ENHANCED VISION transformer USB User manual

Users Manual
by

FCC ComplianCe notiCe
Congratulations on your purchase of the Transformer.
Enhanced Vision products are designed to give you
the highest quality and convenience available.
Transformer is the most flexible and portable solution
for reading, writing and viewing magnified images at
any distance. Compatible with popular magnification
software and the latest windows operating systems,
Transformer’s unique compact design is perfect for
school, work, or home.
The Transformer product can enable people with
low vision to read, write and to see objects at any
distance. The unique design of this product provides
the ultimate in flexibility and offers a large range of
magnification with multiple viewing options that
make reading easier than ever. Simply connect the
Transformer to any laptop or computer.
Prior to using this system, please carefully read and
follow the instructions provided within this booklet.
A thorough understanding of the functionality will
allow you to fully benefit from the flexibility and
great features of this device.
If you have any questions, please contact the eye
care professional or the supplier from whom you
have acquired the unit.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for
help.
Unauthorized changes or modification to this system can void
the user’s authority to operate this equipment.
If your Low Vision device has an option to connect to a TV,
it must be used with shielded interface cables in order to
meet FCC emissions limits for Class B digital devices. It is the
responsibility of the user to use the shielded interface cables
supplied with the equipment.
FCC COMPLIANCE NOTICE

table oF Contentstable oF Contents
Using 3rd party software 20
Using the Find 21
Using the Freeze 22
Using the Rotate 22
Color select mode 23
Upgrading your software 23
Chapter 6: Using the menu
Accessing the menu 24
Enable/Disable Window markers 25
Adjusting the Size/Position of Selected marker 26
Adjusting the Color Balance 27
Changing Favorite color modes 28
Chapter 7: Troubleshooting
Troubleshooting 29-30
Chapter 8: Specications
Specifications 31-32
Chapter 9: Warranty information
Warranty information 33-34
Chapter 10: Other Enhanced Vision Products
Other Enhanced Vision Products 35-38
Chapter 1: Safety Precautions
General guidelines 2
Transportation 3
Care & Maintenance 3
Chapter 2: System Requirements
System Requirements 5
Chapter 3: Getting Started
Setting up your Transformer 6-7
Software installation 8-9
Keyboard shortcuts 10
Chapter 4: Package Contents & Controls
Package Contents & Controls 11-12
Accessories 11-12
Chapter 5: Using the Transformer
Viewing Modes 13-15
Adjusting magnification 16
Adjusting window divider 17-18
Capturing a still image 19
Viewing a stored image 20

32 Chapter 1 saFety preCautions
Chapter 1 saFety preCautions
For your safety and to obtain the most benefit and life
from the Transformer, please read these important
safety precautions carefully.
General guidelines for use:
▶Use the Transformer on a stable, level surface such
as a solid desk or table, according to its intended
design specifications.
▶Always use the power supply provided with your
package. Do not attempt to use any other power
supply; doing so will harm the unit and void the
warranty
▶Use care when using the Transformer outdoors it
should NOT be exposed to extreme or rapid chang-
es in temperature or humidity.
▶Do not place the Transformer near a radiator, heater
or areas exposed to long hours of direct sunlight.
▶Prevent the risk of electrical shock by NOT attempt-
ing to disassemble the unit. Please refer all service
to an authorized repair facility.
▶Do not use the Transformer in, near or around wa-
ter. The Transformer is not designed to offer protec-
tion against contact with liquids of any kind.
▶Do not use the Transformer during an electrical
storm, lightning, or other severe weather.
▶Do not use the Transformer near open flames, flam-
mable materials or liquids.
Transportation:
▶Transformer comes with a convenient carrying case
for transport. To prevent the unit from being acci-
dentally dropped and damaged, always return the
Transformer to the carrying case while not in use.
▶This product is intended to be used as a portable
device. Please use care when connecting/discon-
necting cables and accessories.
Care & Maintenance:
▶Always turn the power OFF on the Transformer
when the system is not in use.
▶To prolong battery life, remove the battery from the
Transformer if the system is not being used for one
week or more.
▶If needed, clean the surface of the Transformer with
a soft damp cloth or an electrostatic dusting wipe.
DO NOT use liquid cleaners on the plastic surfaces.
No additional methods of sterilization or cleaning
are recommended or required.
SAFETY PRECAUTIONS

Laptop or Desktop PC Minimum Requirements:
Operating Systems:
Supported platforms for our Viewer application:
• *WindowsXP(ServicePack2orhigher)
• *WindowsVista(32-bit&64-bit)
• *Windows7(32-bit&64-bit)
Minimum requirements:
• OS: *Windows XP, *Windows Vista, or *Windows 7
• Processor: Intel Pentium M 1.5 GHz
• Memory:512MB
• USB2.0(high-speed):1availableportrequired
• Graphicscard:MustsupportDirectX8.1
• Harddisk:100MBoffreespaceavailable
Intheinterestofcontinuousimprovement,productspecications
and/orminimumsystemrequirementsaresubjecttochange
withoutpriornotice.
Minimumrecommendedrequirementsfor*WindowsVista&
*Windows 7:
• OS:*WindowsVista,or*Windows7
• Processor:IntelCore2Duo
• Memory:2GB
• USB2.0(high-speed):1availableportrequired
• Graphicscard:MustsupportDirectX9.0
• HardDisk:100MBoffreespaceavailable
*Windows® isaregisteredtrademarkofMicrosoftCorporation.All
otherbrandnamesaretrademarksoftheirrespectiveowners.
54Chapter 2 system requirements
Chapter 1 saFety preCautions
▶This product contains moving parts.
Please use caution when moving the
adjustable arm or when transport-
ing the Transformer to avoid possible
injury to hands and fingers.
▶To avoid personal injury or damage to the Trans-
former, do not make any other type of connections
to the camera input jacks other than those indicated
in the photo below.
Susceptibility to Interference:
There may be temporary performance degradation
of the Transformer when subjected to a strong
magnetic and/or radio-frequency field, electrostatic
discharge or transient electrical noise. An
electrostatic discharge (caused by static electricity)
may cause image distortion. If this happens, switch
the unit off and try moving the unit to a different
location.
SYSTEM REQUIREMENTS

1.Setup the Transformer
Remove the Transformer from the
case. Place the unit on a flat, level
surface such as a table or desk.
2. Connect the AC power
Connect the attached power cord to an available wall
outlet. (See Figure 1) To offer additional protection
during an electrical storm, a surge protector may also
be used and is recommended.
3. Connecting USB to Computer
Connect USB cable that was provided to the back of
your Transformer. Plug in the opposite end to your
desktop or laptop computer. (See Figure 2). If this is
your first time using this product, refer to page 8for
software installation
76 Chapter 3 GettinG started
Figure1
Figure2
Chapter 3 GettinG started
Figure3
Figure1
Figure4
Figure2
4. Unfolding the Transformer
▶Keep the base of the unit on the
flat surface. From the folded po-
sition gently pull the arm of the
Transformer to a vertical posi-
tion. (See Figure 2)
▶Pull the arm that is connected
to the camera head slowly to a
horizontal position. (See Figure
3) Upon unfolding the Trans-
former the LED light and unit
should automatically turn on.
▶Once the unit is open, grasp the
feet and move them away from
each other. Next rotate the cam-
era head toward the object you
wish to magnify. (See Figure 4)
▶To fold back to starting position
repeat steps in reverse.
5. Turning the power on and off
The Transformer will always be off
in the closed position. Upon
unfolding the Transformer the LED
light and unit should automatically
turn on. If you wish to turn off the
unit while it is still open, hold
down the illuminated power
button for 3 seconds until LED
light and unit turn off. (See Figure
1)
GETTING STARTED

98 Chapter 3 GettinG started Chapter 3 GettinG started
Software installation
IfthisisyourrsttimeusingtheTransformer,usethe
followinginstructionstoinstalltheviewersoftware.
NOTE:Ifyouhavepreviouslyinstalledthissoftware,
theViewershouldautomaticallyopenoncetheUSBis
connectedandthepowerison.
1. StartupyourPCasnormal.PlugintheUSBintoyour
PCandtheoppositeendintoyourtransformer.
2. Ifapop-upwindowappears:
 a)IfyouareoperatingonWindowsXPorVistaclickon
EVVieweroptiononthepop-upmenu(Seegure1),goto
step4.
b)IfyouareoperatingonWindows7,selectopenles
fromthepop-upmenu(Seegure2),gotostep3c.
3.Ifapop-updoesn’tappear:
 a)Navigatetoyourstartmenuandgoto“MyComputer”(See
gure3).
b)Oncethe“MyComputer”isopen,doubleclickontheEV
icon .
 c)Doubleclickthesetup.exetostarttheinstaller(Seegure4).
4.OncetheSetupwizardappearsonscreen,clickonthe
“Next”button(Seegure5).
5.Choosethedestinationfoldertoinstallthesoftwareand
clickonthe“Next”buttontocontinuetheinstallation
process(Seegure6).
6. Areadytoinstallscreenwillappear,click“Install” to
continuetheinstallation.
7. Thesoftwarewillstartinstalling,thisshouldtakeaprox.1
min.
8.Oncetheinstallationhasfullycompleted,theviewer
applicationwillautomaticallyopen.
Figure1Figure2
Figure3
Figure5Figure6
Figure4

1110 Chapter 3 GettinG started
Switch Keyboard Comments
Zoom+ Up
Arrow Zooms in and navigates menu.
Zoom- Down
Arrow Zooms out and navigates menu.
Freeze F This key acts as a toggle between live video and
Freeze frame mode.
When held for more than 3 seconds, the device
will enter Menu.
Escape Enter menu.
Mode M This key shall toggle between the favorite color se-
lect modes. Selects menu items (Mode switch only)
Holding this key for more than 3 seconds will re-
store to normal color mode.
Enter Select menu item.
LED
on/o
LThe LED’s are on automacally when the camera
is in the open posion. This switch provides the
capability to switch on/o the LED’s manually.
Find Space bar When the user holds this buon the camera shall
zoom to wide angle. When the user releases this
buon, the camera shall resume back to the zoom
level that it was prior to pushing this buon.
Rotate RWhen user acvates this key the camera image
will be rotated to accommodate le, forward, or
right viewing posion.
F5 Captures the current image and saves it to a le
(Saves to Documents folder as Default)
F6 Open an image that was saved.
F8 Change window posion.
Shi+Up/
Down/
Le/Right
Resize window while window posion is acve.
Acvate
Viewer
Ctrl+Alt+A This will acvate the viewer to allow keyboard
shortcuts.
Keyboard Shortcuts
Chapter 4 paCkaGe Contents & Controls
A. Camera: Rotates 330˚
B. Lens Release: Releases lens for distance viewing
C. Camera Lens
D. Find Button
E. LED Light
F. Battery Compartment (Integrated Charger)
G. Rotate Button: Rotates current image.
H. Illuminated Power Button: Turns unit on/off
I. Mode Button: Changes current favorite color mode
J. Zoom Wheel: Magnifies image, and navigates menu
K. Freeze Button: Freezes image on-screen
L. USB Input
M. Power Supply Input Port (DC IN)
Please note the locations of the following controls on
your Transformer:
Accessories
1. Soft Carrying Case
2. Sleeve
3. AC Adaptor
4. Battery (included inside Transformer)
5. USB cable
Please refer to the illustrations on the next page to
identify the package contents and controls of your
Transformer. In addition to this users guide, you’ll find
the following items inside the box:
PACKAGE CONTENTS & CONTROLS

1312 Chapter 4 paCkaGe Contents & Controls
CD
E
B
A
K
J
1
2
5
F
G
H
I
L
M
3
4
Chapter 5 usinG the transFormer
Distance Viewing Reading and Writing Self Viewing
USING THE TRANSFORMER
Now that your Transformer is installed and ready to operate
we can focus on the ease of use, and functionality
available to you.
Viewing Mode
The Transformer can be used to view objects at a distance,
up close, or any where in between. To change viewing
mode, simply turn the position of the camera by rotating
it on the arm. Your Transformer has a memory feature that
allows each viewing mode to be remembered by the 3 dif-
ferent viewing angles. The three viewing angles are:
▶Distance Viewing
▶Reading and Writing
▶Self Viewing
Camera pointed
away from Self
w/ lens open
Camera pointed down
at reading material
w/ lens closed
Camera pointed
towards Self
w/ lens open

1514 Chapter 5 usinG the transFormer
330˚
Distance Viewing Mode
The camera can rotate forward to capture people,
objects and scenery. Be sure to press the lens release
button, and open the Reading Lens for Distance
Viewing (See Figure 1).
The LED light should automatically turn off in this posi-
tion. However, if you prefer for it to be on, simply press
the illuminated power button.
Figure 1 Figure 2
Adjusting the Viewing Mode
The Transformer Camera rotates
330 degrees, providing
unsurpassed flexibility for the
visually impaired. Do NOT
force the camera beyond its
330-degree angular range as
this may damage the unit.
NOTE:FortheTransformertobeabletofocusatalllevelsof
magnicationindistancemode,theobjectortargetshouldbe
atleast3ormorefeetaway.
Chapter 5 usinG the transFormer
Reading and Writing Mode
The Camera can be adjusted downward for reading,
writing and enjoying crafts or other hobbies (See Figure
1). This makes it ideal for classroom use. When the
camera is rotated downward it is best to close the zoom
lens for optimal viewing clarity.
Figure 1
LeftForwardRight
Viewing Position
While in Reading and Writing mode the Transformer has
the flexibility to be used in three different positions, Right,
Forward, and Left. For each different position simply press
the rotate button (See Figure 2) until the image is displayed
correctly on screen.
Figure 2
NOTE: The default viewing position is Right. The rotation
cycle is as follows: Right, Forward, Left, Right.

1716 Chapter 5 usinG the transFormer
Figure 2
Figure 1
Adjusting Magnification
The Transformer offers a large range of magnification
capabilities. The following directions can be used with the
Zoom wheel (See Figure 2).
▶To adjust the magnification scroll the Zoom wheel + or -
until you reach your desired magnification.
Self Viewing Mode
The Camera can be rotated backwards to provide you
with the equivalent of a full-length mirror. In this
position, you can use the Transformer to help you put
on make-up, shave or perform other personal
hygiene. Be sure to press the lens release button, and
open the Reading Lens for Self Viewing.
(See Figure 1)
The LED light should automatically turn off in this
position. However, if you prefer for it to be on, sim-
ply press the illuminated power button.
NOTE: The extent of the magnification is dependent
upon the distance of the Camera to the object.
Adjusting the Video Window Divider:
Press the [F8] function key on your PC keyboard
to toggle the position of the on-screen camera
window. Each press of the [F8] key will rotate the
camera window position clockwise (left, top, right
or bottom, or full screen). After cycling through all
five camera window positions, pressing the [F8]
key a sixth time will exit the camera viewing win-
dow, returning you to your full screen PC desktop.
Pressing [F8] again will repeat all six screen rota-
tion cycles in sequence (See Figure 1).
Figure1
Chapter 5 usinG the transFormer

1918
Once you’ve chosen the position of the on-screen
camera image, use the following procedure to adjust
the width/height of the video window divider, relative
to your PC display:
• If the on-screen camera image is positioned to the
left or right of
your display, hold
down the [SHIFT]
button while
pressing either the
left or right arrow
keys on your PC keyboard to increase or decrease
the width of the video divider window. This adjust-
ment is useful when viewing magnified documents
side-by-side with your PC display.
• If the on-screen camera image is positioned to the
top or bottom of
your display, hold
down the [SHIFT]
button while press-
ing either the up or
down arrow keys
on your PC keyboard to increase or decrease the
height of the video divider window. This adjustment
is useful when viewing magnified documents above
and below your PC display.
Chapter 5 usinG the transFormer
Capturing a Still Image:
The Viewer application allows you to capture a still
photo (or “snapshot”) of the camera image. This is
especially useful in school or work settings, where
it may be desirable to magnify and store text that is
located on an distant object (i.e. chalkboard or dry
erase board) and later recall the image (homework
assignments, etc.). Use the following procedure to use
the Image Capture feature:
1) Focus on either a near or distant object. The object
viewed on the display will be captured as shown.
2) Press the [F5] function key on your PC keyboard.
to capture the still image. A standard “Save As”
dialog box will appear on screen.
3) Select the directory in which you wish to store
the file. If desired give the snapshot a descriptive
file name. If no filename is entered, the default
timestamp filename will be used. The image will be
saved as a standard .JPEG file (Windows* JPEG).
Chapter 5 usinG the transFormer

2120
Using Third-party Screen Magnication Software:
The Transformer viewer application can be used in
conjunction with the following magnification software
products:
▶Dolphin SuperNova
▶AISquared ZoomText
▶Issist iZoom
While the Transformer Viewer application is running
you may open up your third-party magnification soft-
ware at any time to simultaneously run the software
and the viewer application. Refer to the manual of
your magnification software for detailed instructions
on its usage.
Chapter 5 usinG the transFormer
Viewing a Stored Image:
1) Press the [F6] function key on your PC keyboard.
to open a previously stored image. The standard
“Open” dialog box will appear.
2) Choose the directory in which the stored file is
located and select “Open” to view the image.
NOTE: The image will open in the Windows program
you have currently set as your default picture viewer
In the interest of continuous product improvement,
third-party software compatibility is subject to change
without prior notice.
Chapter 5 usinG the transFormer
Using Transformer
Using the Find
The Transformer Find feature can help you quickly
identify where you are currently magnified on a page,
or can easily locate a specific part of an object you
want to view more closely.
NOTE: You cannot use object Find if you are magnified
at 1x.
While magnified, press
and hold down the Find button
on the camera head (See Figure 1)
1. The Transformer will automati-
cally zoom out to the widest
field of view, and a "target" (as
shown in Figure 2) will appear
in the center of the monitor
screen.
2. Move your work or reading material until you
have located the desired item within the "target"
area. (See figure 2)
3. Release the Find button, and it will magnify the
item you located within the targeted area. (
See
Figure 3)
Figure 2 Figure 3
Figure 1

2322 Chapter 5 usinG the transFormer
Using the Freeze Function
Freeze allows you to take a snap shot of what the
Transformer is magnifying in order for you to have
extended time to view the image. This is particularly
helpful when taking notes in a classroom.
The following directions can be used to apply the
Freeze mode using the Transformer only:
1. Press the Freeze button to activate Freeze mode
(See Figure 1).
2. To release the Freeze mode, press any key or
change the viewing angle.
Figure 1 Figure 2
Using the Rotate Function
The Rotate function allows you to rotate an image
on-screen (180˚ or 90˚). You can use this function
at any time. Simply Flip the image by pressing the
Rotate button located on the underside of the arm.
(See Figure 2) To rotate the image back to original
position press the Rotate button again or change the
viewing angle.
Chapter 5 usinG the transFormer
Color Select Mode
The Transformer was designed to provide optimum
viewing for people with certain visual conditions by
offering a range of choices in both text and
background colors. Use the Mode key (See Figure 1) to
toggle between full color viewing, enhanced positive,
enhanced negative, and your 6 favorite color select
modes. The 6 favorite color select modes can be
modified to any of the 28 color select options by
following the instructions provided on page 27.
NOTE: You are only allowed up to 6 favorites at any one time.
However, you have the flexibility to change them at any time.
Figure 1
Freeze
Zoom
wheel
Mode
Upgrading Your Software
In the interest of continuous product improvement,
updates to the Viewer software will be made
available on the Enhanced Vision website at:
http://www.enhancedvision.com/transformer-update.
For assistance in locating and downloading updates,
call the toll free support number, 1-800-440-9476.

Accessing the Menu
▶You can access the menu by pressing and hold-
ing the Freeze button on arm of the Transformer
for 3 seconds. .
▶Once the setup menu shows on-screen, (See
figure 1) use the Zoom wheel + or - to scroll
through the functions. To activate one of the
functions press Mode while it is highlighted.
▶To exit at any time press Freeze button while
setup menu is on-screen
25
24 Chapter 6 usinG the menu
Figure 1
USING THE MENU
Chapter 6 usinG the menu
Enabling/Disabling Line & Window Markers
Line & Window Markers are used to frame an image
between two horizontal lines. These lines may be used
as a reading guide for long passages of text, as a guide to
help keep your place as you move from one side of the
page to the other, or just to make writing easier.
The following directions can be used to Enable/Disable
Line & Window Markers
1. Press and hold the Freeze button for at least 3 sec-
onds or until setup menu shows on-screen.
2. Scroll with the Zoom wheel + or - to Line Marker
(See Figure 1) or Window marker (See Figure 2) and
press Mode to Enable.
3. See page 21 for instructions on how to adjust the
size and position or your Markers.
4. To Disable Line or Window marker, scroll with the
Zoom wheel + or - to the Marker currently Enabled
and press the Mode button or press Freeze at any
time.
Figure 1 Figure 2

2726 Chapter 6 usinG the menu
Adjusting the Size/Position of the Selected Marker
The following directions can be used to adjust the Size/
Position of the Line or Window Marker:
1. Make sure the Line/Window marker is currently
Enabled. (Refer back to page 24 if you are not sure
how to do this)
2. To increase or decrease Line/Window marker size
scroll with the Zoom wheel + or - to Marker size on
the setup menu (See Figure 1) and press the Mode
button.
3. Use the Zoom wheel + or - to increase or decrease
the size of the Line/Window marker. To exit back to
menu press the Mode button.
4. To move your Line/Window marker up and down,
scroll with the Zoom wheel + or - to the Marker po-
sition (See Figure 2) and press the Mode button.
5. You can now scroll with the Zoom wheel + or - to
move the Line/Window marker up and down. Press
Mode button to exit out of scroll mode.
6. To exit Marker mode, go to the Line/Window Mark-
er that is currently enabled and the press Mode button
or press Freeze at any time.
Figure 1 Figure 2
Chapter 6 usinG the menu
Adjusting the Color Balance
Color is often affected by the lighting used in a
room. The Transformer Color Balance control allows
you to achieve optimum clarity.
The following directions can be used to adjust the
Color Balance:
1. Press and hold the Freeze button for 3 seconds
until setup menu shows on-screen
2. Scroll with the Zoom wheel + or - and press Mode
on the desired Color button. (See Figure 1)
▶Color: Normal automatically adjusts to the lighting
in the room
▶Color: Warm casts a brighter yellow tone
▶Color: Cold casts a blue tone
3. To exit press Freeze button
Figure 1

Figure 3
2928 Chapter 6 usinG the menu
Figure 2
Figure 4
Changing Favorite Color Modes
The Transformer provides 28 selectable color modes,
and allows selecting up to 6 favorites for use, as
described on page 22. The following directions can
be used to change the favorite color modes on your
Transformer:
1. Press and hold the Freeze but-
ton for 3 seconds until the on-
screen menu shows up.
2. Scroll with the Zoom wheel + or - to
the color mode selection and press the
Mode button. (See Figure 1)
3. You will see a sub menu show-
ing the current color modes with a
check box. (See Figure 2)
4. To change your color modes high-
light one with a current check box,
and deselect it by pressing Mode.
(See Figure 3) Choose an alternative
color mode.(You are only allowed
up to 6)
5. Use the Next and Previous menu
items to view more available color
modes. (See Figure 3)
6. To exit use the Zoom wheel + or -,
go to exit on the menu (See Figure
4) and press Mode. Or just press
Freeze button to exit at any time.
Figure 1
Chapter 7 troubleshootinG
No power to the unit
Can you power the unit using the included AC adaptor?
(Pages 10-11)
Is the power supply properly connected to a surge
protector or an AC outlet (mains)? (page 6)
NOTE: A Viewer software reset may be necessary in the
event of a power surge.
Video image on Computer screen is blurry not clear or slow
Clean the LCD display and/or camera lens using a
cleaning cloth.
Adjust the distance of the Transformer from your
reading material or adjust the handle angle as needed
to improve image quality (focus)
Try selecting different viewing modes to improve image
quality (See Page 13)
NOTE: Having programs running in the background of
your computer may affect the quality of the image and
response time.
Video image on LCD display is too bright/dark
The Transformer is designed to be used in moderate
lighting conditions, preferably indoors. Bright lighting
(or direct sunlight) may produce shadows and/or
reduce visibility. Try moving to a more shaded area to
improve image quality.
Adjust the distance of the Transformer from your
reading material or adjust the angle of the handle as
needed to improve image quality (focus)
Try selecting different color modes to improve image
quality (See Page 23)
TROUBLESHOOTING

3130 Chapter 7 troubleshootinG
Batteries will not charge
▶Can you power the unit using the included AC adap-
tor? (Pages 10-11)
▶Is the power supply properly connected to a surge
protector or AC mains? (Page 6)
▶Is the correct battery being used and does it need to
be charged or replaced? (Page 11-12)
A Warning message is displayed on-screen
▶If you see a warning message appear on screen with
a low battery icon, simply plug the Transformer into
an available outlet with the AC power supply provid-
ed. The message should go away and the unit should
charge.
▶If you see a warning message saying “Connect En-
hanced Vision Device” ( See figure 2). The power to
your unit has either been manu-
ally shut off, the unit is not con-
nected to the PC, or the battery
has been drained. Make sure
your Transformer is plugged into
an outlet with the included AC
power supply. If you still do not
have power press and hold the illuminated power
button (refer to page 10-11) until the image shows on
screen.
Figure 2
Chapter 8 speCiFiCations
SPECIFICATIONS
Features:
• Lightweight,portabledesign
• 330˚adjustablecamerahead
• 6userfavoritecolormodes(with28tochoosefrom)
• 28availablecolormodes
• Magnication2.45Xupto30X(Basedona17”monitor)
• Image“Freeze”mode
• Integratedbatterycharger
Battery:
• D-Li1,Li-ion2Cell,7.4V,2,600mAhRechargeable
(includedinpackage)
Camera: DigitalCCD,Autofocus
Physical Dimensions:
~10”Lx3.65”Wx3.25”H(closed)
~13”Lx10.5”Wx9.25”H(fullyextendedinreadingview)
Weight: ~1.7lb.(withbatteriesinstalled)
Magnication Ranges:2.45Xupto30X
17” LCD: 2.4 (minimum) – 30.0 (maximum)
19” LCD: 2.7 (minimum) – 33.5 (maximum)
17”/19” Field of View (Near Mode): 13.7 cm (min) : 1.12 (max)
17”/19” Working Distance (Near Mode): 17.5 cm
Warranty: 2 years
Indicator lights:
• Greensolid=pluggedin
• Greenoff=notplugged
• Redsolid=fullbattery
• Redblinking=charging(ifpluggedin)orrunningfrom
battery(ifnotpluggedin)
• Redoff=nobattery

3332 Chapter 8 speCiFiCations
Environment:
• OperatingTemperature:32˚–104˚F(0˚–40˚C)
Humidity10-90%(non-condensing)
• Storagetemperature:-4˚–140˚F(-20˚–60˚C)
Estimated Charge times (using rechargeable battery):
~4hoursmaximum
*Note:OnlywithuseofEnhancedVisionBattery
Wall adapter:
• UL/CErated
• Input:100-240VAC50/60Hz(0.8AMax)
• Output:9VDC,2.5A
• OperationTemperature:0C–40C
• RelativeHumidity:10%-95%
Image:
• 28EnhancedContrastModes
• BlackandWhite
• Color
• PageLocator
Topreventcondensation,donotusetheunitfor1hourafter
transportingtheunitfromextremecoldtoroomtemperature.
**Alltimeslistedareapproximate.ActualChargingandUsage
timesmayvarydependingonthelifecycleremainingon
thebatteries,typeandcurrentratingofbatteriesused,LCD
brightnesssetting,LEDModeandothervariablefactors.
In the interest of continuous product improvement,
specications and/or minimum system requirements are
subject to change without prior notice.
Chapter 9 Warranty inFormation
Enhanced Vision Transformer Warranty Policy
Enhanced Vision products are designed to give you the
highest quality image, convenient features, ease of use
and reliable service. The Transformer has been
inspected and tested prior to shipping. Enhanced Vision
warrants the Transformer against defects in material and
workmanship under normal use for two years from the
date of original purchase. Enhanced Vision, at its
option, will at no charge either repair the product or
replace it during the warranty period. There are no
other expressed or implied warranties accompanying
this product.
This warranty policy does not cover:
a) Defects or damage from misuse, use in other than
normal and customary manner, accident or neglect;
b) Defects or damage from improper operation,
maintenance, installation, adjustment, alterations or
modification;
c) Defects or damage from spills of food or liquid;
d) All plastic surfaces and all other externally exposed
parts that are scratched or damaged due to normal use;
e) Damage due to operation of the Transformer with
equipment not supplied or designed by Enhanced
Vision.
WARRANTY INFORMATION

OTHER ENHANCED VISION PRODUCTS
Merlin LCD – Easy to use!
MerlinLCDisavideomagnierthatpivots
andswivelstothemostcomfortableviewing
position.Thisproductincludesallthesame
featuresastheMerlinbutwithasleek
ergonomicdesign.
Availablein19”or22”LCDversions.
Magnication:2.4X–77X
Merlin LCD Plus – Computercompatible!
MerlinLCDPlusoffersthesameadvanced
featuresastheMerlinLCDbutisalso
compatiblewithmostcomputerworkstations
andoffersasplitscreenmode.Thismodelets
theuserviewmagniedimagesandcomputer
lesconcurrently.Theincludedfootswitch
andSplitScreenControlBoxprovidesline
markersandwindowsizecontrols.
3534 Chapter 9 Warranty inFormation
▶You must provide proof of purchase, bearing the
date of purchase, in order to receive warranty ser-
vice.
▶Anyone using this product does so knowingly as-
suming certain risks, due to the need to utilize vi-
sion enhancement devices.
Service Process
In the event that technical support or repair service is
needed, please contact your local Enhanced Vision
representative or the Enhanced Vision warranty service
center. If warranty service is required, please contact
Enhanced Vision at [phone] Monday through
Friday, between 8 a.m. and 5 p.m. Pacific Standard
Time (PST) to request a return authorization number.
Warranty repairs will not be accepted without a
valid return authorization number.
You may wish to keep the original product pack-
aging in case warranty service is required. The
manufacturer cannot provide packaging for war-
ranty repairs.
NOTE:Pleasecompletelylloutandsendinthe
enclosedwarrantyregistrationcard.
Chapter 10 other enhanCed Vision produCts
