PIONEER
VENTED DECORATIVE
GAS LOG SET
MODELS
LPR2430-1
FOR USE ON BURNER MODEL:
BF(L,M,R)(2124,30)
WARNING
FIRE OR EXPLOSION HAZARD
If the information in this manual is not
followed exactly, a re or explosion may
result causing property damage, personal
injury or loss of life.
— Do not store or use gasoline or other
ammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions.
• If you cannot reach your gas supplier,
call the re department.
— Installation and service must be
performed by a qualied installer,
service agency or the gas supplier.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
CONGRATULATIONS on the purchase of your
new DECORATIVE VENTED GAS LOG SET!
Your Decorative Gas Log Set is designed
and intended for installation in an approved,
existing, fully vented, wood-burning replace,
with a gas hook-up.
The log placement shown in this manual
replicates the set-up shown in the brochure
and provides a great ame pattern.
IMPORTANT! Read these instructions
carefully before installing or operating this
gas appliance. These instructions should be
left with the homeowner for future reference.
WARNING
If not installed, operated and maintained
in accordance with the manufacturer’s
instructions, this product could expose you
to substances in fuel or from fuel combustion
which can cause death or serious illness.
WARNING
This log set is to be installed only in a sol-
id-fuel burning replace with a working ue
constructed of non-combustible material.
The vent damper must also have a damper
clamp attached to it to keep the damper from
accidentally closing during operation.
LPR2430-1 LOGS SHOWN ON BF(L,M,R)30
INSTALLATION INSTRUCTIONS
AND OWNER’S MANUAL

Page 2 39546-0-0518
LPR2430 ON BF(L,M,R)2124

39546-0-0518 Page 3
DESCRIPTION FRONT VIEW - BF(L,M,R)30
(Log L)
DESCRIPTION FRONT VIEW - BF(L,M,R)(2124,30) DESCRIPTION FRONT VIEW - BF(L,M,R)(2124,30)
(Log A) (Log I)
(Log B) (Log J)
(Log C) (Log K)
(Log D)
(Log E)
(Log F)
(Log G)
(Log H)
LPR2430-1 LOG IDENTIFICATION - BF(L,M,R)(2124,30)
NOTE: Logs are not shown to scale.
NOTE: Logs may differ from those shown.

39546-0-0518Page 4
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)2124
TOP VIEW
FRONT VIEW
1. Place Fiber Heat Sink (included with burner) onto top rear log support.

39546-0-0518 Page 5
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)2124
2. Place Log (A) onto top of Fiber Heat Sink.
TOP VIEW
FRONT VIEW

39546-0-0518Page 6
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)2124
3. Place Log (B) onto front right side of Fiber Heat Sink and against top right side of burner pan.
TOP VIEW
FRONT VIEW

39546-0-0518 Page 7
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)2124
4. Place Log (C) onto top left side of Log (A) and against top left side of Log (B).
TOP VIEW
FRONT VIEW

39546-0-0518Page 8
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)2124
5. Place Log (D) onto top left side of burner pan, and left side of Log (B).
TOP VIEW
FRONT VIEW

39546-0-0518 Page 9
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)2124
6. Place Log (E) onto top side of Log (D), and against left end of burner pan.
TOP VIEW
FRONT VIEW

39546-0-0518Page 10
TOP VIEW
FRONT VIEW
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)2124
7. Place Log (F) onto front right side of Log (D) and against front left side of burner pan.

39546-0-0518 Page 11
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)2124
8. Place Log (G) against front right side of burner pan.
TOP VIEW
FRONT VIEW

39546-0-0518Page 12
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)2124
9. Place Log (H) onto the top left end of Log (A) and against the front left side of burner pan.
TOP VIEW
FRONT VIEW

39546-0-0518 Page 13
TOP VIEW
FRONT VIEW
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)2124
10. Place Log (I) onto top of Log (F) and against front center of burner pan.

39546-0-0518Page 14
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)2124
11. Place Log (J) onto top right end of Log (A), and against top right end of Log (B).
TOP VIEW
FRONT VIEW

39546-0-0518 Page 15
TOP VIEW
FRONT VIEW
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)2124
12. Place Log (K) onto the top of Log (C) and against the top left side of Log (J).

39546-0-0518Page 16
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)24
13. Log placement is complete.
TOP VIEW
FRONT VIEW

Page 1739546-0-0518
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)30

Page 18 39546-0-0518
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)30
1. Place Fiber Heat Sink (included with burner) onto top rear log support.
TOP VIEW
FRONT VIEW

Page 1939546-0-0518
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)30
TOP VIEW
FRONT VIEW
2. Place Log (A) onto top of Fiber Heat Sink.

Page 20 39546-0-0518
TOP VIEW
FRONT VIEW
LPR2430-1 LOG PLACEMENT ON BF(L,M,R)30
3. Place Log (B) onto front right side of Fiber Heat Sink and against top right end of burner pan.
