WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death or
property damage.
— Do not store or use gasoline or other
ammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch;
do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier
from a neighbor’s phone. Follow
the gas supplier’s instructions.
• If you cannot reach your gas
supplier, call the re department.
— Installation and service must be
performed by a qualied installer,
service agency or the gas supplier.
This appliance may be installed in an aftermarket,
permanentlylocated,manufacturedhome(USA
only) or mobile home, where not prohibited by
state or local codes.
This appliance is only for use with the type of
gas indicated on the rating plate. This appliance
is not convertible for use with other gases,
unless a certied kit is used.
WARNING
If not installed, operated and maintained in
accordance with the manufacturer’s instructions,
this product could expose you to substances in
fuel or from fuel combustion which can cause
death or serious illness.
NOTICE: Barrier required, but may be sold separately.
HOT GLASS
DO NOT TOUCH
NEVER
WILL
CAUSE BURNS.
GLASS
UNTIL COOLED.
ALLOW CHILDREN
TO TOUCH GLASS.
WARNING
A barrier designed to reduce the risk of burns from the
hot viewing glass is provided with this appliance and shall
be installed for the protection of children and other at-risk
individuals.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
INSTALLATION INSTRUCTIONS
AND OWNER’S MANUAL
DIRECT-VENT ZERO
CLEARANCE GAS FIREPLACE
HEATER MODEL SERIES:
MULTIFUNCTION REMOTE (MF)
DVCX36FP91K(N,P)-3
GAS-FIRED
MH30033

41366-0-0120Page 2
BEFORE YOU START
1. Read the safety information on Pages 60 - 62.
2. If located in the Commonwealth of Massachusetts, please note the special requirements on Page 63.
3. Where are you going to install the unit? See Page 14.
4. Frame the opening. See Page 15.
5. Install the gas lines. See Page 13.
6. Install the wiring. See Pages 14 and 45.
7. Install the venting. See Pages 19 - 24.
8. Installthereplace.SeePages15-18.
9. Connect the gas. See Pages 13.
10. Install the logs. See Pages 31 - 42.
11. Lightthereplaceandtroubleshoot.SeePages43and58-59.
12. Install trim and other accessories. See Page 7.
13. Showthehomeownerhowtooperatethereplace.
14. Show the homeowner how to do the basic maintenance.

41366-0-0120 Page 3
TABLE OF CONTENTS
Carton Contents............................................................................................................................................................4
Introduction...................................................................................................................................................................5
Specications................................................................................................................................................................6
Hardware Package .......................................................................................................................................................7
Accessories ..................................................................................................................................................................7
Fireplace Dimensions ...................................................................................................................................................8
Clearances.............................................................................................................................................................. 9-10
Combustible Material..................................................................................................................................................10
Vent Termination Clearances......................................................................................................................................11
Vent Termination Clearances......................................................................................................................................12
Gas Supply .................................................................................................................................................................13
Locating Fireplace ......................................................................................................................................................14
Electrical Considerations ............................................................................................................................................14
Installation........................................................................................................................................................... 15 - 18
VentSystemIdentication ..........................................................................................................................................19
Vent Systems..............................................................................................................................................................19
Venting Fireplace ................................................................................................................................................ 20 - 22
Top Vent - Horizontal Termination...............................................................................................................................23
Top Vent - Vertical Termination ...................................................................................................................................24
Vertical Termination ............................................................................................................................................ 25 - 26
Framing And Finishing ........................................................................................................................................ 27 - 28
DVVK-5F Flex Vent Instructions ......................................................................................................................... 29 - 30
Liner Placement..........................................................................................................................................................31
Glowing Embers .........................................................................................................................................................31
LogIdentication.........................................................................................................................................................32
Log Placement.................................................................................................................................................... 33 - 42
Lighting Instructions....................................................................................................................................................43
IPI System Wiring Diagram.........................................................................................................................................44
Remote Control Operation Instructions .............................................................................................................. 45 - 50
Intermittent Pilot Parts View........................................................................................................................................52
Intermittent Pilot Parts List..........................................................................................................................................53
Fireplace - All Units Parts View...................................................................................................................................54
Fireplace - All Units Parts List.....................................................................................................................................55
Maintenance And Service ................................................................................................................................... 56 - 57
Control System Troubleshooting......................................................................................................................... 58 - 59
Important Safety Information .............................................................................................................................. 60 - 61
Safety Information For Users Of Propane Gas...........................................................................................................62
Requirements For Massachusetts..............................................................................................................................63
Master Parts Distributor List .......................................................................................................................................64
How To Order Repair Parts.........................................................................................................................................64
Appliance Service History................................................................................................................................... 65 - 67
Warranty .....................................................................................................................................................................68
SECTION PAGE

41366-0-0120Page 4
CARTON CONTENTS
12
5
6
7
3
4
NAT
NAT
4
LP
LP
8
INDEX
NUMBER DESCRIPTION QTY SUPPLIED
1 Rock Wool 2
2 Receptical Cover 2
3 Receptical 2
4Flue Restrictor Assembly -
Natural or Propane 1
5 Hardware Pack 1
6 AA Battery 4
7 AAA Battery 3
8 Remote 1
Not Shown Log Set (see Page 32) 1 set
Not Shown Fireplace 1
Not Shown Accessory Sheet 1
Not Shown Product Registration Card 1
See Parts Lists on Pages 52 - 55 for ordering replacement parts.
Do not order batteries, bolts, screws, washers or nuts. They are
standard hardware items and can be purchased at any local
hardware store.
NATURAL PROPANE

41366-0-0120 Page 5
Instructions to Installer
1. Installer must leave instruction manual with owner after
installation.
2. Installer must have owner ll out and mail product
registrationcardsuppliedwiththereplace.
3. Installer should show owner how to start and operate the
replace.
Thisdirectventgasreplaceheaterisdesignedtooperate
with all combustion air being siphoned from the outside of the
building and all exhaust gases expelled to the outside of the
building. The information contained in this manual pertains to
all models and gas control systems unless otherwise noted.
Appliance Certication
WARNING
This unit is not for use with solid fuels.
ThisreplaceisdesigncertiedinaccordancewithAmerican
National Standard/CSAStandardANSI Z21.88/CSA2.33 and
by Underwriters Laboratories as a Direct Vent Gas Fireplace
Heater and shall be installed according to these instructions.
Consult your local building code agency, prior to installation,
to ensure compliance with local codes-including permits and
inspections.
Thereplace,wheninstalled,mustbeelectricallygrounded
in accordance with local codes or, in absence of local codes,
with the National Electric Code ANSI/NFPA 70 or Canadian
Electric code, CSA C22.1, if an external electrical source is
utilized.
These models may be installed in a bedroom or bed-sitting
room in the U.S.A. and Canada.
Qualied Installing Agency
Installation and replacement of gas piping, gas utilization
equipment or accessories and repair and servicing of
equipmentshallbeperformedonlybyaqualiedagency.The
term“qualiedagency”meansanyindividual,rm,corporation
or company which either in person or through a representative
is engaged in and is responsible for (a) the installation or
replacement of gas piping or (b) the connection, installation,
repair or servicing of equipment, who is experienced in such
work, familiar with all precautions required and has complied
with all the requirements of the authority having jurisdiction.
Commonwealth of Massachusetts: The installation
mustbemadebyalicensedplumberorgastterinthe
Commonwealth of Massachusetts.
WARNING
ANY CHANGE TO THIS FIREPLACE OR ITS
CONTROLS CAN BE DANGEROUS.
Improper installation or use of the replace can cause
serious injury or death from re, burns, explosions,
or carbon monoxide poisoning.
The installation must conform with local codes or, in the
absence of local codes, with the National Fuel Gas Code
ANSI Z223.1/NFPA54* Natural Gas and Propane Installation
Code, or CSA B149.1 in Canada. *Available from the American
National Standards Institute, Inc. 11 West 42nd St., New York, N.Y. 10036.
Any alteration of the original design, installed other than
as shown in these instructions or use with a type of gas
not shown on the rating plate is the responsibility of the
person and company making the change.
Important
All correspondence should refer to complete Model Number,
Serial Number and type of gas.
High Altitude
When installing this unit at an elevation above 2000 feet (in
the United States) it may be necessary to decrease the input
ratingbychangingthe existing burner oricetoasmaller
size. Generally, input should be reduced 4 percent for each
1000 feet above sea level. However, if the heating value of
the gas has been reduced, this general rule may not apply.
CheckwithEmpireComfortSystemsforproperoricesize
identication.
Canadian High Altitude
Altitude: 0-4500 feet (0-1370 m)
When installing this unit at an elevation above 4500 feet (in
Canada), check with Empire Comfort Systems.
Consult your Empire Comfort Systems for assistance in
determiningtheproperoriceforlocation.
Preparation
Thisdirectventgasreplaceanditscomponentsaretested
and safe when installed in accordance with this Installation
Manual. Report to your dealer any parts damaged in shipment,
specically check glass condition. Do not install unit with
damaged, incomplete, or substitute parts. Read all instructions
before starting installation and follow these instructions
carefullyduringinstallationtoinsuremaximumbenetand
safety. Failure to follow them will void your warranty and may
presentarehazard.
The warranty will be voided by, and the warranter disclaims
any responsibility for the following actions:
• Installation of any damaged replace or vent system
component.
• Modicationofthereplaceordirectventsystem.
• Installation other than as instructed by Empire Comfort
Systems Inc.
• Improper positioning of the logs, glass door or decorative
rock.
• Installation and/or use of any component part not
manufactured or approved by manufacturer.
INTRODUCTION

41366-0-0120Page 6
SPECIFICATIONS
DVCX36NAT DVCX36LP
Input BTU/Hr Maximum 37,000 34,000
Input BTU/Hr Minimum 26,000 27,000
KWH (Maximum) 10.84 9.96
KWH (Minimum) 7.62 7.91
Orice(Front/Rear) 47 / 42 58 / 1.45
Air Shutter Opening 3/16 FULL OPEN
Height without standoff 36-7/8 36-7/8
Width 39-5/16 39-5/16
Depth 21-1/16 21-1/16
Gas Inlet Shutoff Valve (pipe) 1/2 NPT 1/2 NPT
Vent Size 5 x 8 5 x 8
NOTE: Airshutter settingsarefactory minimumsettings. Someventing congurationsmay requireminor airshutter adjustmentsfor
optimum performance.
NOTE:Theglassusedinyourreplaceisceramicglass.Iftheglassiscrackedordamagedinanyway,itshouldbereplacedonlywitha
complete glass frame assembly from Empire. See parts list on Pages 52 - 55 for ordering.
GAS SUPPLY PRESSURES
GAS TYPE MAXIMUM MINIMUM MANIFOLD
Natural 14 4.5 3.5
Propane 14 11 10
NOTE: For gas pipe dimensions, see Page 13.

41366-0-0120 Page 7
The following parts can be obtained from your Empire Comfort Systems dealer. Contact your Empire Dealer for more accessory options.
If you need additional information beyond what your dealer can furnish, contact Empire Comfort Systems Inc., 918 Freeburg Ave., Bel-
leville, Illinois 62220-2623.
ACCESSORIES
HARDWARE PACKAGE
Model Number Description Used On
DF362NB Beveled Window Frame, Brushed Nickel DVCX36
DF362BZ Beveled Window Frame, Oil Rubbed Bronze DVCX36
DVD36XBLNB Decorative Door, Brushed Nickel DVCX36
DVP36XCB Ceramic Fiber Liner, Rustic Brick DVCX36
DVP36XWS Ceramic Fiber Liner and Floor, Old World Stone DVCX36
DVP36XKR ReectiveLiner,Black DVCX36
DVF36XKR ReectiveFloor,Black DVCX36
DCA1ABL Decorative Forged Andirons, Black DVCX36
Conversion Kits Description Used On
35401 Conversion Kit, DV (Natural to Propane) ADVCX36FP91
35402 Conversion Kit, DV (Propane to Natural) ADVCX36FP91
HEX HEAD SCREW 10 X 1/2

41366-0-0120Page 8
FIREPLACE DIMENSIONS
INDEX
LETTER DIMENSION DESCRIPTION
DIMENSIONS
(In Inches)
DVCX36FP
AThemaximumheightofreboxface(excludingstandoffs) 41-7/8
BThemaximumwidthofthereboxface(excludingnailinganges) 42-1/4
CThemaximumdepthoftherebox 22-1/16
DTheheightofthereboxopening 27-1/2
EThewidthofthereboxopening 35-15/16
FTheinteriordepthoftherebox 15-1/4
GTherearexteriorwidthoftherebox 28-3/8
HTheheighttothereboxstandoffs 42-1/8
I Width from the left side of the box to the centerline of vent 19-1/8
J Depth from back of box to centerline of top vent 7-11/16
K Height from the bottom of the box to the gas line opening 2
L Depth from the front of the box to gas line opening 4-1/2
M Depth from rear of box to gas line opening 17-1/2
N Glass frame opening height 24
O Glass frame opening width 32-7/8
P Depth from front of box to centerline of vent 14-3/8
QDistancefromoortoreplaceopening 31
RHeightfromoortoventcollar 33-9/16
S Maximum hearth size 1
G
J
P
I
O
A
Q
N
B
E
D
F
H
R
KLM
C
S

41366-0-0120 Page 9
CLEARANCES
CLEARANCE TO COMBUSTIBLES
Back Stand-off 0" (0 mm)
Side Stand-off 0" (0 mm)
Floor 0" (0 mm)
Top Stand-off 0" (0 mm)
Top Framing Edge 6”(152mm)
GLASS FRONT
TOPFRAMING
LEDGE
FINISHED WALL
(COMBUSTIBLE)
2" x 4" HEADER
NAILING
FLANGES
SEE MANTEL CHART FOR
MAXIMUM MANTEL DEPTH
SEE MANTEL CHART
FOR MINIMUM HEIGHT
OF MANTEL ABOVE UNIT
STAND-OFF
6” (152mm) HEIGHT
ABOVE TOPOF
FIREPLACE
REAR
STAND-OFF
SIDE
STAND-OFF
Figure 1
NOTE: Generic Firebox shown.
Mantel Chart
TOP EDGE OF FIREPLACE OPENING
INDEX
LETTER
DIMENSIONS (In Inches)
Distance From Top
Edge Of Fireplace
Opening
(HORIZONTAL)
Distance
From
Fireplace Front
(VERTICAL)
A 12 25-1/2
B 10 25-1/2
C 8 23-3/4
D 6 22-1/8
E 4 20-3/8
F 2 18-3/4
G 0 17
Figure 2

41366-0-0120Page 10
WARNING
This replace has not been tested nor approved to have a
television or other electrical appliance installed above it.
Clearancefrombottomofreplacetoceilingis84inches.Clearance
fromsideofreplacetoadjacentsidewallis6inches.
Television Considerations
Installingatelevisionaboveareplacehasbecomeincreasingly
popular;however,theareaaboveanyreplacegetshotandmost
TV manufacturers recommend against placing their products near
a heat source.
Ifyouinstallatelevisionabovethisreplace,EmpireComfortSys-
tems accepts no responsibility for damage or injuries. Follow the
television manufacturer’s installation instructions, including any
recommendations regarding proximity to heat sources.
IfyouhaveaTVaboveyourreplace,turnoffthereplaceand
let it cool completely before servicing or touching any buttons on
the TV.
CLEARANCES (CONT’D)
Donotattachcombustiblematerialtothemantelofyourreplace.
Thisisarehazard.
Figure 5
NOTE: Generic Firebox shown.
No greeting cards, stockings or ornamentation of any type should be
placedonorattachedtothereplace.Thisisaheatingappliance.
Theowofheatcanignitecombustibles.
Figure 6
NOTE: Generic Firebox shown.
COMBUSTIBLE MATERIAL
Figure 3
Figure 4

41366-0-0120 Page 11
Termination clearance for buildings with combustible and noncombustible exteriors.
Vertical Sidewall Installations
Important! Minimum clearance between vent pipes and combustible
materials is 3 inches (76 mm) on top, and 1 inch (25 mm) on bottom
and sides.
Important! When vent termination exits through foundation less
than 20 inches (508 mm) below siding outcrop, the vent pipe must
extend outward so that the horizontal vent termination is located
ushto,orbeyondtheoutcropsiding.
Information on Various Venting Routes and Components
Important:Itisalwaysbesttolocatethereplaceinsuchaway
that minimizes the number of offsets and horizontal vent length.
Since it is very important that the venting system maintain its balance
betweenthecombustionairintakeandtheuegasexhaust,certain
limitations as to vent congurations apply and must be strictly
adhered to.
Figure 7
VENT TERMINATION CLEARANCES
The graph showing the relationship between vertical and horizontal
side wall venting will help to determine the various vent lengths
allowable.
The horizontal vent run refers to the total length of vent pipe from
theuecollarofthereplacetothefaceoftheouterwall.
The maximum horizontal vent run is 20 feet (6.10 m) when the
vertical vent rise is 8 feet (2.44 m). See Page 22, Figure 33.
Venting termination shall not be recessed into wall or siding.
ATTENTION: Vinyl Soft, Vinyl Ceiling, Vinyl Overhang
Disclaimer
Clearances are to heat resistant material (i.e. wood, metal). This
does not include vinyl. Empire Comfort Systems Inc. will not be held
responsible for heat damage caused from terminating under vinyl
overhangs,vinylceilingsorvinylventilated/unventilatedsofts.

41366-0-0120Page 12
VENT TERMINATION CLEARANCES (CONT’D)
Canadian Installations1 US Installations2 Canadian Installations1 US Installations2
A= Clearance above grade,
veranda, porch, deck, or
balcony
12 in (30 cm) 12 in (30cm) I= Clearance to service
regulator vent outlet 3 ft (91 cm) 6 ft
B= Clearance to window or
door that may be open
6 in (15 cm) for appli-
ances≤10,000Btuh
(3 kW), 12 in (30 cm)
for appliances > 10,000
Btuh(3kW)and≤
100,000 Btuh (30 kW),
36 in (91 cm) for appli-
ances > 100,000 Btuh
(30 kW)
6 in (15 cm) for appli-
ances≤10,000Btuh(3
kW), 9 in (23 cm) for ap-
pliances > 10,000 Btuh
(3kW)and≤50,000
Btuh (15 kW), 12 in
(30 cm) for appliances >
50,000 Btuh (15 kW)
J= Clearance to nonme-
chanical air supply
inlet to building or the
combustion air inlet to
any other appliance
6 in (15 cm) for appli-
ances≤10,000Btuh(3
kW), 12 in (30 cm) for
appliances > 10,000
Btuh(3kW)and≤
100,000 Btuh (30 kW),
36 in (91 cm) for appli-
ances > 100,000 Btuh
(30 kW)
6 in (15 cm) for appli-
ances≤10,000Btuh
(3 kW), 9 in (23 cm) for
appliances > 10,000 Btuh
(3kW)and≤50,000Btuh
(15 kW), 12 in (30 cm) for
appliances > 50,000 Btuh
(15 kW)
C= Clearance to perma-
nently closed window 12 in (30 cm) 12 in (30 cm)
K= Clearance to a mechani-
cal air supply inlet 6 ft (1.83 m)
3 ft (91 cm) above if
within 10 ft (3 m) hori-
zontally
D= Vertical clearance
ventilatedsoftlocated
above the terminal within
a horizontal distance of 2
feet (61 cm) from the cen-
ter line of the terminal
24 in (61 cm) 24 in (61 cm)
L= Clearance above paved
sidewalk or paved drive-
way located on public
property 7 ft (2.13 m) † 7 ft (2.13 m) †
E= Clearance to unventi-
latedsoft 12 in (30 cm) 12 in (30 cm)
M= Clearance under
veranda, porch deck, or
balcony
12 in (30 cm) ‡ 12 in (30 cm) ‡
F= Clearance to outside
corner 6 in (15 cm) 6 in (15 cm) 1 In accordance with the current CSA B149.1, Natural Gas and Propane Instal- lation Code
G= Clearance inside corner 9 in (23 cm) 9 in (23 cm) 2 In Accordance with the current ANSI Z223.1/NFPA 54, National Fuel Gas
Code
H= Clearance to each side
of center line extended
above meter/regulator
assembly
3 ft (91 cm) within a
height 15 ft (4.5 m)
above the meter/regula-
tor assembly
3 ft (91 cm)
† A vent shall not terminate directly above a sidewalk or paved driveway that is
located between two single family dwellings and serves both dwellings
ATTENTION: Vinyl Soft, Vinyl Ceiling, Vinyl Overhang
Disclaimer
Clearances are to heat resistant material (i.e. wood, metal). This
does not include vinyl. Empire Comfort Systems Inc. will not be held
responsible for heat damage caused from terminating under vinyl
overhangs,vinylceilingsorvinylventilated/unventilatedsofts.
‡Permitted only if veranda,, porch, deck, or balcony is fully open on a minimum
oftwosidesbeneaththeoor.
*ForclearancesnotspeciedinANSIZ223.1/NFPA54orCSAB149.1,oneof
the following shall be indicated:
a) A minimum clearance value determined by testing in accordance with section
2.23.5, or;
b) A reference to the following footnote: “Clearance in accordance with local
installationcodesandtherequirementsofthegassupplier.”
Figure 8

41366-0-0120 Page 13
GAS SUPPLY
The gas pipeline can be brought in through the right or left side of
the appliance. Consult the current National Fuel Gas Code, ANSI
Z223.1 CAN/CGA-B149 (.1 or .2) installation code.
Recommended Gas Pipe Diameter
Pipe
Length
Schedule 40 Pipe
Inside Diameter
Tubing, Type L
Outside Diameter
Natural Propane Natural Propane
0-10 feet 1/2” 3/8” 1/2” 3/8”
10-40 feet 1/2” 1/2” 5/8” 1/2”
40-100 feet 1/2” 1/2” 3/4” 1/2”
100-150 feet 3/4” 1/2” 7/8” 3/4”
NOTE:Neveruseplasticpipe.Checktoconrmwhetheryour
local codes allow copper tubing or galvanized.
NOTE: Since some municipalities have additional local codes, it
is always best to consult your local authority and installation code.
The use of the following gas connectors is recommended:
— ANSI Z21.24Appliance Connectors of Corrugated Metal Tubing
and Fittings.
— ANSI Z21.45 Assembled Flexible Appliance Connectors of
Other Than All-Metal Construction
The above connectors may be used if acceptable by the authority
having jurisdiction. The Commonwealth of Massachusetts requires
thataexibleapplianceconnectorcannotexceedthreefeetinlength.
Figure 9
Gas Supply Pressure (inches w.c.)
Minimum Normal Maximum
Natural Gas 4.5" 7.0" 14.0"
Propane Gas 11” 11.0" 14.0"
Manifold Pressure (inches w.c.)
Normal (HI)
Natural Gas 3.5"
Propane Gas 10.0"
Installing a New Main Gas Shut-Off (Check Local Code)
Each appliance should have its own manual gas shut-off.
A manual main gas shut-off should be located in the vicinity of the
unit. Where none exists, or where its size or location is not adequate,
contact your local authorized installer for installation or relocation.
Compounds used on threaded joints of gas piping shall be resistant
totheactionofliqueedpetroleumgases.Thegaslinesmustbe
checked for leaks by the installer. This should be done with a soap
solution watching for bubbles on all exposed connections, and if
unexposed, a pressure test should be made.
Never use an exposed ame to check for leaks. Appliance must
be disconnected from piping at inlet of control valve and pipe
capped or plugged for pressure test. Never pressure test with
appliance connected; control valve will sustain damage!
The appliance and its individual shut-off valve must be disconnected
from supply piping system during any pressure testing of that system
at test pressures in excess of 1/2 psig (3.5 kPa).
The appliance must be isolated from the gas supply piping system
by closing its individual manual shut-off valve during any pressure
testing of the gas supply piping system at test pressures equal to
or less than 1/2 psig (3.5 kPa).
Attention! If one of the procedures results in pressures in excess
of1/2psig(14”w.c.)(3.5kPa)onthereplacegasvalve,itwill
result in a hazardous condition.
Checking Manifold Pressures
Both Propane and Natural Gas valves have a built-in pressure
regulator in the gas valve. Natural Gas models will have a manifold
pressure of approximately 3.5 inch w.c. (.871 kPa) at the valve outlet
with the inlet pressure to the valve from a minimum of 4.5 inch w.c.
(1.120 kPa) for the purpose of input adjustment to a maximum
of 14.0 inch w.c. (3.484 kPa). Propane Gas models will have a
manifold pressure approximately 10.0 inch w.c. (2.49 kPa) at the
valve outlet with the inlet pressure to the valve from a minimum of
10.8 inch w.c. (2.68 kPa) for the purpose of input adjustment to a
maximum of 14.0 inch w.c. (3.484 kPa).
2” 4 1/2”
Figure 10

41366-0-0120Page 14
Figure 11
NOTICE: Island and Room Divider installation is possible as long as the horizontal portion of the vent system does not exceed 20 feet
with a minimum vertical run of 8 feet. See details in Venting Section.
NOTICE: When installing this appliance against an exterior wall, insulate to applicable insulation codes.
When you install your Direct Vent Fireplace in Room divider or Flat on wall corner positions, a minimum of 6 inches clearance must be
maintained from the perpendicular wall and the front edge of the appliance.
LOCATING FIREPLACE
ELECTRICAL CONSIDERATIONS
CAUTION
All wiring should be done by a qualied electrician and
shall be in compliance with all local, city and state building
codes. Before making the electrical connection, make sure
that the main power supply is disconnected. The appliance,
when installed, must be electrically grounded in accordance
with local codes, or in the absence of local codes, with the
National Electrical Code ANSI/NFPA 70 (Latest Edition).
A factory installed junction box is located on the lower right side of
thereplace.Wiringmustbefedtothejunctionboxandattached
to the receptacle that is provided. Leave approximately 6 inches of
wire in the junction box for connection.
Attach black wire to brass colored screw on the receptacle and white
wire to the silver colored screw on the receptacle. The ground wire
should be attached to the green (ground) screw.
Install the receptacle into the junction box. Attach cover plate.
Figure 12

41366-0-0120 Page 15
INSTALLATION
Framing
Fireplaceframingcanbebuiltbeforeorafterthereplaceisset
in place. Framing should be positioned to accommodate wall
coveringandreplacefacingmaterial.Thereplaceframingshould
be constructed of 2 x 4 lumber. The framing headers may rest on
thereplace standoffs.Refer toFigure 13 for minimum framing
dimensions.
ATTENTION: Measure replace dimensions and verify framing
methods and wall covering details before framing construction be-
gins.
Framing dimension "A" includes a six inch clearance for
standoffs on rebox. After installing rebox into framing,
the nished wall surface must cover the six inch opening
above the rebox.
DIMENSIONS (In Inches)
Dim. DVCX36
A 42-5/16
B 42-3/8
C 21-1/2
Figure 13
Framing and Finishing
1. Choose unit location.
2. Frameinreplacewithaheaderacrossthetop.Itisimportant
toallowfornishedfacewhensettingthedepthoftheframe.
3. Attachreplacetoframeusingadjustableframe.Presetdepth
to suit facing material (adjustable to 1/2, 5/8 or 3/4-inch depths).
4.
Locatethenailing angesonthesidesof therebox(two
each side) .
6. Measurefromfaceofreplacetofaceofdrywallstriptodetermine
naldepthandadjustnailingangesasshowninFigure 14.
3/4”
1/2”
3/4”
1/2”
Figure 14
7. Bendthenailinganges90degrees.
Figure 15

41366-0-0120Page 16
Figure 18 - Flush Wall Installation
Figure 19 - Combustible Surround Installation
INSTALLATION (CONT’D)
Vent Pipe Clearance
NOTE: Maintain two inches of clearance around vertical vent pipe
onrsttwelveinches.See Figure 16.
For horizontal vent, maintain a minimum one-inch clearance to
the bottom and sides of the vent, and three-inch clearance to
combustibles above the vent pipe. See Figure 17.
NOTE: Atwo-inchclearancearoundpipeforthersttwelveinches
abovethereplaceisrequired.
Figure 16
Figure 17 - Horizontal Vent Clearances

41366-0-0120 Page 17
INSTALLATION (CONT’D)
Attention: Cold climate installation recommendation: When
installing this unit against a non-insulated exterior wall, the outer
walls should be insulated to conform to applicable codes.
Finishthejointbetweenthereplaceandwallwithsealantrated
at 300 degrees F, or tile/stone over the joint.
Vent Runs
Inplanningtheinstallationforthereplace,itisnecessarytoinstall
certain components before the appliance is completely positioned
and installed. These include the direct vent system, gas piping for
the appliance and the electrical wiring. (If the fan option is used.)
The appliance can be mounted on any of the following surfaces:
1. Aat,hardcombustible(burnable)surface.
2. A raised wooden platform.
3. Four corner supports. (Example: Four concrete masonry blocks.)
These supports must be positioned so they contact all four
perimeter edges on the bottom of the unit.
Securing the Vent Pipe to the Fireplace
1. Hand bend the tabs up on the Outer Wrapper Top Assembly
as shown in Figure 20.
Figure 20
2. Inserttherstpieceofpipeandsecurewith4screwsthrough
the tabs and into the pipe. See Figures 21 and 22.
Figure 21
Figure 22
VERTICAL, 90-DEGREE ELBOW WITH HORIZONTAL
TERMINATION
3” (76mm)
MINIMUM CLEARANCE
TO COMBUSTIBLES
VENT CAP/
THIMBLE
WALL FIRESTOP
“A”
DISTANCE
TO BOTTOM
OF UNIT
12 INCH
RISE
REQUIRED
A DIMENSION (In Inches)
DVCX36 57-1/2
Figure 23

41366-0-0120Page 18
INSTALLATION (CONT’D)
VERTICAL, 90-DEGREE ELBOW TO HORIZONTAL OUT THE
WALL (12 inch minimum rise before elbow)
DIMENSIONS (In Inches)
A B C
9 14 to 15-1/2 4-3/4 to 6-1/4
12 17 to 18-1/2 4-3/4 to 9-1/4
18 20 to 21-1/2 10-3/4 to 12-1/4
Figure 24
CORNER INSTALLATION - VERTICAL, 90-DEGREE ELBOW
TO HORIZONTAL OUT THE WALL (12 inch minimum rise
before elbow)
DIMENSIONS (In Inches)
DIM. DVCX36
A 47
B 33-1/4
C 13-3/4
D 66-3/8
Figure 25
After installing the vent system, install ue heat shield.
1. Handbendtabsonueheatshieldout90°.
2. Attach to insulation box as shown in (Figure 26).
Figure 26 (vent pipe removed for clarity)

41366-0-0120 Page 19
Begin the vent system installation by selecting the type of venting
to be installed and the path that it will take. Verify that clearances
are met throughout the path of the venting system.
Determine how the vent system will be terminated out the side of
the house or through the roof. Verify clearances for the termination.
Whenselectingaventsystemforusewiththereplace,referto
the “Special Vent Systems” section in this manual to determine
what systems are acceptable. Check all clearances and venting
components. Identify if any problems existing in the vent system.
Use (Figure 33) on Page 22 for venting to eliminate issues after
installation.Checkpipediameteronventsystemandreplaceto
verify the size is the same.
NOTICE: All outer connection joints must be sealed with aluminum
tape,screwsorsiliconesealantratedabove300°F/149°C.Theinner
uejointsdonotrequireanysealant.
Figure 27
VENT SYSTEM IDENTIFICATION
SPECIAL DV VENT KITS
Available from Empire Comfort Systems, Inc. dealers.
DVVK-5TP
Direct-Vent Fireplace Vent Kit for Top Vent,
Thru-the-wall, 4 to 6 inch wall thickness, Includes
58DVA-E90, 58DVA-HC, 58DVA-06, and 58DVA-
WTEC
DVVK-5VP Direct Vent Fireplace Vent Kit - Vertical, Includes
58DVA-VCH, 58DVA-SC, and 58DVA-F6
DVVK-5F Horizontal Flex Vent Kit (4' Flex) (1.22m)
(requires 58DVA-06 pipe)
Forventingareplacethroughthetop,seePage22.
VENT SYSTEMS
• Simpson Duravent® GS
• Simpson Duravent® DVA-H2
• American Metal Products (round cap only)
• Selkirk Direct-Temp®
• Security Secure Vent®
• Excel DV Venting
•
• Empire Horizontal Flex Vent Kit DVVK-5F
– 6 inch piece of hard pipe is required.
 (Seeexventinstructionsection)
• Metal Fab Sure Seal®
– Adapter is required to use this vent
Contact Metal Fab
Use one of the following 5 inch x 8 inch vent systems:

41366-0-0120Page 20
VENTING FIREPLACE
CAUTION
Use ue restrictor for vertically terminated units only. Do
not use for horizontally terminated units. Incorrect usage
may cause sooting.
Figures 28 and 29 shows the location and recommended open-
ingsfortheuerestrictor.Adjustmentsmaybemadeforeachpar-
ticular installation.
Figure 28
Figure 29
The minimum hole location dimensions for through the wall
horizontal installations with a 90 degree elbow and 12 inch rise
off the top of the replace.
A
FIREPLACE
SERIES
HARD ELBOW DIMENSIONS (in inches)
A B C D
DVCX36 51-1/2 5-5/16 7-5/16 10-5/8
Figure 30
