Emerson Adapt User manual

iTrust Adapt UPS 20
k V A User
Ma nu a l
Emerson Network Power provides customers with technical support. Users may contact the nearest
Emerson local sales office or service center.
Copyright © 2010 by Emerson Network Power Co., Ltd.
All rights reserved. The contents in this document are subject to change without notice.
Emerson Network Power Co., Ltd.
Address: No.1 Kefa Rd., Science & Industry Park, Nanshan District 518057, Shenzhen China
Homepage: www.emersonnetworkpower.com.cn
E-mail: [e-mail]

Safety
P r e c a u t i ons
This manual contains the information concerning the installation and operation of Emerson iTrust Adapt
/20kVAUPS (hereinafter referred to as UPS). Please
carefully read this manual prior to installation.
The UPS must be installed, commissioned and serviced by engineers designated by the manufacturer or its
agent. Failure to observe this could result in personnel safety risk, UPS malfunction and invalidation of warranty.
The UPS has been designed for commercial and industrial use only, and is not recommended for use in life
support applications.
This is a Class A UPS product. In a residential environment, this product may nevertheless cause radio
interference, in which case, the user may be required to take additional measures.
Conformity And Standards
The UPS complies with 2006/95/EC, 93/68/EEC (LV Safety) and 2004/108/EC (EMC), with Australia and New Zealand EMC
Framework (C-Tick) and with the following product standards for UPS:
* IEC62040-1-1: General and safety requirements for use in operator access area
* IEC62040-2: EMC requirements, Class C2 compliant
* IEC62040-3: Performance requirements and test methods
The UPS installation should follow the above instructions and use the accessories specified by manufacturer.
Warning: High Leakage Current
Earth connection is essential before connecting the input power (AC mains and battery included). This equipment must be
earthed in accordance with the local electrical codes.
Earth leakage current ranges from 3.5mA to 1000mA.
Transient and steady-state earth leakage currents, which may occur when starting the equipment, should be taken into
account when selecting instantaneous residual current circuit breaker (RCCB) or residual current detector (RCD).
RCCB must be selected, which is insensitive to DC unidirectional pulses (Class A) and transient current pulses.
Note that the earth leakage current of the load will be carried by RCCB or RCD.
Warning: Reflected Protection
The UPS has a zero-voltage contact closure signal available for use with an external automatic circuit breaker (single
power), to protect against backfeeding voltage to input terminal through the static bypass circuit. If the installation engineer
do not need to use this signal, the external bypass switchgear must be labelled to advise service personnel that the circuit is
connected to a UPS system.
The label can be written: ISOLATE THE UNINTERRUPTIBLE POWER SYSTEM BEFORE WORKING ON THIS CIRCUIT.
Maintainable Components
All equipment internal maintenance and servicing procedures should be carried out only by trained personnel. Removal of
components behind the protective cover requires the use of a tool and is restricted to service personnel.
The UPS meets the safety requirements completely in operator access area. Only the service personnel can contact with the
hazardous voltage inside the UPS. However, the risk of contacting with these voltages is minimized as the components with
hazardous voltage may be contacted only uses a tool to remove the protective cover. No risk will exist if you follow the
general norms and in accordance with the procedures recommended in this manual on equipment operation.

Battery Voltage Above 400Vdc
Tools or keys must be used for all batteries maintenance, which should be carried out by trained personnel.
Battery use requires special care. After the battery is connected, the voltage of the battery terminal will exceed 400Vdc, and
physical contact would be fatal.
Battery manufacturer provides the precautions to be observed when working on, or in the vicinity of the battery string. These
precautions should be followed implicitly at all times. Particular attention should be paid to the recommendations concerning
local environmental conditions and the provision of protective clothing, first aid and fire-fighting facilities.

Con t en t s
Chapter 1 Product Introduction...........................................................................................................................................
1
1.1 F
ea t ures ................................................................................................................................................................1
1.2 Model
Con fi gura ti on ..............................................................................................................................................1
1.3 Appearance And
Componen t s ..............................................................................................................................2
1.3.1
Appearance............................................................................................................................................... 2
1.3.2
Components.............................................................................................................................................. 2
1.4 Operating Principle ...............................................................................................................................................3
1.5 UPS State And Operation
Mode........................................................................................................................... 3
1.5.1 Normal
Mode .............................................................................................................................................3
1.5.2 Bypass
Mode .............................................................................................................................................3
1.5.3 Battery
Mode ............................................................................................................................................. 4
1.5.4 ECO Mode (For Single System O
n l y) ........................................................................................................4
1.5.5 Fault
State................................................................................................................................................. 4
1.6 S
pec ifi ca ti ons ........................................................................................................................................................5
Chapter 2 Installation..........................................................................................................................................................
6
2.1 Unpacking I
nspec ti on ............................................................................................................................................6
2.2
Location ................................................................................................................................................................ 6
2.2.1 Distribution
Room ......................................................................................................................................7
2.2.2 Battery
Room .............................................................................................................................................7
2.2.3 St
orage ......................................................................................................................................................7
2.3 Installation
tools.................................................................................................................................................... 7
2.4 Mechanical I
ns t a ll a ti on ..........................................................................................................................................8
2.4.1 Tower Installation ......................................................................................................................................8
2.4.2 Rack
Installation ........................................................................................................................................ 9
2.5 External Protective
Dev i ce ..................................................................................................................................10
2.5.1 Rectifier And Bypass
Inputting................................................................................................................. 10
2.5.2 Battery
Input............................................................................................................................................ 11
2.5.3 UPS Output .............................................................................................................................................11
2.6 Connecting Power Cables ..................................................................................................................................11
2.6.1 Cables S
e l ec ti on ......................................................................................................................................11
2.6.2 Connecting I/O
Cab l es .............................................................................................................................12
2.6.3 Connecting Battery
Cab l es ......................................................................................................................17
2.7 Connecting Communication
Cables.................................................................................................................... 18
2.7.1 Connecting Dry Contact Communication Cable ......................................................................................18
2.7.2 Connecting USB Communication
Cab l e ..................................................................................................19
2.7.3 Connecting SNMP Card Communication
Cable...................................................................................... 19
2.8 Parallel S
ys t em ...................................................................................................................................................20

2.8.1 Mechanical Installation............................................................................................................................20
2.8.2 Setting Parallel A
ddresses .......................................................................................................................21
2.8.3 Connecting Parallel Cables .....................................................................................................................21
2.8.4 Connecting 1 + 1 Parallel POD
Cables.................................................................................................... 22
2.9 Shared B
a tt ery ....................................................................................................................................................22
2.10 Double Bus System ..........................................................................................................................................23
2.10.1 System Installation ................................................................................................................................23
2.10.2 External Protective
Device..................................................................................................................... 23
2.10.3 Power
Cables ........................................................................................................................................ 23
2.10.4 LBS Control
Cab l es ...............................................................................................................................23
Chapter 3 Operation And Display P
ane l............................................................................................................................24
3.1 I
n t roduc ti on .........................................................................................................................................................24
3.1.1 LED I
nd i ca t ors .........................................................................................................................................24
3.1.2 Audible Alarm
( B uzzer) ............................................................................................................................24
3.1.3 Control B
u tt ons ........................................................................................................................................25
3.1.4 LCD And Menu B
u tt ons ...........................................................................................................................25
3.2 LCD Screen T
ypes ..............................................................................................................................................25
3.2.1 Start S
creen .............................................................................................................................................25
3.2.2 Primary S
creen ........................................................................................................................................26
3.2.3 Default S
creen .........................................................................................................................................26
3.3 Detailed Description Of Menu Items ...................................................................................................................27
3.4 PromptWi
ndow ...................................................................................................................................................29
3.5 UPS Alarm Message
L i s t....................................................................................................................................29
Chapter 4 UPS Operation I
ns t ruc ti ons ..............................................................................................................................32
4.1 UPS St
ar t -up .......................................................................................................................................................32
4.1.1 Normal Module Start-up P
rocedure .........................................................................................................32
4.1.2 Battery Module Start-up
Procedure ......................................................................................................... 32
4.2 Transferring Procedures Between Operation
Modes ..........................................................................................32
4.2.1 Transferring From Normal Mode To Battery
Mode ..................................................................................32
4.2.2 Transferring From Normal Mode To Bypass
Mode.................................................................................. 33
4.2.3 Transferring From Bypass Mode To Normal
Mode.................................................................................. 33
4.2.4 Transferring From Normal Mode To Maintenance Bypass
Mode ............................................................ 33
4.3 Complete Shutdown
Procedure.......................................................................................................................... 33
4.4 EPO P
rocedure ...................................................................................................................................................34
4.5 Auto
Res t ar t........................................................................................................................................................34
4.6 UPS Reset P
rocedure .........................................................................................................................................34
4.7 Language
Selection ............................................................................................................................................ 34
4.8 Changing Current Date And Ti
me .......................................................................................................................35
4.9 Controlling P
assword ..........................................................................................................................................35

Chapter 5
Ma i n t enance .....................................................................................................................................................36
5.1 Fan
Maintenance................................................................................................................................................ 36
5.2 Battery
Ma i n t enance ...........................................................................................................................................36
5.3 Cleaning UPS.....................................................................................................................................................36
5.4 Checking UPS
State........................................................................................................................................... 36
5.5 Checking UPS F
unc ti ons ....................................................................................................................................36
Appendix 1 Battery
Module ............................................................................................................................................... 38
Appendix 2 Optional Part
L i s t............................................................................................................................................40

Chapter 1 Product Introduction
1
Chapter 1 Product
I n t r oduc t i on
iTrust Adapt and 20kVA UPS (UPS for short) is an intelligent online UPS system with sine wave output developed by
Emerson Network Power Co., Ltd. The UPS offers reliable and high qualityAC power to your precision instrument.
The UPS adopts modular design, and rack/tower installation can be used depending on your requ i remen t s . It is
applicable to supplyingAC power to small scale computer center, network, communicationsystem, automatic control
system and precision instrument.
This chapter gives a brief description of the UPS, including the UPS features, model configuration, appearance,
components, operating principle, state, operation mode and specifications.
1.1 Features
iTrust Adapt UPS is compatible with iTrust Adapt 20kVA UPS. The UPS features include:
• Compatible with two modes: 3-phase mains output and single-phase mains output. You should check the
system wiring and conduct the panel setting manually
• Capable of parallel connection to achieve up to 3 + 1 parallel redundant power
• High-frequency double conversion topology structure, with high input power factor, wide input voltage range, and
output immune to grid interference, thus adaptable to areas with unstable mains supply
• High power density
• Full digital control technologybased on digital signal processor (DSP) to achieve high system reliability with
self-protection and fault diagnosis functions
• Intelligent battery management to extend the battery module life
• Operation and display panel with both LCD and LED indication to help you learn about the system operation
state and operating parameters
• 3U thickness. Tower installation and rack installation are optional to meet different installation requirements
• Capable of ECO power supply mode, which helps you save energy to the maximum extent
• Flexible network management with Emerson monitoring software
• Fan fault self-test and automatic recognition functions
• SNMP card optional, providing network communication function
• Capable of connecting multiple battery strings, extending the power supply time of Battery mode
1.2 Model Configuration
The description of model configuration is shown in Table 1-1.
Table 1-1 Model configuration
Model
Description
UHA3R-0200L
For single and parallel 1 + 1 system, four battery modules are available; for parallel system above 1 + 1,
battery connection is required

2
Chapter 1 Product Introduction
iTrust Adapt UPS 20kVA User Manual
1.3 Appearance And Components
1.3.1 Appearance
The UPS appearance is shown in Figure 1-1.
Ventilation holes
Operation and
displaypanel DIP switch, batterycoldstart
button (withprotectivecover)
Figure 1-1 UPS appearance
Note
Non-authorized personnel are prohibited from opening the UPS chassis cover. Otherwise, electric shock may occur.
1.3.2 Components
Front
p a n e l
As shown in Figure 1-1, the UPS front panel provides ventilation holes, operation and display panel, DIP switch and
battery cold start button (with protective cover). The operation and display panel provides LCD, menu buttons, LED
indicators and control buttons. Refer to Chapter 3 OperationAnd Display Panel for details.
Rear
p a n e l
As shown in Figure 1-2, the UPS rear panel provides parallel ports, load bus synchronization (LBS) ports, dry contact
I/O port, SNMP card port, USB port, I/O terminal block and ventilation holes.
Parallelports LBS ports
I/O terminalblock (withprotectivecover)
SNMP card
port
(with protectivecover)
Dry contactI/O port USB port
Ventilation holes
Figure 1-2 UPS rear panel

Chapter 1 Product Introduction
3
1.4 Operating Principle
The operating principle of the UPS is shown in Figure 1-3.
Bypass
I/O filter Rectifier/PFC Inverter
Mains
DC/DC chargerOutput
Battery
GND GND
Figure 1-3 Operating principle
1. The UPS is composed of mains input, I/O filter, rectifier/PFC, DC/DC charger, inverter, bypass, battery and UPS
output.
2. When the mains is normal, the rectifier will start, and the DC/DC charger will charge the battery string. Before
turning on the UPS, the output voltage is the bypass voltage.After turning on the UPS, the electronic transfer switch
connects the inverter output to the load, and the mains supplies DC power to the inverter through the rectifier/PFC
circuit. The inverter then converts DC power into pure sine wave AC power, and suppliesAC power to the load
through the electronic transfer switch.
3. When the mains is abnormal, the rectifier/PFC circuit boosts the battery voltage and supplies it to the inverter. The
inverter then converts it into pure sine wave AC power, and suppliesAC power to the load through the electronic
transfer switch.
4. After the mains returns to normal state, the UPS will automatically transfer from Battery mode to Normal mode, the
mains power supplies DC power to the inverter through the rectifier/PFC circuit, and then the electronic transfer
swit ch supplies DC power to the load.
1.5 UPS State And Operation Mode
The UPS state and operation mode include: Normal mode, Bypass mode, Battery mode, ECO mode and Fault state.
For the indicators introduced in this section, refer to Chapter 3 Operation And Display Panel.
1.5.1 Normal Mode
When the mains input is normal, the load is powered with voltage-stabilizing and frequency-stabilizing power by the
mains after processing of the rectifier and the inverter, and meanwhile, the operation mode that the charger charging
the battery is the Normal mode. In Normal mode, the inverter indicators are on (green).
1.5.2 Bypass Mode
If the overload overtime, inverter or rectifier failure appear during the UPS operation in Normal mode, the UPS will
transfer to Bypass mode, that is, the load is powered by the bypass source, which comes directly from the mains
input; if the rectifier is normal, the internal charger will charge the battery. In Bypass mode, the inverter indicators are
off.
Note
In the event of mains failure or mains voltage out of range in Bypass mode, the UPS will shut down and stop the output.

4
Chapter 1 Product Introduction
iTrust Adapt UPS 20kVA User Manual

Chapter 1 Product Introduction
5
1.5.3 Battery Mode
Upon mains failure, rectifier overload or mains voltage out of range, the rectifier and internal charger will become
inoperative, and the battery will supply power to the load through the inverter. The inverter indicators are on together
with buzzer alarming, which notifies you that the UPS is in Battery mode.
Note
1. The battery has been fully charged before delivery. However, transportation and storage will inevitably cause some capacity
loss. Therefore, it is required to charge the battery for eight hours before putting the UPS into operation, so as to ensure the
adequate stand time for battery.
2. The battery cold start can also be used to start the UPS from the Battery (charged) mode upon mains failure. Therefore, the
battery power can be used independently for improving the system availability to some extent.
1.5.4 ECO Mode (For Single System Only)
In ECO mode, the load is powered by bypass when the bypass voltage is normal, and the load is powered by inverter
when the bypass voltage is abnormal. ECO mode is an energy-saving operation mode. For some power equipment
that insensitive to power grid quality, you can use the ECO mode for power supply through bypass to reduce the
power loss.
Note
1. In ECO mode, if the bypass failure or abnormal bypass voltage appears when the output is not overloaded, the UPS will transfer
to Normal mode. However, if the bypass failure or abnormal bypass voltage appears when the output is overloaded, the UPS will
not transfer to Normal mode, but shut down the bypass.
2. In ECO mode, the efficiency of the UPS is up to 98%.
1.5.5 Fault State
In Normal mode, the UPS will transfer to Bypass mode if the inverter failure or UPS overtemperature appears. In
Battery mode, the UPS will shut down and stop the output if the inverter failure or UPS overtemperature appears. In
Fault state, the fault indicators will turn on, the buzzer will keep beeping, and the corresponding fault information will
be displayed on LCD panel.
Note
In Fault state, if the bypass failure or abnormal bypass voltage appears when the output is not overloaded, the UPS will shut down
and be transfered to the inverter for power supply, such as radiator overheat. However, if the bypass failure or abnormal bypass
voltage appears when the output is overloaded, the UPS will not be transfered to the inverter for power supply, but shut down the
bypass.

6
Chapter 1 Product Introduction
iTrust Adapt UPS 20kVA User Manual
1.6 Specifications
The UPS specifications are listed in Table 1-2.
Table 1-2 UPS specifications
Product model
UHA3R-0200L
Input
Rated voltage
3-phase: 380Vac
Voltage range
304Vac ~ 478Vac, at full load
228Vac ~ 304Vac, linear derating
228Vac, at half load
Rated frequency
50Hz/60Hz
Frequency range
40Hz ~ 70Hz
Power factor
≥0.99, at full load; ≥0.98, at half load
Output
Rated power
18kW
Voltage
220Vac ± 1% (3-phase balance load)
Frequency sync range
Rated frequency ± 2Hz (range is settable: ±0.5Hz ~ ±3Hz)
Frequency track rate
1Hz/s. Range is settable: 0.1Hz/s ~ 3Hz/s (single), 0.2Hz/s (parallel)
Rated power factor
0.9
Crest factor
3:1
Voltage harmonic
distortion
<2% (linear load), <5% (non-linear load)
Dynamic response
recovery time
60ms
Overload capacity
105% ~ 125%, 5min
125% ~ 150%, 1min
Bypass voltage
Upper limit: +10%, +15% or +20%; default: +15%
Lower limit: -10%, -20%, -30% or -40%; default: -20%
Mains efficiency
>93%, up to 94%
Battery
Type
Sealed, lead-acid, maintenance-free battery
Cell No.
30, 32, 34, 36, 38, 40
Rated voltage
360Vdc ~ 480Vdc
Charge power
4.5kW
Transfer time
Mains←→Battery
0ms
Inverter←→Bypass
Synchronous transfer: ≤1ms
Asynchronous transfer (default): ≤20ms
Or 40ms, 60ms, 80ms and 100ms are available
Noise
≤58dB
Panel display mode
LED and LCD
Safety
IEC/EN62040-1-1
EMC
Conduction emission
IEC/EN62040-2
Immunity
I≤16A ， IEC/EN61000-3-3; 16A<I≤75A, IEC/EN61000-3-11
Harmonic current
I≤16A
，
IEC/EN61000-3-2; 16A<I≤75A, IEC/EN61000-3-12;
YD/T1095-2001, level 2 ， 15%
Surge protection
IEC/EN-61000-4-5, enduration level 4 (4kV) (live line to earth), level 3 (2kV)
(during live lines)
Protection level
IP20
Ambient
condition
Operating temperature
0°C ~ +40°C
Storage temperature
-40°C ~ +70°C (battery excluded); -20°C ~ +55°C (battery included)
Relative humidity
5%RH ~ 95%RH, non-condensing
Altitude
<2000m; derating in accordance with GB/T3859.2 when higher than 2000m
Size
W × H × D
435mm × 130mm × 750mm
Weight
Net weight
35kg
Gross weight
38kg

iTrust Adapt UPS 20kVA User Manual
6
Chapter 2 Installation
Chapter 2
I ns t a ll a t i on
This chapter introduces the UPS installation. Each site has its peculiarity, so this chapter provides the guidance with
general installation procedures and methods for the installation engineer, who should conduct the installation
according to the actual conditions.
Warning: Professional Installation
The UPS equipment should be installed by a qualified engineer in accordance with the information contained in this chapter. If any
problem is found, please get in touch with Emerson local service center immediately.
Approved by the commissioning engineer, the UPS can be powered on.
Note: 3-phase 5-line for power input
The UPS can be connected to 3-phase 5-line (A, B, C, N, PE) TN, TT and IT AC power distribution system (IEC60364-3).
Warning: Battery Hazards
Special care should be taken into account when installing the battery. When connecting the battery, the voltage of the battery
terminal will exceed 400Vdc hazardous voltage.
• Eyeshade should be worn to prevent injury from accidental electric arcs
• Remove rings, watches and all metal objects
• Use tools with insulated handles
• Wear rubber gloves
• If a battery leaks electrolyte, or is physically damaged, it must be replaced, stored in a container resistant to sulfuric acid and
disposed in accordance with local regulations
• If your skin contacts with the electrolyte by accident, wash it immediately with water
2.1 Unpacking Inspection
After the UPS arrival, you should unpack it and check the following items:
1. Visually inspect the UPS appearance for transportation damage. If any problem is found, please notify the carrier
immediately.
2. Check the accessories and model against the delivery list. If any problem is found, please notify the dealer
immediately.
2.2 Location
To extend the UPS life, the selection of the UPS location should be:
• Convenient wiring
• Adequate operator access area
• Well-ventilated location to meet the heat rejection requirement
• Non-corrosive gas surrounded
• No excessive moisture and heat sources
• Free of dust
• Compatible with fire-fighting requirements
• Temperature of operation environment complies with the specifications, see Table 1-2 for details

Chapter 2 Installation
7
2.2.1 Distribution Room
The UPS is designed for indoor installation, which should be installed in clean and well-ventilated environment, so as
to keep the ambient temperature within the specifications range.
The internal fans provide the forced air cooling for the UPS. Cooling air enters the UPS through the front ventilation
holes, and exhausts the hot air through the back ventilation holes. Therefore, do not restrict the ventilation holes. The
front, rear and side panels of the UPS should be kept at least 200mm distance from the wall or consecutive
equipment, so as not to obstruct the UPS ventilation and heat rejection. Otherwise, the UPS internal temperature will
rise, which will shorten the UPS life.
If necessary, an indoor extractor fan should be installed to keep the indoor temperature from rising. An air filter should
be used where the UPS is to operate in a dirty environment.
Note
The UPS is only suitable for installing on the concrete surface or other non-flammable surfaces.
2.2.2 Battery Room
A small amount of hydrogen and oxygen will be generated at the end of battery charging, therefore, you must ensure
the fresh air ventilation of battery installation environment to meet the EN50272-2001 requirements.
The battery ambient temperature should be the constant temperature, for the ambient temperature is the main factor
to affect the battery capacity and life. The battery standard operating temperature is 20°C, operation above this
temperature will shorten the battery life, and operation below this temperature will reduce the battery capacity. If the
battery average temperature in operation rises from 20°C to 30°C, the battery life will be reduced by 50%; if the
battery temperature in operation exceeds 40°C, the battery life will be decreased exponentially. In general, the
enabled ambient temperature of the battery is 15°C ~ 25°C. The battery should be kept away from heat and
ventilation holes.
When the UPS uses an external battery, you must install a battery protective device (such as fuse or circuit breaker)
in areas near the battery, and use the shortest wiring distance for the protective device and battery connection.
2.2.3 Storage
The UPS must be stored indoors to protect against the excessive moisture or overtemperature environment, when
the UPS does not need to be installed immediately. The battery requires dry and low temperature, well-ventilated
environment for storage, and the most suitable storage temperature is 20°C ~ 25°C.
Warning: Battery Hazards
During the battery storage period, the battery must be periodically charged according to the battery instructions. You can connect
the UPS to the mains temporarily when charging the battery, so as to charge the battery for battery activation.
2.3 Installation tools
Prepare installation tools according to Table 2-1. The tools must be insulated and ESD-proof processed prior to
use .
Table 2-1 Installation tools list
Installation tool
Specification
Application
Cross screwdriver
EJ5100mm
Remove the protective cover of terminal
block, connect power cables
Wire-pressure plier
YT-12
Press wires for terminal block
Diagonal plier
MTC3C
Make cables

iTrust Adapt UPS 20kVA User Manual
8
Chapter 2 Installation
2.4 Mechanical Installation
Note
The UPS is suitable for resistive-capacitive load (like computer), resistive load and micro-inductive load. It is not suitable for purely
inductive load or purely capacitive load (like motor, air-conditioner and duplicator), nor can it be connected to half-wave rectifier
load.
Two installation modes are available: tower installation and rack installation. You can select an appropriate installation
mode according to the actual conditions.
According to different configuration requirements, the UPS has two configurations: battery modules excluded, and
four battery modules. For tower installation, you should prepare the battery rack and battery cabinet for installing the
battery modules; for rack installation, the battery modules and the UPS can be installed in the same rack together.
2.4.1 Tower Installation
1. Assemble a pair of support bases (accessories) and a support base extension (accessory) together through
fastenings, as shown in Figure 2-1.
Supportbase
Fastening
Support base
extension
Figure 2-1 Connecting the support base with support base extension
2. Repeat step 1 to connect another pair of support bases with a support base extension.
3. Place the UPS on the support bases and support base extensions, as shown in Figure 2-2.
Support base
UPS
Support base
Figure 2-2 Installation complete
Note
For tower installation, two pairs of support bases should be placed respectively at both sides of the UPS, as shown in Figure 2-2.
Otherwise, the UPS may be dumped.

Chapter 2 Installation
9
2.4.2 Rack Installation
Installation procedures for battery modules e xc l ud e d
1. Take out eight M4*10 screws, and fix two brackets (accessories) respectively on both sides of the UPS front panel,
as shown in Figure 2-3.
UPS
Bracket (2 pcs) Screw(8 pcs)
Figure 2-3 Installing brackets
Note
Moving the UPS through brackets is prohibited.
2. Place the UPS on the guide rails in the rack, and push it completely into the rack. Take out four M6*16 screws to fix
the UPS on the rack through brackets, as shown in Figure 2-4.
Guide
rail
Rack
UPS
Bracket
Screw(4 pcs)
Figure 2-4 Installing the UPS
Installation procedures for battery modules i n c l ud e d
The installation method of the battery module is the same as that of the UPS. Repeat the above procedures to install
and fix the four battery modules and UPS on the rack one by one. As the battery module is heavy, you should pay
attention to the following items in installation:
• Two persons or more are required for the installation
• Install the battery module, start the installation from the bottom, and then place the UPS onto the top, as shown
in Figure 2-5
• Moving the UPS and battery modules through brackets is prohibited

iTrust Adapt UPS 20kVA User Manual
10
Chapter 2 Installation
UPS (1
piece)
Battery
module
(4 pcs)
Figure 2-5 UPS installation diagram of battery modules included
2.5 External Protective Device
The circuit breaker or other protective devices must be installed at the external AC input port of the UPS. This section
provides the general guidance for qualified installation engineer. The qualified installation engineer should learn about
the local wiring regulations for the equipment to be installed.
2.5.1 Rectifier And Bypass Inputting
O
v e r c u rr e n t
The appropriate overcurrent protective device should be installed on the mains input distribution, and the current
capacity of power cable and the system overload requirements should be taken into account in installation (see Table
1-2). It is generally recommended to use the thermomagnet circuit breaker of IEC60947-2 tripping curve C (normal),
when the current value reaches 125% of the current value listed in Table 2-2.
Split-bypass:When the system adopts split-bypass, the protective devices should be respectively installed at the
mains input distribution for mains and bypass.
Main/Bypass reflected p r o t e c t i on
When using the main/bypass reflected protection function, the gross mains input needs to be equipped with the
protective device with auxiliary contact function. The recommended model is S1N125 R125 TM FFC 4P + 1A + 1B +
YO (220Vac).
Note
The same neutral must be used for the rectifier and bypass power.
For IT power grid system, the protective device with four poles must be installed at the UPS external I/O distribution.
Earth leakage
c u rr e n t
The residual current detector (RCD) for the UPS upstream input distribution should be:
• Sensitive to the DC unidirectional pulse (level A) in distribution network
• Insensitive to the transient current pulse
• General sensitivity type, settable: 0.3A ~ 1A
