ENERGY SISTEM Energy 230 User manual

15
ENGLISH
ON / OFF
VOL +
SCAN - SCAN +M+ SET/MEMO
VOL -
SLEEP
OFF
1
2
User Manual

17
ENGLISH
INTRODUCTION
Energy Sistem®thanks you for buying your new Energy™ Clock Radio 230 we wish you enjoy using it.
Clock Radio with 2 independent alarms, you can choose between any FM radio station or the buzzer. You can see the projection clock
on any place that you want and get an easy view all time.
We recommend you to read this user manual in order to enjoy the product in a safe way and with the best results.
CARE AND MAINTENANCE
≥Do not expose your Energy™ Clock Radio 230 to shock, dust, humidity or high temperatures.
≥Do not use cleaners or scouring agents.
≥Keep the unit clean and dust with a soft, dry cloth.
≥ Do not disassemble the device. Any repairs must be done by qualified service personnel authorised only by Energy Sistem Soyntec SA.
≥Keep your Energy™ Clock Radio 230 away from water or moisture, it can be harmful to both speakers or amplifier device.
BATTERY DISPOSAL
≥Please ensure batteries are disposed of safely.
≥Never dispose of batteries in a fire or with other household waste.
≥Check with your local authority for disposal regulations.

18
TECHNICAL SPECIFICATIONS
≥Backlight LCD display.
≥12/24 hour display setting.
≥Dual alarm (FM radio or buzzer).
≥Perpetual calendar.
≥Hi-Lo dimmer backlight.
≥SNOOZE function.
≥Sleep mode.
≥PLL FM radio.
≥10 radio presets station.
≥Volume control (16 levels).
≥Button cell battery backup (included).
PACKAGE CONTENT
≥Energy™ Clock Radio 230.
≥User Manual.
≥AC adapter.

19
ENGLISH
GENERAL OVERVIEW
Vista Frontal
1. ON / OFF - OFF: ON / OFF the device. Stops the Alarm.
2. 1: ON / OFF and set the alarm 1.
3. 2: ON / OFF and set the alarm 2.
4. SNOOZE/LIGHT: Snooze function and dimmer.
5. Projector.
6. SCAN+: FM requency up.
7. SET/MEMO: Clock setting /Setting the preset radio station.
8. MEM+: Preset.
9. SCAN-: FM requency down.
10. SLEEP: Sleeptimer.
11. VOL -: Volume level down.
12. VOL +: Volume level up.
ON / OFF OFF
VOL +
SCAN - SCAN +M+ SET/MEMO
VOL -
1
2
SLEEP
FOCUS ADJUST
PROJECTOR ROTATE
AC: 7V
BACKUP BATTERY
ENERGY Clock Radio 230
1 4 52 3
12
11
10
1
1
89 67

20
MAIN FEATURES
Using your Energy™ Clock Radio 230 you can program the two different alarms totally independent and select the radio station that
you prefer as wake up sound. Project the clock viewing on any surface, turn and rotate as you want for better view.
POWERING UP
Place the Energy™ Clock Radio 230 on the desired place; connect the AC adapter to the wall power connection. Finally insert the
cable into the supply socket.
ON / OFF
Once that you had connected your Energy™ Clock Radio 230 to the main power press the ON / OFF - OFF to power on. If you want
to turn off the device you only have to hold ON / OFF - OFF two seconds.
SETTING CLOCK
Once you had connected your Energy™ Clock Radio 230 to the main power for first time, the display will “12:00”. To set the correct
time the product has to be in standby mode.
Hold SET/MEMO until the digits in the display start flashing. Use SCAN- and SCAN+ to adjust the hour. Press SET/MEMO again to
adjust the minutes, finally press SET/MEMO again and you can adjust the desired date.
The sequence is: 12/24 format> Hour > Minutes > Year > Month > Day
Press SET/MEMO for the final confirmation.

21
ENGLISH
BACKUP BATTERY
You can find it in the back side of the device and it only helps you to do not lose the setting that you did before, that means, if you
have any unexpected power outage you can keep the setting that you did before.
SETTING ALARMS
To set the alarms the device has to be in standby mode.
Press 1 to check the status of the first alarm.
Hold 1 to enter to the setting mode of the alarm. Use SCAN+ y SCAN- to select the desire hour and minutes.
When you have set the alarm, you most select when do you want to activate the alarm (during all week, from Monday to Sunday),
during the labor days (only from Monday to Friday) or only the weekend.
Now you have to select the alarm’s sound; that means if you want to use the FM radio or the buzzer. If you select the FM radio you
can select one of the 10 preset radio stations.
Finally, you have to choose the maximum volume level (16 is the maximum level). The alarm volume works in an increasing way,
reaching the maximum volume the same as you choose before.
It is so important to note that the volume ajust for the alarm is only for the FM radio option. If you use the buzzer you can not ajust
the volume and it will be as the standard predefined in the device.
Follow the same steps to set the second alarm using the 2.
To switch off any alarm you have to press OFF.
To disable any alarm you have to press 1 or 2 according to the alarm that you can to inactivate.

22
SNOOZE MODE
During the wakeup time, press the SNOOZE/LIGHT button once to temporarily turn off the alarm. After approximately 9 minutes the
alarm will sound again. The cycle will repeat when the SNOOZE / LIGHT button is pressed again.
FM RADIO
In standby mode, press ON / OFF - OFF and you activate the FM radio, use SCAN+ and SCAN- to turn your favourite radio
station.
Store up to 10 presets. If you want to save the radio station in the presets you have to keep pressed SET/MEMO and select the
preset number using the SCAN+ and SCAN- buttons, to confirm press SET/MEMO. To find the pre-stored memory use the MEM+
button. Keep pressed the MEM+ to do a quick search over the presets.
SLEEP MODE
When in Radio mode, press the SLEEP button to turn on the sleep timer. Press the SLEEP button again to set the desire sleep time.
Timer sequence: 90 > 80 > 70 > 60 > 50 > 40 > 30 > 20 > 10 > OFF.
TIME PROJECTOR
The projector is activated when you press SNOOZE/LIGHT.
The projection is off after 60 seconds. To adjust the projection you have to focus the projection using the controls on the back side
of the projector.
The projection can rotate 360º using the rotation control on the back.

23
ENGLISH
WARRANTY
≥Energy Sistem Soyntec SA is liable for any lack of conformity which exists at the time the goods were purchased during a period of
36 months. Batteries are excluded from the 36-month warranty, having a warranty period of 12 months.
This warranty covers any defects in workmanship or materials. This warranty doesn’t cover any failure of the product due to
accidents, misuse or alteration made by an unauthorized person.
The special 36-months warranty is valid for the European Union. For other countries, please refer to your specific legislation or
your local distributor.
WARRANTY PROCEDURE
1. Visit the Support section at http://support.energysistem.com and select your product to view the FAQ (Frequently Asked Questions).
The solution to your problem is very likely to have been already published there. You will also be able to download user manuals, user
guides, drivers and updates.
You can check the availability of the user manual in your language at http://www.energysistem.com/es-es/support/manuals
2. If you cannot find an appropriate solution in the Support section, you may send us your enquiry or warranty service request by
email: [email protected]
3. Alternatively, you may prefer to contact the distributor from which you purchased the product, presenting the purchase receipt or
invoice.
Important: This warranty doesn’t cover any damage or loss to any data stored in the product memory, therefore Energy Sistem’s
Technical Service will not assume any loss of the above mentioned information so it is recommended to make a backup of your data
and to remove any data or personal info from its internal memory before you send the product, or to send it only with the original
factory default values.
Specifications are subject to change without notice.
Trademarks. All company, brand and product names are trademarks or registered trademarks of their respective companies.
© 2012 by Energy Sistem®. All rights reserved.

24
DECLARATION OF CONFORMITY
Manufacturer Name: Energy Sistem Soyntec S.A.
Address: Pol. Ind. Finestrat, C/. Calpe, 1 - 03509, Finestrat Alicante (Spain)
Tel: [phone]
Fax: [phone]
NIF: A53107488
We declare under our own exclusive responsibility that the product:
Energy Sistem®Energy™ Clock Radio 230
Manufacturing country: China
Is in compliance with the essential norms and standards of the Directive 2004/108/EC of the European Parliament and of the Council
of December 15th 2004.
This symbol on the product or the instructions means that your electrical and electronic equipment should be disposed at the
end of life separately from your household waste. For more information, please contact the local authority or dealer where you
purchased the product.
04/09/2012
