INSTALLATION INSTRUCTIONS
AND OWNER'S MANUAL
OUTDOOR VENTLESS FIREBOX
MODELS:
OP32FB2MF-3*
OP36FB2MF-3
OP42FB2MF-3
* Please note, Empire Comfort Systems does not
offer an outdoor gas burner to t the OP32FB2MF
rebox. You will need to nd a suitable burner from
another manufacturer.
GAS-FIRED
FOR USE ONLY WITH A LISTED GAS-FIRED
UNVENTED DECORATIVE ROOM HEATER
NOT TO EXCEED 50,000 BTU/H.
DO NOT BUILD A WOOD FIRE.
Carefully review the instructions supplied
with the decorative type unvented room
heater for the minimum rebox size
requirement.
DO NOT INSTALL AN APPLIANCE IN THIS
FIREBOX UNLESS THIS FIREBOX MEETS
THE MINIMUM DIMENSIONS REQUIRED
FOR THE INSTALLATION.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING
If the information in this manual is not
followed exactly, a re or explosion may
result causing property damage, personal
injury or loss of life.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open ame.
3. If odor continues, keep away from the
appliance and immediately call your gas
supplier or re department.
WARNING
Improper installation, adjustment,
alteration, service or maintenance can
cause injury or property damage. Read the
installation, operating and maintenance
instructions thoroughly before installing or
servicing this equipment.
This product complies with ANSI Z.21.91 for outdoor use with
Z21.97 burners, 50,000 BTU Max.
MH45080

33857-4-0117Page 2
SECTION PAGE
BEFORE YOU START .............................................................................................3
CARTON CONTENTS & HARDWARE PACKAGE..................................................3
IMPORTANT SAFETY INFORMATION....................................................................4
HOMEOWNER REFERENCE INFORMATION .......................................................5
INTRODUCTION.................................................................................................5 - 6
ACCESSORIES .......................................................................................................6
FIREBOX DIMENSIONS..........................................................................................7
CLEARANCES......................................................................................................8-9
PLANNING INSTALLATION..............................................................................10-11
FIREBOX INSTALLATION INSTRUCTIONS ....................................................11-12
INSTALLING HOOD...............................................................................................12
GAS LINE CONNECTION .....................................................................................13
MAINTENANCE .....................................................................................................13
PARTS VIEW .........................................................................................................14
PARTS LIST...........................................................................................................14
MASTER PARTS DISTRIBUTOR LIST..................................................................15
HOW TO ORDER REPAIR PARTS........................................................................15
WARRANTY TERMS .............................................................................................16
TABLE OF CONTENTS

33857-4-0117 Page 3
BEFORE YOU START
Sample Warnings and Denitions:
DANGER
Indicates a hazardous situation which, if not avoided, will result
in death or serious injury.
WARNING
Indicates a hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION
Indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
NOTICE: Indicates information considered important but not
hazard related.
1. Read the Safety Information on page 4.
2. Determinewheretoinstalltherebox.Seepages10-11.
3. Frame the opening. See page 11.
4. Install optional drain tray. (See instructions with drain tray)
5. Installtherebox.Seepages12.
6. Install the gas lines. See page 13.
7. Install hood, optional bifold door or optional extension hood.
8. Install and light the burner (sold seperately).
9. Show homeowner how to do basic maintenance.
HARDWARE PACKAGE & CARTON CONTENTS
Hardware Package
Hood
Note: See parts view and parts list on page 14 for ordering replacement parts.
Note: Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at hardware stores.
SCREW, 10-32 X 1/2TYPE F
PHILLIPS PAN HEAD (QTY 4)
SCREW, 10-24 X 1/2TYPE
PHILLIPS HEX HEAD (QTY 2)

33857-4-0117Page 4
IMPORTANT SAFETY INFORMATION
FOR THE INSTALLER
• Leaveinstructionmanualwiththehomeowner
• ThisreboxcomplieswithANSIZ21.91foroutdoorusewith
Z21.97 burners, 50,000 BTU MAX.
• Installationandrepairshouldbedonebyaqualiedservice
person.Thisreboxshouldbeinspectedbeforeuseandat
leastannuallybyaqualiedserviceperson.
• Duringmanufacture,thisreboxistreatedwithoils,lms
and bonding agents. These are not harmful but may produce
smoke and odor as they burn off during initial operation. This
is normal.
• Anymodicationtothisreboxortocontrolscanbe
dangerous.Improperinstallationoruseofthereboxcan
causeseriousinjuryordeathfromre,burns,explosionor
carbon monoxide poisoning.
• Thereboxhoodmustnotbemodied.
• UseNon-CombustibleMaterialswhereindicatedforthe
reboxinstallation.Non-combustiblematerialsdonotignite.
These include metal, brick, ceramic, concrete, slate, glass,
and plaster. Adhesives must be rated for high temperatures
(300°F +). Any mechanical fasteners used to install material
must also be non-combustible, including wall anchors
and tile spacers. Materials that pass the ASTM E 136 test
(Standard Test Method for Behavior of Materials in a Vertical
Tube Furnace at 750C) are considered non-combustible.
• Whenthereboxisinstalleddirectlyoncarpeting,tileor
othercombustiblematerial,otherthanwoodooring,the
reboxmustbeinstalledonametalorwoodpanelextending
the full width and depth of the enclosure.
FOR THE HOMEOWNER
• Alertchildrenandadultstothehazardsofhighsurface
temperatures. Keep children and other at-risk individuals
away to avoid burns or clothing ignition.
• Carefullysuperviseyoungchildrenwhentheyareinthe
sameareaastherebox.
• Donothangorplaceclothingorotherammablematerials
onorneartherebox.
• DonotallowCombustibleMaterialsadjacenttoorincontact
withfaceoftherebox.Combustiblematerialsincludewood,
orothermaterialsthatwillburnevenwhentreatedwithre-
retardant chemicals.
• Keepreboxareaclearandfreefromcombustiblematerials,
gasolineandotherammablevaporsandliquids.
• Donotallowfanstoblowdirectlyintoorattherebox.
• Avoidanydraftsthatalterburneramepatterns.
• Donotoperatethisreboxwithglassdoorsorweatherdoor
intheclosedposition.Areboxscreenmustbeinplace
when the burner is being used.
• Donotusethisreboxifanyparthasbeenunderwater.
Immediatelycallaqualiedservicetechniciantoinspectthe
reboxandtoreplaceanypartofthecontrolsystemandany
gas control which has been under water.

33857-4-0117 Page 5
Moisture Resistance
Thisoutdoorreboxwillshedmoderateamountsofwater,butis
not waterproof. Water and condensing water vapor may enter the
chase under certain conditions.
Thereboxwillnotperformasanexteriorwall.Moisture
penetration must be considered for construction that places the
reboxinstructurewallsoronmoisturesensitivesurfaces.
When installed next to exterior walls: Empire Comfort Systems
recommendsthereboxchasebeconstructedoutsidethe
structure's weather envelope. Where the platform meets the wall,
useaashingdetailsimilartothatrequiredforattacheddecks.
Chase platforms, including hearths should slope away from the
structureat1/4inchperfoot.Thereboxcanbeshimmedlevel.
When installed on surfaces where water may collect or cause
damage: Empire Comfort Systems recommends a slope of
1/8 inch to 1/4 inch per foot towards the drain port suggested.
Thereboxcanbeshimmedlevel.
Hearthsshouldslopeawayfromthefrontofthereboxand
chase at 1/8 inch to 1/4 inch per foot. Metal safety strips must
be on top of any combustible hearth materials used for moisture
management.
Whenpurchasingareboxwerecommendyoualsobuya
weathercoverorglassdooraccessorytoprotectthereboxfrom
moisture.Neverinstallthereboxwheremoisturecannotdrain
easily.
Screened Porch Installation
ThereboxmaybeinstalledsafelyandisdesigncertiedbyUL
to be installed in a screen porch with the following guidelines.
MinimumPorchArea 96sqft
Minimum Ceiling Height 84 inch
See Pages 10 - 11, Planning Installation.
Instructions to Installer
1. Leave instruction manual with owner after installation.
2. Show home owner Product Registration Card supplied with
rebox.
3. Fill in the Homeowner Reference Information above.
4. Show owner how to start and operate outdoor burner (not
provided).
Always consult your local Building Department regarding
regulations, codes or ordinances which apply to the installation of
anoutdoorrebox.
This application is only for use with the type of gas indicated on
the burner rating plate. Burner sold separately.
WARNING
Any change to this FIREBOX can be dangerous.
Improperinstallationoruseofthereboxcancauseserious
injuryordeathfromre,burns,explosionorcarbonmonoxide
poisoning.
ThisreboxisdesigncertiedinaccordancewithAmerican
National Standard Z21.91 for outdoor use with Z21.97 burners.
Note: This rebox has been tested and approved up to
50,000 BTU’s. DO NOT USE WITH BURNERS OVER 50,000
BTU’s.
Important
All correspondence should refer to complete Model Number, and
Serial Number. Refer to the Homeowner Reference Information
above.
INTRODUCTION
HOMEOWNER REFERENCE INFORMATION
Werecommendthatyourecordthefollowinginformationaboutyourrebox.
Model Number: _____________________________ Date purchased: ________________________
Serial Number: _____________________________  Locationofrebox: ______________________
Dealer Name: ______________________________ Dealer Phone: _________________________
Notes: ______________________________________________________________________________

33857-4-0117Page 6
INTRODUCTION
Qualied Installing Agency
Installation and replacement of gas piping, gas utilization
equipmentoraccessoriesandrepairandservicingofequipment
shallbeperformedonlybyaqualiedagency.Theterm"qualied
agency"meansanyindividual,rm,corporationorcompany
which either in person or through a representative is engaged
in and is responsible for (a) the installation or replacement of
gas piping or (b) the connection, installation, repair or servicing
ofequipment,whoisexperiencedinsuchwork,familiarwithall
precautionsrequiredandhascompliedwithalltherequirements
of the authority having jurisdiction.
Whenthereboxisconnectedtoaxedpipingsystem,the
installation must conform with local codes, or in the absence
of local codes with the National Fuel Gas Code, ANSI Z223.1*/
NFPA 54, or International Fuel Gas Code.
*Available from the American National Standards Institute, Inc.
1430 Broadway, New York, N.Y. 10018.
During manufacture and fabricating, components of this
appliance are treated with oils, lms, and/or bonding
agents. These are not harmful, but may produce smoke and
smells as they are burned off during initial operation of the
appliance. This is normal.
Solidfuelsshallnotbeburnedinthisrebox.
Cleaning Instructions at Installation
Thisreboxisbuiltusingmostlyhigh-gradestainlesssteelto
resist rust-through. In outdoor applications, all stainless steel will
develop a dull patina and, depending on the local environment
and on the materials used in the installation, may develop some
surface oxidation (rust). This does not affect the performance
oftherebox,anddoesnotrequireanyactiontocorrect.Ifyou
preferkeepingyourreboxfrontlookingfactory-fresh,cleanitas
requiredwithstainlesssteelcleaner.
When installation application includes highly acidic applications
such as acid wash or stone etching, do not remove the protective
PVClmfromthestainlesssteeluntilafterthisapplicationis
complete.Oncethelmhasbeenremovedwerecommend
that the appliance be cleaned with a stainless steel cleaner
immediately.
Pleasenotethatareaswherethelmhasbeenformed(corners,
hems,etc.)mayrequireextracleaningduetothepropertiesof
thelm.Ensurethatallprotectivelmhasbeenremovedfrom
thereboxpriortoburningtherebox.
Commonwealth of Massachusetts: The installation must be
madebyalicensedplumberorgastterintheCommonwealth
of Massachusetts.
Sellersofunventedpropaneornaturalgas-redsupplemental
room burners shall provide to each purchaser a copy of 527
CMR-30 upon sale of the unit.
In the Commonwealth of Massachusetts, unvented propane and
naturalgas-redspaceburnersshallbeprohibitedinbedrooms
and bathrooms.
Model Number Description
BD32SS 32-Inch Bifold Glass Door
BD36SS 36-Inch Bifold Glass Door
BD42SS 42-Inch Bifold Glass Door
DT32SS 32-Inch Drain Tray - Stainless Steel
DT36SS 36-Inch Drain Tray - Stainless Steel
DT42SS 42-Inch Drain Tray - Stainless Steel
WD32SS 32-Inch Weather Door - Stainless Steel
WD36SS 36-Inch Weather Door - Stainless Steel
WD42SS 42-Inch Weather Door - Stainless Steel
VB4H32SS 32-Inch Extended Hood - Stainless Steel
VB4H36SS 36-Inch Extended Hood - Stainless Steel
VB4H42SS 42-Inch Extended Hood - Stainless Steel
The following accessory parts can be obtained from your Empire Comfort Systems dealer. Contact your Empire Dealer for more acces-
sory options. If you need additional information beyond what your dealer can furnish, contact Empire Comfort Systems Inc., 918 Freeburg
Ave., Belleville, Illinois 62220-2623.
ACCESSORIES

33857-4-0117 Page 7
FIREBOX DIMENSIONS
INDEX
LETTER
DIMENSION DESCRIPTION DIMENSIONS (in inches)
OP32 OP36 OP42
AThemaximumheightofreboxface(excludingstandoffs) 33-1/16 35-1/16 35-1/16
BThemaximumwidthofthereboxface(excludingnailinganges) 35 40 44
CThemaximumdepthoftherebox 16-9/16 19 19
DTheheightofthereboxopening 22-1/4 24-1/4 24-1/4
EThewidthofthereboxopening 31 36 40
FTheinteriordepthoftherebox 13-3/16 15-9/16 15-9/16
GTherearexteriorwidthoftherebox 27-7/8 31-7/8 35-7/8
K Height from the bottom of the box to the gas line opening 8-11/16 8-11/16 -11/16
L Depth from the front of the box to gas line opening 11-5/8 14 14
M Depth from rear of box to gas line opening 4-3/4 4-3/4 4-3/4
QDistancefromoortoreboxopening 6-3/16 6-3/16 6-3/16
S Overall height to header 33-13/16 35-13/16 35-13/16
TInteriorfrontheightofrebox 21-3/8 24-3/16 24-3/16
UInteriorrearheightofrebox 17-7/8 19-1/4 19-1/4
VInteriorfrontwidthofrebox 29-7/16 34-5/16 38-5/16
WInteriorrearwidthofrebox 24 28 32
X Corner installed depth 30-3/16 34-11/16 36-3/4
Y Corner installed wall length 42-11/16 49-1/16 51-15/16
Z Corner installed width 60-3/8 69-5/16 73-5/16
G
Z
D
Q
E
B
M
C
K
L
A
X
Y
INNER FIREBOX DIMENSIONSINNER FIREBOX DIMENSIONS
T
W
V
F
U
TOP VIEW
SIDE VIEW
GAS INLET HOLES
BOTH SIDES
OUTER FIREBOX DIMENSIONS
S

33857-4-0117Page 8
3/4" GAP REQUIRED
ACROSS ENTIRE TOP
OF FIREPLACE
2 X 4
TOP PLATE
COMBUSTIBLE
FINISHED WALL
OR MANTEL
NON-COMBUSTIBLE
BOARD OR FACING
CLEARANCES
Top Framing and Finishing: Combustible framing materials
requires3/4inchtotopofrebox.See Figure 1.
Sidewall Clearances: The clearance from the inside of the
reboxtoperpendicularcombustiblesidewallshouldnotbe
less than 6 inches. See Figure 2.
Firebox Face Clearance: 3/8 inch from face and back 1 3/4
inches.
Firebox Side and Back Clearances:Thereboxoutercasing
sideandbackangesarezeroclearancetocombustibles.
Firebox Front Clearance: Leave at least 36 inches clearance
fromthefrontofthereboxintotheroom.
Ceiling Clearances: The ceiling height should not be less than
84inchesfromtheoor.See Figure 3.
Mantel Clearances: Firebox models must use the hood supplied
withtherebox,ortheoptionalextensionhoodavailablefor
each model. If a combustible mantel is installed, it must meet
theclearancerequirementsdetailedinFigure 3.
Grate Clearance: The minimum clearance between the front
legsofthegrateandfrontedgeofthereboxis2inches.
6"
MIN.
FIREBOX
(TOP VIEW)
FRONT FACE (SIDE)
3”
MAX.
1 3/4”
PERPENDICULAR
SIDE WALL
COMBUSTIBLE
MATERIALS ALLOWED
IN SHADED AREAS
45°
3/8”GAP REQUIRED
BOTH SIDES
FIREBOX WALL
OUTER WRAPPER
Figure 2
Figure 1 - Clearances to Combustibles

33857-4-0117 Page 9
CLEARANCES
Mantel Chart Television Considerations
Installingatelevisionaboveanreboxhasbecomeincreasingly
popular;however,theareaaboveanyreboxgetshotandmost
TV manufacturers recommend against placing their products
near a heat source.
Ifyouinstallatelevisionabovethisrebox,EmpireComfort
Systems accepts no responsibility for damage or injuries. Follow
the television manufacturer’s installation instructions, including any
recommendations regarding proximity to heat sources.
IfyouhaveaTVaboveyourrebox,turnoffthereboxandletit
cool completely before servicing or touching any buttons on the TV.
HOOD
FIREBOX
FACE
84”
MIN.
(CEILING TO FLOOR)
CEILING
FLOOR
WALL FACING
A
B
C
D
E
F
9 3/4”
28 1/2”
MIN.
18 3/4”
MIN.
3/4”TO COMBUSTIBLES
REQUIREDACROSS
ENTIRETOP EDGE
OF FIREPLACE
53 1/2”
MIN.
COMBUSTIBLES
ALLOWED
WALL STUD
INDEX
LETTER
Dimensions in inches
DISTANCE FROM
WALL SURFACE
DISTANCE ABOVE
Firebox HOOD
A 2 18 ¾
B 4 21 ½
C 6 24 ¼
D 8 27
E 10 27 ¾
F 12 28 ½
Figure 3

33857-4-0117Page 10
Inplanningtheinstallationfortherebox,itisnecessaryto
determine where the unit is to be installed. Gas supply piping
should also be planned at this time.
Thereboxcanbemountedonanyofthesesurfaces:
1. Aatcombustibleornon-combustiblesurface.
2. A raised platform combustible material.
3. Fourcornersofthereboxsocontactismadeonallfour
perimeter edges on its bottom.
(Example: Four concrete blocks - if allowed by local code.)
Ifthereboxisinstalleddirectlyoncarpeting,tileorother
materialotherthanwoodooring,itshouldbeinstalledona
metal or wood panel extending the full width and depth of the
rebox.
Decide what components to include in your installation.
Thisreboxisintendedforinstallationonanoutdoorpatioor
inyouryard.Thisreboxshallbeusedonlyoutdoorsinawell
ventilated space and shall NOT be used in a building, garage, or
other enclosed area.
Installthereboxinanareashelteredfromdirectwind,which
maycauseerraticamesandmainburneroutage.Erraticames
could also cause soot on logs, walls or ceiling. Flame outages
and sooting are nuisances but pose no safety issues.
Typical installation may include covered patio, gazebo or an
outside wall of a house.
• Minimumporcharea–96sqft
• Minimum ceiling height – 84 inches
Installation in partial enclosures must conform with one of the
following conditions:
• With walls on all sides, but with no overhead cover. See
Figure 4.
FIREPLACE
Figure 4
• Within a partial enclosure which includes an overhead cover
and no more than two side walls. These side walls may be
parallel, as in a breezeway or at right angles to each side.
See Figure 5.
FIREPLACE
Figure 5
• This partial enclosure includes an overhead cover and three
walls, no more than 30% or more of the horizontal periphery
(i.e. perimeter) of the enclosure permanently open. These
openings cannot be screened or have operable windows or
shutters. See Figure 6.
FIREPLACE
Figure 6
Outdoor Firebox Enclosure Requirements
Donotinstallreboxuntilallnecessaryprovisionsaremadefor
combustion and ventilation air. Consult the written instructions
providedwiththereboxforinformationconcerningcombustion
and ventilation air. In the absence of instructions, refer to
the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Air for
Combustion and Ventilation, or applicable local codes.
ATTENTION: Vinyl Soft, Vinyl Ceiling, Vinyl Overhang
Disclaimer
Clearances are to heat resistant material (i.e. wood, metal).
This does not include vinyl. Empire Comfort Systems Inc.
will not be held responsible for heat damage caused to vinyl
overhangs,vinylceilingsorvinylventilated/unventilatedsofts.
PLANNING INSTALLATION

33857-4-0117 Page 11
PLANNING INSTALLATION
Television Considerations
Installingatelevisionaboveareboxhasbecomeincreasingly
popular;however,theareaaboveanyreboxgetshotandmost
TV manufacturers recommend against placing their products
near a heat source.
Ifyouinstallatelevisionabovethisrebox,EmpireComfort
Systems accepts no responsibility for damage or injuries. Follow
the television manufacturer’s installation instructions, including
any recommendations regarding proximity to heat sources.
IfyouhaveaTVaboveyourrebox,turnoffthereboxandletit
cool completely before servicing or touching any buttons on the
TV.
ThemaximumBTUinputforthisreboxis50,000.Verifythat
any burner and/or accessory are rated for use up to 50,000
Btubeforeinstallingitintothisrebox.Followanyspecial
installation instructions that came with the burner or accessory
(i.e. clearances, combustion and ventilation air, and enclosure
information).
WARNING
Improper installation, adjustment, alteration, service or
maintenance can cause property damage, personal injury or
loss of life. Installation and service must be performed by a
qualiedinstaller,serviceagencyorthegassupplier.
FIREBOX INSTALLATION INSTRUCTIONS
InstallonlyanANSIZ21.97burnerintothisrebox.
Any burner must be “For use with approved ANSI Z21.11.2
unvented room heater.”
Inplanningtheinstallationfortherebox,itisnecessaryto
determinewherethereboxistobeinstalledandwhether
optional accessories are desired. Gas supply piping should also
be planned at this time.
FOR
A RAISED HEARTH:
COVER
ANY COMBUSTIBLE
MA
TERIALS WITH
NON-COMBUSTIBLE
MA
TERIAL THE WIDTH
OF
THE FIREPLACE
OPENING
AND EXTENDING
AT
LEAST 16 INCHES FROM
THE FIREPLACE
BOTTOM OF
FIREPLACE
OPENING
COMBUSTIBLE MATERIALS
HEARTH PLATFORM
Figure 7
NOTICE: Hearthisnotrequiredifreboxisinstalledonnished
oor.
Firebox Framing
Fireboxframingcanbebuiltbeforeorafterthereboxisset
in place. Framing should be positioned to accommodate wall
coveringandreboxfacingmaterial.Thereboxframingshould
be constructed of 2 x 4 lumber or heavier. The framing top plate
or header may be as close as 3/4 inch above the top of the
rebox.RefertoFigure 8forreboxframingdimensions.
A
B
C
Deluxe Vent-Free Firebox Framing Dimensions (inches)
A B C
Model Framing
Height
Framing
Width
Framing
Depth
OP32FB2MF 34 36 16-3/4
OP36FB2MF 36 41 19-1/4
OP42FB2MF 36 45 19-1/4
Figure 8
Premium Fireplace Framing Dimensions -
If Installing Optional Drain Tray (inches)
Model A B C
OP32FB2MF 35 36 16-3/4
OP36FB2MF 37 41 19-1/4
OP42FB2MF 37 45 19-1/4

33857-4-0117Page 12
Installing the Hood
Ahoodthatisfurnishedwitheachrebox(oroptionalextension
hood)MUSTbeinstalledbeforethereboxisused.Failuretodo
somaycreateapossiblerehazard.
1. Loosenthetwoscrews(A)holdingreboxtoptofacepanel,
thenslidethehoodangebetweenthereboxtopandface
panel and re-tighten the screws. See Figure 11.
2. Install one screw at each end of the hood as shown (C). See
Figure 11.
ACAC
Figure 11
Finishing
All joints (top, bottom and sides), where the wall or decorative
facingmaterialmeetsthereboxsurroundmustbesealedwitha
non-combustible material (300°F + Sealant).
NOTICE: When installation application includes highly acidic
applications such as mortar or stone etching, do not remove
theprotectivePVClmfromthestainlesssteeluntilafterthis
applicationiscomplete.Oncethelmhasbeenremovedwe
recommendthatthereboxbecleanedwithastainlesssteel
cleaner immediately.
Cleaning Instructions at Installation
Thisreboxisbuiltusingmostlyhigh-gradestainlesssteelto
resist rust-through. In outdoor applications, all stainless steel will
develop a dull patina and, depending on the local environment
and on the materials used in the installation, may develop some
surface oxidation (rust). This does not affect the performance
oftherebox,anddoesnotrequireanyactiontocorrect.Ifyou
preferkeepingyourreboxfrontlookingfactory-fresh,cleanitas
requiredwithstainlesssteelcleaner.
FIREBOX INSTALLATION INSTRUCTIONS
Locating Firebox
Pry the top standoffs up and bend pieces as shown. Attach
free-end to face top with two hex-head screws from hardware
pack.Placereboxinframingopening.Usethetabsontheside
ofthereboxtoattachreboxtoframing.Differenttablocations
canbeusedfornishingmaterialswiththicknessesof1/2inch
and 5/8 inch. See Figure 9.
Framingtabsshouldtdirectlyagainstframingmaterial.Useat
least one nail per bracket to secure in place.
Checksquarenessofthereboxpriortosecuringtoframed
opening. See Figure 10.
FRAMING
TABS
Figure 9
CHECK TO SEE
THAT BOX IS SQUARE
PRIOR TO ATTACHING TO
FRAMING
FIREBOX OPENING
3/4" GAP
REQUIRED
3/8" GAP
REQUIRED
Figure 10
Extended Hoods
Ifthenon-combustiblefacingmaterialusedtonishthereboxis
over 1 inch thick, an extended hood that extends 2 inches farther
into the room is recommended. Contract your Empire Dealer for
details.
VB4H32SS Stainless Steel Extended Hood
VB4H36SS Stainless Steel Extended Hood
VB4H42SS Stainless Steel Extended Hood
FRAMING HARDWARE
NOT INCLUDED

33857-4-0117 Page 13
GAS LINE CONNECTION
ThereboxisdesignedtoacceptagaslineforanANSI
approvedburner.Havethegaslineinstalledbyaqualied
service person in accordance with all building codes. Consult
local building codes to properly size the gas supply line leading
to the hook-up at the installed burner. The Commonwealth of
Massachusettsrequiresthataexiblegasconnectorcannot
exceed three feet in length.
Gasaccessholesareprovidedonbothsidesoftherebox.See
Figure 12. Carefully remove the knockout in the refractory brick
panel using a large standard screwdriver and hammer. First,
place screwdriver in groove next to plug and pry sideways to
pop out main plug. Then remove the remaining concrete in hole
with gentle tapping with ball peen hammer and/or screwdriver. A
masonry drill and bit may also be used to create a clean hole for
the gas line to pass through. See Figure 13.
Afterthebrickpanelknockoutisremoved,thereboxwrapwill
have a round metal knockout that must be removed also. Use a
screwdriver to punch out the metal knockout.
WARNING: CONNECTION DIRECTLY TO AN
UNREGULATED L.P. SUPPLY CAN CAUSE AN EXPLOSION.
Figure 12
TAP AROUND KNOCK-OUT
TO REMOVE
Figure 13
Note: Use caution when removing the brick panel knockouts to
avoid damaging the brick panel.
MAINTENANCE
Vacuum or brush the control compartment at least twice a year.
Follow the maintenance instructions provided with the burner.

33857-4-0117Page 14
PARTS VIEW
10
11
5
76
13
13
9
12
8
8
4
1
2
3
PARTS LIST
USE ONLY MANUFACTURER’S REPLACEMENT PARTS. USE OF ANY OTHER PARTS COULD CAUSE INJURY OR DEATH.
Index No. Part No. Description
OP32FB2MF OP36FB2MF OP42FB2MF
1 33847 33848 33849 Face, Bottom
2 33850 33851 33852 Face, Top
3 33853 33854 33854 Face, Side - Right
4 33855 33856 33856 Face, Side - Left
5 R10387 R10391 R10391 Liner, Side - Left
6 R10388 R10392 R10392 Liner, Side - Right
7 R10386 R10390 R10394 Liner, Rear
8 33885 33885 33885 LinerBracket(2required)
921117 21162 33609 Hood
10 R11107 R11036 R11037 Curtain,Rod(2required)
11 R11108 R10765 R10765 Curtain,Screen(2required)
12 R11104 R11105 R11106 Liner, Bottom
13 27338 27338 37338 TopLinerBracket(2required)

33857-4-0117 Page 15
To Order Parts Under Warranty, please contact your local Empire dealer. See the dealer locator at www.empirecomfort.
com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and
thenatureoftheproblemwiththerebox.
To Order Parts After the Warranty Period, please contact your dealer or one of the Master Parts Distributors listed below.
This list changes from time to time. For the current list, please click on the Master Parts button at www.empirecomfort.
com.
Please note: Master Parts Distributors are independent businesses that stock the most commonly ordered Original
EquipmentrepairpartsforHeaters,Grills,andFireboxsmanufacturedbyEmpireComfortSystemsInc.
MASTER PARTS DISTRIBUTOR LIST
Parts Not Under Warranty
Parts can be ordered through your Service Person, Dealer, or a Master Parts Distributor. See this page for the Master Parts Distribu-
tors list. For best results, the service person or dealer should order parts through the distributor. Parts can be shipped directly to the
service person/dealer.
Warranty Parts
Warranty parts will need a proof of purchase and can be ordered by your Service Person or Dealer. Proof of purchase is required for
warranty parts.
AllpartslistedinthePartsListhaveaPartNumber.Whenorderingparts,rstobtaintheModelNumberandSerialNumberfromthe
nameplateonyourequipment.ThendeterminethePartNumber(not the Index Number) and the Description of each part from the fol-
lowing illustration and part list. Be sure to give all this information . . .
Appliance Model Number Part Description
Appliance Serial Number Part Number
Type of Gas (Propane or Natural)
Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store.
Shipmentscontingentuponstrikes,resandallcausesbeyondourcontrol.
HOW TO ORDER REPAIR PARTS
Dey Distributing
1401 Willow Lake Boulevard
Vadnais Heights, MN 55101
Phone: [phone]
Toll Free: 800-397-1339
Website: www.deydistributing.com
Parts: Heater, Hearth and Grills
F. W. Webb Company
200 Locust Street
Hartford, CT 06114
Phone: [phone]
Toll Free: 800-243-9360
Fax: [phone]
Toll Free Fax: [phone]
Websites: www.fwwebb.com & www.victormfg.com
Parts: Heater, Hearth and Grills
East Coast Energy Products
10 East Route 36
West Long Branch, NJ 07764
Phone: [phone]
Toll Free: 800-755-8809
Fax: [phone]
Website: www.eastcoastenergy.com
Parts: Heater, Hearth and Grills

33857-4-0117Page 16
WARRANTY TERMS
Empire Comfort Systems Inc. warranties this hearth product to be free from defects at the time of purchase and for the
periodsspeciedbelow.Hearthproductsmustbeinstalledbyaqualiedtechnicianandmustbemaintainedandoperated
safely, in accordance with the instructions in the owner’s manual. This warranty applies to the original purchaser only and
isnottransferable.Allwarrantyrepairsmustbeaccomplishedbyaqualiedgasappliancetechnician.
Limited Five-Year Parts Warranty – All Components
(Except Remote Controls, Accessories and
Replacement Parts)
• Shouldanypartfailbecauseofdefectiveworkmanship
ormaterialwithinveyearsfromthedateofpurchase,
Empire will repair or replace at Empire’s option.
Limited One-Year Parts Warranty – Remote Controls,
Accessories, and Parts
• Shouldanyremotecontrol,accessory,orotherpartfail
because of defective workmanship within one year from
the date of purchase, Empire will repair or replace at
Empire’s option.
Duties of the Owner
• Theappliancemustbeinstalledbyaqualiedinstaller
and operated in accordance with the instructions furnished
with the appliance.
• Abillofsale,cancelledcheck,orpaymentrecordshould
be kept to verify purchase date and establish warranty
period.
• Readyaccesstotheapplianceforservice.
What Is Not Covered
• Damagesthatmightresultfromtheuse,misuse,or
improper installation of this appliance.
• Travel,diagnosticcostsandfreightchargeson
warranted parts to and from the factory.
• Claimsthatdonotinvolvedefectiveworkmanshipor
materials.
• Unauthorizedserviceorpartsreplacements.
• Removalandreinstallationcost.
• Inoperableduetoimproperorlackofmaintenance.
How To Get Service
• Tomakeaclaimunderthiswarranty,pleasehaveyour
receipt available and contact your installing dealer. Provide
the dealer with the model number, serial number, type
ofgas,andpurchaseverication.Theinstallingdealer
is responsible for providing service and will contact the
factory to initiate any warranted parts replacements.
Empire will make replacement parts available at the
factory. Shipping expenses are not covered.
• If,aftercontactingyourEmpiredealer,servicereceived
has not been satisfactory, contact: Consumer Relations
Department, Empire Comfort Systems Inc., PO Box
529, Belleville, Illinois 62222, or send an e-mail to info@
empirecomfort.com with “Consumer Relations” in the
subject line.
Your Rights Under State Law
• Thiswarrantygivesyouspeciclegalrights,andyou
may also have other rights, which vary from state to state.
www.empirecomfort.com
Empire Comfort Systems Inc.
Belleville, IL
Ifyouhaveageneralquestion
about our products, please e-mail
us at [email protected].
If you have a service or repair
question,pleasecontactyourdealer.
