ENERCORP Mr. Heater 1000ID Assembly instructions
OPERATING INSTRUCTIONS AND OWNER’S MANUAL
READ INSTRUCTIONS CAREFULLY: Read
and follow all instructions. Place instructions in
a safe place for future reference. Do not allow
anyone who has not read these instructions to
assemble, light, adjust or operate the heater.
MODEL
MODEL
1000ID, 2000ID
3000ID
1000ID, 2000ID
3000ID, 4000ID
08/08 #50120
INDIRECT FIRED
PORTABLE HEATER
HEATSTAR
BY ENERCO
MR. HEATER
If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or loss of life.
WARNING:
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
— Service must be performed by a qualified service agency.
This is a vented portable heater. It uses air (oxygen) from the area in which it is used. Adequate
combustion air and ventilation must be provided. Refer to page 5.
2
ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual
WARNING:
FIRE, BURN, INHALATION, AND EXPLOSION HAZARD.
KEEP SOLID COMBUSTIBLES, SUCH AS BUILDING MA
TERIALS, PAPER OR CARDBOARD, A SAFE DISTANCE
AWAY FROM THE HEATER AS RECOMMENDED BY THE
INSTRUCTIONS NEVER USE THE HEATER IN SPACES
WHICH DO OR MAY CONTAIN VOLATILE OR AIRBORNE
COMBUSTIBLES, OR PRODUCTS SUCH AS GASOLINE,
SOLVENTS, PAINT THINNER, DUST PARTICLES OR UN
KNOWN CHEMICALS.
WARNING:
ING THIS PRODUCT CONTAIN CARBON MONOXIDE,
A CHEMICAL KNOWN TO THE STATE OF CALIFORNIA
TO CAUSE CANCER AND BIRTH DEFECTS (OR OTHER
REPRODUCTIVE HARM).
GENERAL HAZARD WARNING:
FAILURE TO COMPLY WITH THE PRECAUTIONS AND
INSTRUCTIONS PROVIDED WITH THIS HEATER, CAN
RESULT IN DEATH, SERIOUS BODILY INJURY AND
PROPERTY LOSS OR DAMAGE FROM HAZARDS OF FIRE,
EXPLOSION, BURN, ASPHYXIATION, CARBON MONOX
IDE POISONING, AND/OR ELECTRICAL SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW
THE INSTRUCTIONS SHOULD USE OR SERVICE THIS
HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION
SUCH AS AN INSTRUCTIONS MANUAL, LABELS, ETC.
CONTACT THE MANUFACTURER.
WARNING:
NOT FOR HOME OR RECREATIONAL VEHICLE USE
WARNING:
YOUR SAFETY IS IMPORTANT TO YOU AND TO OTHERS,
SO PLEASE READ THESE INSTRUCTIONS BEFORE YOU
OPERATE THIS HEATER.
The State of California requires the following warning:
CONTENTS
WARNINGS.................................................................................. 2
SPECIFICATIONS........................................................................... 3
OPERATION ................................................................................. 4
SAFETY DEVICES.......................................................................... 4
MAINTENANCE............................................................................ 5
VENTILATION............................................................................... 5
TROUBLESHOOTING .................................................................... 6
WIRING DIAGRAMS..................................................................... 7
PARTS LIST..................................................................................11
WARNING:
READ THE INSTRUCTIONS GIVEN IN THIS
MANUAL BEFORE USING THE APPLIANCE.
FUELS.
IS CONNECTED MUST COMPLY WITH ALL SAFETY
REGULATIONS IN FORCE. A RESIDUAL CURRENT
CIRCUIT BREAKER MUST BE PROVIDED ON THE MAIN
DISTRIBUTION BOARD.
SERVICE OR MAINTENANCE.
USE. IT MUST NOT BE BENT, CRUSHED, OR ANYWAY
DAMAGED.
BY QUALIFIED PERSONNEL.
WITH WATERPROOF PLUG.
OF BURNS!
3Operating Instructions and Owner’s ManualENERCO GROUP, INC. |Indirect Fired Portable Heater
TECHNICAL SPECIFICATIONS MH 1000ID
HS 1000ID
MH 2000ID
HS 2000ID
MH 3000ID
HS 3000ID HS 4000ID
Heat input [kBTU/h] 110 205 300 400
Air flow [cfm] 880 1,530 2,500 2,760
Fuel Type
Heat output [kBTU/h] 91.9 174.9 254.4 335.6
Fuel consumption [gal/h] 0.80 1.48 2.28 2.82
[lb/h] 5.53 10.35 15.07 20.07
Power supply
Phase 1 1 1 1
Voltage [V] 120 120 120 120
Frequency [Hz] 60 60 60 60
Electric consumption [W] 520 785 1.240 1.440
[A] 5.76 8.30 11.40 13.20
Nozzle [USgal/h]
Pump pressure [psi] 167 P1: 137 P1: 160 P1: 203
P2: 239 P2: 350 P2: 348
Max static pressure [in WC] 0.5 0.5 0.5 0.5
Recommended max. temp. in the air
duct 250 250 250 250
Adjustment of combustion air flap [in] a=0.32
A=1.02 A=1.50 B=1.14
Flue diameter [in] 5.9 5.9 5.9 5.9
Compulsory flue draft [in WC] 0.05 0.05 0.05 0.05
Tank capacity [gal] 10.8 17.2 27.7 35.7
Dimensions, L x W x H [in] 49.3x20.0x30.5 56.5x23.2x37.60 68.5x27.6x37.7 66.3x27.6x45.6
Net Weight [lb] 94 176 264 330
IMPORTANT
Before using the heater, read and understand all instructions and
follow them carefully. The manufacturer is not responsible for
damages to goods or persons due to improper use of units.
GENERAL RECOMMENDATIONS
combustion send hot air and the combustion products into
the room, while those with indirect combustion are fitted
with a flue to take the fumes away through the chimney.
Always follow local ordinances and codes when using this
heater:
heater.
content.
materials (the minimum distance must be 6 ft.).
to the heater requirements. Direct combustion heaters
should only be used in well vented areas in order to avoid
carbon monoxide poisoning.
fumes (see “Ventilation” on page 5) and connected to an
electrical switchboard.
shall terminate in a vertical section at least two feet long
and sufficient draft shall be created to assure safe and
proper operation of the heater.
heating oil.
children and animals away from it;
ventilator fan.
distribute warm air, with respect to the max. static pressure
declared (see “TECHNICAL SPECIFICATION” sheet).
4
ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual
Models X Y Z
ID1000 .079 in .118 in .256 in
ID2000 .158 in .098 in .158 in
ID3000 .158 in .098 in .158 in
ID4000 .158 in .098 in .158 in
the room where the heater is operated.
reason.
WARNING
OR VAPORS MAY BE PRESENT.
LATED IN THE CHAMBER.
HEATER.
The heater can only work automatically when a control device,
such as for example a thermostat or a timer, is connected to the
heater. Connection to the heater is made by removing the socket
cover(4) and inserting the thermostat plug.
To start the machine you must:
);
When unit is started for the first time or is started after the oil
tank has been totally emptied, the flow of oil to the burner may
be impaired by air in the circuit. In this case the control box will
cut out the heater and it might be necessary to renew the starting
procedure once or twice by depressing the reset button (1).
Should the heater not start, check that oil tank
is full and depress reset button (1).
Should the heater still not work, please refer to chapter
“OBSERVED FAULTS, CAUSES AND REMEDIES”.
STOPPING THE HEATER
Set main switch (3) on “0” position or turn thermostat or other
control device on lowest setting.
The flame goes out and the fan continues to work for approx.
90sec. cooling the combustion chamber.
SAFETY DEVICES
The unit is fitted with an electronic flame control box. In case of
malfunction this box will cut in and stop the heater, at the same
time the pilot lamp in the control box reset button (1) will light up.
Heaters are also equipped with an overheat thermostat safety
cutout which will stop the heater in case of overheating. This
thermostat will reset automatically but you will have to depress
button (1) on control box before being able to restart the heater.
TRANSPORT
WARNING
nate reason of overheating.
Before heater is moved it must be stopped and unplugged. Before
moving the heater wait till it has totally cooled off and make sure
oil tank cap is securely fixed.
1 4
O N
O N
0
3 2 5
1 RESET BUTTON WITH CONTROL LAMP
2 CONTROL LAMP
3 MAIN SWITCH
4 ROOM THERMOSTAT PLUG
5 POWER CORD
OPERATION
Before any attempt of starting the heater is made, check that
your electrical supply conforms to the data on the model plate.
Control Board
Gap of Electrodes
Clearances
The following minimum safety clearances from materials or objects
in the surroundings of the heater must be ensured:
Sides 2.5 ft. Air Inlet 2.5 ft.
Top 6 ft. Air outlet 12 ft.
X
Z
Y
5Operating Instructions and Owner’s ManualENERCO GROUP, INC. |Indirect Fired Portable Heater
5
4
A
3
2
D
C
1
B
The hot air heaters with wheels must be wheeled. The suspended
version which has no wheels must be transported with adequate
machinery.
MAINTENANCE
Preventive and regular maintenance will ensure a long trouble free
life to your heater.
WARNING
Severe burns or electrical shock can occur.
Every 50 hours of operation: disassemble filter and wash with
clean oil, remove upper body parts and clean inside and ventilator
with compressed air, check correct attachment of H.T. connectors
to the electrodes and check H.T. cables, remove burner assembly,
clean and check electrode settings, adjust according to scheme
“GAP OF ELECTRODES”.
Flue Connections Diagram
VENTILATION
A
6
2
D
C
1
B
5
E
Description
A) Minimal 39”
B) Minimal 39”
C) The shortest
D) The same or bigger than the smokes outlet diameter of
heater
E) Minimal 1m
1)
2)
3) Chimney 8” x 8” of minimal inside measure
4)
5) External seating wall
6) Chimney ending H shape
N.B. Above recommendation indicative only. Have your
installation checked by local authority.
6 “
6
ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual
TROUBLESHOOTING
TROUBLE CAUSE SOLUTION
Motor does not start, no ignition No electrical current Check mains (should be 120 V – 1~ – 60 Hz)
Check proper positioning and functioning of switch
Check fuse
Wrong setting of room ther
mostat or other control
Check correct setting of heater control. If thermostat, make
sure selected temperature is higher than room temperature
Thermostat or other control
defective
Replace control device
Electrical motor defective Replace electrical motor
Electrical motor bearings
defective
Replace electrical motor bearings
Burned out condenser Replace condenser
Motor starts, no ignition or cuts out Electric ignitor defective Check connection of H.V. Ieads to electrodes and transformer
Check electrodes setting (see scheme “GAP OF ELECTRODES”)
Check electrodes for cleanliness
Replace H.V. transformer
Flame control box defective Replace control box
Photocell defective Clean or replace photocell
Not enough or no fuel at all
at burner
Check fuel line system including fuel filter for possible leaks
Clean or replace oil nozzle
Solenoid defective Check electrical connection
Check thermostat LI
Clean or replace solenoid
Motor starts, heater emits smoke Not enough combustion air Make sure air inlet and outlet are free
Check setting of combustion air flap
Clean burner disc
Too much combustion air Check setting of combustion air flap
Fuel contaminated or con
tains water
Drain fuel in tank with clean fuel
Clean oil filter
Air leaks in fuel circuit Check the seals on the ducts and the diesel filter
Not enough fuel at burner Check pump pressure
Clean or replace fuel nozzle
Too much fuel at burner Check pump pressure
Replace nozzle
Heater does not stop Solenoid Replace solenoid coil or complete solenoid
If heater still not working properly, please revert to nearest authorized dealer.
7Operating Instructions and Owner’s ManualENERCO GROUP, INC. |Indirect Fired Portable Heater
WIRING DIAGRAM
1000ID SERIES MODELS
FU Fuse
IT Transformer H.V.
LI1 Overheat Thermostat
EV1
FO Photocell
CO Condenser
MV Fan Motor
ST Electric pilot
RV Control
TA Room Thermostat
RE Relays
AP Control Box
PA Air pressure control
RF Heater filter
FA Fan thermostat
PE Ground
DRAWING LEGEND
8
ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual
WIRING DIAGRAM
2000ID AND 3000ID SERIES MODELS
FU Fuse 20A
IT Transformer H.V.
LI1 Overheat Thermostat
FO Photocell
CO Condenser
MV Fan Motor
ST Electric pilot lamp
RV Control
TA Room Thermostat plug
RE Relay
AP Control Box
FA Fan thermostat
PA Air pressure control
RF Heated filter
PA Air pressure switch
PE Ground
DRAWING LEGEND
9Operating Instructions and Owner’s ManualENERCO GROUP, INC. |Indirect Fired Portable Heater
WIRING DIAGRAM
4000ID SERIES MODELS
FU Fuse 20A
IT Transformer H.V.
LI1 Overheat Thermostat
FO Photocell
CO Condenser
MV Fan Motor
ST Electric pilot lamp
RV Control
TA Room Thermostat plug
RE Relay
AP Control Box
FA Fan thermostat
RF Heated filter
CN Connector
LI2 Overheat safety
thermostat
PE Ground
DRAWING LEGEND
10
ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual
29
30
31
04
41
B
09
07
08
A
38
42
25
24
19
06
01
02
03
40
27
28
32
20
22
21
77
15
73
75
74
68
76
62
43
48
50
49
51
55
61
57
58
60
67
65
64
63 68
66
44
45
59
53
52
56
54
18
23
35
36
37
34
33
39
72 26
47 46
81
80
81
82
71
69
70
05
86
10
11
13
12
17 15 18
15
14
83
89
87 88
84
78 77 85
16
A
35
B
Optional
1000ID Series Indirect-Fired Portable Heater
11 Operating Instructions and Owner’s ManualENERCO GROUP, INC. |Indirect Fired Portable Heater
NO. STOCK NO. DESCRIPTION
01 OUTLET CONE
02 G06077 CHIMNEY Ø 150
03 G06079 COMBUSTION CHAMBER SUPPORT
04 G06081 COMBUSTION CHAMBER
05 UPPER BODY
06 LOWER BODY
07 MOTOR 200WWITH CONDENSER
08 E11208 CONDENSER 20 F
09 G06067 MOTOR FLANGE
10 FAN PROTECTION RING
11 T10207
12 M20402
13 P30165 INLET GRILLE
14 I40330 TUBE BP 1/4” FF L.420MM
15 I20104 NIPPLE FE 1/4” MM
16 T20239 FILTER WITH CARTRIDGE
17 FILTER SUPPORT
18 I40329 TUBE BP 1/4”FF L.260MM
19 C30307 PROTECTION CABLE Ø 35
20 HANDLE
21 C30319 PLUG Ø25
22 FOOT
23 I40331 TUBE BP 1/4” F L.580MM
24 I30695 PASCANTE L.150MM
25 I30737
26 POWER LEAD HOOK
27 FUEL TANK
28 C30356 DRAIN PLUG
29 WHEEL AXLE
30 WHEELS AXLE SUPPORT
31 C10546
32 M20202 SPRING WASHER Ø20
33 I25019 FUEL TANK
34 C30350 OR Ø30 X 2.62
35 G00212 EL. COMPONENTS DRAWER
36 C30425 SEAL
37 P50127 CONTROL BOX COVER
38 BASE
39 E50101 LIMIT THERMOSTAT
40 G06087 BLAST TUBE
41 E50102 FAN THERMOSTAT
42 G06072 SLEEVE Ø8 X Ø6 X 9.5
43 P50126 ELECTR. COMPONENTS DRAWER
44 E20508 FUSE HOLDER
45 E10308 FUSE (6X30) 10A
NO. STOCK NO. DESCRIPTION
46 G06102 SWITCH SUPPORT
47 E50437 PRESSURE SWITCHES HONEYWELL
48 E20319 TERMINAL BOARD
49 E20305 TERMINAL BOARD
50 E11125 RELAY FINDER 65.31 AC
51 TRANSFORMER H.T. 818C 110V
52 G06109 TRANSFORMER H.T. FLANGE
53 G06103 SUPPORT
54 E40107
55 E40113
56 G06073 PLATE FOR ELECTRICAL COMPONENTS
57
58 E20640
59 E20665 DRAIN PLUG
60 E30443 EL. WIRE WITH PLUG AND CABLE
FASTENER
61 E11030 LAMP 230V
62 T20339
63 I33001 NOZZLE SUPPORT
64 P20526 BURNER FLANGE Ø 80MM
65 I31034 NUT M14
66 E10248 ELECTRODE
67 G02076
68 I40192 MICRO PIPE
69 E50306 LD. PH. UNITL&G QRB1A
70 E50307 FIXING CLAMP
71 E50308 PHOTO RESISTANCE FLANGE
72 C30352 CABLE PROTECTION Ø15
73 PUMP DANFOSS BFP01
74 T20118
75 T20117 SOLENOID VALVE DANFOSS
76 I20115 NIPPLE FE 1/8” MM
77 E10513 COUPLING K1
78 E20953 CABLE HOLDER PG11
79 E20954 RING NUT PG11
80 I20325 CONNECTION1/8”
81 I31130 CONN. STRAIGHT Ø6 1/8”
82 I40332 SILICONE PIPE Ø5X9
83 C30319 RUBBER TAP
84 T20241 OR KIT OIL FILTER
85 T20242 FILTER CARTRIDGE
86 T20201 OIL FILTER 1/4”
87 T20234 OR KIT OIL FILTER
88 T20206 FILTER CARTRIDGE
89 T20212 FILTER HOUSING
1000ID Series Indirect-Fired Portable Heater Parts List
12
ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual
2000ID/3000ID Series Indirect-Fired Portable Heaters
25
27
29
04
47
A
05
15
08
09
B
50
46
17
10
07
01
02
03
48
37
30
12
20
11
16 14 17
14
13
88
14
83
85
84
79
87
71
52
57
58
59
60
64
70
66
67
69
81
75
76
77
53
54
56
68
55
62
61
65
63
19
33
34
49
32
45
72
06
18
22
23
21
19
24
26
28
35
31
36
38
38
41 44
39
40
37
38
42
43
51
38
80
78
79
74
73
82
89
90
86
A
33
B
15
13 Operating Instructions and Owner’s ManualENERCO GROUP, INC. |Indirect Fired Portable Heater
NO. STOCK NO. 2000 3000 DESCRIPTION
01 OUTLET CONE
02 G06077 CHIMNEY Ø 150
03 G06115 COMBUSTION CHAMBER SUPPORT
G06116
04 G06117 COMBUSTION CHAMBER
G06118
05 UPPER BODY
06 COVER INSPECTION
07 LOWER BODY
08 MOTOR 450W WITH CONDENSER
MOTOR 750W WITH CONDENSER
09 E11230 CONDENSER 40F
E11229 CONDENSER 40F
10 MOTOR FLANGE
11 T10260
T10261
12 P30169 INLET GRILLE
P30129
13 I40330 TUBE BP 1/4” FF L.420MM
14 I20104 NIPPLO FE 1/4” MM
15 T20239
16 FILTER SUPPORT
17 I40329 TUBE BP 1/4” FF L.260MM
18 HANDLE
19 C30319 PLUG Ø25
20 FOOT
21 I40331 TUBE BP 1/4” F L.580MM
22 I30696 PASCANTE L.220MM
23 I30737
24 POWER LEAD HOOK
25 FUEL TANK 65 L
FUEL TANK 105 L
26 C30367 DRAIN PLUG
27 WHEEL AXLE
WHEELS AXLE SUPPORT
28
29 C10546 SPRING WASHER Ø 25
30 M20202 FUEL TANK
31 I25019 OR Ø30 X 2.62
32 C30350 EL. COMPONENTS DRAWER
33 G00213 SEAL
34 C30425 CONTROL BOX COVER
35 P50127 BASE
36
CONN. STRAIGHT Ø6 1/8”
37 I31130 SILICONE PIPE Ø5X9
38 I40332 CONNECTION 1/8”
39 CONNECTION 1/8”
40 I20325 CONNECTION 1/8”
NO. STOCK NO. 2000 3000 DESCRIPTION
41 I31130 CONN. STRAIGHT Ø6 1/8”
42 E20953 CABLE HOLDER PG11
43 E20954 RING NUT PG11
44 C30307 PROTECTION CABLE 035
45 E50102 LIMIT THERMOSTAT
46 M20107 WASHER Ø5 X Ø15 X 1.5
47 E50101 FAN THERMOSTAT
E50104
48 G06132 BLAST TUBE
49 G06133 CLIP FOR FLEXIBLE DUCTS
50 I40801
I40802
51 G06134 AIR FLAP
52 P50126 ELECTR. COMPONENTS DRAWER
53 E20508 FUSE HOLDER
54 E10313 FUSE (6X30) 20A
55 G06102 SVVITCH SUPPORT
56 E50437 PRESSURE SWITCHES HONEYWELL
57 E20319 TERMINAL BOARD
58 E11125 RELAY FINDER 65.31 AC
59 E20305 TERMINAL BOARD
60 TRANSFONNER H.V. 818C 110V
61 G06109 TRANSFONNER H.V. FLANGE
62 G06103 SUPPORT
63 E40107
64 E40113
65 G06073 PLATE FOR ELECTRICAL COMPONENTS
66
67 E20640
68 E20665 DRAIN PLUG
69 E30443 EI. WIRE WITH PLUG AND CABLE FASTENER
70 E11030 LAMP 230V
71 T20354
T20351
72 P10137 BURNER’S HEAD WITH ELECTRODES
P10138 BURNER’S HEAD WITH ELECTRODES
73 E10254 ELECTRODES
74 P10134 ELECTRODES STIRRUP
75 I33002 NOZZLE SUPPORT
76 I30685 WASHER DIAM. 14
77 P20529 BURNER FLANGE 0 102MM
78 G02076
79 I40192 MICROPIPE
80 E50306 LD PH. UNIT L&G QRB1A
81 E50307 FIXING CLAMP
82 E50308 PHOTORESISTANCE FLANGE
83 PUMP DANFOSS BFP 52E R3
PUMP DANFOSS BFP 52E R5
84 T20118 SOLENOID SPOOL BFP 52E DANFOSS
85 T20129 SOLENOID VALVE DANFOSS (NO)
86 T20117 SOLENOID VALVE DANFOSS (NC)
87 I20115 NIPPLO FE 118” MM
88 E10513 COUPLING K1
E10514 COUPLING K2
89 T20241 OR KITOIL FILTER
90 T20242 FILTER CARTRIDGE
2000ID/3000ID Series Indirect-Fired Portable Heater Parts List
14
ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual
4000ID Series Indirect-Fired Portable Heaters
A
38
39
40
43
42
41
01
06
05
07
08
12
13 14
16
15
19
20
15
27
26
35
36
28
33
29
32
30
31
10
11
17
09
17
B
21
23
24
22
25
02
18
44
45
46
47
48
03
03
18
34
37
04
24
15 Operating Instructions and Owner’s ManualENERCO GROUP, INC. |Indirect Fired Portable Heater
4000ID Series Indirect-Fired Portable Heaters
85
86
80
82
81
76
84
83
49
55
56
57
58
62
68
64
65
67
50
51
53
66
52
60
59
63
61
54
69
73
74
70
77
75
76
72
71
79
78
95
96
48
87
46 45
47
88
90
89
21
86
97
94
86
98
91
C
54
92
93
22
21
38
C
A
94
16
ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual
4000ID Series Indirect-Fired Portable Heater Parts List
NO. STOCK NO. DESCRIPTION
01 Outlet cone
02 G06157 Centrifuge air fan
03 E50767
04 G06171 Combustion chamber support
05 G06158 Combustion chamber
06 G06077 Chimney 0 150
07 Upper body
08 Cover inspection
09 Lower body
10 Motor 750W with condenser
11 E11229 Condenser 80 µF
12 Motor flange
13 T10261
14 P30129 Inlet grille
15 C30328 Plug 030
16 Handle
17 Washer for Air duct
18 C30307 Protection cable 0 35
19 P50133 Crankcase
20 Wheels frame
21 140333 Tube BP 1/4” FF L.200mm
22 140330 Tube BP 1/4” FF L.420mm
23 130696 Pascante L.290mm
24 130737
25 Stirrup
26 Wheels support
27 C10547 Pivotal wheel
28 Wheel axle
29 Wheels axle support
30 C10546
31 M20202 Spring washer 025
32 125019 Drain plug
33 C30350 OR 030 x 2,62
NO. STOCK NO. DESCRIPTION
34 Fuel tank 135 I
35 C30367 Drain plug
36 Power lead hook
37 Base
38 G00214 EI. componets drawer
39 C30425 Seal
40 P50127 Control box cover
41 E50102 Limit Thermostat
42 M20107 Washer 05 x 015 x 1,5
43 E50104 Fan Thermostat
44 G06167 Blast tube
45 M20408 Nut M5
46 G06133 Clip for flexible ducts
47 M10244 Screw TCEI M5x14
48 140803 Air duct L=600 mm
49 G06153 Electr. componets drawer
50 E20508 Fuse holder
51 E10313 Fuse (6x30) 20A
52 G06102 Switch support
53 E50437 Pressure switchesHONEYWELL
54 140332 Silicone pipe 05x9
55 E20319 Terminal board
56 E11125 Relay Finder 65.31 AC
57 E20305 Terminal board
58 Transformer H.T. 818C 110V
59 G06109 Transformer H.T. flange
60 G06103 Support
61 E40107
62 E40113
63 G06073 Plate for electrical components
64
65 E20640
66 E20665 Drain plug
17 Operating Instructions and Owner’s ManualENERCO GROUP, INC. |Indirect Fired Portable Heater
4000ID Series Indirect-Fired Portable Heater Parts List
NO. STOCK NO. DESCRIPTION
67 E30443 EI. wire with plug and cable fastener
68 E11030 Lamp 230V
69 T20353
70 P10137 Burner’s head with electrodes
71 E10254 Electrodes
72 P10134 Electrodes stirrup
73 133002 Nozzle support
74 P20529 Burner flange 0 102mm
75 G02076
76 140193 Micropipe L=800 mm
77 E50306 Ld ph. Unit L&G QRB1A
78 E50307 Fixing clamp
79 E50308 Photoresistance flange
80 Pump Danfoss BFP 52E R3
81 T20118 Solenoid spool BFP 52E Danfoss
82 T20129 Solenoid valve Danfoss (NO)
83 T20117 Solenoid valve Danfoss (NC)
84 120115 Nipplo FE 1/8” MM
85 E10513 Coupling K1
86 12010 4 Nipplo FE 1/4” MM
87 C10328 Leitungskanal
88 C10326 Spiral fan
89 G06168 Shutter for air regulation
90 T10262 Fan AP 160x55 F12,7
91 Support fan and motor
92 Motor 200W with condenser
93 E11233 Condenser 20 IJF
94 T20239
95 T20241 OR KIToil filter
96 T20242 Filter cartridge
97 Filter support
98 131121 Conn. Straight 04,5 M5
COLUMN INTENTIONALLY
LEFT BLANK
18
ENERCO GROUP, INC. |Indirect Fired Portable Heater Operating Instructions and Owner’s Manual
OPERATING INSTRUCTIONS AND OWNER’S MANUAL
READ INSTRUCTIONS CAREFULLY: Read
and follow all instructions. Place instructions in
a safe place for future reference. Do not allow
anyone who has not read these instructions to
assemble, light, adjust or operate the heater.
MODEL
MODEL
1000ID, 2000ID
3000ID
1000ID, 2000ID
3000ID, 4000ID
HEATSTAR
BY ENERCO
MR. HEATER
Mr. Heater is a registered trademark of Enerco Group, Inc.
© 2004, ENERCO GROUP, INC. All rights reserved
WARNING:
USE ONLY MANUFACTURER’S REPLACEMENT PARTS. USE OF ANY OTHER PARTS
COULD CAUSE INJURY OR DEATH. REPLACEMENT PARTS ARE ONLY AVAILABLE
DIRECT FROM THE FACTORY AND MUST BE INSTALLED BY A QUALIFIED SERVICE
AGENCY.
PARTS ORDERING INFORMATION:
PURCHASING: Accessories may be purchased at any Mr. Heater/HeatStar local dealer
or direct from the factory
FOR INFORMATION REGARDING SERVICE
Our office hours are 8:30 AM – 5:00 PM, EST, Monday through Friday.
Please include the model number, date of purchase, and description of problem in all
communication.
LIMITED WARRANTY
The company warrants this product to be free from imperfections in material or workmanship,
under normal and proper use in accordance with instructions of The Company, for a period
of one year from the date of delivery to the buyer. The Company, at its option, will repair or
replace products returned by the buyer to the factory, transportation prepaid within said one
year period and found by the Company to have imperfections in material or workmanship.
Address any Warranty Claims to the Service Department, Enerco Group, Inc., 4560 W. 160TH
ST., Cleveland, Ohio 44135. Include your name, address and telephone number and include
details concerning the claim. Also, supply us with the purchase date and the name and address
of the dealer from whom you purchased our product.
The foregoing is the full extent of the responsibility of the Company. There are no other
warranties, express or implied. Specifically there is no warranty of fitness for a particular
purpose and there is no warranty of merchantability. In no event shall the Company be liable for
delay caused by imperfections, for consequential damages, or for any charges of the expense
of any nature incurred without its written consent. The cost of repair or replacement shall be
the exclusive remedy for any breach of warranty. There is no warranty against infringement of
the like and no implied warranty arising from course of dealing or usage of trade. This warranty
will not apply to any product which has been repaired or altered outside of the factory in any
respect which in our judgment affects its condition or operation.
Some states do not allow the exclusion or limitation of incidental or consequential damages, so
the above limitation or exclusion may not apply to you. This Warranty gives you specific legal
rights, and you may have other rights which vary from state to state.
Enerco Group, Inc. reserves the right to make changes at any time, without notice or obligation,
in colors, specifications, accessories, materials and models.
08/08 #50120
MODÈLE
LISEZ SOIGNEUSEMENT LES INSTRUCTIONS :
Lisez et observez toutes les instructions. Conservez
les instructions pour vous y référer ultérieurement.
Interdisez à quiconque n’ayant pas lu les présentes
instructions d’assembler, d’allumer, de régler ou de
faire fonctionner cet appareil de chauffage.
1000ID, 2000ID
3000ID
GUIDE D’UTILISATION ET INSTRUCTIONS DE FONCTIONNEMENT
MR. HEATER HEATSTAR
BY ENERCO
1000ID, 2000ID
3000ID, 4000ID
MODÈLE
ENERCO GROUP, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 É.-U. • 800-251-0001
Mr. Heater et HeatStar sont des marques de commerce déposées de Enerco Group, Inc.
© 2003, Enerco Group Inc. Tous droits réservés.
AVERTISSEMENT:
N’UTILISEZ QUE LES PIÈCES DE REMPLACEMENT DU FABRICANT. IL EST POSSIBLE
DE SE PROCURER CES PIÈCES DIRECTEMENT DE L’USINE OU PAR L’ENTREMISE DES
DÉTAILLANTS LOCAUX MR. HEATER/HEATSTAR.
INFORMATIONS SUR LA COMMANDE DE PIÈCES :
ACHAT : On peut se procurer les accessoires par l’entremise de tous les détaillants
locaux Mr. Heater/HeatStar ou directement du fabricant
POUR OBTENIR DES INFORMATIONS SUR LE SERVICE
Appelez sans frais au 800-251-0001 • www.enerco-mrheater.com
Nos heures d’ouverture sont de 8 h 30 à 17 h HNE, du lundi au vendredi.
Adressez vos courriels à : techservice@mrheater.com
Veuillez indiquer le numéro du modèle, la date d’achat et la description du problème
dans toutes vos communications avec nous.
GARANTIE LIMITÉE
L’entreprise garantit ce produit contre tout défaut de matériel ou de main-d’œuvre, dans des
conditions d’utilisation normale et adéquate, conformément aux instructions de l’entreprise,
pour une période d’un an à compter de la date de livraison à l’acheteur. L’entreprise réparera ou
remplacera, à sa discrétion, les produits retournés port payé par l’acheteur au fabricant dans la
période d’un an et jugés par l’entreprise comme présentant des défauts de matériel ou de main-
d’œuvre.
Si une pièce est endommagée ou manquante, téléphonez à notre service de soutien technique
au 800-251-0001.
Adressez toute réclamation relative à la garantie à Service Department, Enerco Group, Inc., 4560
W. 160TH ST., Cleveland, Ohio 44135 États-Unis. Indiquez vos nom, adresse et numéro de téléphone
ainsi que les détails de la réclamation. Indiquez-nous également la date d’achat et le nom et l’adresse
du détaillant de qui vous avez acheté le produit.
Ce qui est énoncé ci-dessus constitue la responsabilité totale de l’entreprise. Il n’existe aucune autre
garantie, expresse ou tacite. Plus précisément, il n’y a aucune garantie concernant l’adéquation à une
utilisation particulière ni aucune garantie concernant la qualité marchande. En aucun cas l’entreprise
ne sera tenue responsable des retards causés par des défectuosités, ni des dommages indirects,
ni des dépenses encourues sans son consentement écrit, quelle que soit leur nature. Le coût de la
réparation ou du remplacement sera le seul recours possible en cas de violation de garantie. Il n’y
a aucune garantie contre une transgression de ce genre ni aucune garantie tacite découlant des
usages du commerce ou de la façon habituelle d’échanger. La présente garantie ne s’applique à
aucun produit qui a été réparé ou modifié par d’autres que le fabricant si cela influe de quelque
façon que ce soit sur l’état de l’appareil ou son fonctionnement, selon notre jugement.
Certains États ou provinces ne permettent pas d’exclure ou de limiter les dommages indirects ou
subséquents. Par conséquent, les limitations ou exclusions ci-dessus mentionnées ne vous concernent
peut-être pas. La présente garantie vous accorde des droits juridiques précis, mais vous pourriez
avoir d’autres droits qui varient selon la province ou l’État.
Enerco Group Inc. se réserve le droit d’effectuer des modifications en tout temps, sans préavis ni
obligation, aux couleurs, aux spécications, aux accessoires, aux matériaux et aux modèles.
08/08 #50120ENERCO GROUP, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 800-251-0001
17 Le fait de Faire marcher des Instructions et le Manuel de PropriétaireENERCO GROUP, INC. |Chauffage portatif indirect-tiré
4000ID Série Chauffage Portatif Indirect-tiré
NO. STOCk NO. DESCRIPTION
67 E30443 Cable avec fiche et presse cable
68 E11030 Lampe 230V
69 T20353 Gicleur 1,50 GPH 45° W
70 P10137 Tete brOleur avec electrodes
71 E10254 Electrodes
72 P10134 Etrier pour electrodes
73 133002 Support gicleur
74 P20529 Bride BrOleur 0 102mm
75 G02076 Conn. cable 90° H.T.
76 140193 Microtube L=800 mm
77 E50306 Photoresis. L&G QRB1A
78 E50307 Boucle de fixage
79 E50308 Bride photoresistance
80 T20439-1 Pompe Danfoss BFP 52E R3
81 T20118 Bobine EV BFP 52E Danfoss
82 T20129 Electrovanne Danfoss (NO)
83 T20117 Electrovanne Danfoss (NC)
84 120115 Nipplo FE 1/8" MM
85 E10513 Accouplememt PI. K1
86 12010 4 Nipplo FE 1/4" MM
87 C10328 Canal du liaison
88 C10326 Ecrou ventilateur
89 G06168 Ciapet reglage air
90 T10262 Ventilateur AP 160x55 F12,7
91 G06169-9005 Support moteur et ventilateur
92 E10677-110 Moteur 200W avec condensateur
93 E11233 Condensateur 20 IJF
94 T20239 Filtre pre-chauffage 1/4"
95 T20241 KIT OR filtre gasoil
96 T20242 Cartouche filtre
97 G06170-9005 Support
98 131121 Raccord droit 04,5 M5
LA COLONNE A INTENTIONNELLEMENT
QUITTÉ LE BLANC
Other manuals for Mr. Heater 1000ID
1
This manual suits for next models
8
Table of contents
Other ENERCORP Heater manuals
ENERCORP
ENERCORP HeatStart HS80CV Assembly instructions
ENERCORP
ENERCORP HEATSTAR HST 45 Assembly instructions
ENERCORP
ENERCORP HEATSTAR HS4030 Assembly instructions
ENERCORP
ENERCORP Mr.Heater 1000IDCT Troubleshooting guide
ENERCORP
ENERCORP HEATSTAR HS4000 NG/LP Assembly instructions
ENERCORP
ENERCORP Heatstar HS50K Assembly instructions
ENERCORP
ENERCORP HEATSTAR HS22LP Assembly instructions
ENERCORP
ENERCORP HEATSTAR HSU 45 User manual
ENERCORP
ENERCORP HeatStar HS180ID Assembly instructions
ENERCORP
ENERCORP HEATSTAR HS200CV Assembly instructions
ENERCORP
ENERCORP MR. HEATER MH125FAV Assembly instructions
ENERCORP
ENERCORP Mr. Heater 1000ID Assembly instructions
ENERCORP
ENERCORP HEATSTAR HS4000 NG Assembly instructions
ENERCORP
ENERCORP MR. HEATER MH40NG Assembly instructions
ENERCORP
ENERCORP FIRE 155 Assembly instructions
ENERCORP
ENERCORP HeatStar HS35FA Assembly instructions
ENERCORP
ENERCORP HeatStar HS35FA Assembly instructions
ENERCORP
ENERCORP MH400FAVT Assembly instructions
ENERCORP
ENERCORP HS155IR Heatstat User manual
ENERCORP
ENERCORP Heatstar HS50K User manual
Popular Heater manuals by other brands
Commercial Electric Heat
Commercial Electric Heat ODH-4500R installation instructions
EUROM
EUROM 332841 instruction manual
nedis
nedis HTIF20FYW quick start guide
Orbegozo
Orbegozo FH 5034 instruction manual
Honeywell
Honeywell HZ-0360 Series Operating and safety instructions
Navien
Navien Mate EQM 350 user manual
