Enwork Skyline User manual

Skyline Compression Bracket Panel Topper Installation Guide – Rev A.
SKYLINE COMPRESSION TOPPER
SCREEN INSTALLATION GUIDE
SCREENS
TI0057
WARNING:
Acrylic screens scratch and scuff easily. After removing
protective lm, immediately and carefully install the screen.
DO NOT remove protective lm from acrylic screens, then stack
them in a pile or against each other. Experience shows this will
cause marring and scratching.

INSTALLATION GUIDE
1) PARTS AND FASTENERS INCLUDED
Acrylic Screen
PNX-1060-xx
Panel Clamp Bracket
PNM-1990-xx
10-24 x .375-.50 Binding Bolt
2) TOOLS AND SUPPLIES REQUIRED
Phillips Screw Driver

INSTALLATION GUIDE
Aligning the holes in the Acrylic Screen and
the Panel Clamp Bracket. Sandwich the Acrylic
Screen between the Panel Clamp Bracket.
Loosely attach all the Binding Bolts.
Install Screen/Clamp Bracket assembly over panel.
Tighten all Binding Bolt.
Assembly complete
FI GU RE 3.1
FIGURE 3.2
FIGURE 3.3
3) ASSEMBLY:

Specications subject to change without notice.
Rev 09.2020
