Emerson RIDGID FT-103 User manual

A-Frame Fault Locator
Model FT-103 Transmitter and
Model FR-30 Receiver
•Français – 15
•Castellano – pág. 33
A-Frame Operator’s Manual

ii 999-995-095.10_REV. A
A-Frame Fault Locator
T ble of Contents
Recording Form for Machine Serial Number .....................................................................1
Safety Symbols.....................................................................................................................2
General Safety Rules
Work Area Safety...............................................................................................................2
Electrical Safety.................................................................................................................2
Personal Safety .................................................................................................................2
Equipment Use and Care ..................................................................................................2
Service ..............................................................................................................................3
Specific Safety Information
A-Frame Fault Locator Safety............................................................................................3
RIDGID Contact Information................................................................................................4
Description............................................................................................................................4
Transmitter.........................................................................................................................4
Receiver ............................................................................................................................5
Specifications .......................................................................................................................5
Standard Equipment..........................................................................................................6
Changing/Installing Batteries..............................................................................................6
Transmitter.........................................................................................................................7
Receiver (A-Frame) ...........................................................................................................7
Pre-Operation Inspection ....................................................................................................7
Set-Up And Operation Instructions ....................................................................................7
Fault ocating
Connecting Transmitter......................................................................................................8
Locating.............................................................................................................................9
Locating Below Paved Surfaces ......................................................................................10
Multiple Faults..................................................................................................................11
Path ocating
Direct Connect Path Locating Method .............................................................................11
Inductive Clamp Path Locating........................................................................................12
Broadcast Inductive Path Locating ..................................................................................12
Storage ................................................................................................................................13
Maintenance
Cleaning ..........................................................................................................................13
Calibration .......................................................................................................................13
Service And Repair..........................................................................................................13
Optional Equipment ...........................................................................................................14
Disposal ..............................................................................................................................14
Battery Disposal ..............................................................................................................14
EC Declaration of Conformity............................................................................................14
FCC Statement....................................................................................................................14
Electromagnetic Compatibility (EMC) ..............................................................................14
ifetime Warranty .................................................................................................Back Cover
*Original Instructions - English

A-Fr me F ult Loc tor
Model FT-103 Tr nsmitter nd
Model FR-30 Receiver
A-Frame Fault ocator
A-Frame Fault Locator
Record Serial umber below and retain product serial number which is located on nameplate.
Serial
o.
WARNING!
Read this Operator’s Man ual
carefully before usin this
tool. Failure to understand
and follow the contents of this
manual may result in electri-
cal shock, fire and/or serious
person al injury.

S fety Symbols
In this operator’s manual and on the product, safety symbols and signal words are used to
communicate important safety information. This section is provided to improve under-
standing of these signal words and symbols.
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
DANGER indicates a hazardous situation which, if not avoided, will result in death or
serious injury.
WARNING indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION indicates a hazardous situation which, if not avoided, could result in minor
or moderate injury.
NOTICE indicates information that relates to the protection of property.
This symbol means read the operator’s manual carefully before using the equipment. The oper-
ator’s manual contains important information on the safe and proper operation of the equipment.
This symbol means always wear safety glasses with side shields or goggles when handling
or using this equipment to reduce the risk of eye injury.
This symbol indicates the risk of electrical shock.
conditions. Water en tering equipment will
increase the risk of electrical shock.
Person l S fety
•Stay alert, watch what you are doing
and use common sense when operat-
ing equipment. Do not use equipment
while you are tired or under the influ-
ence of drugs, alcohol or medication. A
moment of inattention while operating
equipment may result in serious personal
injury.
•Use personal protective equipment. Al -
ways wear eye protection. Protective equip-
ment such as dust mask, non-skid safety
shoes, hard hat or hearing protection used
for appropriate conditions will reduce per-
sonal injuries.
•Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in unex-
pected situations.
•Do not let familiarity gained from fre-
quent use of tools allow you to become
complacent and ignore tool safety prin-
ciples. A careless action can cause severe
injury within a fraction of a second.
Equipment Use nd C re
•Do not force equipment. Use the correct
equipment for your application. The cor-
2999-995-095.10_REV. A
A-Frame Fault Locator
Gener l S fety Rules
WARNING
Re d ll s fety w rnings nd instruc-
tions. F ilure to follow the w rnings nd
instructions m y result in electric shock,
fire nd/or serious injury.
SAVE ALL WARNINGS
AND INSTRUCTIONS FOR
FUTURE REFERENCE!
Work Are S fety
•Keep your work area clean and well lit.
Cluttered or dark areas invite accidents.
•Do not operate equipment in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. E quip -
ment can create sparks which may ignite
the dust or fumes.
•Keep children and by-standers a way
while operating equipment. Distrac tions
can cause you to lose control.
Electric l S fety
•Avoid body contact with earthed or
ground ed surfaces such as pipes, radi-
ators, ranges and refrigerators. There
is an increased risk of electrical shock if
your body is earthed or grounded.
•Do not expose equipment to rain or wet
NOTICE
DANGER
WARNING
CAUTION

SAVE ALL WARNINGS
AND INSTRUCTIONS FOR
FUTURE REFERENCE!
Keep this manual with the tool for use by
the operator.
A-Fr me F ult Loc tor S fety
•Do not expose the equipment to water
or rain. This increases the risk of electrical
shock.
•Do not operate the transmitter if opera-
tor or transmitter is standing in water.
Operating transmitter while in water in-
creases the risk of electrical shock.
•Do not connect to live voltage or ac-
tive utility lines. Disconnect the conductor
to be tested from any other service, com-
ponents, or anything that might be affected
by high voltage. De-energize any circuits in
or around the work area.
•Always attach transmitter test leads be-
fore turning unit ON and turn unit OFF
before disconnecting leads. This will re-
duce the risk of electrical shock.
•Never turn transmitter ON when anyone
is touching the conductor, ground stake,
or any part of the transmitter. Turn OFF
transmitter before touching test lead or any
un-insulated conductor.
•Do not use where a danger of high volt-
age contact is present. Do not attach
leads to high voltage conductors. The
equipment is not designed to provide high
voltage protection and isolation.
•ocating equipment uses electromag-
netic fields that can be distorted and in-
terfered with. More than one utility may
be present in a given area. Follow local
guidelines and one call/call before you dig
service procedures. Exposing a utility is
the only way to verify its existence, location
and depth.
•Avoid traffic. Pay close attention to mov-
ing vehicles when using on or near
roadways. Wear visible clothing or reflec-
tor vests.
•Before operating the RIDGID A-Frame
Fault ocator, read and understand this
operator’s manual and the instructions
for any other equipment used. Failure to
follow all instructions and warnings may re-
sult in property damage and/or serious in-
jury.
rect equipment will do the job better and
safer at the rate for which it is designed.
•Do not use equipment if the switch does
not turn it ON and OFF. Any tool that can-
not be controlled with the switch is dan-
gerous and must be repaired.
•Remove the battery pack from the equip-
ment before making any adjustments,
changing accessories, or storing. Such
preventive safety measures reduce the risk
of injury.
•Store idle equipment out of the reach of
children and do not allow persons unfa-
miliar with the equipment or these in-
structions to operate the equipment.
Equipment can be dangerous in the hands
of untrained users.
•Maintain equipment. Check for missing
parts, breakage of parts and any other
condition that may affect the equipment’s
operation. If damaged, have the equip-
ment repaired before use. Many accidents
are caused by poorly maintained equip-
ment.
•Use the equipment and accessories in
accordance with these instructions,
taking into account the working condi-
tions and the work to be performed.
Use of the equipment for operations differ-
ent from those intended could result in a
hazardous situation.
•Keep handles and grasping surfaces
dry, clean and free from oil and grease.
Slippery handles and grasping surfaces
do not allow for safe handling and control of
the tool in unexpected situations.
Service
•Have your equipment serviced by a qual -
i fied repair person using on ly identical
replacement parts. This will ensure that the
safety of the tool is maintained.
Specific S fety
Inform tion
WARNING
This section cont ins import nt s fety in-
form tion th t is specific to this tool.
Re d these prec utions c refully before
using the RIDGID®A-Fr me F ult Loc tor
to reduce the risk of electric l shock or
serious person l injury.
3
999-995-095.10_REV. A
A-Frame Fault Locator

Figure 1 – A-Frame Fault ocator
Tr nsmitter
Transmitter Controls:
Figure 2 – Transmitter Controls
•Use this manual in conjunction with all
company, utility or facility procedures
and policies. Familiarize yourself with all
required procedures and policies, including
safety practices, prior to entering an area
and using the equipment.
Ridge Tool Company, its affiliates
and suppliers, will not be liable for any injury or
any direct, indirect, incidental or consequential
damages sustained or incurred by reason of
the use of the A-Frame Fault Locator.
RIDGID Cont ct
Inform tion
If you have any question concerning this
RIDGID®product:
– Contact your local RIDGID distributor.
– Visit RIDGID.com to find your local
RIDGID contact point.
– Contact Ridge Tool Technical Service
De partment at rtctechservices@emer -
son.com, or in the U.S. and Canada call
[phone].
Description
The RIDGID®A-Frame Fault Locator is a highly
sensitive transmitter and receiver specifically
designed to detect the location of a path to
ground fault (Direct Fault Finding (DFF)) in
the insulation of a buried conductor (such as a
wire or cable). Damaged insulation, severed
conductor, and other faults with ground leak-
age are easily and precisely located.
Model FT-103 Transmitter connects to the insu-
lated conductor and establishes a current flow,
the current leaks to ground through the insula-
tion fault and back to the ground stake. Model
FR-30 Receiver detects the current flow to
ground through the insulation fault. The re-
ceiver provides audio and visual indications of
both signal strength and direction to assist in
detecting and locating the fault. For the A-
Frame fault detector to work, the conductor
must be in contact with the earth – it will not
work with conductors in conduit.
Additionally, the transmitter can be used to
apply a signal to the conductor for path locat-
ing with other receivers, such as RIDGID
SeekTech®or NaviTrack®Locators. This can be
done by direct connect and inductive methods.
Multiple frequencies and power levels are pro-
vided.
4999-995-095.10_REV. A
A-Frame Fault Locator
NOTICE
Ground Stake
Transmitter
Red Test ead
(To Conductor)
Black Test ead
(To Ground Stake)
Receiver
# Icon Description
1. — LCD Screen
2. O /OFF and Inductive Mode Switch
Main Power Switch – Short press turns unit O /OFF
Long press (5 seconds) enables Broadcast Inductive mode.
3. Frequency Selection
Selects the frequency of transmitter from preloaded fre-
quencies. See Specifications for frequencies
4. — Serial and Warning Label (back of unit)
5. Inductive Clamp Jack
6. — Positive Terminal (to Conductor)
7. egative Terminal (to Ground Stake)
8. Signal Power Setting
Depressing the Signal Power Button cycles the Signal
Power between Low, Medium and High
9. — Broadcast Inductive Decal (top and bottom)
2
1
7
8
3
5
4
6
9
9

Receiver Controls/Display:
Figure 5 – Receiver Controls
Specific tions
FT-103 Transmitter:
Operating
Frequencies .......Direct Fault Finding:
797 z - “dFF” displayed
Receiver
Figure 4 – A Frame Receiver
5
999-995-095.10_REV. A
A-Frame Fault Locator
Number Icons Description
1–––kHz Frequency. “dFF” shown for fault finding.
2 Signal Power - # Of Bars On Increases with Increasing Power. Three Levels – Low, Medium
and High.
3––– Circuit Information, mA, V or Resistance in Ohms. Transmitter cycles through each at 2
second intervals.
4 Voltage Warning – Transmitter connected to energized conductor – risk of electrical shock.
Do not touch transmitter, leads or connections. Use high voltage precautions to disconnect.
5 Transmitter Set for Fault Finding (dFF displayed in Frequency area (1)).
6 Transmitter Set for Inductive Clamp Use for Path Locating (Insert Inductive clamp into Jack)
7 Transmitter Set for Direct Connect Use for Fault Finding or Path Locating.
8 Transmitter Set for Broadcast Inductive Mode for Path Locating.
9 Transmitter Battery Status.
5
8
1
3
4
2
6
7
T
ransmitter Display:
9
Figure 3 – Transmitter Display
Display
Screen and
Controls
Front
Spike
Serial abel
Battery
Compartment
Warning
abel
Rear
Spike
2
13
# Icon Description
1 Reference Button
Stores and displays starting signal strength when pressed.
2 O /OFF Button
Main Power Switch – Press to turn unit O /OFF
3 Directional Arrow
Indicates direction of fault
4–– Signal Strength
Displays absolute signal Strength from 0 to 99.
5 Low Battery Indicator
5
4
Ref

Power Supply.....6 × AA (LR6) Batteries,
9 Volt
Battery Life..........Continuous: up to 40 hours,
Intermittent: up to 82 hours
Operating
Temperature.......-4°F to 133°F
(-20°C to 55°C)
Storage
Temperature.......-13°F to 140°F
(-25°C to 60°C)
IP Rating ............IP54
Size....................30.3" x 30.4" x 1.5"
(77 cm x 77 cm x 4 cm)
Weight................3 lbs. (1.3 kg)
St nd rd Equipment
The A-Frame Fault Locator package includes
the following items:
• FR-30 A-Frame Receiver
• FT-103 Transmitter
• Ground Stake
• Red and Black Test Leads (7.5' (2.3 m) long)
• Carry Cases
• Batteries
• Operator’s Manual Pack
This equipment is used for conduc-
tor fault and path locating. Incorrect use or
improper application may result in incorrect or
inaccurate locating. Selection of appropriate lo-
cating methods for the conditions and proper
operation is the responsibility of the user.
Ch nging/Inst lling
B tteries
WARNING
Switch unit OFF nd remove ny con-
nections from the Tr nsmitter/Receiver
before ch nging b tteries.
The A-Frame Fault Locator is supplied without
the batteries installed. Remove the batteries
prior to storage to avoid battery leakage. When
the low battery indicator appears on the trans-
mitter ( ) or receiver ( ) display, the bat-
teries need to be replaced.
Use the batteries that are of same
type. Do not mix battery types. Do not mix
new and used batteries. Mixing batteries can
cause overheating and battery damage.
Path locating:
128 z, 1 k z, 8 k z, 33
kz, 93 k z
Direct Connect:
128 z, 1 k z, 8 k z, 33
k z, 93 k z
Inductive Clamp:
8 k z, 33 k z, 93 k z
Broadcast Inductive:
33 k z, 93 k z
Load Range .......5 Ω to 2M Ω
Output Power .....Up to 3 Watts (Low,
medium and high settings)
Output Voltage ...5 Volts - 600 Volts
Power Supply .....8 × C (R14) Cell
Batteries, 12 Volt
Battery Life.........Continuous: up to 15 hours,
Intermittent: up to 60 hours
(on low at 1000 Ohm load)
Operating
Temperature.......-4°F to 133°F
(-20°C to 55°C)
Storage
Temperature.......-13°F to 140°F
(-25°C to 60°C)
IP Rating ............IP54
Size....................8.5" x 5.8" x 2.5"
(21 cm x 15 cm x 6 cm)
Weight................2.2 lbs. (1 kg)
Test Lead
Jacks..................0.16" (4mm) as per
IEC61010
FR-30 A-Frame Receiver:
Operating
Frequencies .......Fault Finding:
797 z - “dFF” displayed
Direct Connect:
Fault Finding
Depth .................Up to 20' (6m) (depend-
ing on conditions)
Fault Finding
Length................Up to 3 miles (4800 m)
(depending on conditions)
Display ...............Black and White LCD
Audio
Indication ...........Piezo Response
6999-995-095.10_REV. A
A-Frame Fault Locator
NOTICE
NOTICE

Fult Loc tor nd correct ny problems
to reduce the risk of serious injury from
electric shock nd other c uses, nd
prevent equipment d m ge.
1. Make sure the transmitter and receiver
units are OFF.
2. Remove the batteries and inspect for
signs of damage. Replace if necessary.
Do not use if the batteries are damaged.
3. Clean the equipment. This aids inspection
and helps prevent the tool from slipping
from your grip.
4. Inspect the locator for the following:
• Proper assembly, maintenance and com -
pleteness.
• Any broken, worn or missing parts.
• Inspect the transmitter test leads for
damaged insulation or exposed wire.
• Presence and readability of the transmit-
ter and receiver warning labels (Figure
2 a d 4).
• Any other condition which may prevent
safe and normal operation.
If any problems are found, do not use
the A-Frame Fault Locator until the prob-
lems have been repaired.
5. Inspect and maintain any other equip-
ment being used per its instructions to
make sure it is functioning properly.
Set-Up And Oper tion
Instructions
WARNING
Do not connect to live volt ge or ctive
utility lines. Disconnect the conductor
to be tested from ny other service, com-
ponents, or nything th t might be f-
fected by high volt ge. De-energize ny
circuits in or round the work re .
Alw ys tt ch tr nsmitter test le ds be-
fore turning unit ON nd turn unit OFF be-
fore disconnecting le ds. This will re-
duce the risk of electric l shock.
Never turn tr nsmitter ON the unit when
nyone is touching the conductor, ground
st ke, or ny p rt of the tr nsmitter. Turn
Tr nsmitter:
1. With device OFF, remove the battery com-
partment cover. If needed, remove batter-
ies (Figure 6).
Figure 6 – Changing the Batteries (Transmitter)
2. Install eight new C Cell alkaline batteries
(R14), observing correct polarity as indi-
cated in the battery compartment.
3. Securely reinstall the battery compart-
ment cover.
Receiver (A-Fr me):
1. With device OFF, unscrew the battery
com partment cover on the top tube (Fi -
gure 7). If needed, remove batteries.
Figure 7 – Changing the Batteries (Receiver)
2. Install six new AA alkaline batteries (LR6),
observing correct polarity as indicated
in the battery compartment.
3. Securely reinstall the battery compart-
ment cover.
Pre-Oper tion Inspection
WARNING
D ily before use, inspect your A-Fr me
7
999-995-095.10_REV. A
A-Frame Fault Locator
Battery Compartment
Batteries Cover
Battery
Compartment Cover
Batteries
+-
+
-
+-
+
-

OFF tr nsmitter before touching test le d
or ny un-insul ted conductor.
Do not use where d nger of high volt-
ge cont ct is present. Do not tt ch
le ds to high volt ge conductors. The
equipment is not designed to provide
high volt ge protection nd isol tion.
Loc ting equipment uses electrom g-
netic fields th t c n be distorted nd in-
terfered with. More th n one utility m y
be present in given re . Follow loc l
guidelines nd one c ll/c ll before you dig
service procedures. Exposing utility is
the only w y to verify its existence, loc -
tion nd depth.
Follow set up nd oper ting instructions
to reduce the risk of injury from electric l
shock nd other c uses nd to prevent
tool d m ge
Model FT-103 Transmitter and Model FR-30
Receiver are used for fault locating of con-
ductors through direct connect method.
The Model FT-103 Transmitter only can be
used for path locating with RIDGID SeekTech®
and NaviTrack®Locators. This can be done by
direct connect and inductive methods.
1. Confirm have appropriate work area (See
Ge eral Safety Rules). Operate in clear,
level, stable, dry location.Do not use trans-
mitter while standing in water.
2. Determine the correct equipment for the
application, see Descriptio and Specifi -
catio s sections.
3. Make sure all equipment has been in-
spected and set up as directed in their in-
structions.
F ult Loc ting
It is good practice to locate the conductor path
before attempting to fault locate. This can be
done using a variety of RIDGID locating equip-
ment. If during the location of the conductor
path an unusual amount of signal loss occurs,
this may give some indication of the conductor
insulation fault location. Additionally, use visual
cues and past history to aid in identifying the
conductor path and potential fault locations.
Once the conductor path is determined, the
RIDGID FT-103 Transmitter and FR-30 A-Frame
Receiver can be used to locate ground faults in
the insulated conductor. The Model FT-103
Transmitter connects to the insulated conductor
and establishes a current flow, the current
leaks to ground through the insulation fault
A-Frame Fault Locator
999-995-095.10_REV. A
8
and back to the ground stake. The Model FR-30
Receiver detects the current flow to ground
through the insulation fault. For the A-Frame
fault detector to work, the conductor must be in
contact with the earth – it will not work with con-
ductors in conduit. Generally, the A-Frame Fault
Locator works best in earth. Use with gravel,
asphalt, concrete or other ground covers may
not work as well.
The signal strength at the fault depends on
the amount of current leaking there. The greater
the leakage, the greater the signal strength.
Connecting Tr nsmitter
1. Disconnect all loads and grounds from
the conductor to be tested and all neigh-
boring conductors to prevent damage from
high voltage and false reading. Both ends
should be known and disconnected. Dis -
connecting both ends of the conductor
forces all of the transmitter signal through
the fault, improving the fault locate.
2. Insert supplied ground stake into the earth.
Ideally, the ground stake should be in line
with the conductor, 3' to 6' (1m to 2m)
from the end. If conditions require, the
ground stake can be placed to the side of
the conductor. Do not to place the ground
stake over the conductor. It is not recom-
mended to use other existing grounds,
existing grounds may result in signal being
inadvertently applied to non-target cables.
A good ground results in a stronger tracing
signal. To get a good ground, insert the
ground stake as far as possible into the
earth. Moist earth will give a better ground
than dry earth. Wetting the earth around
the ground stake can improve grounding.
This lowers the resistance of the circuit.
While moist earth around the ground stake
improves the circuit, do not use the trans-
mitter in areas that are wet, this can in-
crease the risk of electrical shock.
3. Make sure that the transmitter is OFF.
4. Connect BLACK test lead to the ground
stake. Always connect to the ground stake
first.
5. Connect the BLACK and RED test leads
to the Transmitter.
6. Connect the RED test lead to the conduc-
tor to be tested (see Figure 9).

Loc ting
1. Make sure that no one is near or touching
the conductor, transmitter, leads or ground
stake. Press the ON/OFF button on the
transmitter to turn the transmitter ON.
When the transmitter is turned on, it is set
to the last used frequency. If needed,
press the frequency button on the trans-
mitter until “dFF” is shown on screen
(Figure 9).
Figure 9 – Transmitter Screen
Adjust the signal power by pressing the signal
power button to cycle through the settings (low,
medium and high). Using high power may re-
sult in signal going to ground at non-target
points, low power may mean a circuit is not cre-
ated. The transmitter will display circuit resist-
ance (O MS) at the bottom of the LCD. The
lower the resistance the better the locate signal.
To improve the circuit, improve the ground,
check the lead connections or increase the
power.
The transmitter will continuously beep when
there is a circuit. The lower the circuit resist-
ance, the quicker the beep. The transmitter
will beep three times and a pause (repeat-
ing) if there is no circuit.
If the transmitter display shows voltage warn-
ing (Figure 3), the transmitter is connected to
live voltage. If this happens, DO NOT TOUCH
A-Frame Fault Locator
999-995-095.10_REV. A 9
THE TRANSMITTER, EADS OR CONNEC-
TIONS. The target conductor is energized and
there is the risk of electrical shock. Use high
voltage precautions to disconnect.
2. When fault locating, generally the receiver
should be used over the conductor, with
the front receiver spike towards the ex-
pected fault and the rear receiver spike to-
wards the ground stake. The receiver
spikes should evenly penetrate the earth
to make good electrical contact. The cur-
rent flowing in and out of the ground
spikes supplies the signal to locate the in-
sulation fault (see Figure 10).
Figure 10 – Receiver Positioning
3. To start the locate, place the A-Frame
receiver between the ground stake and
the transmitter connection to the conduc-
tor. Press the A-Frame Receiver ON/OFF
button to turn receiver ON.
The signal strength will appear on the
receiver display. Signal strength will be the
highest near the ground stake and at
faults. Press the “Ref” button to store a ref-
erence signal strength near the ground
stake.
The receiver display arrows will indicate
the direction of the fault. Fault direction is
also indicated audibly - a long slow beep
indicates forward direction and a quick
beep indicates backward direction.
Figure 8 – Transmitter Connections for Fault ocating
Transmitter
Receiver
Red
Black
Ground Rod Buried Conductor
Earth
Fault
Return Path
Through Soil
3" – 6"
(1 – 2 m)
Conductor (Side View)
Conductor (End View)

A-Frame Fault Locator
999-995-095.10_REV. A
10
4. Remove the receiver from the earth and
move several steps as indicated by the
directional arrow and beeping along the
conductor path. Reinsert the receiver
spikes into the earth (Figure 11).
Continue moving away from the ground
stake along the conductor path. Signal
strength should drop (in some cases going
to zero) and then rise as you move to-
wards a fault.
5. Signal strength will peak over the fault. If
you pass the fault, the directional arrow will
change direction and the beep will change
from long slow to quick beep and the sig-
nal strength will decrease. Continue to
move the receiver back and forth until
slight movement causes the directional
arrows and beeping to toggle back and
forth. At this point, the fault is centered be-
tween the spikes of the receiver.
Compare the signal strength to the refer-
ence signal strength taken near the
ground stake. They should be similar. If the
fault signal strength is much lower than the
reference value, you may not have lo-
cated a fault. For instance, a grounded
splice point would behave as a fault during
the locate, but would give a much lower
signal strength. For a low fault signal
strength, you may want to mark the loca-
tion and continue down the conductor
path looking for a fault signal strength
closer to the reference signal.
Once a fault is located with a signal similar
to the reference signal, turn the A-Frame
Locator perpendicular to the path of the
conductor. Move the receiver back and
forth until slight movement causes the di-
rectional arrows and beeping to toggle
back and forth. At this point, the fault is
centered between the spikes of the re-
ceiver. See Figure 12. Mark the location of
the fault.
6. Once the locating is completed, press the
ON/OFF button to turn the transmitter OFF.
Always turn the unit OFF before discon-
necting the cable leads to reduce the risk
of electrical shock. Remove the cable lead
from the target conductor first. Always dis-
connect the cable lead from the target
conductor first before removing the cable
lead from the ground spike to reduce the
risk of electrical shock. Disconnect the
cable lead from the ground spike.
Loc ting Below P ved
Surf ces
Locating can be difficult if the fault is below a
paved surface, because the receiver spikes
cannot make good electrical contact with
the earth. In this case, there are several
methods that can be used.
Figure 11 – Signal Strength
Figure 12 – Final ocate
Ground Rod
Fault
Signal Strength
Fault
Conductor (Side View)
Conductor (End View)
Signal
Strength
Fault

A-Frame Fault Locator
999-995-095.10_REV. A 11
•If the paved area is relatively small, the
receiver can be used around the periphery
of the area. The receiver can be rotated
side to side, and where the receiver di-
rectional arrows and beeping toggle back
and forth, extend a straight line perpendicu-
lar to the center of the A-Frame Receiver.
Do this in several locations around the
suspected fault area. The straight lines
should all intersect at the same point. This
is the location of the fault. This method of
locating is less exact than placing the re-
ceiver directly over the conductor. See
Figure 13.
• An alternate way to locate below paved
surfaces is to improve the conductivity be-
tween the pavement and the receiver with
water. One method is to attach sponges to
the spikes of the receiver. Wet the sponges
with water and keep wet. Conduct the fault
locate normally.
• Another method is to wet the surface of the
pavement with water and conduct the fault
locate normally. Do not do this in the area
of the transmitter – this increases the risk of
electrical shock.
Figure 13 – ocating below paved surfaces
Multiple F ults
If there are multiple faults in the conductor,
the faults will have signals proportional to
the amount of current leaking. The locate is
done the same as for a single fault, but the
signal strength will not be as strong. Typically,
the largest fault (least resistance fault) is
easiest to find. Best practice is to find and re-
pair the first fault and continue the locate
for other faults.
P th Loc ting
The FT-103 Transmitter can be used with other
commercially available receivers (such as the
RIDGID SeekTech or NaviTrack receivers) to
path locate conductors. The FT-103 transmitter
can be used to apply an active tracing signal to
a conductor in three ways:
• Direct Connect – The transmitter’s leads
are connected directly to the target conduc-
tor and a suitable ground. This method is
most commonly used when the target util-
ity is accessible. Direct connect should not
be used for energized (live) conductors.
• Inductive Clamp (optional equipment) –
the jaws of the inductive clamp encircle
the target conductor; if the conductor is in-
sulated, there is no metal to metal contact.
This method is commonly used when the
target utility is accessible but direct con-
nect is not possible on an insulated cable.
• Broadcast Inductive Mode – The transmit-
ter generates a field, which in turn induces
a current in the target conductor. There is no
direct connection between the transmitter
and the target conductor. The transmitter is
placed over and inline with the target con-
ductor. The transmitter’s internal antenna in-
duces a signal onto the target conductor.
This method is most commonly used when
the target utility is not accessible.
Disconnect all loads from the conductor to
be tested and all neighboring conductors to
prevent damage from high voltage and false
reading.
Direct Connect P th Loc ting
Method
1. Insert supplied ground stake into the
earth. Or, if other good grounds are avail-
able in the area, they can be used.
A good ground results in a stronger tracing
signal. To get a good ground, insert the
ground stake as far as possible into the
earth. Moist earth will give a better ground
than dry earth. Wetting the earth around
the ground stake can improve grounding.
This lowers the resistance of the circuit.
While moist earth around the ground
stake improves the circuit, do not use the
transmitter in areas that are wet, this can
increase the risk of electrical shock.
The far end of the conductor should be
grounded.
2. Make sure that the transmitter is OFF.
3. Connect BLACK test lead to the ground
stake. Always connect to the ground stake
first.
4. Connect the BLACK and RED test leads
to the Transmitter.
Conductor
Fault
Paved Area

5. Connect the RED test lead to the conduc-
tor to be tested.
6. Press the ON/OFF button to turn the trans-
mitter ON. When the transmitter is turned
on, it is set to the last used frequency.
Press the frequency selection button to
cycle through frequency settings to the
desired locating frequency.
Adjust the signal power by pressing the
signal power button to cycle through the
settings (low, medium and high). Using
high power can couple into non-target
conductors, low power may mean a circuit
is not created. The transmitter will display
circuit resistance (O MS) at the bottom of
the LCD. The lower the resistance the bet-
ter the locate signal. To improve the circuit,
improve the ground, check the lead con-
nections, increase power or change the
frequency.
If the transmitter display shows voltage
warning (Figure 3), the transmitter is con-
nected to live voltage. If this happens,
DO NOT TOUCH THE TRANSMITTER,
EADS OR CONNECTIONS. The tar-
get conductor is energized and there is
the risk of electrical shock. Use high volt-
age precautions to disconnect.
7. Check the circuit and adjust signal power,
grounding or connections to ensure locat-
able field.
8. Turn ON the receiver/locator and follow
the instructions for the receiver. Make sure
the receiver’s frequency is set to match that
on the transmitter. Confirm the receiver is
picking up the transmitted frequency by
holding it near the transmitter and observ-
ing the increase in receiver signal.
9. Once the locating is completed, press the
ON/OFF button to turn the transmitter
OFF. Always turn the unit OFF before dis-
connecting the cable leads to reduce the
risk of electrical shock. Remove the cable
lead from the target conductor first. Always
disconnect the cable lead from the target
conductor first before removing the cable
lead from the ground spike to reduce the
risk of electrical shock. Disconnect the
cable lead from the ground spike.
Inductive Cl mp P th
Loc ting
1. This method requires an inductive clamp
(Optio al equipme t). Read and follow
A-Frame Fault Locator
999-995-095.10_REV. A
12
all instruction for the use of the inductive
clamp.
2. Insert the plug of the inductive clamp
into transmitter (see Figure 2).
3. Clamp the jaws of the inductive clamp
around the target conductor. Make sure
that the jaws of the clamp are fully closed.
(See Figure 14). Both ends of the conduc-
tor should be grounded for best results.
Figure 14 – Inductive Clamp Attached to a
Conductor
4. Press the ON/OFF button to turn the trans -
mitter ON. When the clamp is plugged in
the clamp symbol ( ) shows on the
screen and only clamp frequencies are
available. Press the frequency selection
button to cycle through frequency settings
to the desired locating frequency. Adjust
the signal power by pressing the signal
power button to cycle through the settings
(low, medium and high). The inductive
clamp typically works best with frequen-
cies around 8k z, 33 k z, 93k z.
5. Check the circuit and adjust signal strength
(see Figure 3, Circuit I formatio ).
6. Turn ON the receiver/locator and follow
the instructions for the receiver. Make
sure the receiver’s frequency is set to
match that on the transmitter. Confirm
the receiver is picking up the transmitted
frequency by holding it near the trans-
mitter and observing the increase in re-
ceiver signal.
7. Once the locating is completed, press
the ON/OFF button to turn the transmitter
OFF.
Bro dc st Inductive P th
Loc ting
1. Properly place the transmitter relative to
the target conductor (see Figure 15). On
the top of the transmitter is an arrow. Set

A-Frame Fault Locator
999-995-095.10_REV. A 13
transmitter on ground,
align arrow with the
target conductor.
2. Press the ON/OFF
button to turn the
trans mitter ON. Press
and hold the power
button for 5 seconds
selection button to
shift transmitter into
broadcast inductive
mode. Broadcast in-
ductive icon ( ) ap-
pears on screen and
the transmitter will
start beeping to indi-
cate that it is operat-
ing.
Adjust the signal power by pressing the
signal power button to cycle through the
settings (low, medium and high) and
choose high. Press the frequency selec-
tion button to cycle through 33khz and
93k z frequency settings to the desired
locating frequency. When using Broadcast
Inductive Mode, higher frequencies tend
to get a better signal at the receiver.
3. Turn ON the locator and follow its instruc-
tions. Make sure to set the receiver to
the same frequency as the transmitter.
Figure 16 – Orientation to the ine – Inductive
Mode
When the transmitter is in broadcast induc-
tive mode, it generates a field around the
transmitter. This field is in both the ground
(towards the target conductor) and into
the air around the transmitter. When the re-
ceiver is within approximately 30 feet (10
meters) of the transmitter, it will measure
the field directly from the transmitter and
not the signal induced on the target con-
ductor. This is called “Air Coup ling”. Operate
the receiver at least 30 feet from the trans-
mitter to prevent this. (See Figure 16).
One way to confirm that you are tracing the
target conductor and not the transmitter
field is to look for a strong, stable prox imity
signal and a valid depth measurement on
the receiver. While directly over the ener-
gized line you can also raise the receiver a
set distance off of the ground, and verify
that the depth reading on the display e -
quals the distance that you raised the re-
ceiver.
4. Once the locating is completed, press the
Power ON/OFF button for 5 seconds to
exit broadcast inductive mode, then press
the ON/OFF button to turn the transmitter
OFF.
Stor ge
Remove batteries from tool. Store the A-Frame
Fault Locator in case. Avoid storing in ex-
treme heat or cold.
Store tool in a dry, secured
area that is out of reach of children and
people unfamiliar with the RIDGID A-Frame
Fault ocator. The locator is dangerous in
the hands of untrained users.
M inten nce
WARNING
Remove b tteries from tool before per-
forming m inten nce or m king ny
djustment.
Cle ning
Do not immerse the A-Frame Fault Locator in
water. Wipe off dirt with a damp soft cloth.
Avoid rubbing too hard. Do not use aggressive
cleaning agents or solutions.
C libr tion
The A-Frame Fault Locator is factory cali-
brated and only requires recalibration if re-
paired.
Service And Rep ir
WARNING
Improper service or rep ir c n m ke
the m chine uns fe to oper te.
Service and repair on this A-Frame Fault Lo -
Conductor
Transmitter Field
Induced
Field on
Target
Conductor
Conductor
30 feet
Minimum
Figure 15 –
Orientation to the
ine – Inductive
Mode
WARNING

cator must be performed by a RIDGID Inde -
pendent Service Center. Use only RIDGID
service parts.
For information on your nearest RIDGID Inde -
pen dent Service Center or any service or repair
questions, see Co tact I formatio Sectio in
this manual.
Option l Equipment
WARNING
To reduce the risk of injury, only use c-
cessories specific lly designed nd rec-
ommended for use with the RIDGID A-
Fr me F ult Loc tor, such s listed below.
For a complete listing of RIDGID equipment
avail able for this tool, see the Ridge Tool Cata -
log online at RIDGID.com or see Contact
Information.
Dispos l
Parts of this tool contain valuable materials
and can be recycled. There are companies
that specialize in recycling that may be found
locally. Dispose of the components in compli-
ance with all applicable regulations. Contact
your local waste management authority for
more information.
For EC Countries: Do not dispose
of elec trical equipment with house-
hold waste!
According to the European Guide -
line 2012/ 19/EU for Waste Elec trical
and Electronic Equipment and its
imple men tation into national legislation, elec-
trical equipment that is no longer usable must
be collected separately and disposed of in
an environmentally correct manner.
A-Frame Fault Locator
999-995-095.10_REV. A
14
B ttery Dispos l
For EC countries: Batteries must be recycled
according to the guideline 2006/66/EEC.
EC Decl r tion of
Conformity
The EC Declaration of Conformity (890-011-
320.10) will accompany this manual as a sep-
arate booklet when required.
FCC St tement
This equipment has been found to comply
with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable pro-
tection against harmful interference in a resi-
dential installation.
This equipment generates, uses, and can ra-
diate radio frequency energy and, if not in-
stalled and used in accordance with the in-
structions, may cause harmful interference
to radio communications.
owever, there is no guarantee that interfer-
ence will not occur in a particular installation.
If this equipment does cause harmful interfer-
ence to radio or television reception, which can
be determined by turning the equipment OFF
and ON, the user is encouraged to try to cor-
rect the interference by one or more of the fol-
lowing measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equip-
ment and receiver.
• Consult the dealer or an experienced radio/ -
TV technician for help.
Electrom gnetic
Comp tibility (EMC)
The term electromagnetic compatibility is taken
to mean the capability of the product to function
smoothly in an environment where electro-
magnetic radiation and electrostatic discharges
are present and without causing electromagnet
interference to other equipment.
The RIDGID A-Frame Fault Locator
conform to all applicable EMC standards.
owever, the possibility of it causing interfer-
ence in other devices cannot be precluded. All
EMC related standards that have been tested
are called out in the tool’s technical document.
Catalo
No. Description
20973 RIDGID SeekTech 4" (100 mm)
Inductive Signal Clamp
57763 Ground Stake, FT-103
57768 Red and Black Test Leads, FT-103
96967 RIDGID aviTrack II Locator
19238 RIDGID aviTrack Scout Locator
22163 RIDGID SeekTech SR-60 Line Locator
21893 RIDGID SeekTech SR-20 Line Locator
44473 RIDGID SR-24 Line Locator with
Bluetooth®and GPS
NOTICE

Localisateur de rupture A-Frame
Transmetteur FT-103 et
Récepteur FR-30
Localisateur de rupture A-Frame
Loca isateur de rupture A-Frame
Pour future référence, notez ci-dessous le numéro de série de l’appareil qui apparait sur sa
plaque signalétique.
No de
série
AVERTISSEMENT
Fami iarisez-vous avec e présent
mode d’emp oi avant d’uti iser ’ap-
parei . Tout manque de compréhen-
sion ou de respect des consignes ci-
après augmenterait es risques de
choc é ectrique, d’incendie et/ou d’ac-
cident grave.

16 999-995-095.10_REV. A
Loca isateur de rupture A-Frame
Ta le des matières
Fiche d’enregistrement du numéro de série de l’appareil ..............................................15
Symboles de sécurité.........................................................................................................17
Consignes générales de sécurité
Sécurité des lieux ............................................................................................................17
Sécurité électrique...........................................................................................................17
Sécurité individuelle.........................................................................................................17
Utilisation et entretien du matériel ...................................................................................18
Service après-vente.........................................................................................................18
Consignes de sécurité spécifiques
Sécurité du localisateur de rupture..................................................................................18
Coordonnées RIDGID.........................................................................................................19
Description..........................................................................................................................19
Transmetteur....................................................................................................................20
Récepteur ........................................................................................................................21
Caractéristiques techniques .............................................................................................22
Equipements de base......................................................................................................22
Remplacement des piles ...................................................................................................23
Transmetteur....................................................................................................................23
Récepteur A-Frame .........................................................................................................23
Inspection préalable...........................................................................................................23
Préparation et utilisation de l’appareil .............................................................................24
Localisation de rupture
Connexion du transmetteur .............................................................................................25
Localisation .....................................................................................................................25
Localisation sous chaussée ............................................................................................27
Ruptures multiples...........................................................................................................28
Traçage des conducteurs
Traçage par connexion directe.........................................................................................28
Traçage par pince à induction .........................................................................................29
Traçage par transmission inductive .................................................................................30
Stockage .............................................................................................................................30
Entretien
Nettoyage ........................................................................................................................31
Calibrage .........................................................................................................................31
Révisions et réparations ..................................................................................................31
Accessoires ........................................................................................................................31
Recyclage............................................................................................................................31
Recyclage des piles.........................................................................................................32
Déclaration de conformité CE ...........................................................................................32
Enoncé FCC........................................................................................................................32
Compatibilité électromagnétique (EMC) ..........................................................................32
Garantie à vie...................................................................................................page de garde
*Traduction de la notice originale

17
999-995-095.10_REV. A
Loca isateur de rupture A-Frame
Sym oles de sécurité
Les symboles et mots clés utilisés à la fois dans ce mode d’emploi et sur l’appareil lui-même
servent à signaler d’importants risques de sécurité. Ce qui suit permettra de mieux com-
prendre la signification de ces mots clés et symboles..
Ce symbole sert à vous avertir de risques d’accident potentiels. Le respect des consignes qui le
suivent vous permettra d’éviter les risques d’accident grave ou potentiellement mortel.
Le terme DAN ER signifie une situation dangereuse qui, faute d’être évitée, provo-
querait la mort ou de graves blessures corporelles.
Le terme AVERTISSEMENT signifie une situation dangereuse potentielle qui,
faute d’être évitée, serait susceptible d’entraîner la mort ou de graves blessures
corporelles.
Le terme ATTENTION signifie une situation dangereuse potentielle qui, faute d’être
évitée, serait susceptible d’entraîner des blessures corporelles légères ou modérées.
Le terme AVIS IMPORTANT indique des informations concernant la protection
des biens.
Ce symbole indique la nécessité de bien se familiariser avec la notice d’emploi avant d’utiliser ce
matériel. La notice d’emploi renferme d’importantes consignes de sécurité et d’utilisation du
matériel.
Ce symbole impose le port systématique de lunettes de sécurité à œillères lors de la manip-
ulation ou utilisation de ce matériel afin de limiter les risques de lésion oculaire.
Ce symbole indique un risque de choc électrique.
Sécurité électrique
•Evitez tout contact avec des objets reliés
à la terre tels que canalisations, radia-
teurs, cuisinières et réfrigérateurs. Tout
contact avec la terre augmenterait les
risques de choc électrique.
•N’exposez pas l’appareil à la pluie ou
aux intempéries. Toute pénétration d’eau à
l’intérieur d’un appareil électrique aug-
menterait les risques de choc électrique.
Sécurité individuelle
•Soyez attentif, restez concentré et faites
preuve de bon sens lors de l’utilisation
de ce type d’appareil. Ne jamais utiliser
ce matériel lorsque vous êtes fatigué ou
sous l’influence de drogues, de l’alcool
ou de médicaments. Lors de l’utilisation
d’un appareil électrique, un instant d’inat-
tention risque d’entraîner de graves lé-
sions corporelles.
•Prévoyez les équipements de protec-
tion individuelle appropriés. Portez sys-
tématiquement une protection oculaire.
Selon le cas, le port d’un masque à pous-
sière, de chaussures de sécurité antidéra-
pantes, du casque ou d’une protection au-
riculaire peut aider à limiter les risques
d’accident grave.
Consignes générales de
sécurité
AVERTISSEMENT
Familiarisez-vous avec l’ensem le des
consignes de sécurité et d’utilisation. Le
non-respect des consignes ci-après aug-
menterait les risques de choc électrique,
d’incendie et/ou d’accident grave.
Conservez l’ensem le des consignes
de sécurité et d’utilisation pour
future référence !
Sécurité des lieux
•Assurez-vous de la propreté et du bon
éclairage des lieux. Les chantiers en-
combrés ou mal éclairés sont une invitation
aux accidents.
•N’utilisez pas d’appareils électriques en
présence de substances volatiles telles
que liquides, gaz ou poussières com-
bustibles. Ce type de matériel risque de
produire des étincelles susceptibles d’en-
flammer les poussières et émanations com-
bustibles.
•Eloignez les enfants et les curieux durant
l’utilisation des appareils électriques.
Les distractions risquent de vous faire per-
dre le contrôle de l’appareil.
AVIS IMPORTANT
DANGER
AVERTISSEMENT
ATTENTION

18 999-995-095.10_REV. A
Loca isateur de rupture A-Frame
•Maintenez les poignées et autres sur-
faces de prise en main de l’appareil
dans un parfait état de propreté. Cela
assurera une meilleure prise en main du
matériel.
Service après-vente
•Confiez la révision de l’appareil à un ré-
parateur qualifié se servant exclusive-
ment de pièces de rechange identiques
aux pièces d’origine. Cela assurera la
sécurité opérationnelle de l’appareil.
Consignes de sécurité
spécifiques
AVERTISSEMENT
La section suivante contient d’impor-
tantes consignes de sécurité visant ce
localisateur en particulier.
Afin de limiter les risques de choc élec-
trique ou autre accident grave, familia-
risez-vous avec les consignes suivantes
avant d’utiliser le localisateur de rupture
A-Frame.
Conservez l’ensem le des consignes
de sécurité et d’utilisation pour
future référence !
ardez ce mode d’emploi avec l’appareil
afin qu’il soit à portée de main de tout utilisa-
teur éventuel.
Sécurité du localisateur de
rupture A-Frame
•N’exposez pas ce matériel à l’eau ou
aux intempéries. Cela augmenterait les
risques de choc électrique.
•N’utilisez pas le transmetteur lorsque
l’opérateur ou le transmetteur a les pieds
dans l’eau. L’utilisation du transmetteur en
présence d’eau augmenterait les risques de
choc électrique.
•Ne connectez pas ce matériel à un objet
sous tension ou à des lignes électriques.
Déconnectez le conducteur à contrôler de
tout service, composant ou autre élément
qui risque d’être sous haute tension. Coupez
le courant à tout circuit électrique sur le
chantier ou dans ses environs.
•Ne vous mettez pas en porte-à-faux.
Maintenez une bonne assiette et un bon
équilibre à tout moment. Cela assurera
un meilleur contrôle de l’appareil en cas
d’imprévu.
•Ne laissez pas la familiarité issue d’une
utilisation fréquente des appareils vous
rendre complaisant au point d’ignorer
les principes de sécurité applicables.
Le moindre faux pas peut occasionner de
graves blessures en une fraction de sec-
onde.
Utilisation et entretien de
l’appareil
•Ne forcez pas l’appareil. Prévoyez l’ap-
pareil le mieux adapté aux travaux en-
visagés. Un appareil adapté produira de
meilleurs résultats et un meilleur niveau
de sécurité lorsqu’il fonctionne au régime
prévu.
•N’utilisez pas d’appareil dont l’interrup-
teur marche/arrêt ne fonctionne pas cor-
rectement. Tout appareil qui ne peut pas
être contrôlé par son interrupteur est con-
sidéré dangereux et doit être réparé.
•Retirez le bloc-piles de l’appareil avant
tout réglage, remplacement d’outils ou
stockage. De telles mesures préventives
aideront à limiter les risques d’accident.
•Rangez tout appareil non utilisé hors
de la portée des enfants et ne permettez
à aucun individu non familier avec ce
matériel ou les instructions ci-présentes
d’utiliser le matériel. Ce type d’appareil
peut devenir dangereux entre les mains
d’un novice.
•Assurez l’entretien approprié de l’ap-
pareil. Assurez-vous de l’absence d’élé-
ments grippés ou endommagés, voire toute
autre anomalie susceptible de nuire au bon
fonctionnement et à la sécurité de l’ap-
pareil. Ne jamais utiliser d’appareil endom-
mage avant sa réparation. De nombreux
accidents sont le résultat d’appareils mal en-
tretenus.
•Utilisez l’appareil et ses accessoires se-
lon les consignes ci-présentes, tout en
tenant compte des conditions d’inter-
vention et du type de travail envisagé.
L’emploi de ce matériel à des fins autres
que celles prévues pourrait entrainer une
situation dangereuse.
