www.emsgroup.co.uk
RadioDetec torBase
PRESSHERE TO
LOGON
IDENT
www.emsgroup.co.uk
RadioDetec torBase
PRESSHERE TO
LOGON
IDENT
www.emsgroup.co.uk
RadioDetec torBase
PRESSHERE TO
LOGON
IDENT
63 mm
1Pre installation
4 Power device
To unlock, insert a 1.5
mm allen key into the
allen key slot and turn
anticlockwise as shown.
3 Fix mounting plate
2Components
device
unpowered
(pins unlinked)
device
powered
(both pins linked)
!
Installation must conform to applicable local installation
codes and
should only be installed by a fully trained
competent person.
Ensure that the device is installed as per the site survey.
The use of a non-metallic spacer should be considered if
mounting the device on to a metal surface.
Do NOT Press the Log On button on a pre-programmed
device. This will cause communication with the Control Panel
to be lost. Should this happen, delete the device from the
system and add it back on.
This device contains electronics that may be susceptible to
damage from Electrostatic Discharge (ESD). Take appropriate
precautions when handling electronic boards.
Detector Wireless module incl. 300mm cable
Mounting plate
Remove the mounting plate by turning the device
ANTICLOCKWISE, to release it from the mounting plate.
5 Optional device locking 6 Configuration
To lock the detector into
the wireless module,
insert a 1.5 mm allen key
into the allen key slot and
turn clockwise as shown.
Use both mounting holes to ensure a firm fixing.
Use suitable fasteners and fixings.
Once powered, reassemble the device.
Wireless Detector c/w Remote Indicator
Installation Guide
FCX-170-101 Wireless Detector Base c/w Remote Indicator Unit
5-RIM Remote Indicator Unit Only
Example shown:
Model FCX-170-101
Part no Product description
SIZE AA
SIZE AA
SIZE AA
SIZE AA
SIZE AA
SIZE AA
56
Dust cover
4
OBSERVE CORRECT POLARITY, USING SPECIFIED BATTERIES.
If fitting / re-fitting batteries; observe correct polarity, using
only specified batteries.
Connect the power jumper across the PIN header.
www.emsgroup.co.uk
RadioDetector Base
PRESSHERETO
LOGON
IDENT
2 31 5
6
4 7
Front cover Mounting plate
23
7
Fixing screws
1
Remote indicator unit Wireless detector
©2021 EMS Ltd. All rights reserved Page 1 of 2 TSD033-99 Iss 6 23/11/2021 AJM
www.emsgroup.co.uk
Radio Detector Base
PRESSHERE TO
LOGON
IDENT
The device’s loop address is configured within the user interface’s
menu structure.
Refer to the programming manual for full programming details.
Free to download from
www.emsgroup.co.uk
FireCell = MK98
Fusion = TSD062
WZM = TSD143
Closed electrical
connector
www.emsgroup.co.uk
Radio Detector Base
PRESSHERE TO
LOGON
IDENT
Operating
temperature -10 to +55 °C
Storage
temperature 5 to 30 °C
Humidity 0 to 95% non-condensing
Supply 6x AA alkaline (Panasonic LR6AD Powerline /
Varta 4006 Industrial)
CAUTION!
Fitting of an incorrect battery type invalidates the product certification and
may result in poor performance.
IP rating IP23
Operating
frequency 868 MHz
Output
transmitter
power Auto adjusting 0 to 14 dB (0 to 25 mW)
Dimensions
(H x W x D) 85 x 85 x 45 mm (remote indicator unit)
Dimensions
(Ø x D) 113 x 40 (detector base only)
Weight 0.15 kg (remote indicator unit)
0.40 kg (wireless detector with detector fitted)
Location Type A: For indoor use
2012/19/EU (WEEE directive):
Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the
European Union. For proper recycling, return this
product to your local supplier upon purchase of
equivalent new equipment, or dispose of it at
designated collection points. For more information
see www.recyclethis.info
Dispose of your batteries in an environmentally
friendly manner according to your local regulations.
European Union
directives
EMS declares that this device is in compliance with
Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the
following internet address:
www.emsgroup.co.uk
Certification
Certification body
CPR DoP 0359-CPR-0041
0905
10
IMPORTANT
Remove dust cover before use.
The device should be tested upon installation and in accordance
with local requirements.
Testing should only be carried out by a fully trained competent
person.
The manufacturer recommends regular functional testing of at
least once per annum or in accordance with local codes of
practice.
Cleaning and repairs must be undertaken by the manufacturers
authorised representative.
Do not open the case to clean inside the detector.
!
Specification
E
N54-25:2008.Incorporating corrigenda September
2010 and March 2012. Fire detection and fire alarm
systems.
Part 25: Components using radio links.
Approved to
Regulatory information
Manufacturer Carrier Manufacturing Polska Sp. Z o.o. Ul.
Kolejowa 24. 39-100 Ropczyce, Poland
Year of manufacture See devices serial number label
Only use knockouts
shown in shaded
areas.
7 Remove cable entry points 8 Fix to the wall
40 mm
40 mm
Use all four mounting
holes.
Use suitable fasteners
and fixings.
9 Wiring
Connect using the two way + and - terminals, observing
correct polarity.
Pass the cable through the pre-made entry points.
Cabling can be extended up to 30 m if required, using a closed
electrical connector.
A maximum of one detector is to be fitted to the remote
indicator unit.
©2021 EMS Ltd. All rights reserved Page 2 of 2 TSD033-99 Iss 6 23/11/2021 AJM
