EPS eSoft Pro User manual

Water Softener
Installation Manual

Introduction
Thank you for purchasing your eSoft Pro Water Softener. The Clack CI valve with which your water
softener is tted has been selected to provide the best eciency & performance possible. Only
attempt this installation if you have been trained on the installation of water softeners.
Packing List
Your water softener comprises of:
Assembled eSoft Water Softener
Transformer
¾” quick connect ttings
Overow adaptor
Installation Instructions
Firstly, the area needs to be level, have access to electricity and an open drain. Your water softener has
been designed to operate between 1.7 and 5 bar pressure. If your water pressure falls outside these
parameters it may be necessary to t a booster pump or a pressure reducing valve to prevent damage
to the unit. The operating temperature range of the appliance is 3°C and 45°C. Follow the instructions
supplied to connect the ¾”quick connect ttings.
Please observe local regulations concerning the installation of your system. Check that you have
allowed space for access to the unit for possible future maintenance. This installation may require
plumbing work and will require an electrical outlet to be tted near the system. If the system is
installed externally, take necessary precautions to prevent frost damage.
Inlet: This is the water supply from the mains or other. Always
install a suitable prelter on well water supplies.
Outlet:This is the softened water leaving the softener to
supply the rest of the house.
Drain: This is the water used during regeneration which is
ushed to drain. This water will be at mains pressure and must
be taken directly to a waste-pipe with an air gap.
O v e r  o w : This is used in the event of an over-ll of water
to the salt cabinet. This should always be taken directly to
a waste-pipe with an air gap. Install the supplied overow
tting by drilling a 20mm hole. Its recommended to install the
overow 2-3 inches below the salt lid of the cabinet.
Introduction
Thank you for purchasing your eSoft Water Softener. The Clack CI valve with which your water softener
is tted has been selected to provide the best eciency & performance possible. Only attempt this
installation if you have been trained on the installation of water softeners.
Packing List
Your water softener comprises of:
Assembled eSoft Water Softener
Transformer
¾” quick connect ttings
Installation Manual
Overow adaptor
Installation Instructions
Firstly, the area needs to be level, have access to electricity and an open drain. Your water softener
has been designed to operate between 1.7 and 5 bar pressure. If your pressure falls outside these
parameters it may be necessary to t a booster pump or a pressure reducing valve to prevent damage
to the unit. The operating temperature range of the appliance is 3°C and 45°C. Follow the instructions
supplied to connect the ¾”quick connect ttings.
Please observe local regulations concerning the installation of your system. Check that you have
allowed space for access to the unit for possible future maintenance. This installation may require
plumbing work and will require an electrical outlet to be tted near the system. If the system is
installed externally, take necessary precautions to prevent frost damage.
Inlet: This is the water supply from the mains or other. Always
install a suitable prelter on well water supplies.
Outlet:This is the softened water leaving the softener to
supply the rest of the house.
Drain: This is the water used during regeneration which is
ushed to drain. This water will be at mains pressure and must
be taken directly to a waste-pipe with an air gap.
Overow: This is used in the event of an over-ll of water
to the salt cabinet. This should always be taken directly to
a waste-pipe with an air gap. Install the supplied overow
tting by drilling a 20mm hole. Its recommended to install the
overow 2-3 inches below the salt lid of the cabinet.
1.
2.
3.
4.
5.
1.
2.
3.
4.

Controller Features
While in the service position, pressing the“Next” button will toggle between the time, current ow rate in
litres and the capacity remaining. Press and hold“Regen”to force an immediate regeneration. When the
valve is regenerating, it will show a countdown clock for each stage. Press“Regen”once to skip stages.
Warranty
This product is guaranteed for the period of one year from the date of purchase against mechanical and/
or electrical defects. This guarantee is only valid if the unit has been installed and used in accordance these
instructions.
Fig 1
Fig 2
Fig 3
Fig 4
Fig 5
Fig 6
Fig 7
Programming your water softener
To connect the power cable you need to rstly remove the cover, then
remove the drive bracket assembly by pressing up on the drive brackets
release tabs and pulling towards you. (Fig 1)
Feed the cable through the back plate (Fig 2) and connect to PC
board (Fig 3). Its important that the bracket is reapplied with a loud snap to
ensure the gears meet the drive gear.
Press“Set Clock” button, hours will ash.
Use up and down buttons to set hours.
Press“Next” button, set minutes and press“Next”.
Press“Next” and “Up”buttons together and hold until screen changes.
Set hardness based on raw water hardness of water supply.
Press“Next”. Leave next setting at 2 - 0.
Press“Next”. Set the day override (preset at 4).
Press“Next”. Set the regeneration time (preset at 2am).
1.
2.
3.
4.
5.
6.
7.
8.
Commissioning your water softener
With the softener now programmed, press & hold“Regen”until the motor
begins to turn. When the motor stops, the screen will appear as in Fig 4.
Now, open the inlet valve slowly to allow the softener ll with water. At this
point water will discharge to the drain and purge any air from the system.
Manually ll the internal salt tank with 10 litres of water. When the air is
purged from the system, press “REGEN”once to advance to the next cycle,
the screen will appear as in Fig 5. The system is now drawing water from the
internal tank ans slowly discharging to the drain. . Take the time to observe
the water level dropping (which happens very slowly). This is vital as it
ensures the system can regenerate and operate correctly. If the system will
not draw water from the internal tank ensure the ttings are tight and re-do
steps 1 & 2.
Press“REGEN”once, when the motor stops, the screen will appear as in
Fig 6. Monitor this cycle for a moment to ensure water ows well to drain.
Press“REGEN”once, when the motor stops, the screen will appear as in
Fig 7. At this point the system is relling the internal salt tank. Take a
moment to ensure the water level rises sueciently.
Press“REGEN”once, when the motor stops it the system is in HOME position
and ready to oer softened water.
Fill the unit with salt. Monitor the salt level on a regular basis & ll if required.
1.
2.
3.
4.
5.
6.

Schematic
This schematic outlines the best way to check the correct layout and installation of your eSoft water
cabinet.
21
Treated
Water
Raw
Water
5
6
3
4
7
Compact Design
Certified Valve
Up to 4 people
Volumetric
Water Softener
Intelligent
Controls
10L Cabinet
Water Softener
by
e
S ft
PRO
1. Pressure Reducing Valve
Raw water sample point /
Inlet pressure
Bypass
Backwash water pipe minimum
¾”
Drain with air gap
Treated water sample point /
Outlet pressure
2.
3.
4.
5.
6.
Recommended extra bypass
7.
assembly for servicing
Pre Filter & eSoft PRO 10L
By EPS
Assembly: Installation:
C
M
Y
CM
MY
CY
CMY
K
16 - Pre Filter & eSoft PRO 10L.pdf 2 22/10/2020 08:28
Integrated UV board
Sediment Prefilter
Change every 3 months
2
31
Robust Design
Certified
Valve
e S ft
PRO
Large
Family Home
Volumetric
Water Softener
Intelligent
Controls
by
30L Cabinet
Water Softener
WQA Certified
Resin
Assembled in
Ireland
Treated
Water Raw Water
6
7
4
5
8
VIQUA
Pre Filter & eSoft PRO 30L
By EPS
Assembly: Installation:
1. Non Return Valve
Raw water sample point /
Inlet pressure
Pressure Gauge
Bypass
Backwash water
pipe minimum ¾”
Drain with air gap
Treated water sample
point / outlet pressure
2.
3.
4.
5.
6.
7.
Recommended extra bypass
8.
assembly for servicing
C
M
Y
CM
MY
CY
CMY
K
08 - Pre Filter & eSoft PRO 30L.pdf 2 21/10/2020 16:08
21
Treated
Water
Raw
Water
5
6
3
4
7
Compact Design
Certified Valve
Up to 4 people
Volumetric
Water Softener
Intelligent
Controls
10L Cabinet
Water Softener
by
e
S ft
PRO
1. Pressure Reducing Valve
Raw water sample point /
Inlet pressure
Bypass
Backwash water pipe minimum ¾”
Drain with air gap
Treated water sample point /
Outlet pressure
2.
3.
4.
5.
6.
Recommended extra bypass
7.
assembly for servicing
Pre Filter & eSoft PRO 10L
By EPS
Assembly: Installation:
C
M
Y
CM
MY
CY
CMY
K
16 - Pre Filter & eSoft PRO 10L.pdf 2 22/10/2020 08:28
21
Treated
Water
Raw
Water
5
6
3
4
7
Compact Design
Certified Valve
Up to 4 people
Volumetric
Water Softener
Intelligent
Controls
10L Cabinet
Water Softener
by
e
S ft
PRO
1. Pressure Reducing Valve
Raw water sample point /
Inlet pressure
Bypass
Backwash water pipe minimum ¾”
Drain with air gap
Treated water sample point /
Outlet pressure
2.
3.
4.
5.
6.
Recommended extra bypass
7.
assembly for servicing
Pre Filter & eSoft PRO 10L
By EPS
Assembly: Installation:
C
M
Y
CM
MY
CY
CMY
K
16 - Pre Filter & eSoft PRO 10L.pdf 2 22/10/2020 08:28
Integrated UV board
Sediment Prefilter
Change every 3 months
2
31
Robust Design
Certified
Valve
eS ft
PRO
Large
Family Home
Volumetric
Water Softener
Intelligent
Controls
by
30L Cabinet
Water Softener
WQA Certified
Resin
Assembled in
Ireland
Treated
Water Raw Water
6
7
4
5
8
VIQUA
Pre Filter & eSoft PRO 30L
By EPS
Assembly: Installation:
1. Non Return Valve
Raw water sample point /
Inlet pressure
Pressure Gauge
Bypass
Backwash water
pipe minimum ¾”
Drain with air gap
Treated water sample
point / outlet pressure
2.
3.
4.
5.
6.
7.
Recommended extra bypass
8.
assembly for servicing
C
M
Y
CM
MY
CY
CMY
K
08 - Pre Filter & eSoft PRO 30L.pdf 2 21/10/2020 16:08

Naas, Co. Kildare
T045 843614
[e-mail] Wepswater.ie / esoft.ie
Mallow, Co. Cork
T022 31200
Ballyhaunis, Co. Mayo
T094 9633500
Mountrath, Co. Laois
T057 8732279
Naas, Co. Kildare
T045 843614
Installer Information
Installed by: Date:
Mallow, Co. Cork
T022 31200
Ballyhaunis, Co. Mayo
T094 9633500
Mountrath, Co. Laois
T057 8732279
Softener Specication 8 x 13 8 x 17 8 x 24 10 x 35
Total Height 523mm 625mm 800mm 1095mm
Total Depth 440mm 440mm 440mm 580mm
Width 240mm 240mm 240mm 350mm
Maximum working pressure 5 bar 5 bar 5 bar 5 bar
Minimum working pressure 1.7 bar 1.7 bar 1.7 bar 1.7 bar
Service ow rate 10L/min 10L/min 15L/min 23L/min
Pressure drop at service ow 0.2 bar 0.2 bar 0.35 bar 0.55 bar
Resin Volume 5 litres 8 litres 20 litres 30 litres
Minimum supply ow rate 5L/min 8L/min 8L/min 8L/min
Salt use per regeneration 0.75 kgs 1.2 kgs 3.0 kgs 4.5 kgs
Inlet / Outlet / Drain connections ¾”BSPM ¾”BSPM ¾”BSPM ¾”BSPM
Overow connections ⅜”hose sigot ⅜”hose sigot ⅜”hose sigot ⅜”hose sigot
Softening capacity @ 300ppm 830 litres 1330 litres 2500 litres 5000 litres
Note: It is not recommended to install any water softener in an attic.
Specification
