Enerdrive POWER SYSTEM Series User manual

POWER SYSTEM SERIES
Installation Guide

Congratulations on the purchase of your Archie power system from Enerdrive. This all-in-one system
was designed for those who want the best charging, power supply and monitoring package in one
compact portable package. Your system includes the following individual products:
• Enerdrive 12V 100AH eLITE Lithium Battery (Optional 12V 125AH B-TEC Lithium Battery)
• Enerdrive DC2DC40+ DC Battery Charger with Blue Anderson vehicle charge input and Red
Anderson solar charge input.
• Enerdrive ePOWER 600W Inverter
• Enerdrive ePRO PLUS Battery Monitor
• 2 xTwin USB Outlets, 3 x DC Outlets, 2 x 50A Anderson Style Outlets

INSTALLATION GUIDE
Mounting
• Consideration must be given to avoid moisture and excessive dust.
• If you choose to x Archie into a semi permanent location use the supplied mounting brackets.
• Slide each bracket into the slots located on the front and back of Archie.
• Use appropriate fasteners for the material the brackets will be fastened into. It is
recommended where possible use a bolt and nut (nutsert or similar) especially if you are
planning on frequent removal.
• The two handles on Archie can be removed to reduce overall height when used in installed
applications.
• Alternatively you can use 2 x tie down straps over the Archie, run from side to side.
Caution: Ensure any debris from the mounting process is thoroughly removed to prevent damage to
equipment or wiring.
Caution: Ensure that there is adequate spacing for wiring and be sure to check no wiring is in the path of
fasteners when mounting the power system.
Connecting Loads (Appliances)
Archie is designed as a portable/fast install system therefore has the following outlets allowing you to
connect various DC and AC equipment.
• 2x 50 Amp Anderson (1 Front, 1 Rear), protected by the“ANDOS”circuit breaker.
• 2xTwin USB 2.4A Hi Amp Sockets, protected by the“USB Outlets”circuit breaker and controlled
by the“Outlets”circuit breaker.
• 3x 12V DC Power Outlets, 2 on the front, 1 on the rear, protected by the“DC Outlets”circuit
breaker and controlled by the“Outlets”circuit breaker.
• 1x 230V AC outlet supplied from the 600W true sine wave inverter, protected and controlled by
the“Inverter”circuit breaker. Inverter also has internal over load protection.
Always ensure you use the appropriately rated socket for based on the current draw of your appliance being
connected.
Mounting Bracket
& Fasteners
Push to Reset Breakers
(located on the front)
Main Breakers
(located on the back)

Solar Connection
• Using a genuine "red" Anderson plug, connect your unregulated solar panels directly into
Archie. Use of portable folding panels are recommended when Archie will be used in a
portable application. When installed in a vehicle the use of xed panels may be preferred.
Refer to the Specications table for maximum solar panel rating.
Note: Refer to DC2DC manual for information on wiring for vehicles with smart alternators.
INSTALLATION GUIDE
Connecting to Main (Start) Battery
• Using the optionalVehicle Charge Cable Kit connect the lug end to your main/start battery.
The supplied 70A midi fuse must be located as close as possible to the main/start battery.
Connect the "blue" Anderson plug on the cable kit to the“blue”AndersonVehicle Input plug.
This input is protected by the "DC2DC" circuit breaker on the rear.
• If you select to run your own cabling connect a genuine“blue”Anderson plug to the end Archie
will be installed. Connect the other end to you main/start battery. A 70A midi fuse located as
close as possible to the main/start battery is required. Refer below cable sizing chart.
DC2DC Connection
Inputs Require Length & Battery Cable Size
DC2DC set to
50A Output
From Start Battery
2 Meters to 5 Meters (2)
6-16mm² @ 12vdc 16-35mm² @ 12vdc
/ 4-8mm² @ 24vdc
Up to 10 Meters (2) Greater than 10 Meters
Not Recommended
/ 8-16mm² @ 24vdc

INSTALLATION GUIDE
Battery Reset
Archie is tted with a Battery Reset switch. This allows a at battery to be "jump started" from the
main/start vehicle battery, when connected.
1.Turn o ALL DC and AC loads
2. Ensure the "DC2DC" circuit breaker on the back of Archie is turned on.
3. Ensure the blue "Vehicle Input" plug is connected to Archie and the vehicle is running.
4. Hold the green“Reset”button on the back of Archie for 5-10 seconds.
5. Release and wait 10seconds
6. Power should now be restored and charging will commence
7.When the SOC (State of Charge) is above 20%, loads can be switched on if required
Storage
If you will not be using your Archie system for more than a week and will not be connected to vehicle or
solar charge it is recommended to turn o the 4 circuit breaker panels on the rear of Archie. This will reduce
standby current draw.
Battery Reset
Button
Breakers

INSTALLATION GUIDE
Archie - Enerdrive Wiring

INSTALLATION GUIDE
Archie - Capabilities
Vehicle Start Battery
240W Folding Solar Panel Kit
Portable Regrigerator
GoPro
Mobile Phone
Battery Charger
Air Compressor

INSTALLATION GUIDE
5 Year Warranty
Important Note: Consumer Protections
In the unlikely event that a technical issue arises with an Enerdrive product, customers are
encouraged to initially contact the Enerdrive Support Team on 1300 851 535 or
[email protected] for immediate and ecient expertise and rst class product
support.
Enerdrive warrants that its Products will be free from defects in materials and workmanship (subject to limits,
and in normal conditions, as described in the complete Enerdrive Warranty Policy) for up to 5 years from the
date of purchase.
For full terms, conditions and claim process, refer to the Enerdrive website.
https://enerdrive.com.au/warranty/
If you have purchased your product in Australia, you should be aware that:
This warranty is provided in addition to other rights and remedies held by a consumer at law. Our goods
come with guarantees that cannot be excluded under the Australian ConsumerLaw. You are entitled to a
replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss
or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of accept-
able quality and the failure does not amount to a major failure.
DC Charger
Inverter
Output Current Maximum: 40~50A
General
Battery
Dimensions
Weight
AC Output: 230V 50Hz
AC Output Power: 600W Cont (900W Surge)
Standard - 12V 100Ah LiFeP04
Optional - 12V 125Ah LiFeP04 with Bluetooth monitoring
470L x 265W x 415H (without brackets)
490L x 265W x 415H (with brackets)
25.0KG (with 100Ah eLITE)
28.0KG (with 125Ah B-TEC )
Solar InputVoltage: 14.5-45VOC
SolarWattage Maximum: ≤23V Input, 500W (600W allowable),
≥37.5V-45V Input, 750W (800W allowable)
