EMC2 AX100 Series User manual

1
This document describes how to replace an Uninterruptible Power
Supply (UPS) that is connected to an AX100 (dual-SP) storage system.
Topics include
◆Before You Start .....................................................................................2
◆To Replace the UPS................................................................................2
◆To Verify Operation of the Replacement UPS ...................................3
◆To Return the UPS .................................................................................4
AX100-Series
Replacing an Uninterruptible
Power Supply (UPS)
Revision A02
November 19, 2004

2
Before You Start
Before You Start
Before You Start
To complete this procedure, you need a replacement UPS kit.
To Replace the UPS
As you follow the steps below, refer to Figure 1 and the
documentation that shipped with the replacement UPS.
1. Unpack the replacement UPS and save the packaging.
2. Unplug the DB9 serial cable, which is connected to SP A via an
RJ45-to-DB9 adapter, from the serial port on the UPS.
3. Unplug the storage-system power cord from the UPS.
4. Shut down the UPS power.
5. Unplug the UPS from the ac power source.
Figure 1 Disconnecting ac Power from the UPS
ON
I
OFF
O
ON
I
OFF
O
ON
I
OFF
O
ON
I
OFF
O
ON
I
OFF
O
ON
I
OFF
O
+-
EMC2946
UPS
DB9 Serial cable
Power Cords
AX100

AX100-Series Replacing an Uninterruptible Power Supply (UPS)
3
To Verify Operation of the Replacement UPS
6. Unplug the battery connector (refer to the documentation that
shipped with the replacement UPS).
CAUTION
!
The battery must be disconnected before shipping the UPS to the
manufacturer.
7. Remove the defective UPS from the cabinet (refer to the
documentation that shipped with the replacement UPS).
8. Install the replacement UPS in the cabinet.
9. Plug the DB9 serial cable, which is connected to SP A via an
RJ45-to-DB9 adapter, into the serial port on the UPS.
10. Plug the storage-system power cord connected to power
supply A into the power outlet on the UPS.
11. For a 120V UPS, plug the attached UPS power cord into an ac
power source.
Do not connect the UPS to the same power source/circuit as power
supply B.
12. For a 230V UPS, plug one end of the loose UPS power cord into
the UPS power outlet and the other end into an ac power source
in the cabinet (power distribution unit).
Do not connect the UPS to the same power source/circuit as power
supply B.
13. Turn on the UPS power.
To Verify Operation of the Replacement UPS
1. Start Navisphere®Express for the storage system if it is not
already running.
2. In the Navisphere Express navigation pane, under View, click
Components.
3. On the Components page, in the Device column, locate the entry
for the Uninterruptible Power Supply and verify that its State is
Charging or Normal.

4
To Return the UPS
To Return the UPS
To Return the UPS
1. Pack the defective UPS in the packaging from the replacement
UPS.
2. Return the defective UPS to the address provided with the
replacement UPS.
