Endon LULLABY-2WBCR User manual

Lullaby Wall Light
Safety Warnings
INSTRUCTION MANUAL
• Thisproductisonlysuitableforconnectionto240V~50Hzsupply,indooruseonlyandisnotsuitablefora
Bathroomlocation.
• Beforeinstallingyourlightttingalwaysswitchoffthemainssupplyandremovetheappropriatefuseor
switchofftheappropriatecircuitbreakerbeforecommencinginstallation.
• ThisisaClassItting,andmustbeconnectedtoEarth.Theterminalblocksaresuppliedaccordingto
requirementsofthetting.
• Nevertbulbsofahigherwattagethanthosespeciedonthelabel(asthesemaycauseoverheatingand
damagethetting).
• Thisproductcontainsdelicateparts.Takecareduringinstallationandmaintenancetoavoidbreakages
• Ifyouareinanydoubtaboutyourcompetencepleaseconsultaqualiedelectrician.
• Ifanymodicationismadeitwillinvalidatethewarrantyandmayrendertheproductunsafe.
EndonLighting,LS90SE
Assembly/ User Instructions
Pleasereadtheseinstructionscarefullybeforettingandretainforreference.
Checkthepackagingandmakesurethatyouhavealltherequiredparts.
Followeachassemblystepinordertopreventincorrectassembly.
Ensurethattheproductisfullyassembledasillustratedbeforeuse.
The Light pack contains:
Lighttting.
Terminalconnectionblock(s).
Fixingpack.
The following tools may be required:
Selectionofcrossandatheadscrewdrivers.
Electricdrillandassorteddrillbits.
Wirestrippers.
Electricalinsulationtape.
These assembly diagrams are intended as a guide – if in doubt consult a qualied electrician.
Before you start
Care Information
Allow10minutestocoolbeforereplacing,adjustingorcleaning.
Cleanwithadryclothonly.Donotuseliquidorabrasivecleanersonthisproduct.
56653-Lullaby-WB20150814
1. Decideonthepositionofthelighttting/orremoveexistinglighttting.Takeanoteofthepositionofthe
electricalconnections.Ensurethereisasolidmountingsurface,preferablyawoodenjoistorjoistbridgeto
supporttheweightofthelighttting.
2. Unscrewthenialatthebottom,removenutandwasherleavingthreadedtubeinplace.Retaintheseparts.
Removebowlsconce.Fitrubbergrommetshownifnotinplaceincableentryhole.Usethexingbracketas
atemplatetomarkthescrewholesandsecuretothewallwithappropriatescrewxings,makingsurethe
bracketishorizontal.
3. Supportyourttingandconnectthehousewiringtotheterminalblock.Whenyouaresureoftheconnections
wraptheTerminalBlockandoverlapthewiringbothsideswith2layersofinsulationtape.NOTE: This is a
Class I tting and must be earthed.
4. Re-tthesconce,washer,nut,andFinial

56653-Lullaby-WB20150814
EndonLighting,LS90SE
5. Fitthecandledriptubestolampholdersandthentthebulbs.NOTE: Never t bulbs of a higher wattage
than those specied on the label (as these may cause overheating and damage the tting).
6. Turnonthepowerandtest.
Assembly/ User Instructions Continued
