ENGAGE SENDX2680A User manual

Model #: SENDX2680A
SPOTTING SCOPE OWNER’S GUIDE
Архангельск [phone]
Астана (7172)727-132
Астрахань [phone]
Барнаул [phone]
Белгород [phone]
Брянск [phone]
Владивосток [phone]
Волгоград [phone]
Вологда [phone]
Воронеж [phone]
Екатеринбург [phone]
Иваново [phone]
Ижевск [phone]
Иркутск [phone]
Казань [phone]
Калининград [phone]
Калуга [phone]
Кемерово [phone]
Киров [phone]
Краснодар [phone]
Красноярск [phone]
Курск [phone]
Липецк [phone]
Магнитогорск [phone]
Москва [phone]
Мурманск [phone]
Набережные Челны [phone]
Нижний Новгород [phone]
Новокузнецк [phone]
Новосибирск [phone]
Омск [phone]
Орел [phone]
Оренбург [phone]
Пенза [phone]
Пермь [phone]
Ростов-на-Дону [phone]
Рязань [phone]
Самара [phone]
Санкт-Петербург [phone]
Саратов [phone]
Севастополь [phone]
Симферополь [phone]
Смоленск [phone]
Сочи [phone]
Ставрополь [phone]
Сургут [phone]
Тверь [phone]
Томск [phone]
Тула [phone]
Тюмень [phone]
Ульяновск [phone]
Уфа [phone]
Хабаровск [phone]
Челябинск [phone]
Череповец [phone]
Ярославль [phone]
Киргизия [phone]-47 Россия [phone] Казахстан (772)734-952-31
https://bushnell.nt-rt.ru || [e-mail]
Зрительная труба Engage DX

TRIPOD MOUNTING
Your Engage spotting scope should be mounted on a high quality, stable tripod (not included) to ensure safe operation
and a vibration-free viewing experience. Attach the scope’s mounting base to the screw on the tripod’s platform, so that the
scope is held securely in place and provides a level view (adjust tripod as needed). The tripod mounting base can be rotated
by loosening the small “B” logo knob on one side, above the mount (see photo below).
Thank you for purchasing your new Bushnell® Engage™ Spotting Scope.
This manual will help you optimize your viewing experience by explaining how to utilize the scope’s controls and features,
and how to care for it. Read the instructions carefully before using your scope.
NEVER LOOK DIRECTLY AT THE SUN WITH YOUR SPOTTING SCOPE,
AS IT MAY CAUSE SERIOUS DAMAGE TO YOUR EYES
USING THE ZOOM EYEPIECE AND FOCUSING
Rotate the zoom ring (B) on the eyepiece to change magnifying power from low to high. Lower power settings will provide a
brighter image with a wider  eld of view; higher powers allow observing smaller details on more distant subjects. Note: the
zoom eyepiece is not interchangeable. Do not attempt to remove it from the scope.Turn the focus knob in either direction
until your subject appears as sharp as possible. To reduce the need to readjust focus when zooming, set the zoom to its
highest power and focus on your subject. When you zoom back down to lower powers, it will stay in focus.
Tripod Mounting Ring/Base
(D) Loosen knob to rotate mounting ring
PARTS GUIDE ATwist-Up Eyecup
B Zoom Ring
C Focus Knob
D Tripod Mounting Ring/Base
E Objective Lens
F Sliding Sunshade
G Picatinny Accessory Rails
C
D
F
A
B
E
G

USING THE TWIST-UP EYECUP AND SLIDING SUN SHADE
If you are not wearing glasses, twist the rubber eyecup (A) counter-clockwise to extend it. If you experience glare or lens fl are
due to the angle and direction of the sun relative to the objective lens, pull the sun shade (F) out to extend it.
PICATINNY ACCESSORY RAILS
Your Engage spotting scope provides two accessory rails which provide a solid, secure mount for any standard Picatinny
compatible accessory device such as a fl ashlight or laser sight.
WATERPROOF / FOGPROOF
Getting caught in a heavy downpour of rain with your spotter won’t be a problem. Engage spotting scopes are manufactured
and tested to withstand water exposure to IPX7 standards (submersible to a depth of 1 meter for up to 30 minutes). Fogproof
protection is achieved from dry Engagegen purging that removes all internal air, which can retain moisture.
All exterior lens surfaces have our new EXO Barrier™ coating (in addition to full multi-coating). EXO Barrier, quite simply,
is the best protective lens coating technology Bushnell has ever developed. Added at the end of the coating process, EXO
Barrier molecularly bonds to the lens and  lls the microscopic pores in the glass. The result is an ultra-slick coating that repels
water, oil, fog, dust and debris - rain, snow,  ngerprints and dirt will not stick. EXO Barrier is built to last: the bonded coating
will not fade with the passage of time or normal wear and tear.
CLEANING AND GENERAL CARE
The lenses of your Bushnell Engage spotting scope are fully multi-coated for highest light transmission. As with any multi-
coated optics, special care must be taken in cleaning the lenses. Follow these tips for proper lens cleaning:
• Blow away any dust or debris on the lens (or use a soft lens brush).
•To remove dirt or  nger prints, clean with the supplied micro- ber cloth rubbing in a circular motion. Use of a coarse
cloth or unnecessary rubbing may scratch the lens surface and eventually cause permanent damage. The included
washable micro ber cleaning cloth is ideal for the routine cleaning of your optics. Simply breathe lightly on the lens to
provide a slight amount of moisture, then gently rub the lens with the micro ber cloth.
•For a more thorough cleaning, photographic lens tissue and photographic-type lens cleaning fl uid or isopropyl alcohol
may be used. Always apply the fl uid to the cleaning cloth – never directly on the lens.
Never disassemble your spotting scope. Irreparable damage can result from unauthorized service attempts, which also void
the warranty.
SKU
Magnication Range
Objective Diameter
Eyepiece
Field of view
ft@1000 yds /
m@1000 m
Exit Pupil (mm)
@Lo x/Hi x
Eye Relief (mm)
Length (in/mm)
Weight (oz /g)
SENDX2680A 20x-60x 80 MM Angled 98 ft /32.7m @20x
50 ft/16.7m @60x
3.6/1.2 18 15.4/390 60/ 1700
Technical Specications
Eyecup Extended
(A) Sun Shade Extended
(F)
