Emerald Planet EP-RFBASE User manual

EP-RFBASE Installation Instruction
Description:
This base is suitable for use with the following EmeraldPlanet smoke alarm
models:
EP-HW-240-R1
EP-HW-240-Li10
EP-HW-240-Li10v2
Product Specifications:
1. POWER: 220-240V~/50Hz, built-in DC3V(CR123A) Lithium battery
(battery not replaceable)
2. BATTERY LIFE: ten years
3. OPERATION CURRENT:<12uA (quiescent), <30 mA (RF emitter)
4. OPERATING TEMPERATURE: -5 to 45oC
5. AMBIENT HUMIDITY: 5% to 95%
6. WIRELES RF Frequency:433.42MHz
7. WIRED INTERCONNECTION: up to 40 detectors
8. WIRELESS RF INTERCONNECTION: up to 40 detectors
9. WIRELESS RF RANGE:>100 meters in free field
10. COMPLIES WITH:AS/NZS 60065, AS/NZS 60950.1, AS/NZS 4268
NOTE: The maximum number of wired interconnections and wireless
interconnections is up to 40 detectors.
Important Safety Information:
1. This device is not suitable for use in
damp/moist/wet areas.
2. Not suitable for use with non-pure
sinusoidal power sources. (e.g. derived
from square-wave invertors).
3. Only to be installed by a licenced
electrician.
4. Observe and follow all local and national
electrical and building codes for
installation.
Wireless function description:
Warning: wireless bases use coded RF signals
and need to be paired before use.
Pairing Instructions:
Note: Before pairing, the unit must be
connected to a smoke alarm and be in normal
working mode.

1. On the first unit, press the wireless test
button(within the pin hole) 3 times within 2 seconds.
The unit is now in "Learning mode " the red LED goes on for 2 minutes
to indicate successful operation.(see Diagram 1).
2. While the first unit base LED is On, press wireless test button 3 times
within 2 seconds on other unit wireless base of smoke alarm units. The
LED should flash 3 times to indicate successful pairing.
3. Repeat step 2 on all other units.
4. Wait about 2 minutes until the first unit base LED goes out, thenpress
and hold the Test / Hush button for at
least 10 seconds on one smoke alarm to
test the interconnection.Check that all
other wireless interconnected units
respond and sound the alarm. If any unit
fails to respond, pair that unit again by
following steps 1-4.
Base Testing:
1. Pressing the base button for 3
secondstests the wired interconnection
of any connected bases and all wired
interconnected alarms start to alarm.
2. Pressing the base button for 4
secondstests the wireless
interconnection of any connected bases
and all RF interconnected alarms start
to alarm.
Alarm status:
When a single alarm unit detects smoke, it will
alarm without a flashing red LED on the base.
The red LED on any interconnected alarms
will flash twice per second. This way
occupants can identify which alarm caused
the network to activate and thereby the
source of the smoke can be identified.
Low battery reminder:
When the base battery is low, the base red
LED flashes once every 10 seconds.
LED is ILLUMINATED
WHILE BUTTON IS PRESSEDS
WIRELEDD TEST BUTTON
(PIN HOLE)
Diagram 1

Battery Specification:
Voltage: DC 3V (Lithium battery)
GP Energy: CR123A. （Lithium battery）
Installation:
1. Take out the base, knock out the appropriate hole for wiring as required.
Refer to the black areas of Diagram 2.
2. Choose the suitable position where you
want to install the product.
3. Hold the base on the installation position,
mark installation hole of the base with
pencil.
4. Bore two installation holes on the mark
with a 5mm drill bit. Insert the two plastic
plugs into holes with a hammer.
5. Attach the base to the plastic plugs and
fix tightly the screws (3.9*25mm) into the
plastic plugs.
6. Strip the Live, Neutral and Interconnect
wires back to the recommended strip
length (refer to diagram on the right)
7. Connect the external live wire, neutral wire
and interconnection wire to the terminal of
the base, and ensure the terminal screws
are fully tightened.
8. Fit the alarm on the base.
List of material:
Base x 1
Screw 3.9*25mm x 2
Plastic plugs x 2
Bubble bags x 1
Installation manual x 1
Diagram 2
Near the
triangle
mark
Diagram 3

This product should be installed only by a licensed, qualified
electrician.
Observe and follow all local and national electrical and building
codes for installation.
Isolate from mains power prior to wiring.
Use a minimum of 0.8mm2250V insulated wire for all wiring,
including signal wire.
WARNING:
WARNING: Improper wiring may result in damage to the
alarm, failure to operate, or a shock hazard. Do not connect white
interconnection wire to L or N.
Wiring mode:
Before connecting the power cord, please pay attention to the label
indication next to the terminal, and then connect to the L, N, and I line
according to the instructions (see Diagram 3).
L --- Live wire of AC line
N --- Neutral wire of AC line
I --- I/O interconnection line
E ---Earth
Installation:
3.Align the raised Arrow
markings and clickthe smoke
alarminto the base.
2.Fix the base on ceiling with
screws and plastic plugs
1. Connect the L, N,
and I lines to the base
4. To remove, use a flat
screwdriver to gently lever each
of the three tabsopen.
