EMBRON Hatteland E Series User manual

Please visit www.hattelandtechnology.com for the latest electronic version of this manual.
HD 16T30 MMC-xxx-xxxxxx - 15.6 inch Maritime Multi Computer
HD 21T30 MMC-xxx-xxxxxx - 21.5 inch Maritime Multi Computer
HD 24T30 MMC-xxx-xxxxxx - 23.8 inch Maritime Multi Computer
HD 27T30 MMC-xxx-xxxxxx - 27.0 inch Maritime Multi Computer
(where x=congurations/factory options)
Series E - Maritime Multi Computer (MMC) Models
USER MANUAL
User Manual MMC Series E
Updated: 02 Oct 2020 Doc Id: INB101505-1 (Rev 02)
Created: 363 Approved: 6987

Copyright © 2020 Hatteland Technology AS
Eikeskogvegen 52, N-5570 Aksdal, Norway.
All rights are reserved by Hatteland Technology AS. This information may not, in whole or in part, be
copied, photocopied, reproduced, translated or reduced to any electronic medium or machine-
readable form without the prior written consent of Hatteland Technology AS. Review also:
www.hattelandtechnology.com/hubfs/pdf/misc/doc100703-1_permission_to_create_user_manuals.pdf
The products described, or referenced, herein are copyrighted to the respective owners.
The products may not be copied or duplicated in any way. This documentation contains proprietary
information that is not to be disclosed to persons outside the user’s company without prior written consent
of Hatteland Technology AS.
The copyright notice appearing above is included to provide statutory protection in the event of
unauthorized or unintentional public disclosure.
All other product names or trademarks are properties of their respective owners !
WARNING: This is a class A product. In a domestic environment this product may cause radio interference
in which case the user may be required to take adequate measures.
Statement above last revised 31 Jul. 2019

3
IND100130-63
Contents.......................................................................................... 3
Contents of package............................................................................................................... 7
General ............................................................................................ 9
About this manual................................................................................................................. 10
About Hatteland Technology................................................................................................. 10
www.hattelandtechnology.com ............................................................................................. 10
Contact Information .............................................................................................................. 10
Maritime Multi Computer (MMC) Series E - Introduction.......................................................11
Touch screen products ......................................................................................................... 12
Product Labeling................................................................................................................... 14
Installation..................................................................................... 17
General Installation Recommendations................................................................................ 18
First Things First! .................................................................................................................. 18
Installation and mounting...................................................................................................... 18
Installation limitations ........................................................................................................... 19
Ergonomics........................................................................................................................... 21
Cables .................................................................................................................................. 22
Cable Entries & Connectors (Marked area) ...................................................................... 22
Maximum Cable Length .................................................................................................... 22
Housing / Terminal Block Connector Overview .................................................................... 23
Panel Cutout / Console Mounting Bracket Kit - 15.6 inch..................................................... 26
Panel Cutout / Console Mounting Bracket Kit - 21.5, 23.8 and 27.0 inch............................. 28
Mounting Bracket, Table / Desktop / Ceiling - 15.6 inch ....................................................... 29
Mounting Bracket, Table / Desktop / Ceiling - 21.5, 23.8 and 27.0 inch ............................... 31
Physical Connections ........................................................................................................... 33
Module Expansion Matrix ..................................................................................................... 37
Factory Standards ................................................................................................................ 37
COM Ports Numbering ........................................................................................................ 40
Operation....................................................................................... 41
User Controls........................................................................................................................ 42
Contents

Contents
4
IND100130-63
Specications ............................................................................... 45
Specications - HD 16T30 MMC-xxx-xxxxxx........................................................................ 46
Specications - HD 21T30 MMC-xxx-xxxxxx........................................................................ 47
Specications - HD 24T30 MMC-xxx-xxxxxx........................................................................ 48
Specications - HD 27T30 MMC-xxx-xxxxxx........................................................................ 49
Specications - CAN Module with CO-Processor................................................................. 50
ZIA0001310-B ................................................................................................................... 50
Specications - CAN Module with CO-Processor................................................................. 51
ZIA0001310-SLCAN.......................................................................................................... 51
Specications - NMEA / IEC COM Module RS-422 / RS-485 .............................................. 52
PCA100293-1.................................................................................................................... 52
Specications - Isolated Digital Input/Output Module ........................................................... 56
PCA100297-1.................................................................................................................... 56
Specications - LAN Module ................................................................................................ 58
PCA100298-1.................................................................................................................... 58
Specications - Isolated COM Module RS-232 .................................................................... 59
PCA100309-1.................................................................................................................... 59
Specications - COM Module RS-232.................................................................................. 60
PCA100294-1.................................................................................................................... 60
Specications Accessories ......................................................... 61
Specications - JH C01MF A-A ............................................................................................ 62
Specications - External Modules (USB).............................................................................. 63
Technical Drawings ...................................................................... 65
Technical Drawings - HD 16T30 MMC-xxx-xxxxxx............................................................... 66
Technical Drawings - HD 21T30 MMC-xxx-xxxxxx............................................................... 67
Technical Drawings - HD 24T30 MMC-xxx-xxxxxx............................................................... 68
Technical Drawings - HD 27T30 MMC-xxx-xxxxxx............................................................... 69

Contents
5
IND100130-63
Technical Drawings - Accessories.............................................. 71
Technical Drawings - HD CMB SE1-A1................................................................................ 72
Console Mount Kit 15.6 inch ............................................................................................. 72
P025485 (“Type A” Bracket) .............................................................................................. 74
P025487 (“Type B” Bracket).............................................................................................. 75
Technical Drawings - HD CMB SE1-B1................................................................................ 76
Console Mount Kit 21.5 inch ............................................................................................. 76
Console Mounting 21.5 inch.............................................................................................. 77
Flush Mounting 21.5 inch .................................................................................................. 78
Technical Drawings - HD CMB SE1-B1................................................................................ 79
Console Mount Kit 23.8 inch ............................................................................................. 79
Console Mounting 23.8 inch.............................................................................................. 80
Flush Mounting 23.8 inch .................................................................................................. 81
Technical Drawings - HD CMB SE1-B1................................................................................ 82
Flush Mounting 27.0 inch .................................................................................................. 82
Console Mounting 27.0 inch.............................................................................................. 83
Flush Mounting 27.0 inch .................................................................................................. 84
Technical Drawings - HD TMB SE1-A1 ................................................................................ 85
Desktop/Table Mounting Bracket 15.6 inch....................................................................... 85
Technical Drawings - HD TMB SE1-B1 ................................................................................ 86
Desktop/Table Mounting Bracket 21.5/23.8/27.0 inch....................................................... 86
Technical Drawings - External Modules (USB)..................................................................... 87

Contents
6
IND100130-63
Appendixes ................................................................................... 89
Pinout Assignments .............................................................................................................. 90
IoT (Internet of Things) Overview ......................................................................................... 94
SSD Selection Guide............................................................................................................ 95
ATX / AT Power Modes......................................................................................................... 98
Power Mode / COM Cong................................................................................................... 99
Trusted Platform Module (TPM) ........................................................................................ 100
Secure Boot ....................................................................................................................... 101
Choose Boot Device .......................................................................................................... 101
Battery Status and Alarm ................................................................................................... 102
LAN Teaming ..................................................................................................................... 103
Reading internal temperature ............................................................................................ 105
Using the eMMC as a backup/recovery device when SSD is used ................................... 105
Install Operating System (OS) ........................................................................................... 105
Install Microsoft® Windows® 10 with recovery option........................................................ 106
Recovery Image - Quick Start .............................................................................................110
RTC Timer (Apollolake) - User Guide .................................................................................111
BIOS Default Settings Overview......................................................................................... 121
Basic Trouble-shooting ....................................................................................................... 128
Declaration of Conformity ................................................................................................... 129
Return Of Goods Information ............................................................................................. 130
General Terms and Conditions ........................................................................................... 131
Pixel Defect Policy.............................................................................................................. 132
Notes .................................................................................................................................. 133
Revision History.................................................................................................................. 135

7
IND100131-44
Contents of package
Item Description Illustration
TP52/TC01-1,8M
1 x Power Cable (Black) European Type F “Schuko” to IEC. Length 1.8m EUR TYPE F
IEC
TP11/TC01-1,8M
1 x Power Cable (Black) US Type B plug to IEC. Length 1.8m US TYPE B IEC
Test Reports papers:
1 x Product Declaration
1 x Computer Checklist
1 x BurnInTest Certificate
HD CMB SE1-A1
HD 16T30 MMC - EN60945 Tested Bracket Kit suitable for console/panel mounting which contains:
4 x KNURLED KNOB M5 UMBR. Ø=17 mm, 038 0500 599 05 - BLACK (222 38-5 BLACK)
4 x Screw DIN 912 M5x70 UMB. A4 (145 050x070 912 A4)
4 x RAMPA-CAP NUTS TYPE RF 10 15 X 9 M5, STEEL ZINC PL. HEX4 (025509001)
6 x 145 050x012 SZF CSK Screws M5x12 Hex Zinc blank. Kval. 10.9
2 x P022317#02
Suitable for panel thickness min: 3.00 [0.12”] to over 10.00 [0.39”] mm [inch].
HD CMB SE1-B1
HD 21T30 MMC / HD 24T30 MMC / HD 27T30 MMC
Bracket Kit suitable for console/panel mounting which contains:
8 x 145 050x016 A4T (M5x16 Pan Head screw ISO 14583 Torx, A4)
8 x 9991041 (6.4 X 12 X 2.3 Washer DIN6319-C A4 SF)
3 x P025485#01 (Bracket A HD CMB SE1-B1)
1 x P025487#01 (Bracket B HD CMB SE1-B1)
Suitable for panel thickness min: 2.00 [0.08] to max 40.00 [1.57”] mm [inch].
1961986
Terminal Block Connector Kit as follows (may in some cases be already factory mounted):
1 x 2-pin Terminal Block 5.08 (1961986) for DC Power In
Refer to “Conguring Housing / Terminal Block Connector” section for usage. Note: Location may differ
between unit sizes
Note: Entries listed below are for Standard factory shipments. Customized factory shipments may deviate from this list.
Item Description Illustration
Terminal Block Connector Kit
Depending on factory mounted options, Terminal Bracket Connector kit as follows:
2 x 4-pin Terminal Block 3.81 for CAN Interface (ZIA0001310-B / ZIA0001310-SLCAN)
4 x 5-pin Terminal Block 3.81 for RS-422/RS-485 NMEA (PCA200828)
4 x 5-pin Terminal Block 3.81 for Digital Input/Output (PCA100297-1) Note: Location of module(s) may
differ between unit sizes
Package may also include: (based on accessories/options ordered)

8
This page left intentionally blank

9
General

10
Hatteland Technology AS
IND100077-1
General
About this manual
The manual contains electrical, mechanical and input/output signal specications. All specications in this manual,
due to manufacturing, new revisions and approvals, are subject to change without notice. However, the last updated
and revision date of this manual are shown both on the frontpage and also in the “Revision History” chapter. This
user manual is a standard/general manual that applies to all variations of its product family, i.e. deviation from actual
conguration may exist.
About Hatteland Technology
Hatteland Technology is the leading technology provider of specialized display and computer products, delivering high
quality, unique and customized solutions to the international maritime, naval and industrial markets.
The company represents innovation and quality to the system integrators worldwide. Effective quality assurance and
investment in sophisticated in-house manufacturing methods and facilities enable us to deliver Type Approved and Mil
tested products. Our customer-oriented approach, technical knowledge and dedication to R&D, makes us a trusted
and preferred supplier of approved solutions, which are backed up by a strong service network.
www.hattelandtechnology.com
You will nd our website full of useful information to help you make an informed choice as to the right product for your
needs. You will nd detailed product descriptions and specications for the entire range on Displays, Computers and
Panel Computers, Military solutions as well as the range of supporting accessories. The site carries a wealth of
information regarding our product testing and approvals in addition to company contact information for our various
ofces around the world, the global service locations and the technical help desk, all ensuring the best possible
support wherever you, or your vessel, may be in the world.
Contact Information
Head ofce, Aksdal / Norway:
Hatteland Technology AS
Eikeskogvegen 52
N-5570 Aksdal, Norway
Switchboard:
Tel: [phone]
[e-mail]
Sales ofce, Frankfurt / Germany:
Hatteland Technology GmbH
Werner Heisenberg Strasse 12,
D-63263 Neu-Isenburg, Germany
Uwe Scheumann:
Tel: [phone]
Elke Freisens:
Tel: [phone]
Goetz Vogelmann: (Sales Director ASIA)
Tel: [phone]
Sales ofce, Oslo / Norway:
Hatteland Technology AS
Strandveien 35
N-1366 Lysaker
Norway
Switchboard:
Tel: [phone]
[e-mail]
Sales ofce, Aix-en-Provence / France:
Hatteland Technology SAS
Actimart- 1140, rue Ampère, CS 80544
13594 Aix-en-Provence, Cedex 3
France
Mehdi Bounoua (Sales Director Europe, Middle East & Africa):
Tel : [phone]
Sales ofce, Vista / USA:
Hatteland Technology Inc
450 South Melrose Drive,
Suite #107
Vista, CA 92081
USA
Donna Pallonetti:
Tel: [phone]
Fax: [phone]
For an up-2-date list, please visit https://www.hattelandtechnology.com/contact

11
Panel Computers Series E
IND101057-23
General
Maritime Multi Computer (MMC) Series E - Introduction
Series E is the new cost effective Panel Computers portfolio from Hatteland
Technology. Designed for 10 years manufacturing, all Series E Panel Computers
integrate Intel® Apollo Lake processor-based computers, high quality display
technology, fan-less design and low power consumption to deliver a fast, reliable
all-in-one solution for diverse maritime applications.
The integrated nature of Series E Panel Computers enables tangible cost savings
for maritime technology and equipment manufacturers as well as systems integrators.
The portfolio features a range of display sizes, new data storage technology and a
number of IO options, providing full flexibility to integrate the highest quality displays
in a wider range of maritime technology. Especially suited to developing new bridge
solutions, Series E Panel Computers make it possible to continue improving safety
and efficiency through safe navigation, while still retaining focus on quality and cost.
Series E Panel Computers also meet the same extreme quality standards as the
proven Series X Panel Computer range and feature LED Backlight Technology, full
dimming (0-100%) all as standard. In addition there are options such as Multi-Power
(AC/DC) inputs or Single AC input, SSD and m.2 storage mediums and Multiple
interface configurations. The product range can also accommodate and combine
multi-touch screen and optical bonding.
Cost effective Panel Computers...
- Intel® Apollo Lake processor
- Fan-Less Design
- LED Backlight Technology
- Full Dimming 100%,
- Low Power Consumption
- Multi-Power Option
- Superior Optical Bonding Option
- Multi-Touch Option
- EN60945 Tested
- Type Approved EU-RO-MR
- ECDIS Compliant

12
IND100110-12
Touchscreen
Introduction to products with touch screen
Nearly all of our products with touch screen use Projected Capacitive Touch screen (PCTS), widely used with great
success on mobile phones and typical pad devices. PCTS can be equally effective also for marine applications.
One of the advantages of PCTS is that it has features seen in both resistive and surface capacitive touch screen
technologies.
Multitouch is dened as the ability to recognize two or more simultaneous touch points. Using projected capacitive
technology allows us to create a more intuitive form of human-device interaction. Touch interface gestures, supported by
projected capacitive sensors, can simplify the interface and provide an intuitive user experience that goes beyond the
typical "button replacement" found in most simple touch interfaces.
Please review the appropriate Product Datasheet (in this manual) to determine if PCTS are supported and/or its
advanced features of additional touch methods (example Tactor and Active Stylus Pen) are available.
The technical benets of PCTS are:
- Very good optical performance (same as surface capacitive)
- Environmentally strong, the touch sensor is inside the product (better than both surface capacitive and resistive)
- Supports Multitouch (Newer Operating System (OS) required in most cases.
- Excellent readability - light transmission of up to 91% through a standard sensor
- Stability - no drift, therefore no recalibration is required
- Pointing device - works with gloved and ungloved finger
- Resistance to contamination - by harsh cleaning fluids and other noxious substances
- Communicates via USB to external computer or internally
Comparisons between general Touch Technologies used by Hatteland Technology:
Technology Optical Performance Gloves Water Durability Multitouch Stylus Objects (Tactor)
Analog Resistive -- ++ ++ - - - --
Surface Capacitive ++ -- - + - - --
Projected Capacitive ++ + + *++ ++ ++ ++
*Projected Capacitive (PCTS) / Water: Touch Screen Glass Surface can withstand drip and direct rain, but expect reduced capability, detection and
performance if units are exposed to these factors while powered. Hatteland Technology recommends protecting the unit from direct rain or drips if
critical touch operations are to be performed. Take necessary steps (if detected or suspected) within the installation environment to prevent accidental
touch gestures or presses not performed intentionally by a human operator.
Touch screen products

13
Touch screen
IND100110-20
Touch Screen Drivers
All units with Touch Screens are automatically detected by the Operating System via HID. There is no need to install
additional Third-Party touch screen drivers.
Microsoft® Windows® 10 IoT
- Please use Windows® Generic HID driver, no specic driver needed to use multi-touch.
Linux
- Please use Linux Generic Touch driver. Use kernel 4.10 or later.
If you experience any deviation in the touch input accuracy, consider re-calibrating the touch screen for your system.
Please use the standard Operating System functionality to calibrate.
Example for Microsoft® Windows® 10 IoT:
1.Open Control Panel.
2.Click on Hardware and Sound.
3.Under “Tablet PC Settings”, click the Calibrate the screen for pen or touch input link.
4.Under “Display options”, select the display (if applicable).
5.Click the Calibrate button.
6.Select the Touch input option.
Note for units equipped with an PCTS (Projected Capacitive) Touch Screen:
Maritime Multi Computer (MMC, Panel Computer) uses internal USB connection and can be controlled by the Operating
System (OS). So, in order to clean the glass without any touch screen movement being detected, you either have to shut
down the Operating System (either via customized functions from within applications or by touching the Power On/Off
symbol) to make sure the unit has been shut down before attempting to clean the glass surface.
To learn more about how to properly clean glass surfaces, review the “Ergonomics” section in the “General Installation
Recommendations” chapter earlier in this manual.
Touch screen products

14
IND100077-202
Product Labeling
Introduction
This section details the locations, content details and specications for factory mounted labels for all currently
available standard Hatteland Technology Panel Computer (MMC) models. This information will in most cases also
apply for most Customized Models as well, but may differ based on customer requirements, in that case, please refer
to the customized User Manual (paper or electronic version, dependent on customer requirements).
Label Size and Types
ID Label Layout Description Specication
Type : Serial Number Label
Name : Label B
Size : 60mm wide x 20mm high (rectangle size)
Note: Text content of label will match specications
derived from Data Sheet.
Silver with glue on back, non-
tearable and made for thermal
transfer printing.
Barcode type: CODE128 (used extensively world wide in shipping and packaging
industries. The symbology was formerly dened as ISO/IEC 15417:2007.)
Type : Operating System (OS) label.
Size : 70mm wide x 23mm high (rectangle size)
Note: Label only present if OS was part of factory
option order. Linux OS does not have any label.
As per delivered from supplier.
Label applies for:
Windows® 7 Professional
Windows® 7 Ultimate
Type : Operating System (OS) label.
Size : 22mm wide x 9mm high (rectangle size)
Note: Label only present if OS was part of factory
option order. Linux OS does not have any label.
As per delivered from supplier.
Label applies for:
Windows® 10 IoT Enterprise
Type : Touch Screen Label
Name : Label B
Size : 60mm wide x 20mm high (rectangle size)
Note: Only present if Touch Screen was part of factory
option order.
Silver with glue on back, non-
tearable and made for thermal
transfer printing.
Note: Content on label will vary based on Touch Screen type and/or Touch Screen
Controller. Label shown to the right is for illustration purposes only!
Type : Warranty Label
Size : 30mm wide x 23mm high (oval size)
Amount : 2 pcs
Tamper-proof sticker with glue on
back.
Type : Quality Control (QC) Label
Size : 30mm wide x 23mm high (oval size)
Ordinary sticker with glue on
back.

15
Product Labeling
IND100077-202
Label Locations
Number ID and coloring based on “Label Size and Types“ table from previous page. All illustrations below are seen
from rear (and side where needed) with connectors facing down. Actual labels regarding its size and text orientation
vs product size is drawn in. Due to space restrictions on selected units, some labels will be rotated 90 degrees to t
properly. The arrangement of labels may be shifted/stacked differently as it is based on factory options, such as; Touch
Screen and Operating System (OS), but they will be grouped together where possible.
Label Positions Notes Applies for Product Range
Warranty labels covers screw.
Labels placed on rear.
1 on rear chassis
1 on terminal plate
HD 16T30 MMC-xxx-xxxxxx
Warranty labels covers screw.
Labels placed on rear.
1 on rear chassis
1 on terminal plate
HD 21T30 MMC-xxx-xxxxxx
Warranty labels covers screw.
Labels placed on rear.
1 on rear chassis
1 on terminal plate
HD 24T30 MMC-xxx-xxxxxx
Warranty labels covers screw.
Labels placed on rear.
1 on rear chassis
1 on terminal plate
HD 27T30 MMC-xxx-xxxxxx

16
Product Labeling
IND100077-203
Serial Number Label Layout (example)
Manufactured Date yyyymmdd
Product Size and Type
Input Voltages & Power Rating
Manufacturer and Country
Barcode (TYP+SNO)
Warranty Label
If you are to perform service on a unit still under warranty, any warranty will be void if this label show signs of removal
attempts or damaged by screw driver. This label is located on the back of the product and covers a key screw. This is
to aid service departments in determining if there has been any unauthorized service on a unit still under warranty.
Quality Control (QC) Label
This label indicates that the unit is produced, tested and packed according to the manufacture’s QA specications. It
will include a Personal ID and signature by the personnel responsible for approving the unit in production, testing and
warehouse departments.
Please note that typenumber shown above is a generic sample only. May not reect products mentioned in this
manual. Please review actual product S/N label.

17
Installation

18
Installation
IND100078-70
General Installation Recommendations
First Things First!
Applies for non-bonded product only: If exposed to humidity
in combination with temperature variations, product might
show condensation on the glass (inside and outside).
Inside condensation can be removed by power on the
product and set brightness to 100%. During minutes the
internal temperature rise will remove condensation.
Humidity Exposure Notice!
y
y
ATTENTION!
IND100148-5 - Rev 05
To prevent damage to
chassis and glass, please
