EMS 5003 User manual

Portable Exhaust Gas Analyzer
Operators Manual Rev 2019
Model # 5003 (4 & 5 Gas) Live Reading only and
Model # 8000 (Wired RS232)
Emissions Systems, Inc.
480 Wright Dr.
Lake In The Hills, IL. 60156
Voice & Fax: [phone]
Website: www.emsgas.com
Email Address: [email protected]

2
Table of Contents
1. TechnicalData......................................................................... Page3
2. GeneralInformation.................................................................. Page4
3. ButtonOperationModel5002.................................................. Page5
4. RearPanelDescription............................................................ Page6
5. GasAnalyzerPreparation........................................................ Page7
6. GasAnalyzer Operation........................................................... Page 8-9
7. MenuScreen Options................................................................ Page 10
7. Calibration................................................................................. Page 11-13
8. FuelSelection........................................................................ Page 14
9. 4-5Gas Selection................................................................. Page 15
10. LeakCheck Screen.............................................................. Page 15
11. Maintenance Log............................................................. Page 16
12. StatusMessages................................................................. Page 16
13. Set UpMenu................................................................. Page 17-21
14. ComputerMode............................................................. Page 22
15. Contacts &Help Screen..................................................... Page 23
15. Maintenance......................................................................... Page 24-31
16. DiagnosticAccessories........................................................ Page 32
17. Warranty.................................................................................... Page 33

3
Technical Data
Power: 10 -16 VDC
Ranges: HC: 0 - 2000 ppm (0-20,000 ppm High Range)
CO: 0 - 10%
CO2: 0 - 20%
O2: 0 - 25%
NO: 0 - 5000 ppm ( Nitric Oxide ) *
· Warm up: Less than 5 minutes
· Display resolution: HC: 1 ppm vol.
CO: 0.01% vol.
CO2: 0.1% vol.
O2: 0.01% vol.
NO: 1ppm*
· HDTouchScreendisplay:7 “
· Accuracy ( Bar 97 EPAASM ) HC: 4 ppm HC
CO: 0.02% CO
CO2: 0.3% CO2
O2: 0.1% O2
NO: 25 ppm*
· Drift: Zero and span drift are less than ± 0.6% of full scale for the first hour
and less than ± 0.4% of full scale per hour thereafter.
· System response time: Bench: 1.5 Sec/25 ft. hose 5 sec. to 90% of final
reading
· Ambient conditions: 35F (2C) to 120F (45C), rel. humidity 0-98%
· Sample hose:25 feet ( 7.5 m) with QD coupling /200 F Degrees Max.
· Sampleprobe: Stainlesssteel 1200 Degrees F(replaceable flex tip)
Mass: Approx.: 10 LBS. ( 4.5 Kg )

4
General Information
Congratulationsonyour purchaseofan EMSExhaustGasAnalyzer.Thisproductisde-
signedtoassist you in theprocess of diagnosing driveabilityissues.With proper careandmain-
tenancethis productwill provideaccurateinformationformanyyearstocome.
IMPORTANTNOTE: Moisture is the biggest concern for prolonged good operation of the gas
analyzer. Always allow the analyzer to dry out by running the unit with ambient air. This may take only
one auto shut down cycle or as much as a couple hours! The analyzer will not be harmed by powering up
and letting it sit in standby mode till ready to use. Running the analyzer with ambient air in-between
sampling and after a day of testing, is the best thing to do for prolonged life of the bench and compo-
nents not allowing carbon build up due to moisture!
Figure 1 highlights the features and buttons available on the Model 5003 front display
area. The HC will display up to five digits and is in ppm, CO is in percentage, CO2 is in percent-
age, NOX is in ppm, O2 is in percentage, LAMBDAand AFR. The buttons will be described
laterinthis manual.
Figure 1
ZEROING
BUTTON
HOME
BUTTON
CONTACT
BUTTON
HELP
BUTTON
MENU
BUTTON FUEL & 4
OR 5 GAS
SETTING
WINDOW
15 min.
SHUT
DOWN
BUTTON

5
Button Operation Model 5003
Figure2 showsthe controlbuttonsonthetouchscreenof thegas analyzer:
1. The “Zero” button has two functions.
a. Zeroing the gas analyzer as needed during use.
b. Restarting the pump following automatic shutdown.
2. The “Home” button has one function.
a. Brings you back to Gas Sample screen
3. The “Menu” button has several functions.
a.Access calibration screen
b. Change Fuel Type
c. Change display to 4 or 5 Gas
d. Leak Check for sample system
e.Maintenance Log
f. AccessStatusfor ERRORmessagescreen
e.Access Set Up to Check bench SN and PEF Value or enter activation code,
chooseWiFimode; Hostor Clientmodeand Ethernetcableconfiguration.
4. The“Help” buttonis usedto accessthe operationsmanualfor touchscreen operation,
maintenanceinfo.
5. The “Contact” button is for all the EMS shipping info, phone and website.
6. The “Setting Window” is for viewing what fuel type is picked (default is gasoline) and
for 4 or 5 gas setting for reading NOX.
7. The“15 Min Shutdown” isfor standby mode orend oftheday shutdown,oncethe
buttonis depressedthe pumpswill runfor 15min. andshutdown pumps.
Figure 2
1
23 4 5 6
7

6
Rear Panel Description
Figure3shows theview fromtheback ofthe analyzer.The specificdetailsofeach
itemare describedbelow,starting fromthe upperleftcorneroftheanalyzer andworking
clockwise.
Sample Hose Connection: The sample hose connection uses a quick disconnect
coupler.This ishelpfulforstorageoftheanalyzerandmaintenanceofthesamplehose.
Theinlet isconnectedtoaOil/Waterseparatorforpre-moisture extraction.
Display Control Switch: The display switch has two basic positions, Computer and
Display. The switch should normally be in the DOWN position “Display”. If you are using
PC software for display or recording, the switch should be in the UP position. Note: The
switch direction is based upon you looking at the display. The switch should be
changed only with power turned off.
DB9 Computer Connection: This is used to connect the analyzer to your PC/laptop or
wirelessantenna.
Power Cord: Connect to the appropriate voltage supply source.
Sample Air Exhaust: The analyzer discharges the sample air out these ports. Do not
plug..
Drain Hose: This hose will drain moisture collected during the sample process.
External Filter, Water Trap, Water/Oil Separator: This is the primary filtration system.
Filter maintenance will be discussed in the Maintenance section of this manual.
Water Separator Drain: Drain daily opening a ball valve.
Figure 3
WATERSEPARATOR
PRE-FILTER
MANUALDRAIN
WATERTRAPPRE-
FILTERW/AUTOMATIC
DRAIN
HIGHPERFORMANCE
WATER/OILSEPARATOR
WITHMANUALDRAIN
SAMPLE
HOSE CONN. COMPUTER
MODESWITCH
DB9
COMPUTER
CONN.
POWER
CORD
SAMPLEAIR EXHAUST
DRAIN
HOSE
EXTERNAL
FILTER

7
Gas Analyzer Preparation
Getting started is simple. Figure 4 shows the items you should have received in the
shipping container. Note: This description applies to the Model 5003 analyzer with a live
reading only display. The first step is assembling the sample hose. Once the sample hose,
handle and S.S. probe are assembled, connect the hose to the sample hose QD fitting on the
inlet connection of the water/oil separator.
Figure 4
The next step is providing power to the analyzer. The analyzer should be connected to a
12v DC power source. You have several options:
1. Cigarette Lighter Connection - Figure 5 (Supplied by EMS)
2. Cigarette lighter to battery connection with adapter - Figure 6 (Optional)
3.AC to DC Power Supply - Figure 7 ( 5AMP min. and 10AMP) (Optional)
Figure 5 Figure 6 Figure 7
NOTE: Power supply voltage to the analyzer needs to be a consistent 12 VDC. If any
start up issues occur check power supply or battery.

8
Gas Analyzer Operation
Shortlyafterapplyingpower, theanalyzer willdisplay theEMS logo& worldstartupscreen.
Itwilldisappear onceand reappear(Figure8) forapprox.15 sec.thenswitch totheHome sampling
screen(Figure 9).This startsthe analyzerwarm-up modeand willcontinue forapproximately 5to
10minutes, dependingon ambienttemperature. Oncethe warm-upiscomplete,theanalyzerwill
gointothe“ZEROING”mode toset allthegases tozero. Thenthegas samplemode will displayall
the gas values (Figure 10). 4 Gas units will show CO2, CO, HC, O2 (figure 11) Note: Below the
gas data is a status line where operations and/or errors will be displayed.
Figure 8 Figure 9
Figure 10
Once the analyzer has completed the warm-up, the sample hose can now be connected
and the probe placed in the tailpipe.
Caution: Exhaust gases pass through the gas analyzer and vent through its ex-
haust. Use the analyzer in a well vented area. EMS can supply a venting hose assembly.
Note: Gas analyzers are designed for diagnostics and verification of repairs. The
sample probe should be removed from the tailpipe after taking readings to prolong
analyzer life and save on maintenance costs.
Caution: Monitor the clear hose between the filter assembly and the housing. If
moisture appears in the tubing, remove the probe from the tailpipe and disconnect the
sample hose from the analyzer immediately. Use compressed air to remove moisture from
the sample hose. Operate the analzyer without the exhaust sample hose connected until
the moisture is removed. It may be necessary to replace the filters. Once the lines are dry,
normal operation can continue.
Figure 11

9
Gas Analyzer Operation
Manual Zero:Anytime afterwarm-up, youcanzero thegas readingsandcalibrate O2by
pressingthe “ZERO” button(Figure12).Oncethe buttonis depressed,you willsee thebutton
turnredshowingthebutton wasdepressed (Figure13).When thisoperation isbeingdone “ZE-
ROING”will bedisplayed inthestatusline(Figure14) andwill flushthe benchfor 30sec. with
ambientair frominsidetheanalyzer. Ifthe pumpsare shutdown, pushthe“ZERO”buttonand the
pumps willautomaticallystart. Note: The sample probe should be removed from the tailpipe,
when the unit is being zeroed.
Request Zero: The analyzerwill automaticallyrequest azero asneeded. Ifthe analyzer
requestsa zeroduring sampling,you canfinish yourtest firstbefore Zeroing.Thebenchcontrols
theZero requests,normallyafterseveralhours ofrunningthebenchwill notrequestaZero,but
longsampling ordrift maycause thisrequest. Ifany readingsare jumpydue tocontamination, just
keepthe pumpsrunning andZerooftentillthereadingsstabilize.
Figure 15
Low Flow Warning: If gas flow into the bench becomes restricted due to clogged filters or re-
strictedsamplehose, thestatus line will indicate “LOW FLOW” (Figure15) andthe pumps
wouldshutoff. To cleartheLOW Flowwarning, gotothe Leakcheck screentoperform aleak
test.Disconnect andcheckthe samplehose forrestrictions orkinks.If noproblems arefound,
checkthe filters.Begin withthe Externaland watertrap filter thencheck theInternal filter.Keepin
mind,the watertrapassemblythegasflowsthrough theinside tothe outsideofthe filter.The filter
maylookclean ontheoutside, butbe clogged onthe inside. Thebest check isto lookatthe
bottomof thewatertrap filter.If the LOW FLOW continuesto bedisplayed, thesolenoid valvewill
needtobe checkedor possibly replaceddue tocarbonbuildup. Pumpswillstart oncethe restric-
tion is cleared.
Figure 12 Figure 13
Figure 14

10
Figure16 showsthe controlbuttons ontheMENUtouchscreenofthe gasanalyzer:
1.The “CALIBRATION” buttonhas onefunction.
a.Calibration ofHC,CO,CO2,Nox.
2. The“FUEL” buttonhasonefunction.
a.Change thefueltype beingtested tocorrecttheAFR/LAMBDAformula.
3. The“4 or 5 GAS” buttonhasonefunction.
a. Changes the HOME screen to display 4 gases or 5 gases.
4. The“LEAK CHECK” buttonis used tocheckfor leaksinsidethe analyzer orthe com-
pleteanalyzer andsample hoseprobe assembly..
5. The“MAINTENANCE LOG” buttonallows youto enteradate offilter andsensor
changeout.
6.The “STATUS” is forviewingany errormessages from thebench andsensors.
7. The“SETUP” .buttonhas severalfunctions
a.Checkthe EMSdisplay softwareversion.
b.Check thebenchSN.
c. Checkbench PEFvalues; LOWandHIGH.
d.Enterthe display softwareActivationcode.
e.Ethernet cableconfigurationDataAcquisition interface.
f. Choose WiFi mode; Host mode: EMS live reading display interface.
g. Choose WiFi mode; Client mode: DataAcquisition interface
e.Access Statusfor ERRORmessage screen
8. The “RESTART” is for restarting the EMS processor for debugging in case of connection
problemsso youdon’tpower downthe analyzer. Note: Ifyou restartthe processorand gobackto
theHomescreen, aZero isrequired toestablishbench communication.Note: Restart is
required after WiFi Host or Client mode is selcted.
1 2
3 4
6
7
5
Figure 16
8
MENU SCREEN

11
The gas analyzer should be checked periodically for accuracy. For normal shops using
the analyzerthis wouldbe approx.3-6 months,for higherusage approx.every 1monthormore.
Theanalyzer canbe calibratedinthefield.Inordertoperformthe calibrationprocedure youwill
need a bottle of calibration gas and a calibration kit (Figure 17). The calibration Kit (EMS-5500)
canbepurchased fromEMSor your localdistributor.The recommendedcalibrationgas is Bar97
Low and can be purchased from EMS, Part No.EMS-5502; BAR 97 LOW.
Calibration
Figure 17
Calibration Procedure:
1. To begin the calibration procedure depress the “Menu” button on the Home sampling
screen.Themain menuscreen willshowyouthe“Calibration”button(Figure16)Press
the“CAL”button and thedisplay willgo tothecalibration screenand showthestored
calibrationgas valueshighlightedin whitebox (Figure18). Comparethesenumberstothe
calibrationgas bottle.If thenumbers donot match,change thevalues bypressing each
gasvaluebox,a keypad willopen( Figure19)press Backto clearthevalue, andenterthe
newvalues foreach gasasneededandpresstheEnt,enterbutton. Oncethe valuesare
changedpressthe “Accept”button. NOTE: In4 Gasmodethe Noxwindow willnotappear
orbecalibrated inthe calibrationroutine.
Figure 18 Figure 19

12
Calibration
2.The statuslinewilldisplay“Zeroing” (Figure20) oncethe calibrationgas valueshave
beensent tothe bench,the analyzerwill Zerofor 30seconds.thenthecalibrationscreen2
will appear (Figure 21). Once screen 2 appears, calibration gas can be connected and
turned on as indicated on the status line. (Note: Do not adjust the regulator, this was
preset to the appropriate flow rate. DO NOT press the save button with out calibra-
tion gas attached and flowing to the analyzer.)
3.Cal 2screen shows3columns.Thefirstcolumnshowsthestoredcalibrationvalues
typedinfrom thecal bottlescreen1. Themiddle columnwill display thecalgas liveread-
ingvalues fromthecalbottle,thelastcolumn isa %variance tothe calibrationvalues and
thelivereadings.Withthe calgas connected,oncethe gasvalues stabilize(Figure22),
Note:TheO2readingmust be1% orlessto activatethe savebutton.pressthe“Save”
button( Figure23).Thestatusbarwillshow savingcal data,and thencalibration complete,
andthe valuesshould bereading accurately.Apercentagedifferencevalueisshowninthe
3rdcolumnto seehow faroffcalibration wasbefore andthenafter calibration(Figure 24).
Thecalibrationprocess isnow complete.Turnthe calibrationgasofftosave gas.The
calibrationprocessshould takeapprox30-40 sec.
Figure 20 Figure 21
Figure 22 Figure 23

13
Calibration
Figure 24 Figure 25
NOTE: Thehydrocarbongas inthe calibrationcylinderis propane(LPG), andthegas
analyzer generally measures hexane. This is problematical, as hexane is a molecule that
is about twice as large as propane. This means that the typical HC reading on the gas
analyzer(hexane) shouldbe about½ thepropane value(Figure25)onthecalibration
cylindertag. Thatis,ifthetag statesthat thecylinder contains1200 ppmpropane, thenan
analyzermeasuringHC ashexane willreportHC atabout 600ppm.The PEFvalue (
Propaneequivalence factor)can beused tocalculate theHexane gasvalue. Youhave
accessto thebenchPEF valuein theSETUPMenuscreen.Youcanalso gointo thefuel
selectionscreenand pickLPG foran accuratecalibrationgas valuethat thedisplaycalcu-
lates automatically. NOTE: EMS recommends allowing the analyzer to warm up for a
min. of 1 hour before calibrating. You may also need to calibrate more than once to
get the Nox sensor to calibrate more accurate, ecspeacially for BAR 97 HIGH gas.
If checking accuracy you will also see the Nox get more accurate as you allow the
analyzer to run, warming up all the sensors to a consistent temperature approx. 2-
3 hours.
After calibration you will see a Bad Nox sensor message, this is a False error we
can’t seem to eliminate! Zero the analyzer on the Home screen to clear the error
message.

14
Figure 27
FUEL SELECTION
The default fuel is Gasoline, you can pick from the default and E85, Diesel, LPG, & CNG fuel
(Figure26). Thepurposeof thefuel changeistocalculatethe LAMBDA/AFRvalue moreaccu-
ratelyfor thedifferentfueltypes.Thisisdone bychanging theatomic ratio’sof thedifferent fuelsin
theLAMBDA formula.The formulaused isthe BrentscheinderFormula (Figure27).
Figure 26

15
4-5 GAS SELECTION
TheGasAnalyzer willbe set upfor 4or5 gasoperationat thetime of purchase.The 4 gasunit
displaysHC,CO,CO2,O2,AFRandLAMBDAand the5gas unithasHC,CO,CO2, O2,NOX,AFR
andLAMBDA.Theunitwould notneed to bechanged bythecustomer. To choose4-5gas goto
themenuscreen andpress 5 or4 gasbutton, thenchoose the 5or 4gasbutton (Figure28).
Returntothe Homescreen andthe displaywillindicate 4or 5gasin thesetting window.
Figure 28
TheGasAnalyzer needsto be checkedoccasionally for LEAKS.O2 leaks cancause gas read-
ingstobe offor not readat all.LeakCheck shouldbeperformed afterevery filter changeout to
insurenoO2 leakscausing invalidgasreadings.To performaLeak Checkpress the menubutton
onthe Homescreenand presstheleak checkbutton onthe Menuscreen .Thisbringsyouto the
leak check screen (Figure 29) Leak Check duration is 30 Sec.
Plugthe inletquick connectoron theanalyzer witha rubbercap foran internalleak check.The
model5003 willshowLOW FLOW:Yes/Noonthescreenand thepumpswillshutoff, pressthe
Test buttontostartthe 30sec. leakcheck. Ifthe pumpsstayoff theduration ofthe test,thereare
noleaksand thetest statuswillindicate pass/fail.·
Leak Check your sample hose and probe every filter change out only after you have verified no
internal instrument leaks. Connect the sample hose to the analyzer and plug the end of the
probe with the red/black plastic cap supplied by EMS. The same low flow codes will come up
as described above and the low flow should hold for the duration of the test. If a leak is de-
tected, meaning the pumps turn back on losing vacuum, the most common leak is at the external
filterbowl connection. Thiscanbeverifiedbyusingabutanelighter openingraw butanenext to
thefilterhead, yourHC readingwillspike ifthere isaleak.You shouldalso check allthreaded
connections and hose connections including tie straps, twisting to ensure a seal.
LEAK CHECK SELECTION
Figure 29

16
Iftheopticalbenchdetects anyerrors duringoperation,a messagewill bedisplayedon the
Status Line of the Home screen. If any error messages comes up, press the menu button, and
thenpress thestatus button(Menu Screen). Atthis pointyou cansee anyerrors beingsent from
theopticalbench(Figure32). Theerrors thatwouldpossibly bedisplayed are:
-Bench inWarmUp:ThisiscontrollerbythebenchMPwith acount down.
-Bench Requestsa Zero:This iscontroller bytheIRbench,pressZerobutton.
-LOWFlow: Thiswould be cloggedfilter orrestrictedsample hose.
-HCZero Warning: Thiscould beabad calibrationorbad opticalbench channel.
-COZero Warning: Thiscould beabad calibrationora badopticalbench channel.
-CO2ZeroWarning:This couldbea badcalibration or abad opticalbenchchannel.
- Bad NOX: This could be a bad calibration or a bad NOX sensor.
- Bad O2 : This would be a bad O2 sensor.
If an error message does appear and is a bad calibration or the optical bench detected as not
normal, depress the “ZERO” button on the “Home” sampling screen to clear the error. If the
error message doesn’t go away, either the bench has an error or is bad or one of the sensors
(O2,NOX) need to bereplaced.Note:Aftercalibration,the bench sendsaFALSEbadNox
error,Zeroto clear.
STATUS MESSAGES
Figure 32
MAINTENANCE LOG
TheGasAnalyzerneeds regularmaintenance forfilter replacementand sensorreplacement (See
maintenancesection forrecommended changeout frequency).EMS hasgivenyouamanual
maintenancelog totrackfilter andsensor replacement(Figure 30).The defaultdatewill bethe
timeof manufacture.The mainfilters toreplace areWatertrapfilter; EMS-5371,Particulate filter;
EMS-5371,Internal filter;EMS-5093.Sensors arethe O2sensor; EMS-5060andNoxsensor;
EMS-5065.
To enter thedate, pressthebox nexttothe description,and akeypadwillopen (Figure31).
Presstheclear(CLR)or theback space(BS)button toremove theexistingdate, thenenter the
newdate andhitenter(ENT)buttontoclose thekey pad.
Figure 30 Figure 31

17
SETUP MENU
TheGasAnalyzerSETUPscreen hasinformation andWiFi/Ethernetcableconfigurationfunctions
(Figure33). Thefirst5 linesare information:
1)Version; Showstheversion ofdisplay softwareon thedisplay processor.
2)Serial#: IR Bench serial# and EMS ID.
3)PEF(LOW) PropaneEquivalence Factor(PEF) for theanalyzer.See calibrationsection
forexpanded explanation.
4)PEF (HIGH)Propane EquivalenceFactor (PEF)for theanalyzer.
5)Activation Code: SN specific activation code, contact EMS for your code # if required.
Thenext 3lines areforconfiguringdifferentconnectionsthatwill beexplained furtherinthenext
pages.6)Ethernet:This configurationis forDATAAcquisitionsoftwareinterface.
7) WiFi Host Mode: EMS1 This is the live reading display WiFi interface.
8) WiFi Client Mode: This configuration is for DATA Acquisition software interface.
NOTE:After anyWiFi configuration youmust Restart thedisplayfrom theMain Menu
button 8 shown on page10.
Figure 33

18
ETHERNET CONFIGURE SCREEN
TheEthernet configurationfunctionallowsyouto connecttothenetwork andshowthenetworkIP
address.You candothistwoways:
1)DHCPis aautomatic connection;Press theDHCPfunction, thenpress connect(Figure
34).The connectbuttonwill turnred forup to30 sec.andonceconnected willbe blueagain. Press
ShowIP toverifyyouareconnected(Figure 34).
2) Static is a manual connection for a data acquisition software that needs a specific IP
addresstocommunicate. Pressthe static IPbox toopenthe keypadscreen( Figure35). Enter
yourIP addresspressEnttoclose. PressNetmask boxand enterthe Netmaskvalue. Note:If
configuringa STATIC IPforEthernet andthere isNO Gateway,thenenter0.0.0.0 forGateway
address.NOTE:Afterany WiFiconfiguration youmustRestart the displayfrom theMain Menu
button 8 shown on page 10 to access the IP address.
WIFI HOST MODE SCREEN
TheWiFi Hostmodefunctionallowsyou toconnect tothe analyzerforalivereading ona device:
1) When WiFi Host mode is selected ( Figure 36), EMS1 will appear in the window as a
defaultname.Youcanchangethisname towhat maybe requiredforyourshop.Press theWiFi
hostboxand akey padwill appear, clearor backspacethedefaultname andenterthe newname
andpressEnt. toclose the keypad.
Figure 36
Figure 34 Figure 35

19
WIFI HOST MODE SCREEN
TheWIFI functionallows youto connectto theWireless LANdongle viaa webbrowser.
WirelessLAN Connection:Toconnectto theEMS wirelessdongle, openyourdevicenetwork
connection screen ( Figure 37) click the EMS LAN connection; ie EMS1, it will require a pass-
word.Thepassword isEMS threetimes:“emsemsems” (Figure 39).Once youhave connected
totheEMSdongle,open yourweb browserforconnecting tothe internet,typeintheEMS code#:
http://10.1.1.1 (Figure 40-1) andyour devicewill connectdirectly to theanalyzeras master
connection.The masterdevicewillhavecontrol oftheZEROfunction oftheanalyzeronly.Any
otherdevice thatconnects mustuse;http://10.1.1.1/view this connectioncan viewgas readings
only, connectup to25 devicesat onetime. (Figure40-2).Note:TheGasAnalyzerconnection will
disconnectyou fromthe internetwhenusedinHostmode.Ifyouneed theinternet atthe same
time, contact EMS for an additional WiFi dongle so you can make a WiFi connection with an
additionalWiFiconnection onyour computerforthe EMSWiFi connection(Figure38).
NOTE:After anyWiFi configuration youmust Restart thedisplayfrom theMain Menu
button 8 shown on page10.
Figure 40-1 Figure 40 -2
Figure 37 Figure 38 Figure 39

20
WIFI CLIENT MODE SCREEN
TheWiFi CLIENTMODEfunctionallowsyoutoconnecttotheanalyzerwirelesslyforDataAcqui-
sitionwith aDynoorothersoftwarewith theEMS5003 protocolto collectandcontroltheanalyzer.
1) When WiFi Client mode is selected, the main Client mode screen will appear to allow
youto connectautomatically “DHCP”or manually“Static”( Figure41).
2)Pressthe Scanbutton, andtheWiFi willsearch foravailable networks(Figure42).
3)Oncethe Scanningisgone, presstheWiFi Networkbox( Figure42). This willopen a
windowshowing availableWiFinetworks (Figure 43),choose yournetworkand pressthe
closebutton.
4)Once youchooseyour network,press thePassphrase( orKey) box( Figure44),this will
openakeypadwindow( Figure45), press clearand enteryournetwork passwordkey, press
“ENT”enterand youwill bebackat theclient modescreen(Figure 44)
Figure 41 Figure 42
Figure 43 Figure 44
Figure 45
