Enviro Cara User manual

SHERWOOD INDUSTRIES IS AN ENVIRONMENTALLY RESPONSIBLE COMPANY. THIS MANUAL IS PRINTED ON RECYCLED PAPER.
BY: SHERWOOD INDUSTRIES LTD
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
50-1630
Cara
This appliance may be installed in an after-
market permanently located, manufactured
(mobile) home, where not prohibited by local codes.
This appliance is only for use with the type of
gas indicated on the rating plate. This appliance is
not convertible for use with other gases, unless a
certied kit is used.
WHAT TO DO IF YOU SMELL GAS
• Open windows/extinguish any open ame.
• Do not try to light any appliance.
• Do not touch any electrical switch or use
any phone in your building.
• Immediately call your gas supplier from
a neighbour’s phone. Follow the gas
supplier’s instructions.
• If you cannot reach your gas supplier, call
the re department.
WARNING: If the information in this
manual is not followed exactly, a re or
explosion may result causing property
damage, personal injury or loss of
life. Installation and service must be
performed by a qualied installer,
service agency or the gas supplier.
FOR YOUR SAFETY: Do not store or use gasoline
or other ammable vapours and liquids in the
vicinity of this or any other appliance.
Massachusetts installations (Warning): This product must be installed by a licensed plumber or
gas tter when installed within the Commonwealth of Massachusetts. Other Massachusetts code
requirements: Flexible connector must not be longer than 36in., a shut off valve must be installed;
only direct vent sealed combustion products are approved for bedrooms/bathrooms. A carbon
monoxide detector is required in all rooms containing gas red direct vent appliances. The replace
damper must be removed or welded in the open position prior to installation of a replace insert.
INSTALLER:
Leave this manual with the appliance.
CONSUMER:
Retain this manual for future reference.
OWNER’S MANUAL

2
FOR SAFE INSTALLATION AND OPERATION OF YOUR “ENVIRO” HEATER,
PLEASE CAREFULLY READ THE FOLLOWING INFORMATION:
• All ENVIRO gas-red appliances must be installed
in accordance with their instructions. Carefully read all
the instructions in this manual rst. Consult the building
authority having jurisdiction to determine the need for
a permit prior to commencing the installation.
• NOTE: Failure to follow these instructions could
cause a malfunction of the replace, which could
result in death, serious bodily injury, and/or property
damage.
• Failure to follow these instructions may also void
your re insurance and/or warranty.
GENERAL
• Installation and repair should be done by a
qualied service person. The appliance should be
inspected before the rst use and, at least, annually
by a qualied service person. More frequent
cleaning may be required due to excessive lint from
carpeting, bedding material, etc. It is imperative the
control compartments, burners and circulating air
passageways of the appliance be kept clean.
• Due to high temperatures, the appliance should
be located out of high trafc areas and away from
furniture and draperies.
Children and adults should be alerted to the
hazards of high surface temperatures and
should stay away to avoid burn or clothing
ignition.
• Young children should be carefully supervised
when in the same room as the appliance.
• Clothing or other ammable materials should not
be placed on or near the appliance.
FOR YOUR SAFETY
• Installation and service must be performed by a
qualied installer, service agency or gas supplier.
• This installation must conform to local codes or, in
the absence of local codes, to the current CAN/CGA-
B149 installation code (Canada) or National Fuel Gas
Code ANSI Z223.1.2 (USA)
• To prevent injury, do not allow anyone who is
unfamiliar with the stove to operate it.
• To prevent injury, if the pilot or pilot and
burners have gone out on their own, open the
glass door and wait 5 minutes to air out before
attempting to re-light the stove.
• Always keep the area around these appliances
clear of combustible material, gasoline and other
ammable liquids and vapours.
• These appliances should not be used as a drying
rack for clothing or for hanging Christmas stockings/
decorations.
• Due to the paint curing on the stove, a faint odor
and slight smoking will likely be noticed when the
stove is rst used. Open a window until the smoking
stops.
Always connect this gas stove to a vent system and
vent to the outside of the building envelope. Never
vent to another room or inside the building. Make sure
the specied vent pipe is used, properly sized and of
adequate height to provide sufcient draft. Inspect
the venting system annually for blockage and signs of
deterioration.
WARNING: Failure to position the parts in accordance
with the diagrams in this booklet, or failure to use only
parts specically approved with this appliance, may
result in property damage or personal injury.
WARNING: Do not operate with the glass front
removed, cracked or broken. Replacement of the
glass should be done by a licensed or qualied service
person.
• Never use solid fuels such as wood, paper,
cardboard, coal, or any ammable liquids, etc., in this
appliance.
• Do not use this heater if any part has been under
water. Immediately call a qualied service technician
to inspect the heater and to replace any part of the
control or gas control systems that have been under
water.
• Do not abuse the glass by striking it or slamming
the door shut.
Safety Precautions

Table of Contents
3
Safety Precautions.....................................................................................................2
Table of Contents......................................................................................................3
Codes And Approvals.................................................................................................4
Specications............................................................................................................5
Rating Label Location.....................................................................................5
Dimensions....................................................................................................5
Operating Instructions...............................................................................................6
Pilot Lighting Instructions................................................................................6
Air Shutter......................................................................................................7
Remote controls (Optional).............................................................................8
Blower Speed (Optional).................................................................................8
Normal Sounds During Operation.....................................................................8
Maintenance And Service...........................................................................................9
Routine Maintenance......................................................................................9
Cleaning The Painted Surfaces........................................................................9
Check Pilot and Burner Flames........................................................................9
Glass Door Removal........................................................................................9
Replacing the Glass.......................................................................................10
Cleaning The Firebox....................................................................................10
Burner Removal & Installation.......................................................................10
Fuel Conversion............................................................................................11
Initial Installation....................................................................................................13
Preparation For Installation...........................................................................13
Clearances to Combustibles...........................................................................13
Planning Your Installation..............................................................................14
Approved Vent Parts.....................................................................................15
Vent Termination Restrictions........................................................................17
Vent Congurations and Restrictor Settings....................................................18
Restrictor Installation....................................................................................19
Horizontal Installation...................................................................................20
Vertical Installation.......................................................................................22
Cathedral Ceiling Installation.........................................................................24
Corner Installations.......................................................................................25
Converting Top Vented into Rear Vented........................................................26
Installation of Rear Vented Appliance.............................................................26
Installation of Top Vented; Horizontal Termination...........................................27
Installation of Top Vented; Vertical Termination...............................................27
Gas Line Connection and Testing...................................................................28
Electrical Requirements For Gas Valve and Optional Blower..............................29
Installation of Optional Blower......................................................................30
Secondary Installation.............................................................................................31
Installation of Log Set...................................................................................31
Installation of Ceramic Firebox Liner (Optional)...............................................34
Trouble Shooting.....................................................................................................35
Parts List.................................................................................................................36
Parts Diagram..........................................................................................................38
Warranty.................................................................................................................39
Installation Data Sheet.............................................................................................42

4
DIRECT VENT ONLY: This type is identied by the sux DV. This appliance draws all of its air for
combustion from outside the dwelling, through a specially designed vent pipe system.
TOP VENT DV Certied for installation from 0-4500 ft (0-1372 m)
REAR VENT DV Certied for installation from 0-4500 ft (0-1372 m) with 36” (915 mm)
snorkel (refer to ‘Converting Top Vented into Rear Vented’).
In the USA: The appliance may be installed at higher altitudes. Please refer to your American Gas
Association guidelines which state: the sea level rated input of Gas Designed Appliances installed at
elevations above 2000 (610 m) feet is to be reduced 4% for each 1000 feet (305 m) above sea level.
Refer also to local authorities or codes which have jurisdiction in your area regarding the de-rate
guidelines.
In Canada: When the appliance is installed at elevations above 4500 feet (1372 m), the certied high
altitude rating shall be reduced at the rate of 4% for each additional 1000 feet (305 m).
• This appliance has been tested by INTERTEK (Warnock Hersey) and found to comply with the
established VENTED GAS FIREPLACE HEATER standards in CANADA and the USA as follows:
VENTED GAS FIREPLACE HEATER (Cara DV; NG/LPG)
TESTED TO: ANSI Z21.88a-2003/CSA 2.33a-2003 VENTED GAS FIREPLACE HEATERS
CAN/CGA 2.17-M91 GAS FIRED APPLIANCES FOR HIGH ALTITUDES
CSA P.4.1-02 TESTING METHOD FOR MEASURING ANNUAL FIREPLACE EFFICIENCY
This ENVIRO CARA Fireplace:
• Has been certied for use with either natural or propane gases. (See rating label.)
Codes And Approvals
• Is not for use with solid fuels.
• Is approved for bedroom or bed sitting room. (IN CANADA: must be
installed with a listed wall thermostat. IN USA: see current ANSI Z223.1
for installation instructions.)
• Must be installed in accordance with local codes. If none exist, use current
installation code CAN/CGA B149 in Canada or ANSI Z223.1/NFPA 54 in the
USA.
• Must be properly connected to an approved venting system and not connected
to a chimney ue serving a separate solid-fuel burning appliance.
IMPORTANT NOTICE (Regarding rst re up): When the unit is turned
on for the rst time, it should be turned onto high without the fan on for
the rst 4 hours. This will cure the paint, logs, gasket material and other
products used in the manufacturing process. It is advisable to open a
window or door, as the unit will start to smoke and can irritate some people.
After the unit has gone through the rst burn, turn the unit off including the
pilot, let the unit get cold then remove the glass door and clean it with a
good gas replace glass cleaner, available at your local ENVIRO dealer.

5
Specifications
WARNING:
Operation of this heater when not connected to a properly installed and maintained venting system can
result in carbon monoxide (CO) poisoning and possible death.
RATING LABEL LOCATION:
The Rating Label is located on the inside surface of the pedestal control door.
DIMENSIONS:
Figure 1: Cara Exterior Dimensions.
Rear Vent
Top Vent
21
1
/ 2 ”
(546mm)
21
1
/ 2 ”
(546mm)
36
1
/ 2 ”
(927mm)
15
3
/ 4 ”
(400mm)
15
3
/ 4 ”
(400mm)
32
5
/ 16 ”
(821mm)
2
13
/ 16 ”
(71mm)
16
7
/ 8 ”
(426mm)
17
3
/ 8 ”
(441mm)

6
Operating Instructions
For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating.
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY
RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OF LOSS OF LIFE.
Figure 2: Lighting Instruction Label.
2. Start the pilot by pressing the gas control knob and turning it to PILOT.
While holding the gas control knob in, press the piezo ignitor several
times until the pilot light starts. Hold the gas control knob in for 30
seconds. Check that the pilot has fully engulfed the thermocouple
assembly (refer to Figure 6).
3. Start the main burner by turning the gas control knob to ON and then
turn the rocker switch to ON. Check that all burner ports have ame.
4. Leak test all gas joints again.
Pilot/Orifice
Ignitor
Thermocouple
Figure 3: Pilot Assembly.
1. Turn off the gas to the replace. If not recently done, remove the door and let the unit air out
for at least ve (5) minutes to clear out any gas. Turn on gas to the heater. Leak test all joints
with soapy water. NEVER USE OPEN FLAME FOR LEAK TESTING.
CAUTION:
1. STOP! Read the safety information above on this label.
2. Turn off all electrical power to this appliance.
3. Turn off the gas control knob clockwise to the off position.
4. Open door. Wait fIve (5) minutes to clear out any gas. Close door. If
you smell gas STOP! Follow “B” in the above safety information.
If you do not smell gas go to the next step.
5. Find pilot-located to the left behind the side log.
Turn the gas control knob counter-clockwise to
“PILOT”. Push the gas control in fully and hold, keep knob
depressed for about 30 seconds after the pilot is lit.
Release knob. If pilot goes out, repeat steps 4 through 5.
Hot while operating. Do not touch, severe burns may result.
Keep children, clothing, furniture, gasoline or other flammable vapors away.
FOR YOUR SAFETY READ BEFORE OPERATING
WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING
PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
A) This appliance is equipped with a pilot, which must be lit by hand by
following these instructions exactly.
B) BEFORE LIGHTING smell all around the appliance area for gas and next to
the floor because some gas is heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance. Do not touch any electrical switch: do not
use any phone in your building. Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppliers instructions. If you cannot reach
your gas supplier, call the fire department.
C) Use only your hand to push in or turn the gas control knob; NEVER
use tools. If the knob will not push in or turn by hand, do not try to
repair it. Call a qualified service technician. Force or attempted repair
may result in a fire or explosion.
D) Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the appliance
and to replace any part of the control system and any gas control
which has been under water.
LIGHTING INSTRUCTIONS
WARNING: This gas valve has a lockout device, which will not allow the
pilot burner to be relit until the thermocouple has cooled. If the knob does
does not pop up when released, stop and immediately call your service
technician or gas supplier. If the pilot does not stay lit after several tries,
turn the gas control knob to “OFF” and call your service technician
or gas supplier.
6. Turn the gas control knob counter clockwise to the “ON” position.
Flip the burner switch to “ON” THEN
TURN THE “HI/LOW” knob to the
desired setting.
7. Turn on the electrical power to the unit.
TO TURN OFF GAS TO APPLIANCE
1. Flip burner switch to “OFF”
2. Turn the gas control knob clockwise to the “OFF” position.
3. Turn off all electrical power to the appliance if service is to be
performed.
CAUTION: Do not operate this fireplace with the glass removed, cracked or broken. Replacement of the glass should be done by a licensed
or qualified person! This appliance needs fresh air for safe operation and must be installed with provisions for combustion and ventilation air.
See installation and operating instructions manual. Keep burner and control compartment clean.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage, or loss of life. Refer
to owner's manual provided with this appliance. See installation and operating instructions accompanying appliance. Installation and service
must be performed by a qualified installer, service agency, or the gas supplier.
O
L
I
T
P
TP TH TP TH
IN OUT
H
I
L
O
N
O
F
O
F
L
I
P
T
O
PILOT LIGHTING INSTRUCTIONS:

7
AIR SHUTTER:
Air Shutter Adjustment Nut
Figure 5: Air Shutter Adjustment.
The air shutter is controlled by
sliding the air shutter adjustment
screw (shown in Figure 5) either
forwards or backwards. The
adjustment screw, for the primary
air, is located on the bottom of the
rebox. The air shutter nut can be
accessed by removing the control
panel. This is best done during the
initial installation.
Sliding the shutter forwards
increases the primary air while
sliding the shutter backwards
decreases the primary air.
The air shutter allows the amount
of air coming into the replace to be
adjusted in order to accommodate
different climates and venting
arrangements. Start the pilot and
then the burner. Make sure the pilot
ame is burning normally and none
of the burner ports are plugged.
Let the replace burn for roughly
fteen (15) minutes and then
examine the ames, compare the
ames to Figure 56.
Operating Instructions
For Your Safety, Read Safety Precautions
And Lighting Instructions Before Operating
Cara
On/Off
High
Low
Off
Fan
Remote Control Receiver
(optional)
Ignitor
Figure 4: Cara Control Panel.

Operating Instructions
For Your Safety, Read Safety Precautions
And Lighting Instructions Before Operating
8
The ideal ame will be blue at the base and light orange above. The ames should be of medium height.
If the ames look like this (refer to Figure 56), no adjustment is needed. If the ames are fairly short and
mostly blue, the replace is getting too much air. Therefore, the air shutter should be closed slightly until
the correct ames are achieved. Flames that are very orange, with tall, dark, stringy tips, are not getting
enough air. Open the air shutter until the ames clean up. If the shutter is opened, or closed all the way,
and the correct ames cannot be attained, turn off the gas and contact the dealer.
Warning: Incorrect air shutter adjustment may lead to improper combustion, which is a safety hazard.
Contact the dealer if there is any concern about the venturi adjustment.
Table 1: Air Shutter Setting Information.
Natural Gas Propane
Amount Air Shutter is Open ” (6mm) minimum Completely Open
REMOTE CONTROLS (OPTIONAL):
This replace can use an optional remote control or an optional cordless wall thermostat. If either of
these are to be used to control the replace for the majority of the time, leave the ON/OFF switch (on the
rear of the unit) in the “ON” position. Consult the instructions included with the remote/wall thermostat
for operation guidelines.
BLOWER SPEED (OPTIONAL):
The blower will come on only when the replace is up to temperature (approximately 12 minutes with
unit on high). When installed, the blower is equipped with a variable fan controller, located in the front
control panel. This control will adjust the fan speed from high to low or turn the fan off.
NORMAL SOUNDS DURING OPERATION:
Table 2: Normal Sounds
Component Sound & Reason
Cara Creaking when heating up or cooling down.
Burner Light pop or poof when turned off; this is more common with LP units.
Temperature Sensor Clinking when it senses to turn the blower on or off.
Pilot Flame Quiet whisper while the pilot ame in on.
Blower / Fan Air movement that increase and decreases with the speed of the blower.
The blower is pushing the heat from the replace into the room.
Gas Control Valve Dull click when turning on or off, this is the valve opening and closing.

9
Maintenance And Service
ROUTINE MAINTENANCE:
At least once a year, run through the following procedures to ensure the system is clean and working
properly. Check the burner to see if all the ports are clear and clean. Check the pilot to make sure it is not
blocked by anything. The pilot ame should be blue with little or no yellow on the tips.
Warning: Clearances must be sufcient to allow access for maintenance and service
Warning: Failure to position the parts in accordance with this manual, or failure to use only parts
specically approved with this appliance may result in property damage or personal injury.
The venting system must be periodically examined; it is recommended the examination is done by a
qualied agency.
CLEANING THE PAINTED SURFACES:
Painted faces should be wiped with a damp cloth periodically.
CHECK PILOT AND BURNER FLAMES:
Door Hook
Door Hooks
Door Hook Slots
Figure 7: Door Removal / Installation.
IMPORTANT: If the door is not engaged
properly on the hooks, damage to the
replace and/or oor, personal injury, or
even death may occur.
1. Turn the unit off and wait until it has
cooled down.
2. Remove the cast iron louvers from above
the door by lifting the louvers up and
out.
3. Pull the two (2) door hooks, on top of the
door, forward and up (see Figure 7).
4. Lift the glass door assembly straight up
and out.
Ensure the door is properly fastened before
attempting to light the appliance. To re-
installing the glass door, slide the three (3)
door hook slots, on the bottom of the door,
over the three (3) door hooks on the unit.
Pull the two (2) door hooks, on top of the
door, forward and slide them into the two
(2) door hook slots.
Periodically do a visual check of the pilot ames. One ame
should encompass the ignitor and thermocouple and the
other should burn over the burner ports (see Figure 6). Also
check that the burner is operating correctly, refer to Figure
56.
GLASS DOOR REMOVAL:
Figure 6: Pilot Flame.

IMPORTANT: Ensure the unit is off and
at room temperature.
To remove the burner:
1. Remove the glass door as shown in
the MAINTENANCE AND SERVICE - GLASS
DOOR REMOVAL.
2. Carefully remove the log set.
3. Slide the burner back just far enough
so the front edge of the burner does
not catch on the front lip of the
rebox.
4. Lift the front of the burner up and out
of the rebox.
To install the burner:
1. Insert the mixing tube into the mixing
tube box (refer to Figure 8).
2. When the burner is resting in the
rebox ensure that the front edge of
the burner is lined up with the front
lip of the rebox (see gure 9).
3. Re-install the logset (see SECONDARY
INSTALATION - LOG SET INSTALLATION) and
the door.
4. Check burner for proper operation. Figure 9: Align Burner With Firebox.
Figure 8: Install the Burner to the Firebox.
10
Maintenance And Service
REPLACING THE GLASS:
IMPORTANT: Do not operate with the glass front removed, cracked or broken. The glass in the
replace is a high temperature ceramic. If the glass is damaged in any way, a factory replacement door
is required (see PARTS LIST). Wear gloves when handling the damaged glass door assembly to prevent
personal injury. When the glass door assembly is being transported, it must be wrapped in newsprint and
tape and/or a strong plastic bag. Removal and replacement of the glass from the door must be done by
a licensed or qualied service person. The door assembly must be purchased from an ENVIRO dealer.
No substitute materials are allowed.
CLEANING THE FIREBOX:
With the replace at room temperature, carefully remove the logs. Gently remove the ceramic burner
and place on a paper towel. Vacuum the bottom of the rebox thoroughly. Carefully clean any dust off
the logs and remove any lint from the burner and pilot. At this time, inspect the burner pan for cracking
or severe warping. If a problem is suspected, contact the dealer. Check the logs for deterioration or large
amounts of soot; a small amount on the bottom side of the logs is normal. Replace the logs as in the LOG
SET INSTALLATION section.
BURNER REMOVAL & INSTALLATION:
Mixing Tube Box
Mixing Tube
Bring front lip of burner
to front edge of firebox.

11
Maintenance And Service
FUEL CONVERSION:
TO BE INSTALLED BY A QUALIFIED SERVICE AGENCY ONLY
Please read and understand these instructions before installing.
Warning: This conversion kit shall be installed by a qualied service agency in accordance
with the manufacturer’s instructions and all applicable codes and requirements of the
authority having jurisdiction. If the information in these instructions is not followed
exactly, a re, explosion or production of carbon monoxide may result causing property
damage, personal injury or loss of life. The qualied service agency is responsible for
the proper installation of this kit. The installation is not proper or complete until the
operation of the converted appliance is checked as specied in the manufacturer’s
instructions supplied with the kit.
Figure 10: Removing the orice.
Kit Parts List:
Orice (NG - PO512-37 DMS or LP - PO512-1/16” DMS)
Installation instruction sheet
Carefully inspect all parts supplied with this conversion kit. If
any parts have been damaged or are missing, contact your
dealer, distributor or courier company to have them replaced
before starting this installation.
Conversion Kit Installation:
1. Turn control knob on the gas valve to the “OFF” position
and shut the gas supply off at the shut-off valve upstream
of the unit. CAUTION: The gas supply must be shut off
prior to disconnecting the electrical power and before
proceeding with the conversion. Allow the valve and unit
to cool down to room temperature.
2. Remove the glass door as shown in the MAINTENANCE AND
SERVICE - GLASS DOOR REMOVAL.
3. Carefully remove the log set.
4. Slide the burner back just far enough so the front edge of
the burner does not catch on the front lip of the rebox.
Lift the front of the burner up and out of the rebox. See
MAINTENANCE AND SERVICE - BURNER REMOVAL & INSTALLATION.
5. Convert the burner orice:
a) Remove the main burner orice with a ” socket
(refer to Figure 10).
b) Install the alternate orice from the kit.
6. Convert the pilot injector:
a) Loosen the pilot stem a half turn using a 7/16” wrench
(refer to Figure 11).
b) Slide the tab to the other side of the pilot stem (refer
to Figures 12 & 13).
c) Tighten the pilot stem.
Figure 11: Turning Pilot Stem.
Natural Gas Position:
NA Stamp Visible
.020” (0.51mm) Hole Size
L.P. Gas Position:
LP Stamp, Hole, & Red
Colour Code Visible
.014” (0.36mm) Hole Size
Figure 12: NG & LP Gas Positions on Pilot.

12
Figure 14:
Removing valve
cap.
Maintenance And Service
screw must be not visible. Figure 16: Flip
valve screw.
Red o-ring
is not visible
Red o-ring
is visible
LPG Configuration
h) Re-attach the black protection cap that
was removed in step a (Figure 14).
8. Re-install the burner, ceramic panels, log
set and glass door. Also refer to SECONDARY
INSTALLATION - LOG SET INSTALLATION. When
re-installing the burner, ensure that the
burner to pilot hood relationship is similar
to what is shown in Figure 18.
9. Reconnect the main gas line if it was Figure 17: O-ring on valve screw.
Loosen
Tighten
Figure 15: Removing
valve screw.
e) Flip the screw (refer to Figure 16).
f) Using the Allen wrench as shown
in Figure 15, rotate the screw
clockwise until a torque of 9 inch lbs.
WARNING! Do not over tighten the
screw. It is recommended that you
grip the wrench by the short side.
g) Verify that if the conversion is from
NG to LPG, the screw must be re-
assembled with the red o-ring visible
(refer to Figure 17). If the conversion
is from LPG to NG, the red o-ring of the
Figure 18. Pilot assembly
beside the burner
disconnected and open the shut-off valve at the gas line to the unit.
10. Use a small brush to apply a warm soapy water solution to all gas
connections (use a half dish soap and half warm water). If a gas leak
is present, bubbling will occur. Gas leaks can be repaired by using an
approved pipe thread sealant or approved Teon tape. NEVER USE AN
OPEN FLAME WHEN TESTING FOR LEAKS.
11. Reconnect the electrical power to the unit.
12. Relight the main burner in both the “HI” and “LO” positions to verify
proper burner ignition and operation and proper ame appearance
(refer to Figure 56). Also refer to SECONDARY INSTALLATION - LOG SET
INSTALLATION for a flame appearance picture.
13. MAKE SURE that the conversion label is installed on or close to the
rating label to signify that the unit has been converted to a different
fuel type.
Fuel
Conversion
Tab on Pilot
7. Convert the SIT gas valve:
a) Remove the extension knobs from the valve.
b) Remove the black protection cap from the HI/LO knob
by hand shown in Figure 14.
c) Insert a 5/32” or 4 mm Allen wrench into the hexagonal
key-way of the screw (see Figure 15), rotate it counter-
clockwise until it is free and extract it.
d) Check that the screw is clean and if necessary remove
dirt.
Figure 13: Fuel Conversion Tab on Pilot.

Initial Installation
QUALIFIED INSTALLERS ONLY
WARNING: Operation of this heater when not connected to a properly installed and maintained venting
system can result in carbon monoxide (CO) poisoning and possible death.
PREPARATION FOR INSTALLATION:
• Remove the packaging from the appliance, and check to make sure there is no damage. If damage is
found, please report it to both the carrier and your dealer as soon as possible.
• Before beginning, carefully check the glass door and the log set
• Locate a position where the ue system of the stove can be properly installed without damaging the
integrity of the building; e.g. cutting a wall or ceiling joist.
• Check stove and ue system clearance requirements.
• Locate the stove where it can be accessed by a gas supply line.
• Locate the stove in a large and open room that is centrally located in the house. This will optimize heat
circulation and comfort.
• As the stove can be equipped with a convection fan, ensure that an electrical outlet is within 6 ft (1.8
m) of the stove.
• The ow of combustion and ventilation air must not be obstructed.
CLEARANCES TO COMBUSTIBLES:
CLEARANCES MUST BE SUFFICIENT TO ALLOW ACCESS FOR MAINTENANCE AND SERVICE.
Figure 19: Clearance to Walls in an Open
Area, refer to Table 3.
13
Table 3: Clearance to Walls in an Open Area, refer to Figure 19.
Letter Description Clearance
A Sidewall to unit 11 inches (279 mm)
B Backwall to unit 2.5 inches (64 mm)
C Corner to unit 2.5 inches (64 mm)
D Ceiling to oor 90 inches (2286 mm)
E Floor (on hardwood
and linoleum)
0 inches (0 mm)
Table 4: Clearance to Walls in an Alcove
Description Clearance
Minimum Width 43 inches (1105 mm)
Minimum Height 48 inches (1219 mm)
Maximum Depth 24 inches (610 mm)
B
A
Back Wall
Side Wall
C
C
Adjacent Wall
Adjacent Wall

Initial Installation
QUALIFIED INSTALLERS ONLY
PLANNING YOUR INSTALLATION:
Vertical
Termination
Storm Collar
Flashing
Round Support
Box/Wall Thimble
Ceiling Firestop
Pipelength
Pipelength
Cathedral Ceiling
Support Box
Pipelength
Round Support
Box/Wall Thimble
Pipelength
Horizontal
Termination
90° Elbow
Figure 20 Common Horizontal Installation.
Figure 21: Common Vertical Installation.
Round Support
Box/Wall Thimble
2 ft (610 mm)
Pipelength
36" (915 mm)
Snorkel
Onto Stove
Adaptor
Figure 22: Common Snorkel Installation.
14

When planning your installation, it will be necessary to select the proper length of vent pipe for your
particular requirements. It is important to note when passing through a wall, the maximum allowable
wall thickness is 10 inches (25.4 cm); 1 inches (3.8 cm) clearance to combustibles must be maintained.
Select the amount of vertical rise desired for “vertical-to-horizontal” type installations. To determine
the length of vent pipe required for vertical installations, measure the distance from the appliance ue
outlet to the ceiling, the ceiling thickness, the vertical rise through the attic or second story, and allow
for sufcient vent height above the roof line. For two story applications, a re stop is required at each
oor level. If an offset is needed in the attic, additional pipe and elbows will be required. To connect the
venting system to the appliance ue outlet, a twist-lock adapter is built into the appliance at the factory.
Refer to INITIAL INSTALLATION - VENT CONFIGURATION AND RESTRICTOR SETTINGS for venting parameters.
Your total vent pipe length must be within the grid area of Figures 24 and 25. If a 90° elbow is used in
the horizontal plane, 36” (91.4 cm) must be subtracted from the allowable horizontal run.
There are three (3) basic types of Direct Vent System installations. The three (3) types of installations are
shown in Figures 20 through 22.
APPROVED VENT PARTS:
Table 5: Approved Vent Manufacturers.
Manufacturer Trade Name Nominal Sizes
American Metal Products AmeriVent Direct 4” - 6 5/8”
Security Chimneys International LTD Secure Vent 4” - 6 5/8”
Selkirk Metalbestos Direct-Temp 4” - 6 5/8”
Simpson Dura-Vent Direct Vent GS 4” - 6 5/8”
The Cara replace has been tested and certied for use with AMERICAN METAL PRODUCTS “AMERIVENT
DIRECT”, SIMPSON DURAVENT TYPE GS PIPE FOR GAS STOVES. SECURITY CHIMNEY’S “SECURE VENT
DIRECT VENT SYSTEM” and SELKIRK “DIRECT-TEMP VENT SYSTEM” kits are available for horizontal and
vertical venting. When using Simpson Duravent, it is recommended that, before installation, a bead of
RTV High Temperature Silicone should be applied to each outer vent joint, and Mil-Pac to each inner
joint. When planning an installation, it will be necessary to select the proper length of vent pipe for the
particular requirements.
WARNING: Do not mix parts from different vent manufacturers’ systems.
EXCEPTION TO WARNING: This product has been evaluated by Intertek for using a Direct Vent GS
starting collar in conjunction with Secure Vent, Direct-Temp, and Ameri Vent Direct venting systems. Use
of these systems with the Direct Vent GS starting collar is deemed acceptable and does not affect the
Intertek WH listing of the appliance.
15
Initial Installation
QUALIFIED INSTALLERS ONLY

16
Table 6: Vent part numbers (Must state if galvanized or black wanted, PART NUMBERS).
Direct Vent GS Direct-Temp Secure Vent Ameri Vent Direct Description
908 4DT-6 SV4L6 6” pipe length
4D7 7” pipe length
907 4DT-9 9” pipe length
906 4DT-12 SV4L12 4D12 12” pipe length
904 4DT-24 SV4L24 4D2 24” pipe length
903 4DT-36 SV4L36 4D3 36” pipe length
902 4DT-48 SV4L48 4D4 48” pipe length
945 4DT-EL45 SV4EBR45 4D45B 45° elbow, black
990 4DT-EL90 SV4EBR90 4D90B 90° elbow, black
950 4DT-VS SV4VS Vinyl siding standoff/sheild
942 4DT-WT SV4RSN 4DWT Wall thimble
953 4DT-SC SV4FC 4DSC Storm collar
963 4DT-FS SV4BF 4DFSP Fire stop
988 4DT-WS/B SV4BM 4DWS Wall strap/support/band
970 4DT-HKA SV0SHK 4DHTK1 Horizontal termination kit (SD: Basic Kit,
SEL: Kit A, SC: Standard Kit)
911 11” to 14 ” pipe, adjustable
4DT-AJ 4D12A 4” to 10” pipe , adjustable
SV4LA12 1” to 12” pipe , adjustable
943 4DT-AF6 4DF Flashing, 0/12 to 6/12 roof pitch
943S 4DT-AF12 4DF12 Flashing, 7/12 to 12/12 roof pitch
SV4FA Flashing, 1/12 to 7/12 roof pitch
SV4FB Flashing, 8/12 to 12/12 roof pitch
943F SV4F Flat ashing
980 4DT-VC SV4CGV 4DVC Vertical termination
991 4DT-HVC High wind vertical termination
984 4DT-HC SV4CHC 4DHC Horizontal square termination
985 4DT-HHC High wind horizontal termination
978 4DT-VKC SV0FAK 4DVTK Vertical termination kit
981 4DT-ST36 SV4STC36 36” Snorkel Termination
971 4DT-HKB SV0SHK2 4DHTK2 Horizontal termination kit
(SD: Kit A, SEL: Kit B, SC: Kit)
Initial Installation
QUALIFIED INSTALLERS ONLY

17
1 In accordance with the current CSA B149, Natural Gas and Propane Installation Code.
2 In accordance with the current ANSI Z223.1 NFPA 54, National Fuel Gas Code.
* These numbers are only estimates. Clearance in accordance with installation codes and the requirements of the gas supplier.
t A vent shall not terminate directly above a side walk or paved driveway that is located between two single family dwellings and it serves both dwellings.
+ Permitted only if verandah, porch, deck, or balcony is fully open on a minimum of two sides beneath the oor.
NOTE: Venting terminals shall not be recessed into walls or siding.
Figure 23: Vent Termination Restrictions, refer to Table 7.
Initial Installation
QUALIFIED INSTALLERS ONLY
VENT TERMINATION RESTRICTIONS:
A
A
DE
LB
C
F
B
B
B
JMK
G
H
I
Openable
Fixed
Closed
Openable Fixed
Closed
Termination Cap Air Supply Inlet Gas Meter
G
G
Restriction Zone
(Termination not allowed)
N
O
Letter Canadian Installation 1US Installation2Description
A 12 in (30 cm) Clearance above grade, verandah, porch, deck, or balcony.
B 12 in (30 cm) 9 in (23 cm) Clearance from window or door that may be opened.
C 12 in (30 cm)* Clearance from permanently closed window (to prevent
condensation).
D 22-3/4 in (57.8 cm)* Vertical clearance to ventilated soft located above the
terminal, within a horizontal distance of 2 ft (60 cm) from
center line of terminal.
E 22-3/4 in (57.8 cm)* Clearance to unventilated soft.
F 12 in (30 cm)* Clearance to outside corner.
G 18 in (45.7 cm)* Clearance to inside corner.
H 3 ft (91 cm) within a height of
15 ft (4.5 m) above the meter/
regulator assembly
3 ft (91 cm) within a height of
15 ft (4.5 m) above the meter/
regulator assembly*
Clearance to each side of center line extended above
meter/regulator assembly.
I 3 ft (91 cm) 3 ft (91 cm)* Radial clearance around service regulator vent outlet.
J 12 in (30 cm) 9 in (23 cm) Clearance to non-mechanical air supply inlet to building, or
the combustion air inlet to any other appliance.
K 6 ft (1.83 m) 3 ft (91 cm) above if within 10
ft (3 m) horizontally
Clearance to mechanical air supply inlet.
L 7 ft (2.13 m)t 7 ft (2.13 m)*t Clearance above paved sidewalk or paved driveway located
on public property.
M 12 in / 30 cm+12 in / 30 cm*+Clearance under verandah, porch, deck, or balcony.
N 12 in (30 cm)* Clearance horizontally to any surface (such as an exterior
wall) for vertical terminations.
O 12 in (30 cm) Clearance above roof line for vertical terminations.
Table 7: Vent termination clearances, refer to Figure 23.

Initial Installation
QUALIFIED INSTALLERS ONLY
VENT CONFIGURATIONS AND RESTRICTOR SETTINGS:
Figure 24 and 25 shows the range of possible vent congurations if the unit is top vented, for vertical
and horizontal terminations, any layout that remains within the grid areas is acceptable. They also show
the vent restrictor required, relative to the length of vent pipe. Longer vertical vent lengths necessitate
greater restriction.
Having the fewest number of elbows is ideal, as they tend to disrupt air movement. Using 45˚ elbows is
preferable to using 90˚ elbows. Also, a shorter vent system will perform better than a longer one.
If the unit is rear vented it may have a maximum horizontal run of 36” (91.4 cm) and must be used with
a 36” (91.4 cm) snorkel termination.
Figure 24: Possible Vent Congurations for Top Vented;
Vertical and Horizontal Terminations with Elbows.
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
Feet of Vent From Top of Unit
75% RESTRICTOR
70% RESTRICTOR
50% RESTRICTOR
NO RESTRICTOR
0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
2 4 6 8 10 12 14 16 18 20
Horizontal Feet of Vent
Vertical Feet of Vent (From Top of Unit)
UP TO 2 ELBOWS
NO RESTRICTOR
50% RESTRICTOR
UP TO 4 ELBOWS
60% RESTRICTOR
UP TO 4 ELBOWS
1 ELBOW
NO RESTRICTOR
0
NOTE: For best results, 3' (76.2cm) or more of
vertical rise is recommended.
Figure 25: Possible Vent Congurations for Top
Vented; Straight Vertical Vent & Terminations.
18

19
Initial Installation
QUALIFIED INSTALLERS ONLY
RESTRICTOR INSTALLATION:
The ENVIRO CARA has been designed for use with an add-in restrictor. The restrictor is designed to
maintain ame appearance when installing this unit with vertical chimneys as well as installations with
longer horizontal vent applications. It does this by controlling the amount of air moving through the vent
pipe.
Figure 27: Flue Restrictor Installation.
Vent
Restrictor
Firebox Liners
Firebox
Baffle
1. Choose the appropriate restrictor
for the installation (see INITIAL
INSTALLATION - VENT CONFIGURATIONS
AND RESTRICTOR SETTINGS). To avoid
injury, install the restrictor when
the replace is cool or use welder’s
gloves or oven mitts.
2. Remove the glass door as shown in
the MAINTENANCE AND SERVICE - GLASS
DOOR REMOVAL.
3. Carefully remove the log set.
4. Slide the burner tray back just far
enough so the front edge of the
burner does not catch on the front
lip of the rebox. Lift the front
of the burner up and out of the
rebox.
5. Remove the rebox liner (see
SECONDARY INSTALLATION - INSTALLATION
OF FIREBOX LINERS).
6. Remove the two (2) Torx T-20
screws holding the back of the
rebox bafe in place and unhook
the front tabs (refer to Figure 26).
7. Remove two (2) ” hex head
screws for the restrictor, place
restrictor in the ue collar (see
Figure 27) and fasten in place with
the two (2) ” hex head screws.
8. Re-install the rebox bafe, rebox
liners, burner (see MAINTENANCE
AND SERVICE - BURNER REMOVAL &
INSTALLATION), log set (see SECONDARY
INSTALLATION - LOG SET INSTALLATION),
and the door.
9. Wait for the unit to warm up to
operating temperature to ensure a
proper and clean burning unit.
Torx T-20 screws
hold back of baffle.
Front tabs hook
on screws that
stay in firebox.
Firebox Baffle
Figure 26: Firebox Bafe Installation.

Initial Installation
QUALIFIED INSTALLERS ONLY
HORIZONTAL INSTALLATION:
1. Set the appliance in the desired location. Check to determine if wall studs or roof rafters are in the
way when the venting system is attached. If this is the case, you may want to adjust the location of
Sealant
Female
Locking
Lugs
Male
Locking
Lugs
Figure 28: Twist-Lock Connection.
Woodscrews
Wall Thimble
Strap
Sheet metal
screws
Fold strap
here
11/4"
(3.2cm)
Figure 30: Installing Decorative Wall Thimble.
10"
(254mm)
10"
(254mm)
Figure 29: Wall Framing Hole for
Horizontal Installation.
the appliance.
2. Direct vent pipe and ttings are designed with special twist-lock
connections. Assemble the desired combination of black pipe and
elbows to the appliance adapter with pipe seams oriented towards
the wall or oor, as much out of view as possible.
Place a bead of Mil-Pac on the outer edge of the inner exhaust pipe
(non-ared end). Place a bead of high temperature silicone on the
male edge of the outer pipe. Push the pipe sections completely
together, then twist-lock one section clockwise approximately 
turn, until the two sections are fully locked. The female locking
lugs will not be visible from the outside, on black pipe. They may
be located by examining the inside of the female ends as shown in
Figure 28.
Notes:
(a) Twist-lock procedure: four (4) indentations, located on the female
end of the pipes and ttings, are designed to slide straight onto the
male ends of adjacent pipes and ttings, by orienting the four pipe
indentations so they match and slide into the four entry slots on the
male end.
(b) Horizontal runs of vent pipe must be supported every 36” (915mm).
Wall straps are available for this purpose, also when running horizontal
pipe minimum clearances to combustibles must be maintained;
2” (51mm) at top, 1” (38mm) at sides, 1” (38mm) at
bottom.
3. With the pipe attached to the stove in the correct location, mark the
wall for a 10” (25.4cm) x 10” (25.4 cm) square hole (refer to Figure
29). The center of the square hole should match the center line of the
horizontal pipe. Cut and frame the 10” (25.4cm) x 10” (25.4cm) hole in
the exterior wall where the vent will be terminated. Refer to Figure 23
and Table 7. If the wall being
penetrated is constructed of
non-combustible material i.e.
masonry or concrete, a 7”
(17.8cm) hole is acceptable.
4. Position the horizontal vent
termination in the center
of the 10” (25.4cm) x 10”
(25.4cm) hole, and attach
to the exterior wall with
the four screws provided.
Before attaching the vent
termination to the exterior
20
