ENHANCED VISION Amigo User manual


TM
High-Resolution. Light. Portable.

Congratulations on your purchase of Amigo from
Enhanced Vision. Like all Enhanced Vision products,
Amigo is designed to give you the highest quality and
convenience available.
Amigo enables people with low vision to see objects
on-the-go. This battery-operated system incorporates
a 6.5” high resolution viewing screen with tilting
capabilities for optimal viewing.
The slim, light and portable Amigo can be used for
reading newspapers, writing a check, looking at photos,
viewing price tags at the grocery store, and much
more. Amigo is designed to incorporate the flexibility
and freedom of your life in one compact video magnifier.
Prior to using this system, please carefully read and
follow the instructions provided within this booklet. A
thorough understanding of the functionality will allow
you to fully benefit from the flexibility and great features
of this device.
If you have any questions, please contact the Eye Care
professional or the supplier from whom you have
acquired the unit.
FCC ComplianCe notiCe

This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
Unauthorized changes or modication to this system can void the
user’s authority to operate this equipment.
If your Low Vision device has an option to connect to a TV, it
must be used with shielded interface cables in order to meet FCC
emissions limits for Class B digital devices. It is the responsibility
of the user to use the shielded interface cables supplied with the
equipment.
FCC ComplianCe notiCe


table oF Contents

System Warnings & Precautions. . . . . . . . . . . . . 2-3
Caring For Amigo ......................... 3

Amigo Controls ..........................4-5
Amigo Contents..........................6-7

Quick Start............................... 8

Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . 9
Adjust Size & Viewing Modes . . . . . . . . . . . . . 10-11
Using Freeze Feature . . . . . . . . . . . . . . . . . . . . . 12
Tilting LCD.............................. 12
Tightening LCD Hinge . . . . . . . . . . . . . . . . . . . . . 13
Writing Stand............................ 13

Amigo ................................. 14
Conserving the Battery . . . . . . . . . . . . . . . . . . . . 14

Replacing & Recharging the Battery. . . . . . . . 15-16

table oF Contents

Connecting to TV ........................ 17

Troubleshooting........................18-21

Specifications .........................22-23

Warranty .............................24-25

Other Enhanced Vision Products . . . . . . . . . . 26-28

Contact Information. . . . . . . . . . . . . . . . . . . . . . . 28

Notes................................29-31

2Chapter 1 important saFety preCautions
To obtain the maximum benefits from your Amigo,
please read these safety precautions carefully.

The Amigo is designed to help people with low vision
read and write. The extent to which Amigo can improve
the ability to see images depends on an individual’s
condition and level of vision. These products are not
designed to restore vision, correct eye conditions or
halt degenerative vision loss. An eyecare professional
can determine the suitability of Amigo for a patient's
condition.

Avoid exposing Amigo to extreme or rapid changes in
temperature or humidity as these conditions may cause
fogging or damage to the product. Amigo should never
be placed near a radiator or heat register.
Do not smoke while using Amigo. Cigarettes, cigars
and pipe smoke release abrasive particles which are
potentially damaging to the Amigo’s optics and
electronics.
Do not use this product near water ( i.e. near a bathtub,
kitchen sink, swimming pool, etc).
Do not place this product on an unstable cart, stand or
table, as the product may fall, causing serious
damage.




3
Chapter 1 important saFety preCautions
Always place the Power/Video cord in an area where it
will not be damaged by persons walking on them.
To avoid the risk of electrical shock, do not disassemble
this product. Return it to the place of purchase if service
or repair work is required. Any attempt to disassemble
your Amigo product will void the warranty.
Always use the power supply provided within your
package. Do not attempt to use any other power supply;
doing so will harm the unit and void the warranty.

Always turn the power OFF when you are not using the
system. Make sure the power is OFF and Amigo is
unplugged from the wall outlet before cleaning. 

The plastic surfaces of your Amigo product may be
dusted with a dry cloth.
The optical surfaces should be cleaned as needed for
best performance. Dampen a lens cleaning tissue with
a small amount of water and gently wipe the surfaces
clean.



4Chapter 2 paCkage Content & Control
Your Amigo is packaged in a convenient soft case for
storage and transport. All required accessories for operation
are included inside the box.

1. Power Button: turns the unit ON and OFF.
2. 6.5” LCD screen: displays magnified images.
3.
Size Wheel: rotates between 5 magnification sizes.
4. Mode Wheel: rotates between 6 different viewing
modes.
5. Freeze button: takes a temporary picture of the image
on the LCD screen.
6. Video Out: used to connect the included Video Out
cable to a TV or external display.
7. LED indicator light: shows the status of the battery.
  Blinking:Batteryiscurrentlycharging
  OFF:Batteryis100%charged
8. DC IN: used when plugging the external power supply
into an AC outlet.
9. Battery Compartment: holds the battery and can be
used as a charger when plugged into an AC outlet .
10. Battery: powers Amigo for approximately 1.75 hours.
(continued on page 6)


5
Chapter 2 paCkage Content & Control













6Chapter 2 paCkage Contents & Controls

11. Carrying Case with Shoulder Strap
12. Amigo 12 Volt Power Supply
13. Right Angle Power Supply Adaptor Plug
(For export versions only. Style depends on country)
14. Video Out Cable
15. Lens Cloth
16.
Writing Stand
17. External Battery Charger
18. Power Supply for External Battery Charger
(style may vary depending on the country where used)
19. Extra Battery

20. Car Charger

Chapter 2 paCkage Contents & Controls 7




 





8Chapter 3 QuiCk start
Here are some of the things you can do with Amigo.
• Read
• Write
• Freeze images
The following steps will give you a quick start on using
the Amigo.
 
Press and hold the Power button for more than 1
second. Amigo should turn ON. (see Figure 1)
 
Simply rest or set the Amigo on top of the desired
object and view the magnified image.
 
Rotate the Size Wheel to change the magnification
size. (see Figure 2)
Figure 1 Figure 2


Chapter 4 using amigo 9
Amigo comes with one fully charged external battery
and one partially charged battery inside the unit. Before
using your Amigo, we recommend plugging the Amigo
into an AC wall outlet to allow the battery inside the unit
to fully charge. This may take up to three hours.



Follow the steps below in order to charge the battery:
1. Connect the Power Supply together with the Right
angle Power Plug. (see page 7, items 12 and 13)
2. Connect the Power Supply tip into the unit where the
DC IN is located. (see page 5, item 8)
3. Plug the Power Supply into an AC outlet or preferably
a power strip.
4. While the battery is being charged, the green LED
indicator light will blink. When the battery is fully
charged, this light will remain solid.
(see page 5 item 7)
5. You can continue to use the unit while charging the
battery at the same time. This will not effect the
charging time which may be up to three hours.
Note: The LED indicator light will turn off when the
power supply is not plugged into the Amigo.


10 Chapter 4 using amigo


Follow the steps below:
1. Connect the Power Supply
together with the Right Angle
Power Supply Plug. (see
Figure 1)
2. Connect the Power Supply tip
to the Amigo as shown. (see
Figure 2)
3. Plug the power supply into an
AC wall outlet or preferably a
power strip.
4. Press and hold the power
button to turn on the Amigo

To adjust the size, rotate the
dial located on the side of the
unit labeled “Size.” There are 5
magnification levels, 3.5x-14x
(see Figure 3)

To adjust the Viewing Mode,
rotate the dial located on the
side of the unit labeled “Mode.”
(see Figure 4)
Figure 1
Figure 2
Figure 4

11
Chapter 4 using amigo
Amigo has the following 6 Viewing Modes:

This mode gives a true color representation of the
image that is being displayed. This mode is ideal for
looking at pictures and writing.

Based on your preference, you can choose the Black &
White mode for viewing objects. This may improve the
legibility of newsprint or other printed text.

This mode provides a white background with black text.
This mode increases the contrast to offer crisp text
images for reading.

This mode provides a black background with white text.
This mode increases the contrast to offer crisp text
images for reading.

For some users, this mode increases the contrast to
offer crisp text images for reading.

For some users, this mode increases the contrast to
offer crisp text images for reading.

12 Chapter 4 using amigo

FREEZE allows you to take a
temporary picture of an image.
This enables you to move the
unit to better view the desired
object.
1. Hold or place the unit over
desired location.
2. Press and hold the “FREEZE” button for 2 seconds.
(see Figure 1) to freeze the image
3. You may freely adjust the image size and color
viewing mode as desired after freezing the image.
(Refer to page 10 for more details)
4. Press the “FREEZE” button
a second time to exit.

The LCD screen is designed
to tilt up 90 degrees.
Depending on the user’s
position, tilting the screen can
sometimes make viewing
images easier and clearer. (see
Figure 2)
Note:DonotforcetheLCDbeyondtheangleof90
degreesoryouwillcausedamagetheunit.
Figure 1
Figure 2
90° max.

13
Chapter 4 using amigo

Depending on the user’s
preference, the LCD hinge can
be tightened or loosened. To
tighten the hinge, turn the
Phillips screws clockwise
located on the front of the unit.
To loosen the hinge, turn the Phillips screws counter
clockwise. 

1. Place the writing stand over the desired material.
The tallest portion of the stand should face you.
2. Turn the Amigo ON. Gently set the Amigo into the
stand with Power Button facing you. Tilt the LCD
toward you.
3. Make sure the viewing mode is set to either Color
or Black & White mode. Reduce the magnification
to the lowest level.
4. Place your pen under stand and write on the
material.

14
Chapter 5 tips For using amigo

• When not using unit for an prolonged period of
time, remove the battery to extend battery life. The
battery will slowly lose its charge while inside the
Amigo.
• To maximize total battery time, charge both batteries
by using either the internal or external chargers.
(see page 9 or 16). Keep a spare battery charging
in the external charger at all times for future use.
Note: Never allow the battery to completely drain.

Amigo works best when placed directly on desired
material. This allows you to change viewing modes
and magnification with ease. Tilting the Amigo allows
you to view images at a comfortable angle. When
viewing objects "on-the-go", hold the object close to
the camera for clearer images. (see Figure 1 & 2)
Figure 1 Figure 2


15 Chapter 6 replaCing the battery


The battery is located in the
battery compartment. To
remove, push down on the
small tab of the battery
compartment and slide the
battery out. (see Figure 1)

To install the battery, set the
battery directly on top of the
battery compartment with
the charging contacts facing
towards the back of the
LCD. Gently press down
and forward to lock it in
place. (see Figure 2)


Figure 1
Figure 2


16 Chapter 7 Charging the battery

1. Remove the battery from the Amigo. (see page 15)
2. Plug the external battery charger (see page 7,
items 17 & 18) into an available AC outlet.
3. Place the battery on the
external charger by
setting the battery directly
on top of the battery
charger with the charging
contacts facing the raised
end of the charger. As
shown in Figure 1, slide
the battery into place until is locks into position.
Theredindicatorlightontheexternalbattery
chargerremainsSOLID
whilethebatteryis
charging.Depending on
the state of the battery, it
may be necessary to
charge the battery
overnight.
4. Whenthebatteryisfully
chargedontheexternalbatterycharger,thered
indicatorlightwillBLINKcontinuously.To
remove the battery, slide the battery away from the
raised end of the charger as shown in Figure 2.
Figure 1
Figure 2

