Entel CXR16 Series Setup guide
CXR16 SERIES
Quick Start User Guide
THROAT MICROPHONE
Designed in the United Kingdom
Contact
For more information about our products please contact us:
All Rights Reserved. Copyright Entel UK Ltd.
V1.0
CXR16 SERIES
Thank you for purchasing the Entel CXR16
throat microphone. This user guide will
explain the features of your microphone,
which with care should provide many years of
trouble-free operation.
The CXR16 is a high-performance throat
microphone that delivers clear, intelligible
audio transmissions, even in high ambient
noise environments.
FITTING
Choose on which side you prefer to wear
the earpiece. The throat microphone should
be worn on the same side, adjacent to your
Adam’s apple. Ensure that the microphone is
applied directly to the skin with no clothing in
between. Fasten the Velcro band securely and
comfortably around the neck, while maintaining
the position of the throat microphone. Connect
the audio connector to the PTT unit.
OPERATING INSTRUCTIONS
• Insert the Nexus connector of the CXR16
directly into the PTT unit.
• Attach the PTT unit to a pocket or collar
using the clip on the rear of the PTT unit.
• Press the PTT button to transmit and
release to receive.
IMPORTANT
Always switch the radio o before
attaching an audio accessory. Models that
are certied to ATEX & IECEx have been
clearly labelled. Should, in the course of
use, any labels be removed or become
illegible please return the accessory to
Entel for relabelling.
Please note that the use of a connector
other than the Nexus connector may
damage the socket and invalidate the
warranty.
SPECIFICATIONS
THROAT MICROPHONE
Speaker impedance 800 ohm
Weight 90g
PTT UNIT
Submersible IP67 (1 metre for 30 minutes)
Dimensions 76mm x 60mm x 24mm
Weight 142g
PACKING LIST
Throat microphone and earpiece
PTT unit
Quick Start User Guide
PTT UNIT
EARPIECE
Model Series PTT model no. Intrinsically
safe cert. no.
Approval
CXR16/950 HT500
HT800
HT900
PT T951C Sira 10ATEX2066X &
IECExSIR10.0097X
ATEX &
IECEx
CXR16/750 HT700 PTT751C None None
CXR16/450 HX PT T4 51C None None
CXR16/DX DX PT T4 51C/DX None None
THROAT MICROPHONE
Above approvals apply to specific models only
