Enduramaxx Silver series Service manual

2M SPRAY BOOM 151050

Outgang Road, Baston, PE6 9PT

www.enduramaxx.co.uk

OPERATOR’S

HANDBOOK

0800

840

4030

SILVER SERIES

READ YOUR OPERATOR’S HANDBOOK CAREFULLY

BEFORE MOUNTING AND USING YOUR SPRAYER.

KEEP YOUR HANDBOOK IN A SAFE PLACE.

Introduction

Congratulations on your purchase of a Enduramaxx Silver Series 2m Spray Boom which is

complete and ready for use. The unit is ideally suited to small farmers for weed spraying, fence

line spraying, spraying of drainage channels and around buildings etc.

Warnings

1. When mounting to any vehicle ensure that you have read the Vehicle Owner’s Manual and

that you comply with all the weight restrictions as speciﬁed by the vehicle manufacturer,

as overloading can cause injury or death.

Remember that 1 litre of water weighs 1 kilogram.

2. To ensure your own safety and that of your employees if applicable you must comply with

all relevant environmental, work place health and safety legislation and codes of practice.

3. Select and wear appropriate Personal Protection Equipment in accordance with the label of

the product you intend using and your own safe work practices.

4. Care should be taken when spraying in windy conditions as spray drift may contaminate the

air and may affect the operator or damage adjacent nontarget vegetation.

5. Once the spraying operation has been completed, decontaminate the spray tank and spray

accessories. Dispose of tank rinsing in compliance with current environmental, work place health

and safety regulations.

6. Personal Protection Equipment must still be worn while decontaminating your sprayer as per

warning at 3 above.

7. Improper or careless use of this sprayer can cause serious injury. Minors should never be

allowed to use this sprayer. This sprayer should not be used when bystanders or animals are in

the area. This sprayer should never be used while children are in the area.

8. Never leave the sprayer unattended without turning off the line pressure, and ﬂushing the

sprayer of any harmful chemicals

9. You must be in good mental health to operate this sprayer and not be under the inﬂuence

of alcohol or any drugs that could impair your vision, physical strength, dexterity, judgement,

or other mental capacity.

Calibration Procedures

The following table gives a step-by-step guidance on the standard method of sprayer

calibration.

Read the LABEL

BOOM SPRAYERS HYDRAULIC NOZZLES EXAMPLE

Spray VOLUME

Product Dose

Spray QUALITY

200 litres/hectare

50 litres/hectare

Medium

Measure time in seconds over land similar to that to be sprayed 200 litres/hectare

50 litres/hectare

Medium

Measure TIME

per 100 Metres

SPEED=360 divided by TIME

Km/h seconds

360/41.9=8.6m/hCalculate SPEED

Normally 0.5 metres (50cm) 0.5 metreMeasure nozzle

SPACING

OUTPUT=VOLUME X SPEED X SPACE X SPACE ÷ 600

Litres/min litres/hectare km/h metre

0.5 metreMeasure TIME

per 100 Metres

NOW, CHECK THE CALIBRATION ON THE SPRAYER

Refer to nozzle manufacturers data charts or other sources and

select the size and type of nozzle that will produce the calculated

OUTPUT and required spray QUALITY

41.9 secondsSelect NOZZLE

With water, check outputs of 4 or more nozzles using a calibrated

jug or ﬂow meter. Check all nuzzles are aligned correctly and

spray patterns are good

Average output

=41.9 litres/minute

Check Nozzle

OUTPUT

SPEED=360 divided by TIME

Km/h seconds

1.40 x 600÷0.5÷8.6Calibrate

SPRAYER

As the nozzle output and therefore the spray volume are less than target ﬁgures, increase the pressure to,

say 2.5 bar and repeat the calibration to achieve 200 litres/hectares

Spray Rate Application Chart

l/ha (nozzle spacing: 100 cm)

All L/Ha calculations above are per nozzle

123008 Grey

Code bar l/min 6 km/h 8 km/h 10 km/h 12 km/h 14 km/h 16 km/h

1 1.41 141 106 85 71 61 53

1.5 1.73 173 130 104 86 74 65

2 2.00 200 150 120 100 86 75

3 2.45 245 184 147 122 105 92

l/ha (nozzle spacing: 100 cm)

123006 Brown

Code bar l/min 6 km/h 8 km/h 10 km/h 12 km/h 14 km/h 16 km/h

1 1.13 113 85 68 56 49 43

1.5 1.39 139 104 83 70 60 52

2 1.60 160 120 96 80 69 60

3 1.96 196 147 118 98 84 74

l/ha (nozzle spacing: 100 cm)

Litres per Hectare – 100cm Spacing

123004 Red

Code bar l/min 6 km/h 8 km/h 10 km/h 12 km/h 14 km/h 16 km/h

1 0.88 88 66 53 44 38 33

1.5 1.08 108 81 65 54 47 41

2 1.25 125 94 75 63 65 47

3 1.53 153 115 92 76 66 58

Exploding Diagram 2m Spray Boom

Item #Part Number Quantity Quantity

137092 2 Nozzle Nut

137094 2 Nozzle strainer, 50 mesh

137090 2 Nozzle body retaining nut

198210 1 Boom, 7’ (2m)

137088 2 Nozzle body, elbow, 3/8” HB

135040 6 Snapper hose clamp

137081 1 Black Vinyl Washer

137082 1 Flat seat 3/8” hose barb

137096

1 Swivel Nut

137068 1 Tee, 3/8” HB

123008 2 Nozzle

Sprayer Decontamination and Maintenance

1. After use, the sprayer must be thoroughly decontaminated, inside and outside – including

pump, hoses, boom and hand lance- to avoid damage to crops from harmful spray residues.

Decontamination prevents sprayer corrosion and abrasion. As a guide follow the

decontamination procedure below.

After spraying, rinse out the tank with several changes of water plus a recommended cleaning

ﬂuid, brushing the inside of the tank.

Nozzles, nozzle ﬁlters, nozzle caps and gaskets should be cleaned by soaking in water, brushing

with a nozzle brush and allowed to dry. Never blow through the nozzles with your mouth, or use

wire or pins to clear any blockages. When re assembling ensure that the nozzle cap gasket is

correctly positioned.

2. When storing the sprayer ensure that it is clean and dry and kept in a ventilated place.

Whilst every care has been taken in the preparation of these instructions, no liabilities can be

accepted with regard to errors or omissions. Product speciﬁcations are subject to change in

line with our commitment to continuous improvement.
