuit

15
Dryair DN100-US - Dryair DN110-US
ElectricalCircuit

16
Dryair DN140-US - Dryair DN170-US
ElectricalPowerCircuit

Emax Air Dryer
REFRIGERATED TYPE COMPRESSED AIR DRYERS
General Arrengements
Main Settings
Drawings

18
Model
Dryair DN10-US
1 * GKO50X + 1 * GKO50Y
MKO50 KIT
16.26
14.29
21.93
70.40
Dryair DN20-US
1 * GKO50X + 1 * GKO50Y
MKO50 KIT
16.26
14.29
21.93
70.40
Dryair DN30-US
1 * GKO50X + 1 * GKO50Y
MKO50 KIT
16.26
14.29
21.93
70.40
Dryair DN40-US
1 * GKO150X + 1 * GKO150Y
MKO150 KIT
18.62
17.83
32.76
112.20
Dryair DN50-US
1 * GKO150X + 1 * GKO150Y
MKO150 KIT
18.62
17.83
32.76
116.60
Dryair DN60-US
1 * GKO150X + 1 * GKO150Y
MKO150 KIT
18.62
17.83
32.76
121
Dryair DN70-US
1 * GKO500X + 1 * GKO500Y
MKO500 KIT
21.77
19.80
34.41
171.60
Dryair DN80-US
1 * GKO500X + 1 * GKO500Y
MKO500 KIT
21.77
19.80
34.41
182.60
Dryair DN90-US
1 * GKO500X + 1 * GKO500Y
MKO500 KIT
21.77
19.80
34.41
189.20
Dryair DN100-US
1 * GKO851X + 1 * GKO851Y
MKO851 KIT
26.69
25.51
45.55
352
Dryair DN110-US
1*GKO1210X+1*GKO1210Y
MKO1210KIT
26.69
25.51
45.55
363
Dryair DN120-US
1*GKO1210X+1*GKO1210Y
MKO1210KIT
37.32
28.66
53.94
484
Dryair DN130-US
1*GKO1210X+1*GKO1210Y
MKO1210KIT
37.32
28.66
53.94
506
Dryair DN140-US
1*GKO1820X+1*GKO1820Y
MKO1820KIT
37.32
31.42
57.48
594
Dryair DN150-US
1*GKO1820X+1*GKO1820Y
MKO1820KIT
37.32
31.42
57.48
627
Dryair DN160-US
1*GKO2700X+1*GKO2700Y
MKO2700KIT
45.79
30.63
67.91
862.40
Dryair DN170-US
1*GKO2700X+1*GKO2700Y
MKO2700KIT
45.79
30.63
67.91
902
Superheat of
thermostatic
expansion
valve
Evaporating
pressure
Fan
pressure
switch
Security(*)
high
pressure
switch
Security(**)
low
pressure
switch
Drain
timer
(***)
Low pres.
High Temp.
switch
(****)
Water flow
valve
(if water
condenser)
41OF - 50OF
29.7 psi
130 - 174 psi
362.5 psi
23.2 psi
1 min. - 5- sec.
5 min. - 4- sec.
113OF
159.5 psi
(*) Available up to Dryair DN40-US and above
(**) Available up to Dryair DN140-US and above
(***) 1 min. - 5 sec. (up to DN100-US and above)
5 min. - 4 sec. (up to DN90-US and above)
(****) Available up to DryairDN140-US and above
7. MAIN SETTINGS
6.GENERALARRANGEMENTS

19
Dryair DN10-US - Dryair DN30-US
8. ED and ID DRAWINGS

20
Dryair DN40-US - Dryair DN60-US

21
Dryair DN70-US - Dryair DN90-US
