Englefield SAPPHIRE Series User manual

1232792-A02-B 20/06/2014
INSTALLATION
INSTRUCTIONS
FURNITURE
Englefield
SAPPHIRETM Mirror Cabinets
Contemporary design and
quality construction,
providing affordable storage
for bathrooms of any size or
style.
It’s the details that Englefield
cares about - from pioneering
the latest technology, to
innovative design.
Englefield
Single Door
Model
Double Door
Model

BEFORE YOU BEGIN
ROUGH-IN
Page 1
INSTALLATION INSTRUCTIONSSAPPHIRE
TM
Mirror Cabinets
Please read these instructions carefully to familiarise yourself with the required tools, materials, and
installation sequences. Follow the sections that pertain to your particular installation. This will help you
avoid costly mistakes. In addition to proper installation, read all operating and safety instructions.
Prior to installation, inspect cabinet and top to ensure that no damage has occurred in transit. If damage
has occurred, or a visible defect exists, do not proceed with installation, and advise your supplier
immediately.
Please leave these instructions for the consumer. They contain important information.
ENGLEFIELD
Instructions, drawings, and diagrams contained in this manual present information available at the time of printing.
changes without further notice.
Single Door Model
Double Door Model
On-wall installation: In-wall installation:
760 720
140
450
120
760 720
140
760
120
The cabinets must be fixed to two nogs in the wall.
The nog size should be 50 x 75mm. If insetting into the wall the cabinets must be fixed to studs and there must be at least a 20mm gap
between the finished wall and the back of the door.
CONSTRUCTION REQUIREMENTS
80
Positioning of the nog near
vertical centre is recommended,
however exact position will
depend on shelving etc.
80mm from top of
cabinet to centre
of nog.
20
Studs Finished wall

1 Fixing the cabinet to the wall
(b) To make installation easier remove the cabinet
door/s. To release hinges press the buttons at
the rear of the hinges and unhook the hinge.
INSTALLATION
TOOLS AND MATERIALS REQUIRED - (Not Supplied)
Page 2
INSTALLATION INSTRUCTIONS
ENGLEFIELD
To suit pipework To suit screws
TOOLS MATERIALS - Not supplied & must be purchased separately
Fixing washers
20mm
Screws (Refer step 3)
10g x 75mm
Hook
Button
SAPPHIRE
TM
Mirror Cabinets
(a) Choose the orientation of the cabinet. The
cabinet can be rotated to be left handed or
right handed.
(c) Fix the cabinet in place using 6 screws (min 10g
x 75mm) and 6 *washers (20mm) to fix the
cabinet.
*Washers must be used to spread the load.
NOTE: Before fastening the cabinet make sure
that it is level and square.
On-wall installation:
Screw through the back wall into the two nog/s.
In-wall installation:
Screw through the sides into the studs.
Screw positions
for cabinet
80
50
Screw positions
for cabinet
2 Installation finalisation
(b) Re-install the cabinet door/s. Hook the hinges
onto the base plates and press down as shown.
(a) Make sure the shelves are installed correctly
for your selected cabinet orientation. The metal
pin must be on the bottom of the shelves.
Hook
Base plate
Shelf
Metal pin
Plastic shelf
clamp
INSTALLATION COMPLETE

CONTACT AND WARRANTY INFORMATION
NEW ZEALAND
KOHLER NZ LTD
Free Ph: 0800 100 382
Free Fax: [phone]
www.englefield.co.nz
AUSTRALIA
KOHLER CO.
Free Ph: 1 800 228 476
www.englefield.com
For warranty information, please visit our website
Englefield
INSTALLATION INSTRUCTIONSSAPPHIRE
TM
Mirror Cabinet
CLEANING AND MAINTENANCE INSTRUCTIONS
Mirror:
It is recommended that all moisture be removed with a soft cloth after each use.
To clean the mirror surface use a soft cloth with warm water and methylated spirits.
Apply the cleaning solution to the cloth. Make sure all edges are thoroughly dry after cleaning.
Cleaners should not be applied directly to the mirror surface as it could come into contact with the back of
the mirror causing damage.
Do not use abrasive cleaners that could scratch the mirror. Acidic, alkali or extra strength ammonia cleaners
should be avoided as these can damage the copper coating and destroy the mirror.
Cabinet:
The materials used in the mirror cabinet are water resistant only, not water proof.
Care must be taken to clean up all water spillage onto the cabinet surfaces. To maintain the finish on your
cabinet clean with mild soapy water and dry with a soft cloth.
CAUTION
Material used in cabinet is water resistant only, not waterproof.
Care must be taken to clean up all water spillage.
