Brief Operating Instructions
Micropilot FMR56, FMR57
HART
Free space radar
These Instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Detailed information about the device can be found in the
Operating Instructions and the other documentation:
Available for all device versions via:
– Internet: www.endress.com/deviceviewer
– Smart phone/tablet: Endress+Hauser Operations App
KA01102F/00/EN/05.18
71394715
2018-04-12

Micropilot FMR56, FMR57 HART
2 Endress+Hauser
Order code:
Ext. ord. cd.:
Ser. no.:
www.endress.com/deviceviewer Endress+Hauser
Operations App
XXXXXXXXXXXX
XXXXX-XXXXXX
XXX.XXXX.XX
Serial number
1.
3.
2.
A0023555

Micropilot FMR56, FMR57 HART Table of contents
Endress+Hauser 3
Table of contents
1 Wichtige Hinweise zum Dokument ................................................ 4
1.1 Symbols ............................................................................. 4
1.2 Terms and abbreviations ................................................................. 6
1.3 Registered trademarks .................................................................. 7
2 Basic safety instructions .......................................................... 8
2.1 Requirements for the personnel ............................................................ 8
2.2 Designated use ........................................................................ 8
2.3 Workplace safety ...................................................................... 9
2.4 Operational safety ......................................................................9
2.5 Product safety ......................................................................... 9
3 Product description .............................................................. 11
3.1 Product design ....................................................................... 11
4 Incoming acceptance and product identification ................................. 12
4.1 Incoming acceptance ................................................................... 12
4.2 Product identification .................................................................. 13
5 Storage, Transport ............................................................... 14
5.1 Storage conditions .................................................................... 14
5.2 Transport product to the measuring point ................................................... 14
6 Installation ...................................................................... 15
6.1 Installation conditions .................................................................. 15
6.2 Measuring conditions .................................................................. 21
6.3 Installation in vessel (free space) .......................................................... 22
6.4 Container with heat insulation ........................................................... 31
6.5 Turning the transmitter housing .......................................................... 31
6.6 Turning the display .................................................................... 32
6.7 Post-installation check ................................................................. 33
7 Electrical connection ............................................................ 34
7.1 Connection conditions .................................................................. 34
7.2 Connecting the measuring device ......................................................... 48
7.3 Post-connection check ..................................................................52
8 Commissioning via SmartBlue (app) ............................................. 52
8.1 Requirements ........................................................................ 52
8.2 Commissioning ....................................................................... 53
9 Commissioning via wizard ....................................................... 57
10 Commissioning (via operating menu) ............................................ 58
10.1 Display and operating module ............................................................ 58
10.2 Operating menu ...................................................................... 61
10.3 Unlock the device ..................................................................... 62
10.4 Setting the operating language ........................................................... 62
10.5 Configuration of a level measurement ...................................................... 63
10.6 User-specific applications ............................................................... 64

Wichtige Hinweise zum Dokument Micropilot FMR56, FMR57 HART
4 Endress+Hauser
1 Wichtige Hinweise zum Dokument
1.1 Symbols
1.1.1 Safety symbols
Symbol Meaning
DANGER
DANGER!
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in
serious or fatal injury.
WARNING
WARNING!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
serious or fatal injury.
CAUTION
CAUTION!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
minor or medium injury.
NOTICE
NOTE!
This symbol contains information on procedures and other facts which do not result in
personal injury.
1.1.2 Electrical symbols
Symbol Meaning Symbol Meaning
Direct current Alternating current
Direct current and alternating current Ground connection
A grounded terminal which, as far as
the operator is concerned, is grounded
via a grounding system.
Symbol Meaning
Protective Earth (PE)
A terminal which must be connected to ground prior to establishing any other connections.
The ground terminals are situated inside and outside the device:
• Inner ground terminal: Connects the protectiv earth to the mains supply.
• Outer ground terminal: Connects the device to the plant grounding system.
1.1.3 Tool symbols
A0011219 A0011220 A0013442 A0011221 A0011222
Cross-head
screwdriver
Flat blade
screwdriver Torx screwdriver Allen key Hexagon wrench

Micropilot FMR56, FMR57 HART Wichtige Hinweise zum Dokument
Endress+Hauser 5
1.1.4 Symbols for certain types of information
Symbol Meaning Symbol Meaning
Permitted
Procedures, processes or actions that
are permitted.
Preferred
Procedures, processes or actions that
are preferred.
Forbidden
Procedures, processes or actions that
are forbidden.
Tip
Indicates additional information.
Reference to documentation.
A
Reference to page.
Reference to graphic.
1.
,
2.
,
3.
… Series of steps.
Result of a step. Visual inspection.
1.1.5 Symbols in graphics
Symbol Meaning
1, 2, 3 ... Item numbers
1.
,
2.
,
3.
… Series of steps
A, B, C, ... Views
A-A, B-B, C-C, ... Sections
-
Hazardous area
Indicates a hazardous area.
.
Safe area (non-hazardous area)
Indicates the non-hazardous area.
1.1.6 Symbols at the device
Symbol Meaning
Safety instructions
Observe the safety instructions contained in the associated Operating Instructions.
Temperature resistance of the connection cables
Specifies the minimum value of the temperature resistance of the connection cables.

Wichtige Hinweise zum Dokument Micropilot FMR56, FMR57 HART
6 Endress+Hauser
1.2 Terms and abbreviations
Term/abbreviation Explanation
BA Document type "Operating Instructions"
KA Document type "Brief Operating Instructions"
TI Document type "Technical Information"
SD Document type "Special Documentation"
XA Document type "Safety Instructions"
PN Nominal pressure
MWP Maximum Working Pressure
The MWP can also be found on the nameplate.
ToF Time of Flight
FieldCare Scalable software tool for device configuration and integrated plant asset management solutions
DeviceCare Universal configuration software for Endress+Hauser HART, PROFIBUS, FOUNDATION Fieldbus
and Ethernet field devices
DTM Device Type Manager
DD Device Description for HART communication protocol
εr (DC value) Relative dielectric constant
Operating tool The term "operating tool" is used in place of the following operating software:
• FieldCare / DeviceCare, for operation via HART communication and PC
• SmartBlue (app), for operation using an Android or iOS smartphone or tablet.
BD Blocking Distance; no signals are analyzed within the BD.
PLC Programmable Logic Controller
CDI Common Data Interface
PFS Pulse Frequence Status (Switching output)

Micropilot FMR56, FMR57 HART Wichtige Hinweise zum Dokument
Endress+Hauser 7
1.3 Registered trademarks
HART®
Registered trademark of the FieldComm Group, Austin, USA
Bluetooth®
The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG,
Inc. and any use of such marks by Endress+Hauser is under license. Other trademarks and
trade names are those of their respective owners.
Apple®
Apple, the Apple logo, iPhone, and iPod touch are trademarks of Apple Inc., registered in the
U.S.and other countries. App Store is a service mark of Apple Inc.
Android®
Android, Google Play and the Google Play logo are trademarks of Google Inc.
KALREZ®, VITON®
Registered trademark of DuPont Performance Elastomers L.L.C., Wilmington, USA
TEFLON®
Registered trademark of E.I. DuPont de Nemours & Co., Wilmington, USA
TRI CLAMP®
Registered trademark of Alfa Laval Inc., Kenosha, USA

Basic safety instructions Micropilot FMR56, FMR57 HART
8 Endress+Hauser
2 Basic safety instructions
2.1 Requirements for the personnel
The personnel must fulfill the following requirements for its tasks:
‣Trained, qualified specialists must have a relevant qualification for this specific function
and task.
‣Are authorized by the plant owner/operator.
‣Are familiar with federal/national regulations.
‣Before starting work, read and understand the instructions in the manual and
supplementary documentation as well as the certificates (depending on the application).
‣Follow instructions and comply with basic conditions.
2.2 Designated use
Application and measured materials
The measuring device described in these Operating Instructions is intended for the
continuous, contactless level measurement of mainly bulk solids. The device can also be freely
mounted outside closed metal vessels (e.g. above basins, open channels or open piles) because
of its operating frequency of about 26 GHz, a maximum radiated pulsed power of 23.3 mW
and an average power output of 0.076 mW. Operation is completely harmless to humans and
animals.
Observing the limit values specified in the "Technical data" and listed in the Operating
Instructions and supplementary documentation, the measuring device may be used for the
following measurements only:
‣Measured process variables: level, distance, signal strength
‣Calculated process variables: Volume or mass in arbitrarily shaped vessels; flow through
measuring weirs or flumes (calculated from the level by the linearization functionality)
To ensure that the measuring device remains in proper condition for the operation time:
‣Use the measuring device only for measured materials against which the process-wetted
materials are adequately resistant.
‣Observe the limit values in "Technical data".
Incorrect use
The manufacturer is not liable for damage caused by improper or non-designated use.
Verification for borderline cases:
‣For special measured materials and cleaning agents, Endress+Hauser is glad to provide
assistance in verifying the corrosion resistance of wetted materials, but does not accept any
warranty or liability.
Residual risk
The electronics housing and its built-in components such as display module, main electronics
module and I/O electronics module may heat to 80 °C (176 °F) during operation through heat
transfer from the process as well as power dissipation within the electronics. During operation
the sensor may assume a temperature near the temperature of the measured material.
Danger of burns due to heated surfaces!
‣For high process temperatures: Install protection against contact in order to prevent burns.

Micropilot FMR56, FMR57 HART Basic safety instructions
Endress+Hauser 9
2.3 Workplace safety
For work on and with the device:
‣Wear the required personal protective equipment according to federal/national
regulations.
2.4 Operational safety
Risk of injury.
‣Operate the device in proper technical condition and fail-safe condition only.
‣The operator is responsible for interference-free operation of the device.
Conversions to the device
Unauthorized modifications to the device are not permitted and can lead to unforeseeable
dangers.
‣If, despite this, modifications are required, consult with the manufacturer.
Repair
To ensure continued operational safety and reliability,
‣Carry out repairs on the device only if they are expressly permitted.
‣Observe federal/national regulations pertaining to repair of an electrical device.
‣Use original spare parts and accessories from the manufacturer only.
Hazardous area
To eliminate a danger for persons or for the facility when the device is used in the hazardous
area (e.g. explosion protection, pressure vessel safety):
‣Based on the nameplate, check whether the ordered device is permitted for the intended
use in the hazardous area.
‣Observe the specifications in the separate supplementary documentation that is an integral
part of these Instructions.
2.5 Product safety
This measuring device is designed in accordance with good engineering practice to meet state-
of-the-art safety requirements, has been tested, and left the factory in a condition in which it
is safe to operate. It meets general safety standards and legal requirements.
NOTICE
Loss of degree of protection by opening of the device in humid environments
‣If the device is opened in a humid environment, the degree of protection indicated on the
nameplate is no longer valid. This may also impair the safe operation of the device.
2.5.1 CE mark
The measuring system meets the legal requirements of the applicable EC guidelines. These are
listed in the corresponding EC Declaration of Conformity together with the standards applied.
Endress+Hauser confirms successful testing of the device by affixing to it the CE mark.

Basic safety instructions Micropilot FMR56, FMR57 HART
10 Endress+Hauser
2.5.2 EAC conformity
The measuring system meets the legal requirements of the applicable EAC guidelines. These
are listed in the corresponding EAC Declaration of Conformity together with the standards
applied.
Endress+Hauser confirms successful testing of the device by affixing to it the EAC mark.

Micropilot FMR56, FMR57 HART Product description
Endress+Hauser 11
3 Product description
3.1 Product design
3.1.1 Micropilot FMR56
1 4
1
22
3
A0016791
 1 Design of the Micropilot FMR56 (26 GHz)
1 Electronics housing
2 Horn 80mm/100 mm (3in/4in), PP cladded
3 Flange
4 Mounting bracket

Incoming acceptance and product identification Micropilot FMR56, FMR57 HART
12 Endress+Hauser
3.1.2 Micropilot FMR57
1
2 4
4
6
3
5 7
1 1
A0016807
 2 Design of the Micropilot FMR57 (26 GHz)
1 Electronics housing
2 Process connection (Thread)
3 Horn antenna
4 Flange
5 Antenna extension
6 Alignment device
7 Parabolic antenna
4 Incoming acceptance and product identification
4.1 Incoming acceptance
Upon receipt of the goods check the following:
• Are the order codes on the delivery note and the product sticker identical?
• Are the goods undamaged?
• Do the nameplate data match the ordering information on the delivery note?
• Is the DVD with the operating tool present?
If required (see nameplate): Are the Safety Instructions (XA) present?
If one of these conditions is not satisfied, contact your Endress+Hauser Sales Center.

Micropilot FMR56, FMR57 HART Incoming acceptance and product identification
Endress+Hauser 13
4.2 Product identification
The following options are available for identification of the measuring device:
• Nameplate specifications
• Extended order code with breakdown of the device features on the delivery note
• Enter serial numbers from nameplates in W@M Device Viewer
( www.endress.com/deviceviewer ): All information about the measuring device is
displayed.
• Enter the serial number from the nameplates into the Endress+Hauser Operations App or
scan the 2-D matrix code (QR code) on the nameplate with the Endress+Hauser Operations
App: all the information for the measuring device is displayed.
4.2.1 Nameplate
Order code:
Ext. ord. cd.:
Ser. no.:
Order code:
Ext. ord. cd.:
Ser. no.:
1
2
3
4
A0030196
 3 Example of a nameplate
1 Order code
2 Serial number (Ser. no.)
3 Extended order code (Ext. ord. cd.)
4 2-D matrix code (QR code)
For detailed information about interpreting the nameplate specifications, refer to the
Operating Instructions for the device.
Only 33 digits of the extended order code can be indicated on the nameplate. If the
extended order code exceeds 33 digits, the rest will not be shown. However, the complete
extended order code can be viewed in the operating menu of the device: Extended order
code 1 to 3 parameter

Storage, Transport Micropilot FMR56, FMR57 HART
14 Endress+Hauser
5 Storage, Transport
5.1 Storage conditions
• Permitted storage temperature: –40 to +80 °C (–40 to +176 °F)
• Use the original packaging.
5.2 Transport product to the measuring point
NOTICE
Housing or antenna horn may be damaged or break away.
Risk of injury!
‣Transport the measuring device to the measuring point in its original packaging or at the
process connection.
‣Do not fasten lifting devices (hoisting slings, lifting eyes etc.) at the housing or the antenna
horn but at the process connection. Take into account the mass center of the device in
order to avoid unintended tilting.
‣Comply with the safety instructions, transport conditions for devices over 18kg (39.6lbs)
(IEC61010).
A0016875

Micropilot FMR56, FMR57 HART Installation
Endress+Hauser 15
6 Installation
6.1 Installation conditions
6.1.1 Mounting position
A
1 2 3
A0016883
• Recommended distance A from wall
to outer edge of nozzle: ~ 1/6 of
vessel diameter.
Nevertheless the device should not be
installed closer than 20 cm (7.87 in)
to the vessel wall.
If the wall of the vessel is not smooth
(corrugated metal, welding seams,
irregularities etc.) the distance from
the wall should be kept as large as
possible. If necessary, use an
alignment device to prevent
interference reflections from the wall
(Verweisziel existiert nicht, aber
@y.link.required='true').
• Not in the center (2), as interference
can cause signal loss.
• Not above the fill stream (3).
• It is recommended to us a weather
protection cover (1) in order to protect
the device from direct sun or rain.
• In extremely dusty applications, the
integrated air purge connection can
prevent clogging of the antenna
(Verweisziel existiert nicht, aber
@y.link.required='true').

Installation Micropilot FMR56, FMR57 HART
16 Endress+Hauser
6.1.2 Vessel installations
a
b
A0018946
Avoid any installations (limit
switches, temperature sensors, braces
etc.) inside the signal beam. Take into
account the beam angle .

Micropilot FMR56, FMR57 HART Installation
Endress+Hauser 17
6.1.3 Reduction of interference echoes
a
b
A0016889
Metallic screens mounted at a slope
spread the radar signal and can,
therefore, reduce interference echoes.
6.1.4 Measurement in a plastic vessel
If the outer wall of the vessel is made of a non-conductive material (e.g. GRP), microwaves can
also be reflected off interfering installations outside the vessel (e.g. metallic pipes (1), ladders
(2), grates (3), ...). Therefore, there should be no such interfering installations in the signal
beam. Please contact Endress+Hauser for further information.

Installation Micropilot FMR56, FMR57 HART
18 Endress+Hauser
2
3
1
A0017125
6.1.5 Optimization options
• Antenna size
The bigger the antenna, the smaller the beam angle α and the fewer interference echoes
→  19.
• Mapping
The measurement can be optimized by means of electronic suppression of interference
echoes.
• Antenna alignment
Take into account the marker on the flange or threaded connection .

Micropilot FMR56, FMR57 HART Installation
Endress+Hauser 19
• Metallic screens mounted at a slope
They spread the radar signals and can, therefore, reduce interference echoes.
• Variable flange seal (FMR56)
Using the variable flange seal, the device can be aligned in the direction of the product
surface. For details refer to Operating Instructions BA01048F, chapter "Accessories".
• Alignment device for FMR57
In FMR57 with alignment device, the sensor can be optimally aimed within the vessel and
thus interference echoes can be avoided. The maximum angle β is ±15°.
In particular, sensor alignment serves to:
– prevent interference reflections
– extend the maximum possible measuring range in conical outlets
6.1.6 Beam angle
a
D
W
a
D
_
=2
2. . tan
W
A0016891
 4 Relationship between beam angle α, distance D and beamwidth diameter W
The beam angle is defined as the angle α where the energy density of the radar waves reaches
half the value of the maximum energy density (3-dB-width). Microwaves are also emitted
outside the signal beam and can be reflected off interfering installations.

Installation Micropilot FMR56, FMR57 HART
20 Endress+Hauser
Beam diameter W as a function of beam angle α and measuring distance D:
FMR56
Antenna size 80 mm (3 in) 100 mm (4 in)
Beam angle α 10° 8°
Measuring distance (D) Beamwidth diameter (W)
3 m (9.8 ft) 0.53 m (1.7 ft) 0.42 m (1.4 ft)
6 m (20 ft) 1.05 m (3.4 ft) 0.84 m (2.8 ft)
9 m (30 ft) 1.58 m (5.2 ft) 1.26 m (4.1 ft)
12 m (39 ft) 2.1 m (6.9 ft) 1.68 m (5.5 ft)
15 m (49 ft) 2.63 m (8.6 ft) 2.10 m (6.9 ft)
20 m (66 ft) 3.50 m (11 ft) 2.80 m (9.2 ft)
25 m (82 ft) 4.37 m (14 ft) 3.50 m (11 ft)
30 m (98 ft) 5.25 m (17 ft) 4.20 m (14 ft)
FMR57 - Horn antenna
Antenna size 80 mm (3 in) 100 mm (4 in)
Beam angle α 10° 8°
Measuring distance (D) Beamwidth diameter W
5 m (16 ft) 0.87 m (2.9 ft) 0.7 m (2.3 ft)
10 m (33 ft) 1.75 m (5.7 ft) 1.4 m (4.6 ft)
15 m (49 ft) 2.62 m (8.6 ft) 2.1 m (6.9 ft)
20 m (66 ft) 3.50 m (11 ft) 2.80 m (9.2 ft)
30 m (98 ft) 5.25 m (17 ft) 4.20 m (14 ft)
40 m (131 ft) 7.00 m (23 ft) 5.59 m (18 ft)
50 m (164 ft) 8.75 m (29 ft) 6.99 m (23 ft)
