Boca Flasher HPNLS-LO User manual

Installation Manual
HPNLS-LO
BocaFlasher.com 1 of 6 REV 10-2020
INTRODUCTION:
The Boca HPNLS-LO is a line voltage xture that eliminates the need for secondary transformers, making installation contractor
friendly. The housing is a clear anodized aluminum with a durable nish making it weather and abrasion resistant. It is UL Listed
for dry, damp or wet location (model dependent). See layout drawings for model provided.
1. Input Voltage: 90-120VAC, 230-277VAC
2. Total linear ft per 20A breaker: Lo8 = 120ft @ 120V,
280V @ 277V
Total linear ft per 20A breaker: Lo6 = 220ft @ 120V,
420ft @ 277V
3. Total linear ft per 15A breaker: Lo8 = 96ft @ 120V,
210ft @ 277V
Total linear ft per 15A breaker: Lo6 = 160ft @ 120V,
320ft @ 277V
ELECTRICAL SPECIFICATIONS:
Fixtures must be installed by a qualied and licensed electrician in
accordance with all national, state and local electrical codes and
regulations. If any part of this manual does not meet the necessary
codes and regulations, contact the factory for more information
before attempting to install.
WARNING: DO NOT LIFT FIXTURE BY CABLES. Do not attempt to install or use the HPNLS-HO xture without
reading the installation instructions and safety labels completely. DO NOT ATTEMPT TO INSTALL OR USE THE
NANOLUME FIXTURE. This could result in permanent damage to both the xture and the cables. Damage resulting
from grasping cables and/or putting undue pressure on the cable connections will not be covered under the warranty!
FAILURE TO ADHERE TO THESE INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR PROPERTY DAMAGE.
DO NOT MODIFY, ALTER OR ATTEMPT TO SERVICE THE HPNLS-HO DOING SO WILL VOID THE WARRANTY.
Max Temp: 55°C
Min. Temp: -40°C
Storage:
Store in a dry, well-ventilated area when product is not in
use. Keep the electrical cord away from heated surfaces
when in use or not in use. If cord shows signs of damage
do not use, return product to manufacturer.
Cleaning:
Dry and Damp (IP65) Rated Fixtures:
To clean surface use a soft damp cloth.
Wet (IP68) Rated Fixtures:
To clean surface use a soft cloth with mild soap and water.
MAINTENANCE:
IP60
Dry Listing Damp Listing
IP65 IP68
Wet Listing

BocaFlasher.com 2 of 7
Installation Manual
HPNLS-LO
REV 10-2020
TURN POWER OFF AT CIRCUIT BREAKER BEFORE BEGINNING INSTALLATION!
INCLUDED IN THE PACKAGE:
2. Mounting Brackets
(2 brackets per xture)
3. Job Specic Drawings1. HPNLS-LO Fixtures, (In lengths shown
on job specic drawings)
OR
OR
Fixed
3” Arc
Swivel
6” Arc
HPNFC-HO
HPNFC-RT
Power cord length is
6.5ft per UL standard
FIGURE A: CLIP ALIGNMENT

BocaFlasher.com 3 of 7
Installation Manual
HPNLS-LO
REV 10-2020
Locking Swivel Bracket:
1. Boca Flasher recommends
using an off set Philips screw
driver with a #2 bit.
2. Screwdriver should be capable
of making a 90° bend.
Screw Information:
1. Screws not provided by
Boca Flasher.
2. Boca Flasher recommends
wide washer at head Philips
#8 screw (not to exceed
.418” in diameter).
3. Length of screw will vary
depending on mounting
surface.
4. For outdoor installations,
installer should use a screw
with weatherproof coating.
1: INSTALL CLIPS INTO SUBSTRATE
1. Fixed Clips
1a 1b
3. 3” Arc and 6” Arc Bracket Installation
1a
1b
1a 1b
2. Swivel Clips
2. INSTALL FIXTURE INTO CLIPS
2a Place the notch on the clip into the rst notch of the xture. 2b Fixture will pivot on notch as it is pushed down.
2c Clip will securely snap into place. 2d If using the Swivel Clip or Arc Bracket loosen the screw where the
clip and swivel bracket meet to adjust angle of the xture.
“SNAP!”

BocaFlasher.com 4 of 7
Installation Manual
HPNLS-LO
REV 10-2020
3. CLIP POSITIONING
3a Fixed Mounting Clip
3c Swivel Mounting Clip
3b Arc Mounting Clip
4. CONNECT CABLES TOGETHER (AS SHOWN ON JOB SPECIFIC DRAWING)
HPNFC-HO
HPNFC-HO
HPNFC-RT
BF-01
IMPORTANT NOTE: Not clicking xtures together represents an
incomplete install and voids the warranty. If any xtures are damaged
as a result of improper installation
4a Rotate xture to see bottom and note
each label.
4b Cross-reference with Job Specic Drawing. 4c Connect Male and Female end caps in
order shown on job specic drawings.
4d Push together until you hear a “CLICK”
then twist until secure.
“CLICK!”

BocaFlasher.com 5 of 7
Installation Manual
HPNLS-LO
REV 10-2020
5. CONNECT FIXTURES TOGETHER
5a See above for information on determining layout.
5b Connect Male and Female cables in order shown on job
specic drawings.
5c Push together until you hear a “CLICK.”
6. CONNECT FIXTURES TO POWER
7. CONNECT FIXTURES TO DIMMING SYSTEM
NOTE:
These xtures can dim on
forward (leading) or reverse
(trailing) phase dimmers. Boca
Flasher does not recommend
the use of a “Smart” or phase-
adaptive dimming module.
TO 20A Breaker
Line Voltage
Connection Box
Input Voltage is Line Voltage
Black (Line)
White (Neutral)
Black (Line)
White (Neutral)
Green (Ground)
Green (Ground)
To 20A Breaker
Line Voltage
Incandescent
(Line voltage)
Dimmer Switch*
Connection Box
Input Voltage is Line Voltage
Black (Line)
White (Neutral)
Black (Line)
White (Neutral)
Green (Ground)
Green (Ground)

BocaFlasher.com 6 of 7
Installation Manual
HPNLS-LO
REV 10-2020
1. DANGER:
To reduce the risk electric shock, always unplug the HPNLS-LO from electrical outlet before cleaning.
Cut breaker if outlet is not available.
2. To reduce the risk of burns, re, electric shock or injury to persons:
– Use the HPNLS-LO only for its intended use as described in these instructions.
– Do not use attachments not recommended by Boca Flasher.
– Never operate the HPNLS-LO if it has a damaged cord, cable or plug, if it is not working properly, if it has been dropped or
damaged, or dropped into water. If the seal appears to be damaged/broken/torn return the xture to a service center for
examination or repair.
– Keep cables away from heated surfaces
– Never drop or insert any object into any opening.
– Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
3. WARNING:
– Do not attempt to install or use the HPNLS-LO without reading the installation instructions and safety labels.
– Failure to adhere to these instructions could result in serious injury or property damage.
4. Do not modify, alter or attempt to service the HPNLS-LO:
– Doing so will void the warranty.
5. There are no serviceable parts within the HPNLS-LO:
– Please contact your local representative if issues arise on site during or after installation.
6. Do not use sharp tools near or on the xture lens:
– Doing so will result in property damage and void the warranty.
8. REMOVING FIXTURES FROM CLIPS
8a Slide a athead screwdriver in between the
clip and xture.
8b While holding xture with other hand, pull
back on screwdriver to release from notch.
8c Once released from one notch, xture can
be fully removed.
Boca Flasher, Inc. 508 South Military Trail, Deereld Beach, Florida 33442 USA Phone: [phone] Fax: [phone] © 2017 Boca Flasher, Inc
We are constantly improving our xtures and reserve the right to change options and specications. Additional information & details at www.bocaasher.com. For
specic requirements, contact your Boca Flasher sales representative. All rights reserved. All names and trademarks are property of their respective owners.
