Empire Filter chamber Manual

Page 1 of 9

Filter Chamber

Operating and Maintenance Instructions

www.empirepumps.com

Product & Chemical Disclaimer

The user must take responsibility in the selection of the products materials of construction. Empire

Pumps Ltd will act in an advisory role and offer recommendations; however, the user is liable for the

product selection in line with solutions and temperatures in which the equipment is operated.

Safety Precautions

WARNING: Prior to operating the filtration system read and understand the operating and maintenance

instructions.

WARNING: Ensure the filtration system is compatible with the fluids and temperatures being

transferred. Always consult Empire Pumps Ltd if there is any change in chemical concentrations or

solution temperatures.

WARNING: Wear protective eye and personal equipment at all times when operating the pump. Follow

standard safety procedures when handling corrosive or harmful solutions.

WARNING: Ensure all operators of this equipment have been trained for safe working practices,

understand its limitations and wear safety goggles and equipment at all times.

WARNING: Correct procedures must be followed to drain the pump of all chemistries prior to physical

inspection of the pump.

WARNING: Excessive Pressure. Can result in serious injury or equipment damage. Do not service or

clean the pump whilst the system is pressurised. Relieve pressure from the system prior to

disassembly.

WARNING: Never operate the filtration system above the specified maximum operating pressure of the

pump.

WARNING: Suction and discharge connections must be compatible with the solutions being pumped

and the maximum pressure capability of the filtration system.

WARNING: Maximum temperatures are based on mechanical stress only. Certain chemicals will

significantly reduce the maximum operating temperature of the pump materials. Consult with the

chemical manufacturer and Empire Pumps Ltd for solution compatibility and temperature limitations.

WARNING: The filtration system must not be used as structural support to the piping system. Ensure

suction and discharge pipe-work are independently supported to avoid stress on the pump parts.

WARNING: Use only Empire Pumps Ltd genuine spare parts to assure compatible pressure rating and

longest service life.

Page 2 of 9

Filter Chamber

Operating and Maintenance Instructions

www.empirepumps.com

WARNING: Re-torque all fasteners before operation. Excessive torque is unnecessary and may cause

damage to the pump.

WARNING: Upon receipt of the filtration system, inspect for any signs of shipping damage. If damage

has occurred contact Empire Pumps Ltd.

Important Checks

****IMPORTANT SAFETY NOTES –PLEASE READ BEFORE USING THIS HOUSING****

1.

Never

attempt

to

open

the

housing

whilst

under

pressure.

It

is

recommended

that

the

user

provides

a

suitable system

to

prevent

opening

under

pressure.

2.

Never

operate

the

housing

outside

of

its

permitted

operating

parameters

as

stated

(i.e.

over

pressure,

under vacuum,

over

or

under

temperature).

3.

Housings

using

Vee

clamps

should

not

be

used

in

cyclic

pressure

or

shock

load

environments,

or

where

highly viscous

fluids

could

solidify

the

closure

seal.

4.

For

safety,

it

is

the

user’s

responsibility

to

ensure

a

suitable

pressure

relief

device

is

installed

in

the

system

to prevent

over-pressurisation.

5.

Never

use

the

housing

for

fluids

other

than

those

it

is

rated

for,

and

ensure

that

the

housing

&

seal

materials

are compatible

with

the

process

fluid.

6.

Care

must

be

taken

to

protect

operators

from

hot

surfaces

if

the

housing

is

being

run

at

high

temperatures.

7.

Failure

of

the

filter

housing

could

result

from

misuse

–

please

ensure

that

these

installation,

operating

&

maintenance

procedures

are

strictly

adhered

to.

8.

After

shutdown

leave

the

vessel

to

stand

for

45

minutes

before

opening

to

allow

for

any

static

dissipation.

9.

Minimum

flow

time

after

the

filter

to

any

open

vessel

to

permit

relaxation

time

(static

dissipation)

of

non-conductive fluids

must

be

greater

than

100

seconds.

10.

For

safety,

it

is

the

user’s

responsibility

to

ensure

the

housing

is

suitably

bonded

and

earthed.

11.

The

surface

temperature

of

the

housing

must

not

exceed

the

value

shown

above

and

80%

of

the

minimum

ignition temperature

of

the

gas

atmosphere.

For

dust

deposits

the

surface

temperature

must

be

75°C

less

than

the

minimum ignition

temperature

of

the

dust

layer.

Page 3 of 9

Filter Chamber

Operating and Maintenance Instructions

www.empirepumps.com

The

following

factors

have

not

been

considered

in

the

design

of

this

housing,

as

they

are

either

negligible

or

not considered

appropriate

for

this

product,

unless

specifically

stated:

1.

Static

pressure/head

2.

Traffic,

wind

and

earthquake

loading

3.

Decomposition

effects

of

unstable

fluids

4.

Creep,

fatigue

and

corrosion

allowances

5.

External

fire

************************************************************************************

*********************************************************************************

Installation

•Re-torque all fasteners before operation.

•The filter chamber should be securely fastened to a solid foundation which will enable the

support of the entire unit.

•Locate the filtration chamber as close to the fluid supply as possible.

•

Vent:

Fit

the

blanking

cap

or

plug

(supplied)

or

the

vent

and

gauge

kit

as

appropriate,

to

the

lid.

Seal

with

the

aid

of PTFE

tape

or

use

an

appropriate

sealant

as

required.

•

Drains:

Fit

the

blanking

caps

(supplied)

or

drain

valves

as

appropriate,

to

the

drain

connections.

Seal

with

the

aid

of PTFE

tape

or

use

an

appropriate

sealant

as

required.

•

Inlet/Outlet:

Connect

the

inlet

and

outlet

pipework

to

the

housing

connections.

For

threaded

connections

use

PTFE

tape

or an

appropriate

sealant

as

a

seal.

For

flanged

connections

use

a

suitable

gasket,

and

for

dairy

connections

use the

correct

sealing

ring.

•

It

is

important

that

the

pipework

to

and

from

the

filter

is

adequately

supported

•

THE FILTER HOUSING MUST NOT BE USED AS A SUPPORT POINT

•

Before operating we recommend that the filter is flushed thoroughly

•The suction and discharge pipe-work must be aligned to avoid placing stress on the filtration

system pump casing.

•Use minimal number of bends at the suction and discharge of the filter chamber

•The suction valve must be completely open to avoid restricting the suction flow.

Page 4 of 9

Filter Chamber

Operating and Maintenance Instructions

www.empirepumps.com

Connections

Inlet:

the

higher

of

the

two

larger

connections

Outlet:

the

lower

of

the

two

larger

connections

Vent:

located

in

the

lid

of

the

housing

Dirty

drain:

located

in

the

inlet

chamber

of

the

housing

(if

applicable)

Clean

drain:

located

in

the

outlet

chamber

of

the

housing

(if

applicable)

Operation

IMPORTANT: ALWAYS ENSURE THAT THE SYSTEM IS NOT

UNDER PRESSURE BEFORE OPENING THE HOUSING

Opening

the

Filter

Housing

For Housings with Vee Clamp Closure

If

the

filter

housing

has

been

in

service,

refer

to

the

instructions

given

in

the

section

“Removing

the

Filter

from

Service”

.

Release

the

Vee

clamp

by

undoing

both

clamp

adjusters

evenly.

Remove

the

Vee

clamp,

lid

and

closure

seal.

Store

them in

a

safe

place

where

they

cannot

get

dirty

or

damaged.

Remove

the

basket

compression

plate(s)

as

appropriate.

For Housings with Bolted Closure

If

the

filter

housing

has

been

in

service,

refer

to

the

instructions

given

in

the

section

“Removing

the

Filter

from

Service”

.

Unscrew

the

bolt

nuts

with

a

suitable

spanner.

Swing

the

clamps

/

swing

bolts

clear

of

the

cover.

Housings without davit:

Remove

the

lid

and

closure

seal.

Store

them

in

a

safe

place

where

they

cannot

get

dirty

or damaged.

Remove

the

basket

compression

plate(s)

as

appropriate.

Housings with davit:

Turn

the

davit

nut

clockwise

(downwards)

to

jack

the

lid

sufficiently

high

so

that

it

safely

clears

the

location

lugs.

Swing

the

lid

away

from

the

housing.

Remove

the

closure

seal

and

store

it

in

a

safe

place

where

it

cannot get

dirty

or

damaged.

Remove

the

basket

compression

plate(s)

as

appropriate.

Page 5 of 9

Filter Chamber

Operating and Maintenance Instructions

www.empirepumps.com

Fitting

the

Perforated

Basket

The

housing

is

supplied

with

a

perforated

bag

support

basket.

There

is

an

inner

gasket

fitted

under

the

basket.

Check

the

'O'

ring

groove

and

inner

gasket

for

any

damage,

and

place

inner

gasket

in

the

groove.

Place

the

basket

into

position ensuring

that

the

inner

gasket

does

not

become

dislodged.

Fitting

the

Filter

Bags

Push

the

bag

into

the

basket

that

is

situated

in

the

housing

and

check

that

the

filter

bag

ring

is

fitted

flush

to

the

basket flare.

Position

the

bag

compression

plate

onto

the

top

of

the

bag

ring,

with

the

large

plate

fitting

against

the

bag

in

the basket

lip.

Turn

the

handle

so

that

it

locates

under

the

2

lugs

positioned

on

the

inside

of

the

housing

body,

this

will compress

the

bag

and

basket

against

the

inner

gasket.

Closing

the

Filter

Housing

For Housings with Vee Clamp Closure

Check

the

body

flare,

closure

seal,

lid

and

the

Vee

Clamp

for

any

dirt

or

damage.

Clean

away

any

foreign

objects

and replace

defective

parts

as

necessary.

Place

the

closure

seal

onto

the

flare

at

the

top

of

the

housing.

Replace

the

lid.

The

clamp

has

two

adjusters,

the

normal

open

coupler

that

is

to

be

placed

at

the

front

of

the

housing,

and

a

second retained

adjuster

at

the

rear.

These

should

be

loosened

before

fitting

the

clamp

around

the

cover

lip

and

housing

flare.

A small

amount

of

suitable

lubricant

can

be

used

on

the

sliding

faces

of

the

clamp.

Tighten

both

clamp

adjusters

evenly

by

Hand Only

to

ensure

that

there

is

even

pressure

by

the

clamp

around

the

periphery

of

the

housing

and

lid.

For Housings with Bolted Closure

Check

the

housing

closure

seal

groove,

the

closure

seal

and

lid

for

any

dirt

or

damage.

Clean

away

any

foreign

objects and

replace

defective

parts

as

necessary.

Place

the

closure

seal

into

the

groove

at

the

top

of

the

housing.

Housings without davit:

Pull

the

lid

down

using

the

lid

handle

ensuring

the

seal

is

not

disturbed.

Housings with davit: Swing

the

lid

into

position.

Slowly

lower

the

lid

assembly

by

turning

the

davit

nut

anti-clockwise

until the

lid

flange

is

fully

seated.

Ensure

that

the

seal

is

not

disturbed

Swing

the

bolts

/

clamps

up

into

position

ensuring

that

the

washers

locate

correctly

and

that

the

lid

is

set

squarely

on

the housing

top

ring.

Tighten

the

nuts

in

a

diagonal

basis

across

the

filter

housing.

Do Not

over

tighten.

Page 6 of 9

Filter Chamber

Operating and Maintenance Instructions

www.empirepumps.com

Putting the filter into service

Ensure

the

inlet

and

outlet

valves

are

shut.

Ensure

that

the

drain

valve

(if

fitted)

is

closed

or

the

drain

plug

is

fitted.

Open the

vent

valve

or

plug.

Gradually

open

the

inlet

valve

on

the

upstream

side

of

the

filter

housing

whilst

ensuring

that

the

down

stream

valve

remains

closed.

As

the

housing

fills,

air

will

be

expelled

from

the

vent.

When

all

the

air

has

been

expelled,

fluid

will

begin

to

flow

from

the vent.

For

safety

reasons,

it

is

important

to

ensure

that

vent

and

drain

connections

are

secure

and

that

released

fluid

is

disposed

of

to

an

appropriate

drain

or

container.

Appropriate

measures

should

be

taken

if

the

liquid

is

hazardous.

Close the

vent

valve

or

plug,

then

slowly

open

the

outlet

valve

–

the filter is

now in service and no attempt should be made to open the closure.

Regular

venting

of

the

housing,

by

opening

the

vent

to

permit

any

trapped

air

to

be

expelled,

will

maintain

the

operating efficiency

of

the

filter.

For

safety

reasons,

it

is

important

to

ensure

that

venting

is

ONLY

performed

via

a

valve,

that

the valve

is

opened

with

extreme

care

and

that

released

fluid

is

disposed

of

to

an

appropriate

drain

or

container.

Appropriate measures

should

be

taken

if

the

liquid

is

hazardous.

The

filter

can

be

operated

until

the

increase

in

the

pressure

differential

across

the

filter

bag

reaches

approximately

1.5

bar g

(25psi)

and

at

this

point

the

filter

bags

should

be

replaced.

Removing the filter from service

Close

the

outlet

valve

Close

the

inlet

valve

Caution

-

the

filter

housing

will

still

be

under

pressure

at

this

point.

Before

opening

the

filter

housing,

the

pressure

must

be

relieved.

This

can

be

done

either

by

carefully

opening

the

vent valve

or

plug

or

the

drain

valve

or

plug,

whichever

is

most

appropriate.

Before

opening

the

closure,

open

the

drain

valve

or

plug

to

allow

all

of

the

fluid

to

drain

out

of

the

housing.

The

vent

must be

open

to

allow

the

housing

to

drain

properly.

If

the

fluid

is

hazardous,

appropriate

measures

should

be

taken

before

opening

the

closure.

Page 7 of 9

Filter Chamber

Operating and Maintenance Instructions

www.empirepumps.com

For

safety

reasons,

it

is

important

to

ensure

that

vent

and

drain

connections

(such

as

any

valves

or

hoses)

are

secure

and that

released

fluid

is

disposed

of

to

an

appropriate

drain

or

container.

Replacing the filer bags

Open

the

filter

housing

according

to

the

instructions

given

in

the

section

“Opening

the

Filter

Housing”

.

Remove

the

sprung

bag

compression

plate

by

pushing

down

on

the

‘T’

bar

and

turning

anticlockwise

to

clear

the

retaining lugs.

Remove

the

filter

bags

from

the

basket

and

dispose

of

as

detailed

in

the

section

“Spent

Filter

Bag

Disposal”

.

In

some

processes,

such

as

tank

recirculation

systems,

it

may

be

acceptable

to

simply

fit

a

new

bag

without

a

cleaning procedure,

as

described

under

“Fitting

the

Filter

Bags”

.

However

in

straight

through

systems

it

may

be

considered necessary

to

completely

clean

the

filter

vessel

before

fitting

a

new

bag.

In

that

case

lift

the

basket

from

the

housing

being

careful

to

lift

the

‘O’

rings

also,

so

that

they

do

not

accidentally

drop

inside

the

vessel,

clean

the

basket,

‘O’

ring

and

vessel

by

hand

or

by

flushing

–

whichever

is

appropriate

for

the

application

and

reassemble

as

described

in

“Fitting

the Perforated

Basket

”,

“Fitting

the

Filter

Bags”

,

“Closing

the

Filter

Housing”

and

“Putting

the

Filter

into

Service”

.

Spent Filter Bag Disposal

The

spent

filter

bags

should

be

disposed

of

in

a

responsible

manner.

The

filter

itself

can

be

disposed

of

by

incineration

or as

landfill

by

an

authorised

contractor;

however,

it

is

important

for

the

user

to

check

how

the

contaminant

contained

in

the filter

should

be

disposed

of.

Maintenance

The

filter

housing

will

require

very

little

maintenance.

The

outer

surface

should

be

kept

clean

and

free

from

dirt.

This

will

prevent

contamination

of

the

filter

during

bag

change. The

Vee

clamp

should

be

maintained

as

follows:

A

small

amount

of

a

suitable

lubricant

should

be

used

on

the

sliding

surfaces

of

the

clamp.

The

clamp

adjuster

thread

must

be

periodically

greased.

We

recommend

the

use

of

molybdenum

based

grease

which

will

adhere

to

the

thread.

Binding

of the

threads

could

occur

if

they

are

not

lubricated

regularly.

Page 8 of 9

Filter Chamber

Operating and Maintenance Instructions

www.empirepumps.com

The

screw

clamp

/

swing

bolt

threads

must

be

periodically

greased.

We

recommend

the

use

of

a

molybdenum

based grease

which

will

adhere

to

the

thread.

Binding

of

the

threads

could

occur

if

they

are

not

lubricated

regularly.

The

davit

nut

and

arm

(via

the

grease

nipple

fitted)

should

be

kept

well

greased.

Grease

selection

should

be

appropriate

for the

operating

environment.

Inspect

the

closure

seal

each

time

the

filter

housing

is

opened

and

replace

as

required.

The

housing

must

be

checked

for

any

visible

signs

of

corrosion

or

wear

damage

internally

and

externally

on

a

routine

basis. Internal

examination

should

be

carried

out

via

the

housing

closure.

Page 9 of 9

Filter Chamber

Operating and Maintenance Instructions

www.empirepumps.com

Warranty

Empire Pumps Ltd warrants this pump product to be free of defects in materials and workmanship for a

period of two years from the purchase date.

It does not cover installation or system design faults, pumps seized due to deposits or damaged

packaging and Empire Pumps Ltd is not liable for consequential losses.

If a warranted defect, which is determined after inspection by Empire Pumps Ltd, occurs within the 24

month warranty period, it will be repaired or replaced as per the manufacturer’s decision. Proof of

purchase is required, along with a manufacturing serial number, data code and date of purchase.

This warranty does not apply to any other equipment used or purchased in combination with this

product. The manufacturer accepts no responsibility for product damage or personal injuries sustained

when the product is modified in anyway. This warranty shall not apply to products which have been

used other than for their intended use, misuse, negligence or accident.

Empire Pumps Ltd shall not be liable for damage or delays caused by defective material, nor shall be

liable for incidental or consequential damages, process down time, loss of production, loss of production

costs, transportation costs, labour costs, product installation or removal costs, or loss of profit. On any

and all events, the manufacturer liability shall not exceed the purchase price of the product and/ or

accessories.

De-contamination of Hazardous Solutions

Prior to returning equipment to Empire Pumps Ltd for refurbishment or inspection, the equipment must

be fully flushed, cleaned and neutralised in accordance with the chemical hazard, safety packaging

regulations and Health & Safety at Work Act 1974.

The equipment must be decontaminated and must be flushed of all dangerous chemicals in accordance

with environmental laws.

Declaration of conformity

Manufacturer: Empire Pumps Ltd

Unit 4, Guide Bridge Trading Estate, South Street, Ashton-Under-Lyne, OL7 0HU, United Kingdom

This declaration of conformity is issued under the sole responsibility of Empire Pumps Ltd. This

declaration certifies that Air-Operated Diaphragm Pump EPA series, Magnetic Driven Pump EPM series,

Drum Pump EPD series, Self-priming Pump EPS series comply with the European Community Directive

2006/42/EC on Machinery, according to Annex VIII. This product has used Harmonized Standard

EN809:1998+A1:2009, Pumps and Pump Units for Liquids - Common Safety Requirements, to verify

conformance.

The conformance is valid only if the pump is used for the liquids communicated by the customer and

for the pump characteristics required with regard to the quotation. Empire Pumps Ltd does not take

any responsibility for its pumps unless the customer operates the equipment strictly in accordance with

the operation and instruction manual.

Signed for and on behalf of Empire Pumps Ltd

Peter Zhang, Director of Operations: ……………………………………………………………………………….

Ashton-Under-Lyne, November 2019

Empire Filter Chamber Manual

Popular Water Filtration System manuals by other brands
