IBASE Technology CSB200-898 User manual

CSB200-898
Slim & Compact SBC System
User’s Manual
Version 1.0b
(Feb. 2019)

ii
CSB200-898 User Manual
Copyright
©2019 IBASE Technology, Inc. All rights reserved.
No part of this publication may be reproduced, copied, stored in a retrieval system, translated
into any language or transmitted in any form or by any means, electronic, mechanical,
photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc.
(hereinafter referred to as “IBASE”).
Disclaimer
IBASE reserves the right to make changes and improvements to the products described in
this document without prior notice. Every effort has been made to ensure the information in
the document is correct; however, IBASE does not guarantee this document is error-free.
IBASE assumes no liability for incidental or consequential damages arising from
misapplication or inability to use the product or the information contained herein, nor for any
infringements of rights of third parties, which may result from its use.
Trademarks
All the trademarks, registrations and brands mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

CSB200-898 User Manual
iii
Compliance
This is a class B product. This product has passed CE tests for environmental
specifications and limits. This product is in accordance with the directives of the
Union European (EU). If users modify and/or install other devices in this equipment,
the CE conformity declaration may no longer apply.
This product has been tested and found to comply with the limits for a Class B
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with manufacturer’s instructions, may cause
harmful interference to radio communications.
WEEE
This product must not be disposed of as normal household waste, in
accordance with the EU directive of for waste electrical and electronic
equipment (WEEE - 2012/19/EU). Instead, it should be disposed of by
returning it to a municipal recycling collection point. Check local
regulations for disposal of electronic products.
Green IBASE
This product is compliant with the current RoHS restrictions and
prohibits use of the following substances in concentrations exceeding
0.1% by weight (1000 ppm) except for cadmium, limited to 0.01% by
weight (100 ppm).
•Lead (Pb)
•Mercury (Hg)
•Cadmium (Cd)
•Hexavalent chromium (Cr6+)
•Polybrominated biphenyls (PBB)
•Polybrominated diphenyl ether (PBDE)

iv
CSB200-898 User Manual
Important Safety Information
Carefully read the precautions before using the device.
Environmental conditions:
•Lay the device horizontally on a stable and solid surface in case the device may
fall, causing serious damage.
•Leave plenty of space around the device and do not block the openings for
ventilation. NEVER DROP OR INSERT ANY OBJECTS OF ANY KIND INTO
THE VENTIILATION OPENINGS.
•Slots and openings on the chassis are for ventilation. Do not block or cover these
openings. Make sure you leave plenty of space around the device for ventilation.
NEVER INSERT OBJECTS OF ANY KIND INTO THE VENTILATIN OPENINGS.
•Use this product in environments with ambient temperatures between -30˚C and
65˚C for SSD, and between -10˚C and 45˚C for HDD.
•DO NOT LEAVE THIS DEVICE IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -40˚C OR ABOVE 85˚C. This
could damage the device. The device must be used in a controlled environment.
Care for your IBASE products:
•Before cleaning the device, turn it off and unplug all cables such as power in case
a small amount of electrical current may still flow.
•Use neutral cleaning agents or diluted alcohol to clean the device chassis with a
cloth. Then wipe the chassis with a dry cloth.
•Vacuum the dust with a computer vacuum cleaner to prevent the air vent or slots
from being clogged.
WARNING
Attention during use:
•Do not use this product near water.
•Do not spill water or any other liquids on your device.
•Do not place heavy objects on the top of the device.
•Operate this device from the type of power indicated on the marking label. If you
are not sure of the type of power available, consult your distributor or local
power company.
•Do not walk on the power cord or allow anything to rest on it.
•If you use an extension cord, make sure that the total ampere rating of the
product plugged into the extension cord does not exceed its limits.
Avoid Disassembly
You are not suggested to disassemble, repair or make any modification to the device.
Disassembly, modification, or any attempt at repair could generate hazards and
cause damage to the device, even bodily injury or property damage, and will void any
warranty.

CSB200-898 User Manual
v
CAUTION
Danger of explosion if internal lithium-ion battery is replaced by an incorrect type.
Replace only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
Warranty Policy
•IBASE standard products:
24-month (2-year) warranty from the date of shipment. If the date of shipment
cannot be ascertained, the product serial numbers can be used to determine
the approximate shipping date.
•3rd-party parts:
12-month (1-year) warranty from delivery for the 3rd-party parts that are not
manufactured by IBASE, such as CPU, memory, HDD, power adapter, panel
and touchscreen.
＊PRODUCTS, HOWEVER, THAT FAILS DUE TO MISUSE, ACCIDENT,
IMPROPER INSTALLATION OR UNAUTHORIZED REPAIR SHALL BE
TREATED AS OUT OF WARRANTY AND CUSTOMERS SHALL BE BILLED
FOR REPAIR AND SHIPPING CHARGES.
Technical Support & Services
1. Visit the IBASE website at www.ibase.com.tw to find the latest information about
the product.
2. If you need any further assistance from your distributor or sales representative,
prepare the following information of your product and elaborate upon the
problem.
•Product model name
•Product serial number
•Detailed description of the problem
•The error messages in text or in screenshots if there is any
•The arrangement of the peripherals
•Software in use (such as OS and application software, including the version
numbers)
3. If repair service is required, you can download the RMA form at
http://www.ibase.com.tw/english/Supports/RMAService/. Fill out the form and
contact your distributor or sales representative.

vi
CSB200-898 User Manual
Table of Contents
Compliance....................................................................................................iii
Important Safety Information.......................................................................iv
WARNING ......................................................................................................iv
CAUTION ........................................................................................................v
Warranty Policy..............................................................................................v
Technical Support & Services ......................................................................v
Chapter 1 General Information................................................................1
1.1 Introduction.............................................................................................2
1.2 Features..................................................................................................2
1.3 Packing List ............................................................................................3
1.4 Optional Accessories ..............................................................................3
1.5 Specifications..........................................................................................4
1.6 Overview.................................................................................................6
1.7 Dimensions.............................................................................................8
Chapter 2 Hardware Configuration.........................................................9
2.1 Essential Installations Before You Begin...............................................10
2.1.1 Memory Installation ................................................................10
2.1.2 Mini PCIe Card / mSATA Card Installation..............................12
2.1.3 HDD Installation......................................................................14
2.1.4 WiFi / 3G / 4G Antenna Installation.........................................15
2.1.5 Device Exploded Diagram ......................................................16
2.1.6 Mounting Brackets Installation................................................18
2.1.7 Pinout for DC Power Input Connector.....................................20
2.2 Setting the Jumpers..............................................................................21
2.2.1 How to Set Jumpers ...............................................................21
2.3 Jumper & Connector Locations on Motherboard...................................22
2.4 Jumpers Quick Reference.....................................................................24
2.4.1 LVDS Panel Power Selection (JP1) .....................................24
2.4.2 LVDS Panel Brightness Control Selection (JP2) ..................25
2.4.3 CMOS Data Clearance (JP4)...............................................25
2.4.4 ME Register Clearance (JP5)...............................................26
2.5 Connectors Quick Reference................................................................27

CSB200-898 User Manual
vii
2.5.1 USB 2.0 Port (CN4)..............................................................28
2.5.2 USB 3.0 Port (CN1)..............................................................28
2.5.3 LAN Port (GbE) (CN3) .........................................................28
2.5.4 Display Port (CN5)...............................................................29
2.5.5 VGA Port (CN6) ...................................................................29
2.5.6 COM1 RS-232/422/485 Port (CN7)......................................30
2.5.7 Audio Connector (J1)...........................................................31
2.5.8 Amplifier Connector (J3) ......................................................31
2.5.9 DDR3L SO-DIMM Socket (J4) .............................................32
2.5.10 LCD Backlight Connector (J7)..............................................32
2.5.11 SATA II / mSATA Port (J9)...................................................32
2.5.12 SATA II Port (J12)................................................................33
2.5.13 SATA HDD Power Connector (J10, J11)..............................33
2.5.14 Full-Size Mini-PCIe Connector (J13)....................................33
2.5.15 Full-Size Mini-PCIe / mSATA Connector (J14).....................34
2.5.16 Half-Size Mini-PCIe Connector (J15)....................................34
2.5.17 Front Panel Setting Connector (J16)....................................34
2.5.18 Motherboard Power Input Connector (J17) ..........................35
2.5.19 COM2 RS-232 Port (J18).....................................................35
2.5.20 Digital I/O Connector (J19)...................................................36
2.5.21 USB 2.0 Connector (J22).....................................................36
Chapter 3 Driver Installation .................................................................37
3.1 Introduction...........................................................................................38
3.2 Intel®Chipset Software Installation Utility..............................................39
3.3 Intel®Graphics Driver Installation..........................................................40
3.4 HD Audio Driver Installation..................................................................41
3.5 Intel®Trusted Execution Engine Installation..........................................42
3.6 USB 3.0 Driver Installation....................................................................43
3.7 LAN Driver Installation ..........................................................................44
Chapter 4 BIOS Setup............................................................................45
4.1 Introduction...........................................................................................46
4.2 BIOS Setup...........................................................................................46
4.3 Main Settings........................................................................................47
4.4 Advanced Settings................................................................................48
4.4.1 ACPI Settings.........................................................................49
4.4.2 iSMART Controller..................................................................50
4.4.3 Super IO Configuration...........................................................52
4.4.4 Hardware Monitor...................................................................55
4.4.5 CPU Configuration..................................................................56

viii
CSB200-898 User Manual
4.4.6 IDE Configuration...................................................................57
4.4.7 USB Configuration..................................................................58
4.5 Chipset Settings....................................................................................60
4.5.1 North Bridge...........................................................................60
4.6 Security Settings...................................................................................61
4.7 Boot Settings.........................................................................................62
4.8 Save & Exit Settings..............................................................................64
Appendix ......................................................................................................65
A. I/O Port Address Map............................................................................66
B. Interrupt Request Lines (IRQ)...............................................................69
C. Digital I/O Sample Code........................................................................70
D. Watchdog Timer Configuration..............................................................75

1
Chapter 1
General Information
The information provided in this chapter includes:
•Features
•Packing List
•Specifications
•Overview
•Dimensions

2
CSB200-898 User Manual
1.1 Introduction
The CSB200-898 is a product series of IBASE embedded computing system,
applicable to thin clients, smart industrial automation or controller, and retail
equipment. It is a compact and fanless design with an Intel®-Atom™ DC
E3825 processor and an Intel®I210IT Ethernet controller. This product
features iSMART that allows the device capable of auto-scheduling for
general applications and gives energy savings on power. It is able to be
operated at the ambient operating temperature ranging from -30 ~ 65 °C for
SSD, -10 ~ 45 °C for HDD, and even from -40 ~ 85 °C for storage.
1.2 Features
•Slim and compact fanless design with IBASE 3.5” disk-sized SBC
•On board Intel®Atom™ DC E3825 SoC at 1.33 GHz
•iSMART for auto-scheduler and power resume
•2.5” drive tray for SATA HDD or SSD
•1 x USB 3.0, 3 x USB2.0, 3 x mini PCIe
•12V DC power input

General Information
CSB200-898 User Manual
3
1
1.3 Packing List
Your CSB200-898 package should include the items listed below. If any of the
items below is missing, contact the distributor or the dealer from whom you
purchased the product.
•CSB200-898 x 1
•Female Terminal Block x 1
(If the optional DC Jack is used, this terminal block
will not be enclosed.)
•Wall Mount Kit x 1
•Screws for Wall Mount Kit x 4
•Disk (including drivers) x 1
•Motherboard IB898 User’s Manual x 1
(You can download CSB200-898 User’s Manual from
our website.)
1.4 Optional Accessories
IBASE provide optional accessories as follows. Please contact us or your
dealer if you need any.
•Power Adapter x 1
•Power Cord x 1
•mSATA Installation Kit (if an mSATA card is used) x 1
Including:
mSATA Plate x 1
Thermal Pad x 1
Screw x 2
Nut x 2

4
CSB200-898 User Manual
1.5 Specifications
Product Name
CSB200-898
System
Motherboard
IB898-I25-ASB
Operating
System
•Windows 7 / 8.1 (32-bit & 64-bit)
•Windows Embedded 8
•Linux (Fedora)
CPU
Intel®Atom™ DC Processor E3825 APU at 1.33 GHz
Chipset
Integrated
Memory
1 x DDR3L-1333 SO-DIMM 2GB, upgradable to 8 GB
Graphics
Intel®HD graphics Gen. 7 with 4EU
Supports DX 11, OGL 3.0, OCL 1.1, OGLES 2.0
Super I/O
Nuvoton NCT5523D
Storage
2.5” drive bay for SSD / HDD
Audio Codec
Realtek ALC269QHD, two-way audio
Network
Intel®I210IT GbE LAN
Power Supply
60W power adaptor (Optional)
BIOS
AMI BIOS
Watchdog
Watchdog Timer 256 segments, 0, 1, 2…255 sec/min
Chassis
Aluminum & steel, black
Mounting
Desktop or wall mount
Dimensions
(W x H x D)
172 x 52 x 111.6 mm
(6.77” x 2.05” x 4.39”)
Net Weight
2.55 kg (5.62 lb)
Certificate
CE / LVD / FCC Class B
I/O Ports
DC Input
Terminal block for 12V DC-In (DC Jack type is optional.)
LAN
1 x RJ45 GbE LAN
USB
•1 x USB 3.0
•3 x USB 2.0
Serial
•1 x COM1 (RS-232/422/485)
•1 x COM2 (RS-232 only)
Display
•1 x Display Port
•1 x VGA

General Information
CSB200-898 User Manual
5
1
Audio Jack
•1 x Microphone input
•1 x Line-out
SATA
2 x SATA II connector
Expansion
•2 x Mini PCIe slot (full-sized, a combo Mini PCIe / mSATA
slot is included.)
•1 x Mini PCIe slot (half-sized)
Environment
Temperature
•Operating:
With SSD: -30 ~ 65 °C (22 ~ 149 °F)
With HDD: -10 ~ 45 °C (14 ~ 113 °F)
•Storage: -40~ 85 °C (-40 ~ 185 °F)
Relative
Humidity
5 ~ 90% at 45 °C (non-condensing)
Vibration
Protection
•Operating: 0.25 Grms / 5 ~ 500 Hz
•Non-operating: 1 Grms / 5 ~ 500Hz
Shock
Protection
•Operating: 20 g / 11 ms
•Non-operating: 40 g / 11 ms
All specifications are subject to change without prior notice.

6
CSB200-898 User Manual
1.6 Overview
Front View
No.
Name
No.
Name
1
Power Button
5
USB 2.0 Ports
2
Reset Button
6
Audio Jack –Line-Out
3
Power LED Indicator
7
Audio Jack –Microphone Input
4
HDD LED Indicator
8
Antenna Hole

General Information
CSB200-898 User Manual
7
1
Rear View
No.
Name
No.
Name
1
DC-In Power Connector
5
Display Port
2
USB 2.0 Port
6
VGA Port
3
USB 3.0 Port
7
COM Ports
4
LAN Port
8
Antenna Holes
Oblique View

8
CSB200-898 User Manual
1.7 Dimensions
Unit: mm

9
Chapter 2
Hardware Configuration
The information provided in this chapter includes:
•Essential installations before you begin
•Information and locations of connectors

10
CSB200-898 User Manual
2.1 Essential Installations Before You Begin
2.1.1 Memory Installation
There is one SO-DIMM DDR3L memory slots inside CSB200-898 and the
maximum memory is expandable up to 8 GB.
If you need to install or replace a memory module, you will have to remove the
metal plate (i.e. PCB bracket as shown below) with I/O module locating above
the memory slot. Follow the instructions to remove the plate.

Hardware Configuration
CSB200-898 User Manual
11
2
1. Loosen 6 screws from the bottom cover.
2. Loosen the 3 screws (M3) to free up the PCB bracket for removal.
3. Take out the PCB bracket with the I/O module carefully.
4. Align the key of your memory module with that on the memory slot and
insert the module slantwise.
5. Gently push the module in an upright position until the clips of the slot click
to hold the module in place when the module touches the bottom of the
slot.
To remove the module, press the clips outwards with both hands.

12
CSB200-898 User Manual
2.1.2 Mini PCIe Card / mSATA Card Installation
If you are using a model type of CSB200-898 that doesn’t include a mSATA
card, you can follow the instructions below to install a mSATA card.
1. Loosen 6 screws from the bottom cover and remove it.
2. Loosen 2 brass standoffs to release COM2 Port.
