Emerson NetSure 501 A50 User manual

NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51
19-Inch Subrack Power Supply System
User anual
Version V1.0
Revision date June 13, 2008
BOM 31011680
Emerson Network ower provides customers with technical support. Users may contact the nearest
Emerson local sales office or service center.
Copyright © 2008 by Emerson Network ower Co., Ltd.
All rights reserved. The contents in this document are subject to change without notice.
Emerson Network ower Co., Ltd.
Address: No.1 Kefa Rd., Science & Industry ark, Nanshan District 518057, Shenzhen China
Homepage: www.emersonnetworkpower.com.cn
E-mail: [email protected]

Safety recautions
To reduce the chance of accident, please read the safety precautions very carefully before operation. The
"Caution, Notice, Warning, Danger" in this book do not represent all the safety points to be observed, and are
only supplement to various safety points. Therefore, the installation and operation personnel must be strictly
trained and master the correct operations and all the safety points before actual operation.
When operating Emerson products, the safety rules in the industry, the general safety points and special safety
instructions specified in this book must be strictly observed.
Electrical Safety
I. Hazardous voltage
Danger
Danger
Some components of the power system carry hazardous voltage in operation. Direct contact or indirect contact through
moist objects with these components will result in fatal injury.
Safety rules in the industry must be observed when installing the power system. The installation personnel must
be licensed to operate high voltage and AC power.
In operation, the installation personnel are not allowed to wear conductive objects such as watches, bracelets,
bangles, rings.
When water or moisture is found on the Subrack, turn off the power immediately. In moist environment,
precautions must be taken to keep moisture out of the power system.
" rohibit" warning label must be attached to the switches and buttons that are not permitted to operate during
installation.
Danger
Danger
High voltage operation may cause fire and electric shock. The connection and wiring of A cables must be in compliance
with the local rules and regulations. Only those who are licensed to operate high voltage and A power can perform high
voltage operations.
II. Tools
Warning
Warning
In high voltage and A operation, special tools must be used. No common or self-carried tools should be used.
III. Thunderstorm
Danger
Danger
Never operate on high voltage, A , iron tower or mast in the thunderstorm.
In thunderstorms, a strong electromagnetic field will be generated in the air. Therefore the equipment should be
well earthed in time to avoid damage by lightning strikes.
IV. ESD

Notice
Notice
The static electricity generated by the human body will damage the static sensitive elements on P Bs, such as large-scale
I s. Before touching any plug-in board, P B or I chip, ESD wrist strap must be worn to prevent body static from
damaging the sensitive components. The other end of the ESD wrist strap must be well earthed.
V. Short circuit
Danger
Danger
During operation, never short the positive and negative poles of the D distribution unit of the system or the non-grounding
pole and the earth. The power system is a constant voltage D power equipment, short circuit will result in equipment
burning and endanger human safety.
Check carefully the polarity of the cable and connection terminal when performing DC live operations.
As the operation space in the DC distribution unit is very tight, please carefully select the operation space.
Never wear a watch, bracelet, bangle, ring, or other conductive objects during operation.
Insulated tools must be used.
In live operation, keep the arm muscle tense, so that when tool connection is loosened, the free movement of
the human body and tool is reduced to a minimum.
Battery
Danger
Danger
Before any operation on battery, read carefully the safety precautions for battery transportation and the correct battery
connection method.
Non-standard operation on the battery will cause danger. In operation, precautions should be taken to prevent
battery short circuit and overflow of electrolyte. The overflow of electrolyte will erode the metal objects and
CBs, thus causing equipment damage and short circuit of CBs.
Before any operation on battery, pay attention to the following points:
Remove the watch, bracelet, bangle, ring, and other metal objects on the wrist.
Use special insulated tools.
Use eye protection device, and take preventive measures.
Wear rubber gloves and apron to guard against electrolyte overflow.
In battery transportation, the electrode of the battery should always be kept facing upward. Never put the battery
upside down or slanted.
BLVD
The system has battery low voltage disconnection (BLVD) function. BLVD means when the mains fail and
batteries supply power, the monitoring module cuts the load off when the battery voltage drops down to below
43.2V to prevent over-discharge. The BLVD voltage is settable. Refer to 4.7.2 Battery Selection, 5.3.6Settings,
or 6.7.3Battery Settings for setting method.
The factory setting is enabling BLVD, which means that if power outage lasts for a long time or the power supply
system fails, there might be BLVD. Users should classify the loads and connect the priority loads to BLVD
routes. For vital loads, users can disable BLVD of these loads to insure reliability of the power supply.

The method of disabling BLVD is:
Set “BLVD Enable” item of the monitoring module to “N”. Refer to 4.7.3LVD Parameter Description, 5.5.2Battery
Management Parameters or 6.7.3Battery Settings for setting method.
Notice
Notice
The advantage of enabling BLVD is protecting the batteries from over-discharge when the battery voltage is low. The
disadvantage of enabling BLVD is that when the battery voltage drops down to a certain value, all the loads (including non-
priority loads and priority loads) will be cut off due to battery disconnection.
The advantage of software disabling BLVD is prolonging the power supply of priority loads. The disadvantage is that
software disabling cannot prevent unwanted power failure due to misoperation or power supply system failure.
Others
I. Sharp object
Warning
Warning
When moving equipment by hand, protective gloves should be worn to avoid injury by sharp object.
II. Cable connection
Notice
Notice
Please verify the compliance of the cable and cable label with the actual installation prior to cable connection.
III. Binding the signal lines
Notice
Notice
The signal lines should be bound separately from heavy current and high voltage lines, with binding interval of at least
150mm.

Contents
Chapter 1 Overview.............................................................................................................................................................. 1
1.1 Model Information................................................................................................................................................... 1
1.2 Composition And Configuration..............................................................................................................................1
1.3 Features................................................................................................................................................................. 3
Chapter 2 Installation Instruction.......................................................................................................................................... 4
2.1 Safety Regulations................................................................................................................................................. 4
2.2 reparation............................................................................................................................................................. 4
2.3 Mechanical Installation........................................................................................................................................... 5
2.4 Electrical Installation............................................................................................................................................... 6
2.4.1 Connecting ower Cables........................................................................................................................... 6
2.4.2 Connecting Signal Cables...........................................................................................................................7
Chapter 3 Installation Testing..............................................................................................................................................11
3.1 Installation Check And Startup..............................................................................................................................11
3.2 Basic Settings....................................................................................................................................................... 11
3.3 Alarm Check And System Operation Status Check..............................................................................................12
3.4 Final Steps............................................................................................................................................................ 13
Chapter 4 Use Of Monitoring Module M500D.....................................................................................................................14
4.1 Front anel........................................................................................................................................................... 14
4.2 ower On Order................................................................................................................................................... 14
4.3 Querying System Status....................................................................................................................................... 16
4.3.1 First age Of System Information.............................................................................................................16
4.3.2 Other System Information ages..............................................................................................................16
4.4 Querying Rectifier Status...................................................................................................................................... 18
4.5 Querying Alarms And Setting Alarm lans...........................................................................................................18
4.5.1 Querying Active Alarm............................................................................................................................... 18
4.5.2 Querying Alarm History............................................................................................................................. 19
4.5.3 Alarm Type Table.......................................................................................................................................20
4.5.4 Changing Audible/Visual Alarm And Alarm Call Back lan.......................................................................22
4.5.5 Changing Alarm Types Of Dry Contacts....................................................................................................22
4.6 Maintenance......................................................................................................................................................... 22
4.7 Setting System arameters.................................................................................................................................. 23
4.7.1 arameter Setting Method........................................................................................................................ 24
4.7.2 Battery Selection....................................................................................................................................... 25
4.7.3 LVD arameter Description.......................................................................................................................26
4.7.4 Charging Management arameters..........................................................................................................27
4.7.5 Battery Test arameters............................................................................................................................28
4.7.6 Temperature Compensation Coefficient arameters................................................................................29

4.7.7 AC Settings............................................................................................................................................... 30
4.7.8 DC Settings............................................................................................................................................... 31
4.7.9 Rectifier Settings....................................................................................................................................... 31
4.7.10 System Settings...................................................................................................................................... 32
4.7.11 Alarm Settings......................................................................................................................................... 34
Chapter 5 Use Of Monitoring Module M800D.....................................................................................................................36
5.1 Operation anel.................................................................................................................................................... 36
5.2 Use Of The Operation anel................................................................................................................................ 37
5.2.1 Main Screen.............................................................................................................................................. 37
5.2.2 Main Menu................................................................................................................................................ 37
5.2.3 Running Information.................................................................................................................................. 37
5.2.4 Maintain..................................................................................................................................................... 40
5.2.5 arameter Set........................................................................................................................................... 41
5.3 Access M800D Through Web...............................................................................................................................44
5.3.1 Overview Of Web Function.......................................................................................................................44
5.3.2 Login......................................................................................................................................................... 44
5.3.3 Homepage Introduction.............................................................................................................................46
5.3.4 Device Explore.......................................................................................................................................... 47
5.3.5 Alarms....................................................................................................................................................... 55
5.3.6 Settings..................................................................................................................................................... 57
5.3.7 Maintenance.............................................................................................................................................. 63
5.3.8 Query........................................................................................................................................................ 72
5.4 Access M800D Through NMS.............................................................................................................................. 75
1.1.1 NMS Supported By SNM Agent..............................................................................................................75
5.4.1 MIB Installation.......................................................................................................................................... 75
5.4.2 Access M800D through NMS.................................................................................................................... 77
5.5 arameter Setting Guidance................................................................................................................................ 77
5.5.1 Rectifier arameters................................................................................................................................. 77
5.5.2 Battery Management arameters............................................................................................................. 77
5.5.3 Energy Management arameters............................................................................................................. 80
5.5.4 Diesel Management arameters...............................................................................................................81
5.5.5 ower Split arameters............................................................................................................................ 81
Chapter 6 Use Of Monitoring Module M501D.....................................................................................................................82
6.1 Front anel........................................................................................................................................................... 82
6.2 ower On Order................................................................................................................................................... 82
6.3 Querying System Status....................................................................................................................................... 84
6.3.1 First age Of System Information.............................................................................................................84
6.3.2 Other System Information ages..............................................................................................................84
6.4 Querying Rectifier Status...................................................................................................................................... 85
6.5 Querying And Handling Alarms.............................................................................................................................86
6.5.1 Querying Active Alarm............................................................................................................................... 86

6.5.2 Querying Alarm History............................................................................................................................. 87
6.5.3 Changing Audio/Video Alarm And Alarm Callback....................................................................................87
6.5.4 Change Alarm Types Of Dry Contacts......................................................................................................88
6.5.5 rogrammable Setting On The Dry Contact Output Alarm Type...............................................................88
6.6 Maintenance......................................................................................................................................................... 89
6.7 Setting System arameters.................................................................................................................................. 90
6.7.1 arameter Setting Method........................................................................................................................ 90
6.7.2 Alarm Settings........................................................................................................................................... 91
6.7.3 Battery Settings......................................................................................................................................... 94
6.7.4 AC Settings............................................................................................................................................. 100
6.7.5 DC Settings............................................................................................................................................. 101
6.7.6 Rectifier Settings..................................................................................................................................... 101
6.7.7 System Settings......................................................................................................................................102
Chapter 7 Alarm Handling................................................................................................................................................. 106
7.1 Handling Alarms................................................................................................................................................. 106
7.2 Handling Rectifier Fault...................................................................................................................................... 107
Appendix 1 Technical And Engineering Data....................................................................................................................110
Appendix 2 Wiring Diagram............................................................................................................................................... 114
Appendix 3 Schematic Diagram........................................................................................................................................ 116
Appendix 4 Glossary......................................................................................................................................................... 122

Chapter 1 Overview 1
Chapter 1 Overview
This chapter introduces model description, composition and configuration, and features.
The “system” in this manual refers to the S48150-3B/1800 (NetSure 501 A50) (abbreviated as “NetSure 501 A50”),
S48300-3C/1800 (NetSure 501 AA0) (abbreviated as “NetSure 501 AA0”) and S48300-3A/3200 (NetSure 701
A51) & S48300-3A/3200-X2 (NetSure 701 A51) (abbreviated as “NetSure 701 A51”) power supply system.
1.1 Model Information
Take S48150-3B/1800 (NetSure 501 A50) power supply system as an example, the model description is given in
Figure 1-1 and Figure 1-2.
150 1800S 48 /
Rated output current: 150A
Rated output power of the rectifier: 1800W
Rated output voltage: -48V
ower supply system
-3B
Version
Fig re 1.1 Model information (1)
NetSure 501 A 5 0
Version
Region. A: Asia- acific region.
The number of the rectifier in the typical power supply system: 5. If the number ranges between
0 ~ 9, the character is represented by a number. If the number is larger than 9, the character is
represented by a letter, for example, A represents the number 10, B represents the number 11,
and so on.
Output power of the rectifier. 501: 1800W. 701: 3200W.
Brand name of the power supply system.
Fig re 1.2 Model information (2)
1.2 Composition And Configuration
System composition
The system consists of power distribution parts, rectifiers and monitoring module. The rectifier model is R48-1800,
R48-2900U or R48-3200 and the model of the monitoring module is M501D or M500D. The internal structures of the
systems are shown in Figure 1-3 to Figure 1-6.
Rectifier
Battery MCB
ositive terminals
Monitoring module
Load MCB
AC input MCB
Dummy plate
Fig re 1.1 NetS re 501 A50 system str ct re
NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51 19-Inch Subrack ower Supply System User Manual

2 Chapter 1 Overview
Dummy plate
AC input MCB
Load MCB
Load MCB
Rectifier
Battery MCB
Monitoring module
ositive terminals
ositive terminals
Fig re 1.2 NetS re 501 AA0 system str ct re
Dummy plate
AC input MCB
Load MCB
Load MCB
Rectifier
Battery MCB
Monitoring module
ositive terminals
ositive terminals
Fig re 1.3 NetS re 701 A51 (PS48300-3A/3200) system str ct re
Battery MCB
ositive terminals
Monitoring module
Load MCB
AC input MCB
Dummy plate
Rectifier
Fig re 1.4 NetS re 701 A51 (PS48300-3A/3200-X2) system str ct re
System configuration
The configurations of the power supply system are described in Table 1-1.
NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51 19-Inch Subrack ower Supply System User Manual

Chapter 1 Overview 3
Table 1.2 Config ration of fixed- config ration system
Item NetSure 501 A50 NetSure 501 AA0 NetSure 701 A51
( S48300-3A/3200)
NetSure 701 A51
( S48300-3A/3200-X2)
Monitoring module Model: M501D Model: M501D Model: M501D Model: M500D
Rectifier
Model: R48-1800.
Standard configuration:
5 pieces
Model: R48-1800.
Standard configuration:
10 pieces
Model: R48-3200.
Standard configuration:
5 pieces
Model: R48-2900U.
Standard configuration: 3
pieces
AC power distribution 3 + N + E/ 380Vac 3 + N + E/ 380Vac 3 + N + E/ 380Vac + N + E/ 230Vac
DC power distribution
BLVD load route: 3 ×
63A/1 , 3 × 32A/1 , 4 ×
10A/1 MCB
No LLVD load route
BLVD load route: 5 ×
63A/1 , 5 × 32A/1 , 8 ×
10A/1 MCB
No LLVD load route
BLVD load route: 5 ×
63A/1 , 5 × 32A/1 , 8 ×
10A/1 MCB
No LLVD load route
BLVD load route: 4 ×
40A/1 , 1 × 10A/1 MCB
No LLVD load route
Battery MCB 2 × 125A/1 2 × 125A/1 2 × 125A/1 2 × 125A/1
Maximum dimensions 483 (W) × 380 (D) × 267
(H)
483 (W) × 380 (D) × 490
(H)
483 (W) × 380 (D) × 445
(H)
483 (W) × 380 (D) × 311
(H)
Weight
25kg (not including
rectifiers and monitoring
module)
30kg (not including
rectifiers and monitoring
module)
25kg (not including
rectifiers and monitoring
module)
25kg (not including
rectifiers and monitoring
module)
Optional parts Temperature sensor and connected cables, remote monitoring unit, battery rack
1.3 Features
The rectifier uses the active ower Factor Compensation ( FC) technology, raising the power factor to 0.99
Wide AC input voltage range: 85V ~ 290V (NetSure 701 A51) or 85Vac ~ 300Vac (NetSure 501 A50 & NetSure
501 AA0)
The rectifier uses soft switching technology, raising the system efficiency to 89% (R48-1800)/ 90% (R48-3200)
Ultra-low radiation. With advanced EMC design, the rectifier meets international standards such as CE and
NEBS. Both the conducted and radiated interference reach Class B
The rectifier safety design complies with UL, CE and NEBS standards
High power density
Rectifiers are hot pluggable. It takes less than 1min to replace a rectifier
Two over-voltage protection methods are optional: hardware protection and software protection. The latter one
also has two optional modes: lock-out at the first over-voltage and lock-out at the second over-voltage
erfect battery management: The management functions include the LLVD (optional), BLVD, temperature
compensation, auto voltage regulation, stepless current limiting, battery capacity calculation and on-line battery
test, etc
Up to 200 pieces of historical alarm records, and 10 sets of battery test data records
Network design: roviding multiple communication ports (such as RS232, modem, RJ45 and dry contacts),
which enables flexible networking and remote monitoring
erfect lightning protection at AC side
Complete fault protection and fault alarm functions
NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51 19-Inch Subrack ower Supply System User Manual

4 Chapter 2 Installation Instruction
Chapter 2 Installation Instruction
This chapter introduces installation and cable connection. Before installation, please read through safety regulations,
and then follow this instruction to carry out the installation step by step.
2.1 Safety Regulations
Certain components in this power system have hazardous voltage and current. Always follow the instructions below:
1. Only the adequately trained personnel with satisfactory knowledge of the power system can carry out the
installation. The most recent revision of these safety rules and local safety rules in force shall be adhered to during
the installation.
2. All external circuits that are below 48V and connected to the power system must comply with the requirements of
SELV as defined in IEC 60950.
3. Make sure that the power (mains and battery) to the system is cut off before any operations can be carried out
within the system subrack.
4. The power subracks shall be kept locked and placed in a locked room. The key keeper should be the one
responsible for the power system.
5. The wiring of the power distribution cables should be arranged carefully so that the cables are kept away from the
maintenance personnel.
2.2 reparation
Unpacking inspection
The equipment should be unpacked and inspected after it arrives at the installation site. The inspection shall be done
by representatives of both the user and Emerson Network ower Co., Ltd.
To inspect the equipment, you should:
1. Open the packing case in which the packing list is put.
2. Take out the packing list.
3. Check against the packing label, including customer name, customer address, machine No., total amount, case
No., contract No.
Unpacking and inspection: After opening the packing case, check the goods one by one according to the goods list
on the packing label. The checking should include:
1. The number of the packing cases and the serial number marked on them.
2. The correctness of the equipment packing according to the packing list.
3. The number and model of the accessories according to the accessory list.
4. The completeness of the equipment set according to the system configuration.
5. The condition of the goods through visual inspection. For example, check the subrack for any damage and
condensation. Shake the rectifier module gently to see if any component or connection has loosened during
transportation.
Cables
The cable design should meet relevant industry standards.
It is recommended to use the RVVZ cables as AC cables. The cable should reach at least +70°C temperature
durability. With cable length shorter than 30 meters, the Cross-Sectional Area (CSA) calculation should be based on
the current density of 2.5A/mm2. The suggested CSA value is no less than 25mm2.
The CSA of DC cable depends on the current flowing through the cable and the allowable voltage drop. To select the
battery cable CSA, see Table 2-1. Select the DC load cable CSA according to the Table 2-2:
NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51 19-Inch Subrack ower Supply System User Manual

Chapter 2 Installation Instruction 5
Table 1.1 Battery cable CSA selection
Battery MCB rated current Max. battery current Min. cable CSA Max. cable length (allowable voltage drop: 0.5V)
125A 100A 25mm214m
Note:
1. The specs are applicable at ambient temperature of 25°C. If the temperature is higher or lower than this, the CSA of the cable
should be increased.
2. The battery cable should reach at least +90°C heat durability. It is recommended to use double-insulated copper-core flame
retardant cable as battery cable
Table 1.2 DC load cable selection
Load route rated
current
Max. output
current
Min. cable
CSA
Max. cable length (volt drop:
0.5V, with min. CSA) Max. cable CSA Max. cable length (volt drop: 0.5V, with max. CSA)
63A 32A 16mm27m 25mm211m
32A 16A 16mm214m 25mm222m
10A 5A 6mm217m 25mm271m
Note:
The specs are applicable at ambient temperature of 25°C. If the temperature is higher or lower than this, the CSA of the cable
should be increased
The MCB capacity should be strictly limited so that it can function properly upon load over-current. The
recommended MCB capacity is 1.5 ~ 2 times larger than the load peak capacity.
The CSA of the system earth cable should be consistent with that of the maximum power distribution cable and no
less than 35mm2.
2.3 Mechanical Installation
For the convenience of maintenance, users should maintain a clearance of 800mm at the front of the power supply
system.
Insert the power supply system into the cabinet. Install the screws in the four installation holes as shown in Figure 2-1
to Figure 2-4 with a hillips screwdriver.
466
483
266
Fig re 1.1 Installation size of NetS re 501 A50 ( nit: mm)
490
483
466.8
Fig re 1.2 Installation size of NetS re 501 AA0 ( nit: mm)
NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51 19-Inch Subrack ower Supply System User Manual

6 Chapter 2 Installation Instruction
483
466
445
Fig re 1.3 Installation size of NetS re 701 A51 (PS48300-3A/3200) ( nit: mm)
465.5
483.0
311
Fig re 1.4 Installation size of NetS re 701 A51 (PS48300-3A/3200-X2) ( nit: mm)
2.4 Electrical Installation
2.4.1 Connecting ower Cables
Connecting AC input cables
Danger
1. Switch off all M Bs before the electrical connection.
2. Only the qualified personnel can do the mains cable connection.
Feed all the cables into the subrack from top of the subrack. Take the NetSure 701 A51 power supply system as an
example, the position of the connection terminals are shown in Figure 2-5. Connect the AC input cables to the AC
input MCB.
NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51 19-Inch Subrack ower Supply System User Manual

Chapter 2 Installation Instruction 7
AC input MCB
Load MCB
Load MCB Battery MCB
ositive terminals
ositive terminals
Fig re 1.1 MCB and terminal positions
Connecting load cables
Connect the negative cable of the load to the upper terminal of load MCB. Connect the positive cable of the load to
the DC positive busbar. The terminals are as shown in Figure 2-5.
Connecting battery cables
1. Note
1. The batteries may have dangerous current. Before connecting the battery cables, the corresponding battery input M Bs or the
battery cell connector must be disconnected to avoid live state of the power system after installation.
2. Be careful not to reverse connect the battery. Otherwise, both the battery and the power system will be damaged!
1. Connect one end of the negative battery cable to the upper terminal of battery MCBs. Connect one end of the
positive battery cable to the DC positive bus bar.
2. Connect copper lugs to the other end of the battery cables. Bind the connecting parts with insulating tape, and put
them beside the battery. Connect the cables to the battery when the DC distribution unit is to be tested.
2.4.2 Connecting Signal Cables
S6415X2 user connector board cable connection
Take the NetSure 501 A50 power supply system as an example, the position of the user connector board is shown in
Figure 2-6. Two communication interfaces are located in the panel: Ethernet and RS232 interface. The power supply
system can be connected to Ethernet through the Ethernet interface or connected to modem through RS232
interface.
Monitoring module
Network port RS232 interface
S6415X2 user
connector board
Fig re 1.1 User connector board position
The interfaces of the signal transfer board are shown in Figure 2-7. The functions of the interfaces are shown in Table
2-3.
NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51 19-Inch Subrack ower Supply System User Manual

8 Chapter 2 Installation Instruction
Fig re 1.2 S6415X2 interface
Table 1.2 Interface f nctions
Connector in Signal name Mark number Logic relation
J3
1 Relay output 1 normal close DO1_NC
2 Relay output 2 normal close DO2_NC
3 Relay output 1 common DO1_COM
4 Relay output 2 common DO2_COM
5 Relay output 1 normal open DO1_NO
6 Relay output 2 normal open DO2_NO
J4
1 Relay output 3 normal close DO3_NC
2 Relay output 4 normal close DO4_NC
3 Relay output 3 common DO3_COM
4 Relay output 4 common DO4_COM
5 Relay output 3 normal open DO3_NO
6 Relay output 4 normal open DO4_NO
J5 1 Relay output 5 normal close DO5_NC
2 Relay output 6 normal close DO6_NC
3 Relay output 5 common DO5_COM
4 Relay output 6 common DO6_COM
5 Relay output 5 normal open DO5_NO
NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51 19-Inch Subrack ower Supply System User Manual

Chapter 2 Installation Instruction 9
Connector in Signal name Mark number Logic relation
6 Relay output 6 normal open DO6_NO
J6
1 Relay output 7 normal close DO7_NC
2 Relay output 8 normal close DO8_NC
3 Relay output 7 common DO7_COM
4 Relay output 8 common DO8_COM
5 Relay output 7 normal open DO7_NO
6 Relay output 8 normal open DO8_NO
J10
1 Digital circuits power +5V
2 Temperature signal 1 input TEM 1 4~20mA
3 Analog ground GND
J11
1 Digital circuits power +5V
2 Temperature signal 2 input TEM 2 4~20mA
3 Analog ground GND
J12, J18
1 Data Carrier Detect DCD232
2 Receive Data RXD232
3 Transmit Data TXD232
4 Data Terminal Ready DTR232
5 Data Communication ground DGND
6 Empty
7 Request To Send RTS232
8,9 Empty
J13
1 Ethernet TX+ NETTX+
2 Ethernet TX- NETTX-
3 Ethernet TR+ NETTR+
4 Empty
5 Empty
6 Ethernet TR- NETTR-
7~12 Empty
J14
1 RS485 communication+ E485+
2 RS485 communication- E485-
3 rotection ground GNG
J19 1 48V+ OWER+
2 48V- OWER-
odem cable connection
Modem is an optional accessory, suitable for those who have purchased the modem remote monitoring system.
Modem configuration:
In modem mode, "Y" should be selected for the communication parameter "MODEM" of the monitoring module. If
modem has the Automatic Answer indicator (AA), the indicator will turn on once modem and monitoring module are
powered on. In the modem mode, the monitoring module will initialize modem upon power-on, reset or upon
communication interruptions that last more than one hour.
NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51 19-Inch Subrack ower Supply System User Manual

10 Chapter 3 Installation Testing
Chapter 3 Installation Testing
This chapter introduces procedures of installation testing. The corresponding safety rules shall be adhered to in the
test.
3.1 Installation Check And Startup
Before the test, inform the chief manufacturer representative. Only trained electrical engineer can maintain and
operate this equipment. In operation, the installation personnel are not allowed to wear conductive objects such as
watches, bracelets, bangles and rings.
During operation, parts of this equipment carry hazardous voltage. Misoperation can result in severe or fatal injuries
and property damage. Before the test, check the equipment to ensure the proper earthing. Installation check must be
done before testing. Then the batteries can be charged for the first time.
Make sure that the AC input MCBs, battery MCBs and load MCBs are switched off. Make sure that all the devices are
properly installed.
Installation check
OK Comments
Check all the MCBs and cables. Are their models correct? 
Check the bus bar connections, input and output cable connection, and connection between the power
system and the system grounding. 
Check the if the number and connections of the batteris are correct. Check the polarity of the battery string
with a voltmeter. 
Make sure all the cable connections are firm and reliable. 
Startup preparations
OK Comments
Make sure that all the MCB are switched off. 
Measure the AC input voltage. Make sure the input voltage is within the allowable range. Umin=___V
Check that the communication and alarm cables are connected to the signal transfer board. 
Check that the temperature sensor, if any, has been installed. 
Check that the battery string circuit is not closed. 
Connect the disconnected batteries to the battery string circuit 
Measure with a voltmeter across the connection points of each battery and make sure that the polarity is
right. For a lead-acid battery with 24 cells, the voltmeter should read 2.0-2.1V/cell or 48-51V/battery. If the
voltage of certain cell is lower than 2.0V, that cell must be replaced.
Umin=___V
Check with an ohmmeter that there is no short circuit between the positive & negative distribution bus
bars, or between the positive & negative battery poles
(Note: ull out all modules before the check and restore them after the check)

Startup
OK Comments
Switch on the system AC input MCB. The green LED on the rectifier will be on and the fan will start running
after a certain delay. The monitoring module will show that the power supply voltage is 53.5V.

Check the system voltage and busbar polarity with a voltmeter. The voltage difference between the
measured value and displayed value should be less than  0.2V.

Start and stop each rectifier of the system by unplugging and inserting each rectifier. Check their output
voltages.

3.2 Basic Settings
When the system is put into service for the first time, the parameters of monitoring module must be set based on the
actual system configuration, such as battery number, capacity, user’s charge current limit and other functional
requirements. Only after that can the monitoring module display system operation information and control the output.
For monitoring module parameter setting method, see 4.7Setting System Parameters if using M500D.
5.2.5Parameter Set if using M800D. See 5.7 Setting System Parameters if using M501D.
NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51 19-Inch Subrack ower Supply System User Manual

Chapter 3 Installation Testing 11
OK Comments
The system model has been set correctly in factory before delivery, check that the setting agrees with
the actual system (NetSure 501 A50: 48V/30A/SET/NONE; NetSure 701 A51 ( S48300-3A/3200):
48V/50A/300/ NONE; NetSure 701 A51 ( S48300-3A/3200-X2): 48V/50A/SET/NONE; NetSure 501
AA0: 48V/30A/300/NONE).

The battery string number set at the monitoring module should be the same as the number actually
connected. (By default: 2)

Set the battery capacity according to the actual capacity of the battery connected to the system.
Default: 300Ah.

Configure the temperature coefficient according to the battery manufacturer’s requirement. Setting
range: 0-500mV/°C. By default: 72mV/°C. (if no temperature sensor is installed, do not set this
parameter)

Set the charge current limit according to your needs. Setting range: 0.1~0.25C10. (By default: 0.1C10)
Set the monitoring module according to the voltage suggested by the battery supplier.
Floating Charge (FC) voltage range: 42V ~ Boost Charge (BC) voltage. Default: 53.5V.
BC voltage range: FC voltage ~ 58V. By default: 56.4V.
For batteries that do not need BC, set the BC voltage to FC voltage plus 0.1V.

ut through the battery MCBs and connect the batteries. 
3.3 Alarm Check And System Operation Status Check
Alarm check
Check that all functional units can trigger alarms that can be displayed on the monitoring module.
OK Comments
ull out one rectifier. The “Rect N Com Failure” alarm should be triggered. Insert the rectifier in. The
alarm should disappear. Repeat the same procedures on other rectifiers.

Remove battery MCB 1. The “Batt1 Failure” alarm should be triggered. ut on the MCB. The alarm
should be cleared. Repeat the same on battery MCB 2.

Switch off a load MCB connected to a load route. The alarm “Load N Failure” should be triggered.
Switch on the MCB, and the alarm should be cleared. Repeat the same on the other load MCBs.

Remove all the battery input MCBs. Keep only one rectifier in operation. Through the monitoring
module, adjust the rectifier FC voltage to make it lower than the alarm point. The alarm “DC Voltage
Low” should be triggered.

Keep the rectifiers in operation. Set through the monitoring module the battery management
parameter to “Manual”. Enter the maintenance menu at the monitoring module. Select “Disconnect”
and confirm it. The battery protection contactor should be open, and the “BLVD” alarm should be
displayed at the monitoring module.

Note: when the preceding alarms are generated, the monitoring module will give alarms after approximately 3s. Refer to
4.5Q erying Alarms And Setting Alarm Plans, 5.2.3R nning Information or 6.5Q erying And Handling Alarms for methods of
querying alarms.
System operation status check
There should be no alarms during normal system operation. The system operation status check can be conducted
through the monitoring module.
For the parameter query method, refer to 4.3Q erying System Stat s if using M500D. 5.2.3R nning Information if
using M800D. Refer to 6.3 Q erying System Stat s and 6.4 Q erying Rectifier Stat s if using M501D.
OK Comments
The system model is NetSure 501 A50: 48V/30A/SET/NONE; NetSure 701 A51 ( S48300-3A/3200):
48V/50A/300/ NONE; NetSure 701 A51 ( S48300-3A/3200-X2): 48V/50A/SET/NONE; NetSure 501
AA0: 48V/30A/300/NONE
The monitoring module should display the correct AC voltage. 
The monitoring module should be able to display the DC voltage. The difference between the
displayed voltage and that measured at the bus bar should be less than 1%.

The monitoring module should display the battery current. The difference between the displayed and
measured battery current should be less than 1%.

Check the number of the rectifier through the monitoring module. The number should be consistent
with the actual number.

NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51 19-Inch Subrack ower Supply System User Manual

12 Chapter 3 Installation Testing
OK Comments
Check the voltage, current, current limiting point of rectifiers through the monitoring module. They
should agree with the actual parameters.

For the system configured with temperature sensor, the monitoring module should be able to display
the battery ambient temperature. Hold the probe of the temperature sensor with hand and watch the
monitoring module, which should diplay the change of temperature.

3.4 Final Steps
OK Comments
Disconnect all test equipment from the system and make sure that materials irrelevant to the equipment
have been all removed.

Restore the equipment to its original condition and close the cabinet door. 
Check and handover the equipment that the user has purchased. 
Note down all the operations taken, including time of the operation and name of the operator. 
If any defect is found in this equipment, inform the personnel responsible for the contract.
If repairing is needed, please fill in the FAILURE RE ORT and send the report together with the defective unit to the
repairing center for fault analysis.
NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51 19-Inch Subrack ower Supply System User Manual

Chapter 4 Use Of Monitoring Module M500D 13
Chapter 4 Use Of onitoring odule 500D
This chapter introduces the front panel and functional keys briefly, and expounds screen contents, access method,
system controlling, information querying and parameter setting.
After the monitoring module is powered on, the language selection screen will pop up, and the monitoring module is
initialized. The default language is Chinese. After the initialization, the first system information page will appear.
4.1 Front anel
There are backlit LCD display, functional keypad, indicators and positioning pin on the front panel of M500D
monitoring module, as shown in the following figure:
Alarm indicator
Run indicator
Critical alarm indicator
LCD
Functional keys
Handle
ESC
M500D
ENT
Fig re 1.1 Front panel of M500D monitoring mod le
Description of the indicators on the front panel is in the following table:
Table 1.2 Monitoring mod le indicator description
Indicator Normal state Fault state Fault cause
Run (green) On Off No operation power supply
Alarm (yellow) Off On There are observation alarms
Critical alarm (red) Off On There are major or critical alarm
M500D monitoring module uses a 128 × 64 LCD, a keypad with 6 keys. The interface language is Chinese/English
optional.
Table 1.3 Description of monitoring mod le keypad
Key Function
ESC Return to the upper level menu
ENT Enter the main menu or confirm the menu operation
“▲” and “▼” Shift among parallel menus. For a character string, these 2 keys can be used to shift among different options
““ and ““ Change values at a value setting interface. For a character string, these 2 keys can move the cursor left or right
4.2 ower On Order
After the system is powered on for the first time, you should set the system type according to the actual configuration.
The monitoring module will restart after the system type is changed. In that case, you should re-configure those
parameters whose default values are inconsistent with the actual situation. Only after that can the monitoring module
operate normally.
After configuring the system parameters, you can carry out various operations directly without resetting the parameter
values. As for those important parameters related to battery management, such as BLVD, you should be fully aware
of their influence upon the system before you change their values.
NetSure 501 A50, NetSure 501 AA0, NetSure 701 A51 19-Inch Subrack ower Supply System User Manual
