Englefield Valencia Single Drawer Vanity User manual

1278274-A02-B 12/8/2016
INSTALLATION
INSTRUCTIONS
FURNITURE
VALENCIATM Single Drawer Vanity
Contemporary design and
quality construction,
providing affordable storage
for bathrooms of any size or
style.
It’s the details that Englefield
cares about - from pioneering
the latest technology, to
innovative design.
Woodgrain
Models
White Painted
Models
1

BEFORE YOU BEGIN
ROUGH-IN
INSTALLATION INSTRUCTIONSVALENCIA
TM
Single Drawer Vanity
Please read these instructions carefully to familiarise yourself with the required tools, materials, and
installation sequences. Follow the sections that pertain to your particular installation. This will help you
avoid costly mistakes. In addition to proper installation, read all operating and safety instructions.
Prior to installation, inspect cabinet and top to ensure that no damage has occurred in transit. If damage
has occurred, or a visible defect exists, do not proceed with installation, and advise your supplier
immediately.
Please leave these instructions for the consumer. They contain important information.
Instructions, drawings, and diagrams contained in this manual present information available at the time of printing.
changes without further notice.
ENGLEFIELD
2
750 900
455 405
90
90
Drain cut
out centered
1200
90
1200
90
90
Drain cut outs
in each drawer

1 Drawer removal
Cabinets must be fixed to a nog and at least one stud in the wall. The nog size should be 50 x 75mm.
Use a stud finder to locate studs & nogs in finished walls.
(a) Open the drawer and
carefully lift up on the end of
the drawer to release it from
the runner locator pins. It may
be necessary to gently pry the
runner away from the drawer.
(b) The drawer is now only held
by the runner hooks at the
back and can be pulled out in
the direction shown.
CONSTRUCTION REQUIREMENTS
INSTALLATION
TOOLS AND MATERIALS REQUIRED - (Not Supplied)
INSTALLATION INSTRUCTIONSVALENCIA
TM
Single Drawer Vanity
To suit pipework To suit screws
TOOLS MATERIALS - Not supplied & must be purchased separately
Fixing washers
20mm
Head Screws
10g x 75mm Pan
A height of 850mm from the
floor to the top of the vanity
top is recommended.
50mm from top of
cabinet to centre
of nog.
3
50
Stud finder
Locator pin Runner hook
850
(c) For 77296A-*:
Button
Hook
To make the installation easier
remove the cabinet door. To
release the door hinges press
the buttons at the rear of the
hinges.

INSTALLATION INSTRUCTIONSVALENCIA
TM
Single Drawer Vanity
3 Water supply and waste pipe holes
4 Fixing the vanity to the wall
(c) Having drilled the required holes fit the cabinet
into position over the pipework.
(e) Fix the cabinet to the wall using at least
6 screws for the 750mm & 900mm cabinets
and 8 screws for the 1200 cabinets (min 10g
x 75mm) and *20mm washers. Screw through
the back wall so that they screw into the nog
and stud(s) in the wall behind.
*Washers must be used to spread the load.
NOTE: Before fastening the cabinet make sure
that it is sitting level and square.
NOTE: Screws should be positioned evenly
and fixed into nogs or studs.
NOTE: This section is only applicable if you have
purchased alternate trim for your vanity cabinet.
(c) Fix the new trim in place using the screws
that were removed from the original trim.
(b) Unscrew the 3-4 screws from underneath the
trim and remove the trim from the cabinet.
NOTE: Keep the screws for use later on.
(a) After the drawer has been removed (refer to
section 1), unscrew the trim fixing screws from
each angle bracket located behind either side of
the trim.
2 Changing drawer trims (Optional)
Trim
Angle
brackets Angle
brackets
(b) With a suitably sized hole saw, drill the holes
for the water supply and waste.
ENGLEFIELD
4
50mm
Maximum
height
260mm
(a) Measure and mark the centres for water
supply and waste pipes on the back of the
cabinet.
NOTE: Ensure that plumbing holes are positioned
to allow for a maximum height of 260mm between
the bottom of the basin to the base of the trap.

5 Vanity top
(a) Unpack the top and check for any damage
that might have occured in transit. Check and
confirm the fit of your selected tapware.
(b) Apply a continuous bead of silicone (not
supplied) to the top edge of the cabinet sides
and back. Ensure there are no gaps in the
sealant bead. This will ensure the top stays
securely fitted to the cabinet and no water
spillage will find its way into the cabinet.
No silicone on
front edge
(a) To re-install the drawer, extend the runners.
Place the drawer onto the runners and slide it
back so that the runner hooks insert into the
rear of the drawer.
(b) Make sure the locator pins line up with the
holes in the bottom of the drawer and press
the drawer down so that the pins slot into
place.
7 Drawer re-installation
(a) All edges MUST be sealed with an approved
Silicone Sealant.
8 Sealing
INSTALLATION COMPLETE
INSTALLATION INSTRUCTIONSVALENCIA
TM
Single Drawer Vanity
6 Waste and tapware
(c) Place the vanity top onto the cabinet ensuring
that the back is flush against the wall and
there is an even overhang on either side of the
cabinet.
(d) Wipe off any excess sealant.
(a) Fit the waste and tapware. Connect the water
supply to the taps and waste pipe to the waste
outlet.
(b) Run hot and cold water and check for leaks.
When satisfied with the results move on to the
next section.
ENGLEFIELD
5
=
=
Locator pin
Runner hook
(c) For 77296A-*: Re-install the cabinet door.
Hook the hinges onto the base plates and press
down as shown.
Hook

CONTACT AND WARRANTY INFORMATION
INSTALLATION INSTRUCTIONSVALENCIA
TM
Single Drawer Vanity
CLEANING AND MAINTENANCE INSTRUCTIONS
NEW ZEALAND
KOHLER NZ LTD
- Please visit our website for warranty and other information.
- Please refer to the Owner’s Information Leaflet for contact information.
For cleaning instructions, please refer to the Owner’s Information Leaflet.
www.englefield.co.nz
AUSTRALIA
KOHLER CO.
www.englefield.com
ENGLEFIELD
6
