ENFORCER MVA-VH01Q User manual

MVA-VH01Q
VGA-to-HDMI Converter with Scaler
Manual
•Converts VGA + Audio to 720p or 1080p HDMI
•Supports input resolutions up to 1920x1080
•Supports up to 1080p on HDMI output
•Stereo audio input
•Switch for switching between 720p and 1080p upscaling
•Plug and play operation

ENFORCER VGA-to-HDMI Converter with Scaler
2SECO-LARM U.S.A., Inc.
Introduction:
The MVA-VH01Q VGA-to-HDMI Converter with Scaler allows the user to convert video from VGA
devices on HDMI displays. Active operation allows the conversion of formats as large as
1920x1080. The MVA
-VH01Q also has a 3.5mm stereo input allowing the conversion of audio as
well.
Specifications:
Input resolution
640x480, 800x600, 1024x768, 1280x720, 1280x768,
1280x800, 1280x960, 1280x1024,1360x768, 1440x900,
1600x1200, 1920x1080
Output resolution
720p, 1080p
Video input signal
3.3V
DDC Input signal
5V
Vertical frequency
60Hz
Video amplifier bandwidth
1.65Gbps/165MHz
Power supply
5VDC (USB)
Operating temperature
32°~158° F (0°~70° C)
Operating humidity
5%~95% RH (no condensation)
Dimensions
23/8" x21/8" x13/16" (60x54x20 mm)
Weight
1.4oz (40g)
Parts List:
1x VGA-to-HDMI Converter with Scaler
1x USB Power cable
1x Manual
Dimensions:
21/
8
"
(54mm)
23/
8
" (60mm)
13/
16
"
(20mm)

ENFORCER VGA-to-HDMI Converter with Scaler
SECO-LARM U.S.A., Inc. 3
Overview:
Input
Output
Power/Scaler
Top
Installation:
1. Decide where the MVA-VH01Q will be installed.
2.
Connect a VGA cable from the VGA source to the VGA input of the MVA-VH01Q.
3.
Connect a stereo audio cable from the source device to the audio input of the MVA-VH01Q.
4.
Connect a HDMI cable from the HDMI monitor to the output of the MVA-VH01Q.
5.
Using the included USB cable, connect the MVA-VH01Q power to a powered USB port on the
VGA source or HDMI monitor.
6.
Select either 720p or 1080p output using the select switch on the side.
7.
Switch on the VGA source and HDMI monitor and verify that the system is functioning properly.
8.
If necessary, use the auto and zoom buttons to correctly fit the image to the screen.
Sample Application:
HDMI Monitor
VGA Source
Cable Legend:
USB
VGA
Stereo
HDMI

ENFORCER VGA-to-HDMI Converter with Scaler
4SECO-LARM U.S.A., Inc.
Troubleshooting:
HDMI Device does not function correctly.
•Make sure the converter is powered.
•Make sure the input and output devices are
powered.
•Test the cables separately to make sure
they are functioning.
•Make sure that you are trying to convert
VGA to HDMI. The MVA-VH01Q does not
convert HDMI to VGA.
Also Available from SECO-LARM:
NOTICE: The SECO-LARM policy is one of continual development and improvement. For that reason, SECO-LARM
reserves the right to change specifications without notice. SECO
-LARM is not responsible for misprints.
Copyright © 2016 SECO
-LARM U.S.A., Inc. All rights r
eserved. This material may not be reproduced or copied, in whole or
in part, without the written permission of SECO
-LARM.
WARRANTY:
This SECO-LARM product is warranted against defects in material and workmanship while used in normal
service for
one (1) year from the date of sale to the original customer. SECO-
LARM’s obligation is limited to the repair or
replacement of any defective part if the unit is returned, transportation prepaid, to SECO
-LARM. Th
is Warranty is void if
damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair or alteration,
improper or abnormal usage, or faulty installation, or if for any other reason SECO
-LARM determines that such eq
uipment is
not operating properly as a result of causes other than defects in material and workmanship.
The sole obligation of
SECO
-LARM and the purchaser’s exclusive remedy, shall be limited to the replacement or repair only, at SECO-
LARM’s
option.
In no event shall SECO-
LARM be liable for any special, collateral, incidental, or consequential personal or property
damage of any kind to the purchaser or anyone else.
