ENKIN SS-EN-00-PDD200 User manual
Load Symbol Compatible Loads Max Loads
LED lighting 1000W
240V Incandescent
& Halogen lamps 1000W
Low voltage lighting with
electronic transformers
1000W
ON & OFF FUNCTION
Dummy dimmer switch is activated by pressing the
dimmer shaft.
• Input voltage: 240V ~ 50Hz
• Max load: 1000W
SS-EN-00-PDD200
Dummy Dimmer
Operating Voltage 240V ac
Nominal Operating Frequency 50 Hz
Dimming Technique N/A
Compliance BS EN 60669-2-1
N
L
LOAD
SWITCHED LIVE
LIVE
L1 CL2
WIRING DIAGRAM - ONE WAY DUMMY DIMMER
WIRING DIAGRAM - TWO WAY
N
L
LOAD
SWITCHED LIVE
LIVE
L1 CL2 L1 CL2
DIMMER DUMMY DIMMER
WARNING
RISK OF ELECTRIC SHOCK
●Hazardous voltage and electrical current may be present at the wire
leads of this product even when the device is switched o.
●Lock out and tag the input circuit before accessing the wiring
connections.
●This device must be installed by a qualied and experienced
electrician in accordance with applicable current electrical regulation.
●To comply with all safety standards, the product must be used only
for the purpose described in this instruction and must be installed in
accordance with the wiring rules and regulation in the location where
it is installed.
●There are no user serviceable parts inside the product.
Failure to follow these instructions can result in death or serious
injury.
EQUIPMENT DAMAGE HAZARD
●Install the device according to instructions in this document.
●Pay attention to the specications and wiring diagrams related to the
installation.
●Do not use this product for any other purpose than specied in this
instruction.
●The product is suitable for indoor use only.
●Apply IEC60898-1 compliant 250V~ 6A MCB as an overload
protective device.
LEGAL DISCLAIMER
The installation of electrical products is inherently dangerous and can
lead to serious injury or death. The products we sell MUST be installed
by a qualied and experienced electrician in accordance with applicable
current electrical regulation. Any advice, guidance or other information
provided by Enkin on their website or within any of our publications
cannot completely anticipate your situation and common sense must
prevail. Products need to be checked prior to installation and regularly
for damage and wear and tear. Products should be returned and not
used if in any doubt of their integrity.
Electrical rated loads and limits of a given product should NEVER be
exceeded at any time. The electricity supply should always be isolated
at its source (Distribution Board) before attempting any installation or
maintenance.
No advice or information, whether oral or written, obtained by you from
us or through the service, our employees, consultants and/or retailers
shall create any warranty not expressly made herein.
You agree to assume all and any risk resulting from the utilisation of
information provided by Enkin. You also expressly agree not to hold us
responsible for any damage, personal injury, death or loss resulting from
your use of our information, service or regulatory compliant products.
Enkin is a trading name of Trade Ivy. Registered in England Number: 10809945. Copyright © 2021 All Rights Reserved
Trade Ivy Limited, Unit 3C Latham Park, St Blazey Road, Par, PL24 2HY
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household
waste.
Please recycle where facilities exist. Check with your local authority or
retailer for recycling advice.
Scan QR Code for more detailed
technical information on this product
IP20
www.enkin.com
