Angler WM-CG-710 User manual

INSTRUCTIONS
Retractable Green Screen
WM-CG-710

2
Thank you for choosing Angler.
Angler’s retractable 7 × 10-foot green screen is ideal for studios and meeting and
conference rooms where space is at a premium, and a green screen needs to be
deployed in seconds. The screen comes in a sturdy metal case that’s equipped
with keyholes for wall mounting, and hooks for suspending it from a ceiling. The
auto-lock holds the screen at the desired length and retracts it with a slight pull,
just like a window shade.
This screen provides a broad background that can fit up to five people and allow
you to shoot in portrait or landscape orientation. Adjust the height to capture
half- or whole-body shots, and use the chroma green backdrop to digitally insert
the background of your choice with most green-screen software. The polyester
fabric absorbs light and prevents glare for even illumination across the screen for
a flawless background from edge to edge.
Precautions
Please read and follow these instructions, and keep this manual in a safe
place.
Do not attempt to disassemble or repair the equipment—doing so will void
the warranty, and Angler will not be responsible for any damage.
Make sure the screen is mounted securely before proceeding.
Check the weight limitations of the supporting structure and mounting
components to ensure you do not exceed the lowest weight capacity.
Examine the front and back of the screen for dirt and debris before rerolling.
Follow the cleaning instructions in this manual.
All images are for illustrative purposes only.

3
Overview
Screen
Lanyard
Screen
handle
Ceiling-mount
hooks
Wall-mount
keyholes

4
Wall Mounting Instructions
1. Measure the distance between the keyholes at the back of the screen’s end
caps. Use that measurement to mark the locations of the mounting holes on
the wall. Use a level to make sure it's even.
Note: Drywall is not strong enough to support the backdrop for repeated use.
For a more secure wall mount, sink the screws into wall studs or fortify your wall
by adding a mounting plate, wood blocking, or bracing.
2. Drill holes in the marked locations for wall
anchors, molly bolts, or toggle bolts. If
you’re using wall anchors, tap the anchors
into the holes.
Note: Many wall anchors and molly bolts
are self-tapping and don’t require a drill for
installation.
3. Insert screws (for wall anchors), molly bolts,
or toggle bolts into the holes. Leave 1/8-
inch of each screw out of the wall. Make
sure they’re secure before mounting the
screen.
4. Align the screen's mounting holes with
the mounting screws, and seat the screen
onto the screws.
3
4

5
Ceiling Mounting Instructions
Use chains to suspend the screen from a ceiling.
1. Measure the distance between the
hooks on the screen’s end caps. Use that
measurement to determine how far apart
the chains should be.
2. Use eye hooks or similar fasteners to attach
the chains to the ceiling.
3. Use chain connectors like carabiners or
threaded quick links to attach the ceiling
mount hooks to the chains.
Wall Extension Bracket Mounting
You can also use chains to suspend the screen from a pair of wall extension
brackets. Mount the brackets to the wall, and then use the Ceiling Mounting
Instructions above to hang the screen from the brackets.
3

6
Operation
Pull the screen down with the lanyard or the
handle. When the screen is at the desired length,
slightly raise the screen to allow the auto-lock to
engage.
Retract the screen by using the handle or lanyard
to pull it down approximately 1 to 2 inches to
disengage the auto-lock, and slowly guide the
screen back into the case.
Important! To ensure the screen does not sustain damage during use:
•Pull the screen straight down and not at an angle to the wall.
• Gently pull the screen down, and slowly guide it up when you retract it.
• Don't let the screen scrape against the case.
• Pull from the handle, and not from the screen material itself.
• Do not touch the screen.
Maintenance
Clean the screen material with soap and water on a soft cloth. When the screen is
not in use, retract it into its case to keep the surface clean.

7
Type Manual
Screen Dimensions 6.9 × 9.9 ft. (211.1 × 302.3 cm)
Screen Color Chroma green
Material Polyester
Case Dimensions
(H × W × D) 3.7 × 86.75 × 3.2 in. (9.5 × 220.3 × 8.2 cm)
Weight 18.7 lb. (8.5 kg)
Specifications

One-Year Limited Warranty
This Angler product is warranted to the original purchaser to be free from defects in
materials and workmanship under normal consumer use for a period of one (1) year from
the original purchase date or thirty (30) days after replacement, whichever occurs later.
The warranty provider’s responsibility with respect to this limited warranty shall be limited
solely to repair or replacement, at the provider’s discretion, of any product that fails
during normal use of this product in its intended manner and in its intended environment.
Inoperability of the product or part(s) shall be determined by the warranty provider. If the
product has been discontinued, the warranty provider reserves the right to replace it with
a model of equivalent quality and function.
This warranty does not cover damage or defect caused by misuse, neglect, accident,
alteration, abuse, improper installation or maintenance. EXCEPT AS PROVIDED
HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY EXPRESS
WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT
LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights,
and you may also have additional rights that vary from state to state.
To obtain warranty coverage, contact the Angler Customer Service Department to obtain
a return merchandise authorization (“RMA”) number, and return the defective product
to Angler along with the RMA number and proof of purchase. Shipment of the defective
product is at the purchaser’s own risk and expense.
For more information or to arrange service, visit www.anglerlights.com or call Customer
Service at 212-594-2353.
Product warranty provided by the Gradus Group.
www.gradusgroup.com
Angler is a registered trademark of the Gradus Group.
© 2021 Gradus Group LLC. All Rights Reserved.
