INSTALLATION INSTRUCTIONS
AND OWNER’S MANUAL
GREAT LAKES OAK
VENTED DECORATIVE
GAS LOG SET
MODELS
LGLO(18,24,30)-1
For use on burner models:
BX(L,M,R)(18,24,30)MTN-1
LGLO18-1 LOGS SHOWN
WARNING
FIRE OR EXPLOSION HAZARD
If the information in this manual is not
followed exactly, a re or explosion may
result causing property damage, personal
injury or loss of life.
— Do not store or use gasoline or other
ammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions.
• If you cannot reach your gas supplier,
call the re department.
— Installation and service must be
performed by a qualied installer,
service agency or the gas supplier.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
CONGRATULATIONS on the purchase of your
new DECORATIVE VENTED GAS LOG SET!
Your Decorative Gas Log Set is designed
and intended for installation in an approved,
existing, fully vented, wood-burning re-
place, with a gas hook-up.
Once you place the base logs, you are free
to arrange the remaining logs to suit your
taste. The log placement shown in this man-
ual replicates the set-up shown in the bro-
chure and provides a great ame pattern.
IMPORTANT! Read these instructions
carefully before installing or operating this
gas appliance. These instructions should be
left with the homeowner for future reference.
WARNING
If not installed, operated and maintained
in accordance with the manufacturer’s
instructions, this product could expose you
to substances in fuel or from fuel combustion
which can cause death or serious illness.
WARNING
This log set is to be installed only in a sol-
id-fuel burning replace with a working ue
constructed of non-combustible material.
The vent damper must also have a damper
clamp attached to it to keep the damper from
accidentally closing during operation.

35716-2-0917Page 2
LOG IDENTIFICATION
LOG
DESCRIPTION
PART NUMBER
LGLO(18,24) LGLO30
Log A FG10171 FG10177
Log B FG10166 FG10176
Log C FG10169 FG10169
Log D FG10168 FG10168
Log E FG10170 FG10170
Log F FG10167 FG10167
Note: Logs may differ from those shown.
Installation
1. PlaceLogCwiththeat,paintedsidesfacingrearand
down.
2. PlaceLogBontothefrontsectionofthegrate.Theat,
paintedsidesoftheFrontLogshouldfacerearanddown.
Figure 1
3. PlacetheremaininglogsontopofLogBandLogCasdesired.
Figure 2
CAUTION
After use, allowlogstocoolcompletelybeforehandling.
LOG INSTALLATION

35716-2-0917 Page 3
ToOrderPartsUnderWarranty,pleasecontactyourlocal Empiredealer.Seethedealerlocatoratwww.empirecomfort.
com.Toprovidewarrantyservice,yourdealerwillneedyournameandaddress,purchasedateandserialnumber,andthe
natureoftheproblemwiththeunit.
ToOrderPartsAftertheWarrantyPeriod,pleasecontactyourdealeroroneoftheMasterPartsDistributorslistedbelow.
Thislistchangesfromtimetotime.Forthecurrentlist,pleaseclickontheMasterPartsbuttonatwww.empirecomfort.com.
Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original
EquipmentrepairpartsforHeaters,Grills,andFireplacesmanufacturedbyEmpireComfortSystemsInc.
MASTER PARTS DISTRIBUTOR LIST
Parts Not Under Warranty
PartscanbeorderedthroughyourServicePerson,Dealer,oraMasterPartsDistributor.SeethispagefortheMasterPartsDistribu-
torslist.Forbestresults,theservice person or dealershouldorderpartsthroughthedistributor.Partscanbeshippeddirectlytothe
service person/dealer.
Warranty Parts
WarrantypartswillneedaproofofpurchaseandcanbeorderedbyyourServicePersonorDealer.Proofofpurchaseisrequiredfor
warrantyparts.
AllpartslistedinthePartsListhaveaPartNumber.Whenorderingparts,rstobtaintheModelNumberandSerialNumberfromthe
nameplateonyourequipment.ThendeterminethePartNumber(nottheIndexNumber)andtheDescriptionofeachpartfromthefol-
lowingillustrationandpartlist.Besuretogiveallthisinformation...
ApplianceModelNumber  PartDescription
ApplianceSerialNumber  PartNumber
Donotorderbolts,screws,washersornuts.Theyarestandardhardwareitemsandcanbepurchasedatanylocalhardwarestore.
Shipmentscontingentuponstrikes,resandallcausesbeyondourcontrol.
HOW TO ORDER REPAIR PARTS
Dey Distributing
1401WillowLakeBoulevard
VadnaisHeights,MN55101
Phone: [phone]
Toll Free: 800-397-1339
Website:www.deydistributing.com
Parts: Heater, Hearth and Grills
F. W. Webb Company
200LocustStreet
Hartford,CT06114
Phone: [phone]
Toll Free: 800-243-9360
Fax: [phone]
Toll Free Fax: [phone]
Websites: www.fwwebb.com&www.victormfg.com
Parts: Heater, Hearth and Grills
East Coast Energy Products
10EastRoute36
WestLongBranch,NJ07764
Phone: [phone]
Toll Free:800-755-8809
Fax: [phone]
Website: www.eastcoastenergy.com
Parts: Heater, Hearth and Grills
