EPOX MVP4M User manual

TRADEMARK
All products and company names are trademarks or
registered trademarks of their respective holders.
These specifications are subject to change without notice.
Manual Revision 1.0
May 10, 1999
MVP4M
ISA/PCI Motherboard with Onboard AGP
VGA, PCI Audio, PCI IDE and Super
Multi-I/O

FeaturesMVP4M
Page 2
FEATURES
MVP4M Features:
•Intel Pentium®Processor, Pentium Processor with MMX technology,
AMDK5/K6, Cyrix 6x86L/6x86MX & idtC6 operating at 133 ~ 500
MHzwith 321 ZIF socket 7 provides scalability to accept faster
Processors in the future.
•Designed with VIA MVP4 AGPset.
•Supports up to 512 Mega of DRAM (minimum of 16 MB) on board,
You can use 168-pin DIMM x 2.
•Supports (1) 16 bit ISA slots, (3) 32 bit PCI slots, (1) AMR Slot and provides
(2) independent high performance PCI IDE interfaces capable of supporting
PIO Mode 3/4 and Ultra DMA 33/66 devices. The MVP4M supports (3)
PCI Bus Master slots and a jumperless PCI INT# control scheme which re-
duces configuration confusion when plugging in PCI card(s).
•Supports ATAPI (e.g. CD-ROM) devices on both Primary and Secondary
IDE interfaces.
•Designed with lntegrated Multi I/O: (1) floppy port, (1) parallel port
(EPP,ECP), and (2) serial ports (16550 Fast UART).
Note: Japanese “Floppy 3 mode” is also supported
•Features Award Plug & Play BIOS. With Flash Memory you can always
upgrade to the current BIOS as they are released. (http://www.2themax.com
please visit our Technical Support section for the latest updates)
•MVP4M utilizes a Lithium battery which provides environmental
protection and longer battery life.
• Software power-down when using Windows®95/98.

FeaturesMVP4M
Page 3
•Supports ring-in feature (remote power-on through external modem,
allows system to be turned on remotely.
•Resume by Alarm - Allows your system to turn on at a preselected time.
•Supports CPU Hardware sleep and SMM (System Management Mode).
•Supports USDM software to offer motherboard various status.
•Supports the CPU and Chassis fan Auto stop in sleep mode.
•Built-in WOL (Wake On LAN) Connector.
• Built-in Sound Blaster/DirectSound AC97 Audio.
• Built-in AGP 2D/3D Graphics Accelerator.

InstallationMVP4M
Page 4
Figure 1
MVP4M Detailed Layout

InstallationMVP4M
Page 5
Easy Installation Procedure
The following must be completed before powering on your new system:
Configure Jumpers
System Memory Configuration
Device Connectors
Configure Jumpers
We design this motherboard with the two DIP Switch to make your install fast and
easy.
Note: The DIP Switch as depicted as shown (Figure 1) in their correct
physical orientation.
1WS UPC erocV
1234 5
NOV1.2
NOV2.2
NOV4.2
NOV8.2
NONOV9.2
NONOV2.3
2WS suB
kcolC
1234
NOzHM66
NOzHM57
NONOzHM38
NONOzHM09
NONOzHM59
NONONOzHM001
NONONOzHM501
NONONOzHM511
2WS UPC
reilpitluM
566
NOX2
NONOX5.2
NOX3
X5.3
NONOX4
NONONOX5.4
NONOX5
NOX5.5
SW1: CPU Vcore Voltage Selection
SW2: CPU Speed Selection

InstallationMVP4M
Page 6
* Reserved
CPUTypeSW2CPU
Bus
Clock
CPU
Multiplier
Pentium/MMX
AMDK5/K6
IDT-C6
Cyrix/IBM
6x86MX/MII1234567
166MHzPR200ONONON66MHz
2.5X
PR233ONONON75MHz
PR266ONONONON83MHz
PR300ONONONON95MHz
250MHzPR366ONONONONON100MHz
200MHzPR266ONON66MHz
3X
PR300ONON75MHz
250MHzPR333ONONON83MHz
PR400ONONON95MHz
300MHz*PR433ONONONON100MHz
233MHzPR300ON66MHz
3.5X
PR333ON75MHz
*PR400ONON83MHz
333MHz*PR466ONON95MHz
350MHz*PR500ONONON100MHz
266MHz*PR333ONONON66MHz
4X
*PR400ONONON75MHz
333MHz*PR466ONONONON83MHz
380MHz*PR533ONONONON95MHz
400MHz*PR550ONONONONON100MHz
300MHzONONONON66MHz4.5X
450MHzONONONONONON100MHz
333MHzONONON66MHz
5X475MHzONONONON95MHz
*500MHzONONONONON100MHz
366MHzONON66MHz5.5X
*550MHzONONONON100MHz
JP1ClearCOMS
1-2 :1-2Normal(default)
2-3 :ClearCMOS
J7
WOL(Wakup OnLAN)Connector
Reserved for NIC (Network Interface Card) to
Wake the System.

InstallationMVP4M
Page 7
System Memory Configuration
Memory Layout
The MVP4M supports (2) 168-pin DIMMs (Dual In-line Memory Module).
The DIMMs can be either EDO (Extended Data Out) or SDRAM (Synchronized
DRAM). The DIMMs may be installed using just one chip.
•We recommend using SDRAM DIMM can not mixing
with EDO DIMM modules.
• DIMM SDRAM may be 83MHz (-12ns), 100MHz (-10ns) or
125MHz (-8ns) bus speed.
• No Registered DIMM support.
Figure 2 and Table 1 show several possible memory configurations using
* SDRAM only supports 8, 16, 32, 64, 128, 256MB DIMM modules.
Table 1
yromeMlatoT 1MMID )0knaB( 2MMID )1knaB(
BM652= mumixaM
*MARDS/ODE ,BM46,BM23,BM61,BM8 1XBM652,BM821 enoN
BM215= mumixaM
*MARDS/ODE ,BM46,BM23,BM61,BM8 1XBM652,BM821 *MARDS/ODE ,BM46,BM23,BM61,BM8 1XBM652,BM821
DIMM 1
DIMM 2
Bank 0
Bank 1 -Synchronous
-EDO
Figure 2

InstallationMVP4M
Page 8
Device Connectors
Please install the motherboard into the chassis.
Now that your motherboard is installed you are ready to connect all your
connections (figure 6).
J2,J3:Chassis Panel Connector
• Power_LED, Speaker, Reset, Power_ON/OFF, Turbo LED and
HDD LED, IR Connector
J4:CPU Fan Power
• A plug-in for the CPU Fan Power
J6:Chassis Fan Power
• A plug-in for the chassis Fan Power
J7:WOL (Wake On LAN) Connector
JP1: CMOS Clear
AUX1: AUX Audio_in
CD1: CD-ROM Audio_in
COM2: RS232 COM2 Connector
IDE1: Primary IDE Connector
IDE2: Secondary IDE Connector
FDD1: Floppy Controller Connector
PW1: ATX Power Connector
• 20-pin power connector
USB Conn.: The second and third USB port (Cable optional)
PS/2 Mouse
PS/2
KEYBOARD
COM1 VGA1
parallel port
Speaker
Joystick/Midi
USB port
Line_in
MIC
Figure 6

InstallationMVP4M
Page 9
Device Connectors(continued)
J2
Speaker - Connect to the system's speaker for beeping
1. Speaker3. GND
2. N/C4. GND
Reset - Closed to restart system.
Power LED - Power LED connector
1. Power LED(+)4. NC
2. N/C5. GND
3. GND
1
1
1
(This is connected to the power button on the case. Using the
Soft-Off by Pwr-BTTN feature, you can choose either Instant
Off (turns system off immediately), or 4 sec delay (you need to
hold the button down for 4 seconds before the system turns off).
When the system is in 4 sec delay mode, there is a special feature
to make the system to go into suspend mode when the button is
pressed momentarily.)
Turbo LED indicator - LED ON when higher speed is selected
IDE LED indicator - LED ON when Onboard PCI IDE Hard
disks is activate
J3 1
+
+
IR Connector
1. VCC 4. GND
2. NC 5. IRTX
3. IRRX
1
Power On/Off
