EMBRON HATTELAND HD 08T30 Series User manual

Please visit www.hattelandtechnology.com for the latest electronic version of this manual.
HD 08T30 MMC-xxx-xxxxxx - 8.0 inch Maritime Multi Computer
HD 13T30 MMC-xxx-xxxxxx - 13.3 inch Maritime Multi Computer
Series X - Maritime Multi Computer (MMC) Models
USER MANUAL
User Manual MMC Series X Compact
Updated: 24 Nov 2021 Doc Id: INB101420-1 (Rev 08)
Created: 363 Approved: 6987

Copyright © 2021 Hatteland Technology AS
Eikeskogvegen 52, N-5570 Aksdal, Norway.
All rights are reserved by Hatteland Technology AS. This information may not, in whole or in part, be
copied, photocopied, reproduced, translated or reduced to any electronic medium or machine-
readable form without the prior written consent of Hatteland Technology AS. Review also:
www.hattelandtechnology.com/hubfs/pdf/misc/doc100703-1_permission_to_create_user_manuals.pdf
The products described, or referenced, herein are copyrighted to the respective owners.
The products may not be copied or duplicated in any way. This documentation contains proprietary
information that is not to be disclosed to persons outside the user’s company without prior written consent
of Hatteland Technology AS.
The copyright notice appearing above is included to provide statutory protection in the event of
unauthorized or unintentional public disclosure.
All other product names or trademarks are properties of their respective owners !
WARNING: This is a class A product. In a domestic environment this product may cause radio interference
in which case the user may be required to take adequate measures.
Statement above last revised 31 Jul. 2019

3
IND100130-59
Contents.......................................................................................... 3
Contents of package ....................................................................................................8
General .......................................................................................... 11
IEC62368 policy - Introduction...................................................................................12
About this manual ......................................................................................................13
About Hatteland Technology ......................................................................................13
www.hattelandtechnology.com...................................................................................13
Contact Information....................................................................................................13
Maritime Multi Computer (MMC) - Introduction ..........................................................14
Product Labeling ........................................................................................................15
Touch screen products ...............................................................................................18
Installation..................................................................................... 21
General Installation Recommendations .....................................................................22
First Things First! .......................................................................................................22
Installation and mounting ...........................................................................................22
Installation limitations .................................................................................................23
Ergonomics ................................................................................................................25
Cables ........................................................................................................................25
Cable Entries & Connectors (Marked area) ........................................................... 25
Maximum Cable Length ......................................................................................... 25
Panel Cutout / Console Mounting Bracket Kit for 8 inch ............................................26
HD CMB SX2-B1 for HD 08T30 MMC (RetroFit HD 07T22).................................. 26
Panel Cutout / Console Mounting Bracket Kit for 13 inch ..........................................27
HD CMB SX2-C1 for HD 13T30 MMC (RetroFit HD 13T21/T22) .......................... 27
External Fan Kit for 8/13 inch.....................................................................................28
HD FAN SX2-A1 for HD 08T30 MMC / HD 13T30 MMC ....................................... 28
Housing / Terminal Block Connector Overview ..........................................................29
Physical Connections.................................................................................................31
Connection area 8 inch unit ................................................................................... 31
Connection area 8 inch unit (with HD IO-Board).................................................... 31
Connection area 8 inch unit (HD 08T21 RetroFit model)....................................... 32
Connection area 8 inch unit (HD 08T21 RetroFit model + HD IO-Board) .............. 32
Connection area 13 inch unit ................................................................................. 33
Connection area 13 inch unit (with HD IO-Board).................................................. 33
Connector Details 8/13 inch units .......................................................................... 34
Additional Connector Details 8/13 inch units (with HD IO-Board).......................... 36
Contents

Contents
4
IND100130-59
Operation....................................................................................... 37
User Controls .............................................................................................................38
Specications ............................................................................... 41
Specications - HD 08T30 MMC-2xx-xxxxAx ...........................................................42
HD 07T22 RetroFit................................................................................................. 42
Specications - HD 08T30 MMC-2xx-xxxxAx (HW00) ..............................................43
HD 07T22 RetroFit................................................................................................. 43
Specications - HD 08T30 MMC-2xx-xxxxHx ...........................................................44
HD 07T22 RetroFit w/HD IO-Board........................................................................ 44
Specications - HD 08T30 MMC-2xx-xxxxHx (HW00) ..............................................45
HD 07T22 RetroFit w/HD IO-Board........................................................................ 45
Specications - HD 08T30 MMC-2xx-xxxEAx ...........................................................46
HD 08T21 RetroFit................................................................................................. 46
Specications - HD 08T30 MMC-2xx-xxxEAx (HW00) .............................................47
HD 08T21 RetroFit................................................................................................. 47
Specications - HD 08T30 MMC-2xx-xxxEHx ...........................................................48
HD 08T21 RetroFit w/HD IO-Board........................................................................ 48
Specications - HD 08T30 MMC-2xx-xxxEHx (HW00) .............................................49
HD 08T21 RetroFit w/HD IO-Board........................................................................ 49
Specications - HD 13T30 MMC-2xx-xxxxAx ............................................................50
HD 13T21/T22 RetroFit.......................................................................................... 50
Specications - HD 13T30 MMC-2xx-xxxxHx ............................................................51
HD 13T21/T22 RetroFit w/HD IO-Board ................................................................ 51
Specications Accessories ......................................................... 53
Specications - JH C01MF A-A..................................................................................54
Specications - External Modules (USB) ...................................................................55

Contents
5
IND100130-59
Technical Drawings ...................................................................... 57
Technical Drawings - HD 08T30 MMC-2xx-xxxxAx....................................................58
Standard Model...................................................................................................... 58
Standard Model - HW00 ........................................................................................ 59
Technical Drawings - HD 08T30 MMC-2xx-xxxxHx ...................................................60
With HD IO-Board .................................................................................................. 60
With HD IO-Board - HW00 Model .......................................................................... 61
Technical Drawings - HD 08T30 MMC-2xx-xxxxAx....................................................62
RetroFit HD 08T21................................................................................................. 62
RetroFit HD 08T21 - HW00 Model......................................................................... 63
Technical Drawings - HD 08T30 MMC-2xx-xxxxHx ...................................................64
RetroFit HD 08T21 w/ HD IO-Board....................................................................... 64
RetroFit HD 08T21 w/ HD IO-Board - HW00 Model............................................... 65
Technical Drawings - HD 08T30 MMC-2xx-xxxxxx ....................................................66
Console Mounting .................................................................................................. 66
Technical Drawings - HD 08T30 MMC-2xx-xxxxxx ....................................................67
External Fan Accessory ......................................................................................... 67
External Fan Accessory - HW00 Model ................................................................. 68
Technical Drawings - HD 13T30 MMC-2xx-xxxxAx....................................................69
Standard Model...................................................................................................... 69
Standard Model - HW00 Model.............................................................................. 70
Technical Drawings - HD 13T30 MMC-2xx-xxxxHx ...................................................71
With HD IO-Board .................................................................................................. 71
With HD IO-Board - HW00 Model .......................................................................... 72
Technical Drawings - HD 13T30 MMC-2xx-xxxxxx ....................................................73
Console Mounting .................................................................................................. 73
Technical Drawings - HD 13T30 MMC-2xx-xxxxxx ....................................................74
External Fan Accessory ......................................................................................... 74
External Fan Accessory - HW00 Model ................................................................. 75
Technical Drawings - HD 13T30 MMC-2xx-xxxxxx ....................................................76
With Desktop/Table Mounting Bracket ................................................................... 76

Contents
6
IND100130-59
Technical Drawings - Accessories.............................................. 77
Technical Drawings - HD CMB SX2-B1 .....................................................................78
Console Mount Kit 7 inch/8 inch ............................................................................ 78
Technical Drawings - HD CMB SX2-C1 .....................................................................79
Console Mount Kit 13 inch ..................................................................................... 79
Technical Drawings - HD FAN SX2-A1 ......................................................................80
External Fan Kit 8/13 inch...................................................................................... 80
Technical Drawings - P015955 - USB Support Bracket .............................................81
Part of HD KIT USB-A1.......................................................................................... 81
Technical Drawings - USBC-24..................................................................................82
Dust Cover for USB................................................................................................ 82
Technical Drawings - PJC-45 .....................................................................................83
Dust Cover for LAN................................................................................................ 83
Technical Drawings - HD TMB SX2-A4......................................................................84
Desktop/Table Mounting Bracket 8 inch................................................................. 84
Technical Drawings - HD TMB SX2-A3......................................................................86
Desktop/Table Mounting Bracket 13 inch............................................................... 86
Technical Drawings - HD VED SX2-L1 ......................................................................87
VESA Adapter Kit 8/13 inch ................................................................................... 87
Technical Drawings - HD VED SX2-L2 ......................................................................90
VESA Adapter Kit 8/13 inch ................................................................................... 90
Technical Drawings - HD 08COV STD-A1 .................................................................92
UV Sun Cover (8 inch) ........................................................................................... 92
Technical Drawings - HD 13COV STD-A1 .................................................................93
UV Sun Cover (13 inch) ......................................................................................... 93
Frame Adapter (for HD 08T21 Cutout RetroFit)..................................................... 94
Technical Drawings - P023456...................................................................................95
IP66 Panel Gasket (8” RetroFit HD 07T22) ........................................................... 95
Technical Drawings - P014338...................................................................................96
IP66 Panel Gasket (8” RetroFit HD 08T21) ........................................................... 96
Technical Drawings - P014441...................................................................................97
IP66 Panel Gasket (13” RetroFit HD 13T21/T22) .................................................. 97
Technical Drawings - HD WBK SX1-A3 .....................................................................98
Wall Mount Box Kit for 8 inch models .................................................................... 98
Technical Drawings - External Modules (USB) ..........................................................99

Contents
7
IND100130-59
Appendixes ................................................................................. 101
Additional features overview/details ........................................................................102
Trusted Platform Module (TPM) ..............................................................................102
Secure Boot ............................................................................................................103
Choose Boot Device ...............................................................................................103
Battery Status and Alarm ........................................................................................104
LAN Teaming ...........................................................................................................105
Reading internal temperature ..................................................................................107
COM Ports Numbering ............................................................................................107
Using the eMMC as a backup/recovery device when SSD is used ........................107
Install Operating System (OS) ................................................................................107
Install Microsoft® Windows® 10 with recovery option .............................................108
RTC Timer (Apollolake) - User Guide .....................................................................112
BIOS Default Settings Overview ..............................................................................122
WatchDog Timer function .........................................................................................129
Basic Trouble-shooting.............................................................................................130
Trouble-shooting ......................................................................................................131
Operating System Recovery (tool) ..........................................................................131
How to activate Windows Recovery Environment on OS Drive ..............................135
Pinout Assignments..................................................................................................136
IEC62368 policy for Hatteland Technology products ...............................................143
Declaration of Conformity.........................................................................................145
Return Of Goods Information...................................................................................146
General Terms and Conditions.................................................................................147
Pixel Defect Policy ...................................................................................................148
Parts and Recycling .................................................................................................149
Notes........................................................................................................................150
Revision History .......................................................................................................152

8
IND100131-41
Contents of package
Item Description Illustration
HD CMB SX2-B1
Console Mounting
Bracket Kit 8 inch models
Console Mounting Bracket Kit for:
- HD 08T30 MMC-2xx-xxxxAx (RetroFit HD 07T22)
- HD 08T30 MMC-2xx-xxxxHx (RetroFit HD 07T22 w/HD IO-Board)
- HD 08T30 MMC-2xx-xxxPAx (RetroFit HD 07T22 IP22)
- HD 08T30 MMC-2xx-xxxPHx (RetroFit HD 07T22 IP22 w/HD IO-Board)
Kit contains:
2 x A008078#02 - Bracket 7 & 8 inch
2 x 209-M05x58RF86 - Knurled head screw M5x58 Black Fine Knurl
2 x 025509001 - RAMPA-CAP NUTS TYPE RF 10 15 X 9
2 x 145 040x012 SZ2 - Wing Screw DIN316, M4x12 Elzink
2 x 9990101 - M4x12 Pan Torx. w/sems Spring/plain washer
2 x 102032 - Springwasher DIN127 B M4
2 x XX259 - Washer Din 9021 M4, 155 D9021 M4,3
M5 Slotted Set Screw
Console Mounting Kit for:
- HD 08T30 MMC-2xx-xxxEAx (RetroFit HD 08T21)
- HD 08T30 MMC-2xx-xxxEHx (RetroFit HD 08T21 w/HD IO-Board)
- HD 08T30 MMC-2xx-xxxSAx (RetroFit HD 08T21 IP22)
- HD 08T30 MMC-2xx-xxxSHx (RetroFit HD 08T21 IP22 w/HD IO-Board)
Unit comes with 4 x M5x15mm Slotted Set Screws (removeable) as indicated.
HD CMB SX2-C1
Console Mounting
Bracket Kit 13 inch models
Console Mounting Bracket Kit for:
- HD 13T30 MMC-2xx-xxxxAx (RetroFit HD 13T21/HD 13T22)
- HD 13T30 MMC-2xx-xxxxHx (RetroFit HD 13T21/HD 13T22 w/HD IO-Board)
- HD 13T30 MMC-2xx-xxxPAx (RetroFit HD 13T21/HD 13T22)
- HD 13T30 MMC-2xx-xxxPHx (RetroFit HD 13T21/HD 13T22 w/HD IO-Board)
Kit Contains:
2 x A008060#02 - Bracket 13.3 inch. AISI Type 316L stainless steel
2 x 209-M05x58RF86 - Knurled head screw M5x58 Black Fine Knurl
2 x 025509001 - RAMPA-CAP NUTS TYPE RF 10 15 X 9
4 x 9990101 - M4x12 Pan Torx. w/sems Spring/plain washer
USBC-24 / PJC-45
Dust Covers
4 x USBC-24 - USB Dust Cover
2 x PJC-45 - RJ45 / LAN / Ethernet Dust Cover
Factory mounted.
HD KIT USB-A1
USB Support Bracket Kit
Kit Contains:
1 x P015955 - USB Support. AISI Type 316L stainless steel
1 x M3x6 Torx w/sems spring plain 7mm Zc1 - M3x6 Panhead screw w/spring and plain
1 x B2-100 Black Cable tie 2,5x100mm - B2-100 Black Cable tie 2,5x100mm
Delivered loose in bag, not factory default mounted.
Terminal Block Connector
for DC Power Input
1 x 2-pin Terminal Block 5.08 Connector for DC Power In
Refer to “Conguring Housing / Terminal Block Connector” section for usage.
1 x IP66 Mount Gasket (EPDM), Flush/Console mount are included in delivery for all models.
Details / Type number reference:
Surface: RAL9011, Glue: ATP S-4215 MF, Thickness 2mm.
P023456 for (RetroFit HD 08T21) - HD 08T30 MMC-2xx-xxxEAx / HD 08T30 MMC-2xx-xxxEHx
P014338 for (RetroFit HD 07T22) - HD 08T30 MMC-2xx-xxxSAx / HD 08T30 MMC-2xx-xxxSHx
P014441 for (RetroFit HD 13T21/HD 13T22) - HD 13T30 MMC-2xx-xxxxxx
Product Declaration, Checklist and Burn-in Certificate (3 x A4 sheets).
Note: Entries listed below are for Standard factory shipments. Customized factory shipments may deviate from this list.

Contents of package
9
IND100131-41
Item Description Illustration
Tx- Tx+ COM Rx- Rx+
Terminal Block Connector Kit
for HD IO-Board
Terminal Block Connector Kit as follows (may in some cases be factory mounted):
4 x 5-pin Terminal Block 3.81 Connector for NMEA COM (isolated RS-422/485)
1 x 5-pin Terminal Block 3.81 Connector for DIO (2 x Digital Input + 2 x Digital Output)
Refer to “Conguring Housing / Terminal Block Connector” section for usage.
Package may also include (based on options ordered):

10
This page left intentionally blank

11
General

12
IND100078-81
General
IEC62368 policy - Introduction
Safety Instructions
Please read and understand the material in this manual in its entirety before doing any installation/servicing/upgrades.
Personnel who are allowed to do work on the unit is detailed in the “IEC62368 policy for Hatteland Technology
product” section later in this manual. Symbols pertaining to different personnel in regard to operations is described in
the user manual.
Based on requirements EN 62368-1:2014 and IEC 62368-1:2018
Authority Description
Children This equipment is not suitable for use in locations where children are likely to be present.
Ordinary person/
Sailor/End-User
Not allowed to open unit.
Not allowed to install the unit.
Not allowed to terminate/connect cables to the unit.
Instructed person Allowed to open hatches/latches which does not require tools, such as Disktrays.
Allowed to open "battery-hatch" to change the battery even if tools are required.
Allowed to install the unit.
Allowed to terminate/connect cables to the unit indoors.
Skilled person Allowed to open and disassemble the unit.
Allowed to install the unit.
Allowed to terminate/connect cables to the unit indoors and outdoors.
Allowed to terminate/connect earth/ground wire.
Note: Be aware that additional denition for “skilled person” may apply, country dependent.

13
Hatteland Technology AS
IND100077-1
General
About this manual
The manual contains electrical, mechanical and input/output signal specications. All specications in this manual,
due to manufacturing, new revisions and approvals, are subject to change without notice. However, the last updated
and revision date of this manual are shown both on the frontpage and also in the “Revision History” chapter. This
user manual is a standard/general manual that applies to all variations of its product family, i.e. deviation from actual
conguration may exist.
About Hatteland Technology
Hatteland Technology is the leading technology provider of specialized display and computer products, delivering high
quality, unique and customized solutions to the international maritime, naval and industrial markets.
The company represents innovation and quality to the system integrators worldwide. Effective quality assurance and
investment in sophisticated in-house manufacturing methods and facilities enable us to deliver Type Approved and Mil
tested products. Our customer-oriented approach, technical knowledge and dedication to R&D, makes us a trusted
and preferred supplier of approved solutions, which are backed up by a strong service network.
www.hattelandtechnology.com
You will nd our website full of useful information to help you make an informed choice as to the right product for your
needs. You will nd detailed product descriptions and specications for the entire range on Displays, Computers,
Panel Computers and Military solutions as well as the range of supporting accessories. The site carries a wealth of
information regarding our product testing and approvals in addition to company contact information for our various
o󰀩ces around the world, the global service locations and the technical support centre, all ensuring the best possible
support wherever you, or your vessel, may be in the world.
Contact Information
Head oce, Aksdal / Norway:
Hatteland Technology AS
Eikeskogvegen 52
N-5570 Aksdal, Norway
Switchboard:
Tel: [phone]
[e-mail]
Sales oce, Frankfurt / Germany:
Hatteland Technology GmbH
Werner Heisenberg Strasse 2,
D-63263 Neu-Isenburg, Germany
Elke Freisens:
Tel: [phone]
Sales oce, Oslo / Norway:
Hatteland Technology AS
Strandveien 35
N-1366 Lysaker
Norway
Switchboard:
Tel: [phone]
[e-mail]
Sales oce, Aix-en-Provence / France:
Hatteland Technology SAS
Actimart- 1140, rue Ampère, CS 80544
13594 Aix-en-Provence, Cedex 3
France
Mehdi Bounoua (Sales Director Europe, Middle East & Africa):
Tel : [phone]
Sales oce, Vista / USA:
Hatteland Technology Inc
450 South Melrose Drive,
Suite #107
Vista, CA 92081
USA
Donna Pallonetti:
Tel: [phone]
Fax: [phone]
For an up-2-date list, please visit https://www.hattelandtechnology.com/contact

14
Compact Panel Computers Series X
IND101057-21
Maritime Multi Computer (MMC) - Introduction
Series X Panel Computers offer the ultimate in performance, convenience, state
of the art design and enduring quality for system integrators and boat builders.
The products offer a range of feature sets optimized for varying requirements and
applications.
Suitable for applications such as engine control systems, automation systems
and more. Innovative Human Machine Interface (HMI) solutions open up new
possibilities for the system integrator. A well implemented touch interface can
be much simpler to use than a conventional mechanical button-based interface
because it can show the user only those controls that are relevant to a particular
operation, while all the controls in a conventional interface are always present.
The GLASS DISPLAY CONTROL™, or GDC, allows control of brightness and
menu options through projected switches under the glass. Integrators can build
software to work with our API to control menu, brightness and other features.
Standard features includes a factory mounted Projected Capacitive Touch Screen
(Multitouch, USB interface), Solid State Fanless Construction - No Moving Parts,
Embedded light sensor, Buzzer and Aluminum Chassis with Glass Front as
standard. Brightness is dimmable from 0-100%.
Additionally, the unit can be factory configured with Optical Bonding Technology or
manufactured as an ATEX Certified model, RetroFit HD 08T21 frame model and
even a Rugged model for MIL/Naval use.
A computer and display, all in one...
- MULTITOUCH
- Type Approved
- IP20 rear / IP66 front
- Module based, tailor-made systems made easy!
- GLASS DISPLAY CONTROL™ (GDC), Solid State Menu System
- Optional Superior Bonding Technology

15
IND100077-193
Product Labeling
Introduction
This section details the locations, content details and specications for factory mounted labels for all currently
available standard Hatteland Technology Panel Computer (MMC) models. This information will in most cases also
apply for most Customized Models as well, but may di󰀨er based on customer requirements, in that case, please refer
to thecustomized User Manual (paper or electronic version, dependent on customer requirements).
Label Size and Types
ID Label Layout Description Specication
Please note that typenumber shown
above is a generic sample only. May
not reect products mentioned in this
manual. Please review actual product
S/N label.
Type : Serial Number Label
Name : Label B
Size : 60mm wide x 20mm high (rectangle size)
Note: Text content of label will match specications
derived from Data Sheet.
Silver with glue on back, non-
tearable and made for thermal
transfer printing.
Barcode type: CODE128 (used extensively world wide in shipping and packaging
industries. The symbology was formerly dened as ISO/IEC 15417:2007.)
Type : Operating System (OS) label.
Size : 22mm wide x 9mm high (rectangle size)
Note: Label only present if OS was part of factory
option order. Linux OS does not have any label.
As per delivered from supplier.
Label applies for:
Windows® Emb. Standard 7
Windows® 10 IoT Enterprise
Type : Touch Screen Label
Name : Label B
Size : 60mm wide x 20mm high (rectangle size)
Note: Only present if Touch Screen was part of factory
option order.
Silver with glue on back, non-
tearable and made for thermal
transfer printing.
Note: Content on label will vary based on Touch Screen type and/or Touch Screen
Controller. Label shown to the right is for illustration purposes only!
Type : Warranty Label
Size : 30mm wide x 23mm high (oval size)
Tamper-proof sticker with glue on
back.
Type : Quality Control (QC) Label
Size : 30mm wide x 23mm high (oval size)
Ordinary sticker with glue on
back.
Type : Handling Symbols Label
Size : 16mm wide x 8mm high (rectangle size)
Symbols indicate Cadmium Free product and proper
waste handling required.
FLEXcon®PHARMcal®V 400 F
WhiteTC-848V-23 TRACrite™150

16
Product Labeling
IND100077-193
Label Locations
Number ID and coloring based on “Label Size and Types“ table from previous page. All illustrations below are seen
from rear (and side where needed) with connectors facing down. Actual labels regarding its size and text orientation
vs product size is drawn in. Due to space restrictions on selected units, some labels will be rotated 90 degrees to t
properly. The arrangement of labels may be shifted/stacked di󰀨erently as it is based on factory options, such as; Touch
Screen and Operating System (OS), but they will be grouped together where possible.
Label Positions Notes Applies for Product Range
Labels placed on rear and
right side.
HD 08T30 MMC-2xx-xxxxAx
Standard Model
Labels placed on rear and
right side.
HD 08T30 MMC-2xx-xxxxHx
w/HD IO-Board
Labels placed on rear and
right side.
HD 13T30 MMC-2xx-xxxxAx
Standard Model
Labels placed on rear and
right side.
HD 13T30 MMC-2xx-xxxxHx
w/HD IO-Board

17
IND100077-113
General
Product Labeling
Serial Number Label Layout (example)
Warranty Label
If you are to perform service on a unit still under warranty, any warranty will be void if this label show signs of removal
attempts or damaged by screw driver. This label is located on the back of the product and covers a key screw. This is
to aid service departments in determining if there has been any unauthorized service on a unit still under warranty.
Quality Control (QC) Label
This label indicates that the unit is produced, tested and packed according to the manufacture’s QA specications. It
will include a Personal ID and signature by the personnel responsible for approving the unit in production, testing and
warehouse departments.
Handling Symbols Label
Ecodesign Requirements for Electronic Displays. The European Union published the Regulation 2019/2021 with
specic environmental ecodesign requirements for various types of electronic displays, such as TVs, monitors, and
digital signage displays.
Reference: https://www.enviropass.ca/2021/03/01/5-ecodesign-requirements-for-electronic-displays/
Please note that typenumber shown above is a generic sample only. May not reect products mentioned in this manual. Please review
actual product S/N label.
Manufacturer/Country
Input Voltage(s)
Type+Serial Number
Barcode (TYP+SNO)
Power Rating Max/Typ
Date of Production (YYYY-MM-DD)
Compass Safe Distance
IP Rating
Lowest value used, higher may apply,
check specications.

18
IND100110-12
Touchscreen
Introduction to products with touch screen (factory option)
Nearly all of our products with touch screen use Projected Capacitive Touch screen (PCTS), widely used with great
success on mobile phones and typical pad devices. PCTS can be equally e󰀨ective also for marine applications.
One of the advantages of PCTS is that it has features seen in both resistive and surface capacitive touch screen
technologies.
Multitouch is dened as the ability to recognize two or more simultaneous touch points. Using projected capacitive
technology allows us to create a more intuitive form of human-device interaction. Touch interface gestures, supported by
projected capacitive sensors, can simplify the interface and provide an intuitive user experience that goes beyond the
typical "button replacement" found in most simple touch interfaces.
Please review the appropriate Product Datasheet (in this manual) to determine if PCTS are supported and/or its
advanced features of additional touch methods (example Tactor and Active Stylus Pen) are available.
The technical benets of PCTS are:
- Very good optical performance (same as surface capacitive)
- Environmentally strong, the touch sensor is inside the product (better than both surface capacitive and resistive)
- Supports Multitouch (Newer Operating System (OS) required in most cases.
- Excellent readability - light transmission of up to 91% through a standard sensor
- Stability - no drift, therefore no recalibration is required
- Pointing device - works with gloved and ungloved finger
- Resistance to contamination - by harsh cleaning fluids and other noxious substances
- Communicates via USB to external computer or internally
Comparisons between general Touch Technologies used by Hatteland Technology:
Technology Optical Performance Gloves Water Durability Multitouch Stylus Objects (Tactor)
Analog Resistive -- ++ ++ - - - --
Surface Capacitive ++ -- - + - - --
Projected Capacitive ++ + + *++ ++ ++ ++
*Projected Capacitive (PCTS) / Water: Touch Screen Glass Surface can withstand drip and direct rain, but expect reduced capability, detection and
performance if units are exposed to these factors while powered. Hatteland Technology recommends protecting the unit from direct rain or drips if
critical touch operations are to be performed. Take necessary steps (if detected or suspected) within the installation environment to prevent accidental
touch gestures or presses not performed intentionally by a human operator.
Touch screen products

19
Touch screen
IND100110-20
Touch Screen Drivers
All units with Touch Screens are automatically detected by the Operating System via HID. There is no need to install
additional Third-Party touch screen drivers.
Microsoft® Windows® 10 IoT
- Please use Windows® Generic HID driver, no specic driver needed to use multi-touch.
Linux
- Please use Linux Generic Touch driver. Use kernel 4.10 or later.
If you experience any deviation in the touch input accuracy, consider re-calibrating the touch screen for your system.
Please use the standard Operating System functionality to calibrate.
Example for Microsoft® Windows® 10 IoT:
1.Open Control Panel.
2.Click on Hardware and Sound.
3.Under “Tablet PC Settings”, click the Calibrate the screen for pen or touch input link.
4.Under “Display options”, select the display (if applicable).
5.Click the Calibrate button.
6.Select the Touch input option.
Note for units equipped with an PCTS (Projected Capacitive) Touch Screen:
Maritime Multi Computer (MMC, Panel Computer) uses internal USB connection and can be controlled by the Operating
System (OS). So, in order to clean the glass without any touch screen movement being detected, you either have to shut
down the Operating System (either via customized functions from within applications or by touching the Power On/O󰀨
symbol) to make sure the unit has been shut down before attempting to clean the glass surface.
To learn more about how to properly clean glass surfaces, review the “Ergonomics” section in the “General Installation
Recommendations” chapter later in this manual.
Touch screen products

20
This page left intentionally blank
