Product Overview
The Enterasys I-Series is a 2-slot modular, industrially-hardened Ethernet switch with an IP50
dust-resistant design and Class 1 Division 2 support suitable for explosive gas and other physically
demanding environments, such as manufacturing plants, oil refineries, and utilities. Along with
its operational tolerance for extreme temperatures ranging from -40° C to 60° C, the I-Series
combines multi-layer switching capabilities with wire-rate performance to support the demanding
requirements of industrial applications. The I-Series provides 2 modular slots which can support
up to 24 10/100Base-T Ethernet ports as well as 2 1 Gbps Small Form Factor Pluggable (SFP)
Ethernet uplink ports. In order to provide a reliable, high-availability network, all I-Series models
support redundant, 24-volt external power supplies as well as Link Aggregation Groups (LAGs) for
scalable, redundant uplinks.
The DIN-mountable I-Series utilizes industrial-grade components and provides a set of event-driven
relay connectors to support external alarms. In addition, the I-Series offers a portable, non-volatile
memory card, which is capable of storing the system configuration and may be used by non-
technical personnel to quickly replicate the configuration on a replacement switch thus making it
an ideal solution for dynamic environments without requiring dedicated technical support personnel.
In conjunction with its non-blocking architecture, the I-Series provides strong support for a
variety of network-attached devices such as Programmable Logic Controllers (PLCs), shop
floor workstations, and security cameras. The I-Series’ highly customizable Layer 2/3/4 packet
classification capabilities together with its intelligent queuing mechanisms ensure that mission-
critical devices and applications receive prioritized access to network resources.
Making use of Enterasys’ policy capabilities, a network administrator can define distinct roles or
profiles that represent industry-specific operational groups or devices. Each defined role is granted
individualized access to specific network services and applications (e.g., supervisor, operator, PLC,
security camera) and these access privileges remain associated with users/devices for both wired
and wireless network access. Users and devices are authenticated via IEEE 802.1X, MAC address,
or web-based authentication, and then assigned a pre-defined operational role ensuring that each
user has access to appropriate information, thus aligning network resource utilization with business
goals and priorities.
In order to sustain a secure, feature-rich and cost-effective network well into the future, the I-Series
comes with a 5-year warranty.
There is nothing more important
than our customers.
Industrial Ethernet switch with
2 modular slots for configuration
flexibility
Industrial-grade components
support explosive gas and other
physically demanding environments
Strong authentication
capabilities enable placement in
unsecured locations
Redundant, 24-volt external
power supplies
I-Series
Policy-based Industrial Ethernet Switch
DATASHEET
Benefits
Business Alignment
• Supportsavarietyofnetwork-attached
devices such as Programmable
Logic Controllers (PLCs), shop floor
workstations,andsecuritycameras
• DIN-mountableandrack-mountablefor
flexible installation
• Portable,non-volatilememorycard
enablesquickcongurationofnewor
replacement switches
Operational Efficiency
• Operationaltoleranceforextreme
temperatures (-40° C to 60° C) enables
placement in uncontrolled temperature
environments
• High-availabilitydesignandsimple
field maintenance minimizes technical
support expense
• Externalalarmsupportenablesproblem
notification without physical monitoring
Security
• Integralsecuritywithoutperformance
degradation
• Networksecuritymaintained
concurrently with user/device mobility
• Networkresourcessecurelyallocated
according to user/device operational roles
Support and Service
• Industry-leadingcustomersatisfaction
and first call resolution rates
• Personalizedresponseservices
• 5-yearwarranty

Layer 2 Capabilities
• IEEE802.1D–SpanningTree
• IEEE802.1t–802.1DMaintenance
• IEEE802.1p–TrafcManagement/Mapping
 to6of8HardwareQueues
• IEEE802.1Q–VirtualLANsw/Port-based
 VLANs
• IEEE802.1s–MultipleSpanningTree
• IEEE802.1w–RapidSpanningTree
Reconvergence
• IEEE802.1X–Port-basedAuthentication
• IEEE802.3–10Base-T
• IEEE802.3ab–1000Base-T
• IEEE802.3ad–LinkAggregation
• IEEE802.3u–100Base-T
• IEEE802.3x–FlowControl
• PrivatePort(PrivateVLAN)
• Many-to-OnePortMirroring,One-to-OnePort
 Mirroring
• Per-Port Broadcast Suppression
• SpanningTreeBackupRoot
• STPPassThru
• RFC1213–MIBII
• RFC1493–BridgeMIB
• RFC2668–Ethernet-likeMIB
• RFC2233–InterfacesGroupMIBusing
 SMIv2
• RFC2618–RADIUSAuthentication
 ClientMIB
• RFC2620–RADIUSAccountingMIB
• RFC2674–VLANMIB
• RFC2737–EntityMIBversion2
• RFC2819–RMONGroups1,2,3,&9
• IEEE802.1XMIB(IEEE802.1-PAE-MIB)
• IEEE802.3ADMIB(IEEE802.3-AD-MIB)
Authentication
• MACAuthentication
• WebAuthentication(PWA)
• 802.1XAuthentication
• RFC3580–DynamicVLANAssignment
• RADIUSClient
• RADIUSAccountingforMACAuthentication
• EAPPassThrough
• DynamicandStaticMacLocking
QoS
• Strict or Weighted Round Robin
• InboundRateLimiting
• 8HardwareQueues/Port
• 802.3xFlowControl
• 64kbpsIncrementGranularity
Management
• NMSConsole
• NMSPolicyManager
• NMSInventoryManager
• NMSAutomatedSecurityManager
• WebView
• SSLInterfacetoWebView
• TelnetwithSSH
• RadiusControltoManagementInterface
• RMON(4Groups:History,Statistics,Alarms,
and Events)
• Text-basedCongurationUpload/Download
• SimpleNetworkTimeProtocol(SNTP)
• AliasPortNaming
• Node/AliasTable
• RFC854–Telnet
• RFC1157–SNMPv1,v2c,andv3
• RFC1901–Community-basedSNMPv2
• RFC2271–SNMPFrameworkMIB
• RFC2465-IPv6MIB
• RFC2466-ICMPv6MIB
• RFC3413–SNMPv3Applications
• RFC3414–User-basedSecurityModelfor
 SNMPv3
• RFC3415–View-basedAccessControl
 ModelforSNMP
Industrial-Grade Reliability: Maintenance-free
reliability can provide years of uninterrupted
service in a wide range of severe temperature
and hazardous gas conditions.
Advanced Security and Traffic Control Features
in a Hardened Switch: Noswitchvendor
matches Enterasys for providing a secure
infrastructure.Thissamefunctionalityisnow
available in a fully-industrialized switch.
Fully Managed Solution: TheI-Seriesissecurely
SNMP-managedtoallowcontrolofthedevice
by authorized users from anywhere on the
network,whilealleventsandtrafcstatisticsare
reportedandtrackedbytheEnterasysNetwork
ManagementSuite(NMS).
Easy Installation:Optionalmemory
configuration card allows non-technical
personnel to field-replace I-Series switches with
a simple removal and reinsertion of a memory
congurationcard.Thecardcarriesacopyof
the switch configuration and allows settings to be
quicklytransferredtoanother
I-Series switch.
Standards and Protocols
Features and Benefits
Page 2

Physical Ports
2slotsfor10/100MbpsI/Omodules
2slotsforGigabitEthernetSFPuplinks
I/O Modules
12-port10/100Base-T
8-port100Base-FX
4-port100Base-FX
6-port10/100Base-Twithmemory
configuration slot
4-port100Base-FXwithmemory
configuration slot
8-port10/100Base-Tand2-port100Base-FX
LED
1red/greenLEDshowingsystemstatus
2greenLEDsshowingeachpowerinputstatus
2greenLEDsshowinglinkactivityofSFPports
Capacity & Performance
AddressTableSize–8000MACAddresses
1024VLANsSupported
8HardwareQueues/Port
VLANSpanningTree(802.1S)
– 4InstancesSupported
802.3ADLinkAggregation
– 8portspertrunkgroup,6groupssupported
Mainmemory:256MB
Flashmemory:32MB
Physical Specifications
Dimensions (H x W x D):
8.89cmx33.86cmx18.41cm
(3.5”x13.33”x7.25”)
I/O Module Dimensions:
4.57cmx10.7cmx11.4cm(1.8”x4.21”x4.5”)
Weight:
I3H252-12TX 4.35kg(9.57lbs)
I3H252-4FXM 4.33kg(9.53lbs)
I3H252-4FX-MEM 4.34kg(9.55lbs)
I3H252-6TX-MEM 4.34kg(9.55lbs)
I3H252-8FXM 4.43kg(9.75lbs)
I3H252-8TX-2FX 4.31kg(9.48lbs)
I3H-12TX 0.24kg(0.53lbs)
I3H-4FX-MM 0.22kg(0.48lbs)
I3H-4FXM-MEM 0.23kg(0.51lbs)
I3H-6TX-MEM 0.23kg(0.51lbs)
I3H-8FX-MM 0.32kg(0.70lbs)
I3H-8TX-2FX 0.20kg(0.44lbs)
MTBF
I3H252-12TX 182,146hours
I3H252-4FXM 184,898hours
I3H252-4FX-MEM 159,144hours
I3H252-6TX-MEM 164,848hours
I3H252-8FXM 164,891hours
I3H252-8TX-2FX 177,472hours
I3H-12TX 657,722hours
I3H-4FX-MM 695,075hours
I3H-4FXM-MEM 432,172hours
I3H-6TX-MEM 819,538hours
I3H-8FX-MM 477,350hours
I3H-8TX-2FX 600,601hours
Environmental Specifications
Operating Temperature:
-40°Cto60°C(-40°Fto140°F)
Storage Temperature:
-40°Cto70°C(-40°Fto158°F)
Operating Humidity:
95%RelativeHumidityNon-Condensing
Power Consumption:
TheI-Seriesaccepts24voltDCpoweronly.The
customermustprovideDCpowertotheswitch
orpurchasetheoptionalexternalDCpowerunit
(I3H-PWR).
Operation Shock:
50GTrapezoidalShock
Agency and Standards
Specifications
Standard Safety:
UL60950-1,CSA22.260950-1-03,
EN60950-1,andIEC60950-1
Standard EMC:
FCCPart15ClassA,ICES-003ClassA,BSMI,
VCCIV-3,AS/NZSCISPR-22ClassA,EN55022
ClassA,EN55024ClassA
Industrial EMC:
EN61000-6-4,EN61000-6-2,EN55011
Hazardous Locations:
ANSI/ISA12.12.01;CAN/CSAC22.2No.213-
M1987;EN60079-0:2006;EN60079-15:2005;
foruseinClass1,Division2,GroupsA,B,C,
andD
Service and Support
Enterasys Networks provides comprehensive
service offerings that range from Professional
Services to design and implement customer
networks, customized technical training, to
service and support tailored to individual
customer needs. Please contact your Enterasys
account executive for more information about
Enterasys Service and Support.
Warranty
As a customer-centric company, Enterasys is
committed to providing quality products and
solutions. In the event that one of our products
fails due to a defect, we have developed a
comprehensive warranty that protects you and
provides a simple way to get your products
repaired or media replaced as soon as possible.
The Enterasys I-Series comes with a 5 year
warranty against manufacturing defects. For
full warranty terms and conditions please go to:
www.enterasys.com/support/warranty.aspx.
Specifications
Page 3

Formoreinformation,callEnterasysNetworkstollfreeat1-877-801-7082,
or[phone]andvisitusontheWebatenterasys.com
ContactUs
Delivering on our promises. On-time. On-budget.
OrderingInformation
Part Number Description
I3H252-12TX FactoryConguredI-SeriesbaseunitwithoneI3H-12TX
I3H252-4FXM FactoryConguredI-SeriesbaseunitwithoneI3H-4FX-MM
I3H252-4FX-MEM FactoryConguredI-SeriesbaseunitwithoneI3H-4FXM-MEM
I3H252-6TX-MEM FactoryConguredI-SeriesbaseunitwithoneI3H-6TX-MEM
I3H252-8FXM FactoryConguredI-SeriesbaseunitwithoneI3H-8FX-MM
I3H252-8TX-2FX FactoryConguredI-SeriesbaseunitwithoneI3H-8TX-2FX
I3H-12TX 12-port10/100TXI/Ocard
I3H-4FX-MM 4-port100FXI/Ocard
I3H-4FXM-MEM 4-port100FXI/OcardwithMemoryCongurationSlot
I3H-6TX-MEM 6-port10/100TXI/OcardwithMemoryCongurationSlot
I3H-8FX-MM 8-port100FXI/Ocard
I3H-8TX-2FX 10-portI/Ocard(8-port10/100TXand2-port100FX)
I3H-DIN-KIT DINRailKitforI-Series
I3H-PWR 24VDCPowerUnitforI-Series
I3H-RACK-MNT 19”RackMountKitforI-Series
I3H-MEM MemoryCongurationCard;workswiththefollowingI-Seriespartnumbersonly:I3H-4FXM-MEMandI3H-6TX-MEM.
I-MGBIC-GZX MiniGBIC1000Base-LX,single-modeber,maximumdistance80km,industrialversionforusewithI-Seriesonly.
I-MGBIC-GLX MiniGBIC1000Base-LX,multi-modeorsingle-modeber,maximumdistance550meters(multi-mode),10km(single-mode)industrialversionfor
use with I-Series only.
I-MGBIC-GSX MiniGBIC1000Base-SX,multi-modeber,maximumdistance550meters,industrialversionforusewithI-Seriesonly.
I-MGBIC-GTX MiniGBIC1000Base-T,twistedpair,100meters,industrialversionforusewithI-Seriesonly.
© 2009 Enterasys Networks, Inc. All rights reserved. Enterasys Networks reserves the right to change
specifications without notice. Please contact your representative to confirm current specifications.
Please visit http://www.enterasys.com/company/trademarks.aspx for trademark information.
02/09
Patented Innovation
