Epson ActionPC 8600 Installation and operation manual

EPSON ActionPC and ActionTower 8600
2/96 ActionPC and ActionTower 8600 - 1
POWER
light
SPEED
light
hard disk
accesslight
(HDD) drive bays RESET
button
Slimline
computer
diskette drive POWER
button
12
VGA
monitor
printer
(parallel
port)
serial 2serial 1
keyboard mouse
POWER
button
RESET
button
Tower
computer POWER light
SPEED light
hard disk
access light
(HDD)
drive bays
option
slots
VGA monitor
printer
(parallel port)
serial 2
serial 1
mouse
keyboard
power outlet
power inlet
voltage selector
switch
Computer Specifications
CPU and Memory
Controllers
64-bit CPU 586-class processor
Green PC
energy saver Energy Star compliant, low-power, doze, standby, and suspend modes for the CPU,
hard disk drive, and VGA display; select time-
out periods, power-saving rates, and other
options in SETUP
Memory 64-bit DRAM interface supporting 8MB RAM
standard on two 4MB SIMMs; expandable to
128MB using 4MB, 8MB, 16MB, and 32MB
SIMMs; SIMMs must be tin-plated, 72-pin,
32-bit or 36-bit, fast-page mode or EDO mode,
parity or no-parity type with access speed of
70ns or faster
ROM 128KB Phoenix
®
system BIOS, video BIOS,
and SETUP code in a flash memory device on
system board
Video RAM 1MB video DRAM on system board;
expandable to 2MB using two 512KB, 40-pin,
SOJ flat pack video DRAM chips
Shadow RAM Supports shadowing of system and video
BIOS ROM into RAM; video and option ROM
shadowing selectable in SETUP
Cache 16KB of internal cache in the processor;
256KB of external cache installed on system
board with two pipelined burst SRAM chips;
internal and external cache controllable
through SETUP
Math
coprocessor Math coprocessor built into the 586-class processor
Clock/
calendar Real-time clock, calendar, and CMOS RAM socketed on system board with integrated
backup battery
PCI chipset Provides PCI caching, memory, and control
for the PCI bus and the two-channel, bus-
mastered, PCI IDE interface (described under
Hard disk and other IDE devices below);
integrated PCI bridge translates CPU bus
cycles to PCI bus cycles and CPU-to-PCI
memory write cycles to PCI burst cycles

EPSON ActionPC and ActionTower 8600 champpig.fm5 (Left) 2/16/96 2:22pm
2 - ActionPC and ActionTower 8600 2/96
Interfaces
Video S3

Trio64V+

PCI VGA controller with
integrated 24-bit RAMDAC, 64-bit DRAM
interface; includes power-saving and
multimedia features; supports resolutions up
to 1280
×
1024 in 16 colors with 1MB of video
RAM, increasing to 256 colors with 2MB of
video RAM; True Color

support at 640
×
480
resolution and Hi-Color support at 800
×
600
resolution
Diskette Controller on system board supports up to
two diskette drives, or one diskette/combo
diskette and one tape drive
Hard disk and
other IDE
devices
Two PCI, ATA-2 compatible, bus-mastered
IDE interfaces on system board support up to
four IDE devices (two on each interface); IDE
CD-ROM drives cannot be connected to the
primary IDE interface or to the same interface
as IDE hard disk drives; BIOS provides hard
disk auto-sensing and enhanced IDE functions
Monitor Energy Star compliant video interface for
fixed or multifrequency monitor built into
system board; 15-pin, D-shell connector
Parallel One standard, multimode parallel interface
built into system board; supports 8-bit
unidirectional, 16-bit bidirectional EPP
(Enhanced Parallel Port) and ECP (Extended
Capability Port) modes; 25-pin, D-shell
connector; operation controllable by SETUP
program and jumpers
Serial Two high-speed RS-232C, programmable,
asynchronous interfaces built into system
board; 16C550 compatible; 9-pin, D-shell
connectors; operation controllable through
SETUP
Keyboard PS/2 compatible keyboard interface built into
system board; 6-pin, mini DIN connector
Mouse PS/2 compatible mouse interface built into
system board; 6-pin, mini DIN connector
Option slots Connector card with five I/O expansion slots;
three ISA compatible (8.33 MHz bus speed)
and two PCI bus-mastering slots (33 MHz bus
speed)
Speaker Internal
Mass
Storage
Slimline
Internal bay:
One 3.5-inch wide, one-inch high drive
Externally accessible bays:
One 3.5-inch wide, one-inch high drive and
two 5.25-inch wide, half-height drives
Tower
Front internal bay:
One 3.5-inch wide, one-inch high drive
Rear internal bracket:
Two 3.5-inch wide, one-inch high drives or
one 3.5-inch wide, full-height drive
Externally accessible bays:
Two 3.5-inch wide, one-inch high drives and
two 5.25-inch wide, half-height drives
Diskette drive
types 3.5-inch diskette drive, 720KB or 1.44MB storage capacity; 5.25-inch diskette drive,
360KB or 1.2MB storage capacity; or a
combination 3.5-inch/5.25-inch diskette drive
Hard disk
drive types 5.25-inch or 3.5-inch form factor hard disk drive(s), up to half-height size; maximum of
four drives
Other devices Half-height tape drives, CD-ROM drives,
optical drives, PCMCIA card readers, or other
devices; 5.25-inch, or 3.5-inch with mounting
frames
Keyboard
Detachable, two-position height; 104 or 105
sculpted keys; country-dependent main
typewriter keyboard; numeric/cursor control
keypad; four-key cursor control keypad;
12 function keys; 3 Windows 95 keys
Mouse
Detachable, two-button, PS/2 compatible
SETUP
Program
Stored in ROM; accessible by pressing Del
during boot
System
security User and Supervisor level passwords available for system boot or diskette access
Virus
protection Write protection feature for the hard disk drive boot sector

EPSON ActionPC and ActionTower 8600
2/96 ActionPC and ActionTower 8600 - 3
Power Supply
Option Slot Power Limits
Physical Characteristics
Environmental Requirements
Jumper Settings
*Default setting depends on speed of CPU
* Default setting
* Default setting
* Default setting
Type 200 Watt, UL/TUV/CSA listed, fan-cooled
Input ranges 98132 VAC or 196264 VAC; switch-
selectable
Maximum
output +5 VDC at 20 Amps, 5 VDC at 0.5 Amp +12 VDC at 8 Amps, 12 VDC at 0.5 Amp
Frequency 48 to 63 Hz
Cables Two to system board, five to mass storage
devices; for more than five devices, Y cables
can be installed on the existing cables
Output voltage
(VDC) +5 Volts –5 Volts +12 Volts –12 Volts
For all slots 12 Amps 0.4 Amp 4.0 Amps 0.4 Amp
Dimension Slimline Tower
Width 16.8 inches (427 mm) 7.125 inches (181 mm)
Depth 15.8 inches (401 mm) 16.25 inches(413 mm)
Height 4.4 inches (112 mm) 13.25 inches(337 mm)
Weight 18.2 lb (8.3 kg) with one
diskette drive, but without
keyboard
20.6 lb (9.3 kg) with one
diskette drive, but without
keyboard
Condition Operating range Storage range
Temperature 41
°
to 90
°
F
(5
°
to 32
°
C) –4
°
to 140
°
F
(–20
°
to60
°
C)
Humidity (non-condensing) 20% to 90% 10% to90%
Altitude –330 to 9,900 ft
(–100 to 3,000 m) –330 to 39,600 ft (–100 to 12,000 m)
CPU clock jumper settings
CPU type * External clock speed JP12 JP17 JP29
Cyrix 6x86-P120+ (100 MHz) 50 MHz Open 1-2 Open
Cyrix 6x86-P150+ (120 MHz) 60 MHz 3-4 1-2 Open
Cyrix 6x86-P166+ (133 MHz) 66 MHz 1-2, 3-4 1-2 Open
Pentium 75 MHz 50 MHz Open Open Open
Pentium 90 MHz 60 MHz 3-4 Open Open
Pentium 100 MHz 66 MHz 1-2, 3-4 Open Open
Pentium 120 MHz 60 MHz 3-4 1-2 Open
Pentium 133 MHz 66 MHz 1-2, 3-4 1-2 Open
Pentium 150 MHz 60 MHz 3-4 1-2 1-2
Pentium 166 MHz 66 MHz 1-2, 3-4 1-2 1-2
Parallel port ECP mode DMA channel (DRQ) settings
DMA channel JP23 JP24
DRQ1 1-2 * 1-2 *
DRQ3 2-3 2-3
VGA DRAM jumper settings
Timing mode JP3 JP20
Fast page mode 1-2 * 1-2 *
EDO mode 2-3 2-3
Miscellaneous jumper settings
Jumper
number Jumper setting Function
JP1 1-2
Open * Clear the CMOS SETUP values Normal CMOS operation
JP4 2-3 *
1-2 1MB video DRAM 2MB video DRAM
JP6 2-3 *
1-2 System clock PCICLK/4 System clock PCICLK/3
JP16 1-2
Open * Write-back cache Write-through cache
JP18 5-6 *
3-4
1-2
+3.3 V CPU voltage
+3.358 V – 3.36 V (VR) CPU voltage
+3.525 V – 3.528 V (VRE) CPU voltage
JP21 1-2 *
2-3 Enable VGA controller Disable VGA controller
JP22 1-2 *
2-3
Enable serial ports and diskette drive
controller
Disable serial ports and diskette drive
controller
J20 5-6, 7-8 *
Open Use serial port for infrared (IR) device Use IR module connector for IR device

EPSON ActionPC and ActionTower 8600 champpig.fm5 (Left) 2/16/96 2:22pm
4 - ActionPC and ActionTower 8600 2/96
System Board Components
The diagram below illustrates the components on the system board.
SVGA feature
connector
JP23 JP22 JP24
JP3
JP4 JP1
JP12
JP13
J9 U10
U22 U20
U33
U31
J21
U35
U28
U34
U29
U9 U8 U7
U26
S1
U3 U2
U17
JP21
JP20
JP6
JP9
JP8
JP10
JP11
JP16 JP17 JP15
JP29
JP18
J20
VGA
port parallel device port serial 2 port serial 1 port mouse port keyboard port
SIMM sockets
video memory
chips and sockets
diskette drive connector
primary IDE connector
secondary IDE connector
power supply
connector
tag RAM
external cache
speaker
video controller
core logic chipset
IR module
connector processor
VRM
connector voltage regulator

EPSON ActionPC and ActionTower 8600
2/96 ActionPC and ActionTower 8600 - 5
System board components
Connector Function
PS1 Power connector
J14 Primary IDE connector
J1 PS/2 keyboard connector
J13 Diskettedrive connector
J15 Secondary IDE connector
J22 HDD LED connector
J3 PS/2 mouse connector
J5 Serial 1 port connector
J6 Serial 2 port connector
J21 Pins 2-3: Turbo LED connector
Pins 9-10: Hardware reset connector
Pins 11-13: Power LED connector
Pins 17-20: Speaker connector
J7 Printer (parallel) port connector
J9 SVGA feature connector
J8 15-pin DIN type VGA connector
S1 Riser card slot; default settings of PCI AD Select are
AD12 and AD13
U28, U35 External cache SRAM chips
U2 AMIKEY-2 keyboard controller
U27 Cache tag RAM chip
U3 Phoenix system and video BIOS chip
U31 Processor (CPU)
U6 Dallas DS 12887 real-time clock chip
U17 SMC FDC 37C665parallel port super I/O diskette
controller
U8, U10 Soldered standard video RAM
U20, U29,
U33, U34 PCI chipset
U22 S3 Trio64V+ VGA controller
U7, U9 Video DRAM expansion sockets
SIMM Installation
The computer comes with 16MB of RAM standard on two
8MB SIMMs. You can increase the memory up to 128MB
using 4MB, 8MB, 16MB, or 32MB SIMMs. The SIMMs must be
tin-plated, 72-pin, single- or double-sided, fast-page mode or
EDO mode, parity or no-parity type with an access speed of
70ns or faster. Be sure all the SIMMs operate at the same
speed.
The table below lists all the possible SIMM configurations; do
not install SIMMs in any other configuration.
SIMM configurations
Bank 0 Bank 1
Total memorySIM1 SIM2 SIM3 SIM4
4MB 4MB — — 8MB
——4MB4MB8MB
4MB 4MB 4MB 4MB 16MB
4MB 4MB 8MB 8MB 24MB
4MB 4MB 16MB 16MB 40MB
4MB 4MB 32MB 32MB 72MB
8MB 8MB — — 16MB
— — 8MB 8MB 16MB
8MB 8MB 4MB 4MB 24MB
8MB 8MB 8MB 8MB 32MB
8MB 8MB 16MB 16MB 48MB
8MB 8MB 32MB 32MB 80MB
16MB 16MB — — 32MB
— — 16MB 16MB 32MB
16MB 16MB 4MB 4MB 40MB
16MB 16MB 8MB 8MB 48MB
16MB 16MB 16MB 16MB 64MB
32MB 32MB — — 64MB
— — 32MB 32MB 64MB
32MB 32MB 4MB 4MB 72MB
32MB 32MB 8MB 8MB 80MB
32MB 32MB 16MB 16MB 96MB
32MB 32MB 32MB 32MB 128MB

EPSON ActionPC and ActionTower 8600 champpig.fm5 (Left) 2/16/96 2:22pm
6 - ActionPC and ActionTower 8600 2/96
System Memory Map
Video Memory
The computer comes with 1MB of video memory. You can
increase the video memory to 2MB by installing two 512KB,
40-pin, SOJ flat pack video DRAM chips.
*Non-interlaced and interlaced
** Interlaced
Processor Upgrades
You can upgrade your processor with a faster one to improve
system performance. If you upgrade the processor,you may
want to lay the computer on its side to make the process
easier. If you are upgrading to a 100 MHz processor, make
sure you use a standard 3.3 V processor.
Address range Function
FE0000h-FFFFFFh 128KB duplication of ROM BIOS stored at
0E0000h-0FFFFFh
100000h-FDFFFFh System extended memory (128MB maximum)
0E0000h-0FFFFFh 128KB ROM BIOS
0C8000h-0DFFFFh Adapter ROM BIOS
0C0000h-0C7FFFh Video ROM BIOS
0A0000h-0BFFFFh 128KB video memory
000000h-09FFFFh 640KB base memory
Resolution
Memory
require-
ments Color Refresh rates (Hz) Remarks
640 ×480 1MB 256 60/72/75 8 bits/pixel
1MB 32K/64K 60/72/75 16 bits/pixel
2MB 16.8M
(True
Color)
60/72/75 24 bits/pixel
800 ×600 1MB 256 56/60/72/75 8 bits/pixel
1MB 32K/64K 60/72/75 16 bits/pixel
2MB 16.8M
(True
Color)
60/72/75 24 bits/pixel
1024 ×768 1MB 256 43.5/60/70/75 8 bits/pixel*
2MB 64K 43.5/60/70/75 16 bits/pixel**
1280 ×1024 1MB 16 43.5/60/72/75 4 bit planes*
2MB 256 43.5/60/72/75 8 bits/pixel**
1600 ×1200 2MB 256 43.5 8 bits/pixel**
Hard Disk Drive Types
The computer comes with a hard disk auto-sensing feature.
To use it, select one of the drives you have installed from the
Fixed Disk Setup screen. On the screen that appears for that
drive, press
Enter
to select the
Autotype Fixed Disk
option. The system detects the type of hard disk drive, fills in
the drives parameters, and sets the remaining options on the
screen.
Hard Disk Drive Information
The IDE hard disk drives listed in the tables below are
qualified for use in your computer.
IDE hard disk drive parameters
Parameters
Conner
®
NEC
®
Seagate
®
CFS1275A CFS850A CFS635A CFS541A D3747 D3745 ST31640A ST51270A ST3630A
Formatted
capacity (MB) 1275 850 635 540 1620 1080 1625 1282 631
Size,width ×
height (in) 4 ×14×14×14×14×14×14×14× .75 4 ×1
Weight (lb) 1.25 1.25 1.25 1.25 1.25 1.25 1.5 .75 1.3
Cylinders 3640 3640 3640 3924 3678 3678 4708 5414 3164
Disks 32213 2322
Heads 64326 4644
Sectors per
track 77 - 143 78 - 143 78 - 144 90 - 170 76 - 142 66 - 115
Rotational
speed (RPM) 3600 3600 3600 3600 4500 4500 5400 5400 3811
Buffer size
(KB) 64 64 64 64 256 256 256 128 120
Averageseek
time (ms) 14 14 14 14 11 11 10.5 10.5 14
Encoding
method RLL 1,7 RLL 1,7 RLL 1,7 RLL 1,7 PRML PRM LRLL 1,7 RLL 1,7 RLL 1,7
Power
dissipation
(seek)
3.5
W3.5 W3.5 W3.9 W4.0 W4.0W 8.41 W6.4W 5.2 W
Logical parameters
Cylinders 2477 1651 1238 1048 3144 2096 3150 2485 1223
Heads 16 16 16 16 16 16 16 16 16
Precomp
zone 00000 0000
Landing
zone 2477 1651 1238 1048 3144 2096 4726 5376 3164
Sectors 6363636363 63636363

EPSON ActionPC and ActionTower 8600
2/96 ActionPC and ActionTower 8600 - 7
DMA Assignments
Hardware Interrupts
IDE hard disk drive settings
Model number Single drive Master drive Slave drive
Conner CFS1275A C/D jumpered C/D jumpered No jumpers
Conner CFS850A C/D jumpered C/D jumpered No jumpers
Conner CFS635A C/D jumpered C/D jumpered No jumpers
Conner CFS541A C/D jumpered C/D jumpered No jumpers
NEC D3747 SW1 on,
SW2–SW4 off SW1 on, SW2–SW4 off SW1–SW4 off
NEC D3745 SW1 on,
SW2–SW4 off SW1 on, SW2–SW4 off SW1–SW4 off
Seagate ST31640A No jumpers 3-4 jumpered 1-2 jumpered
Seagate ST51270A No jumpers 3-4 jumpered 1-2 jumpered
Seagate ST3630A No jumpers No jumpers 7-8 jumpered
Level Assigned device
DMA0 Reserved
DMA1 Available
DMA2 Diskette drive controller
DMA3 Available
DMA4
Cascade from DMA1
DMA5 Spare
DMA6 Spare
DMA7 Spare
IRQ no. Function
IRQ0 Internal timer
IRQ1 Keyboard
IRQ2 Cascade to IRQ9
IRQ3 Serial port 2
IRQ4 Serial port 1
IRQ5 LPT2
IRQ6 Diskette drive controller
IRQ7 Parallel port 1
IRQ8 Real-time clock
IRQ9 Cascaded from IRQ2
IRQ10 Available
IRQ11 Available
IRQ12 PS/2 mouse
IRQ13 Mathcoprocessor
IRQ14 Primary IDE controller
IRQ15 Secondary IDE controller
System I/O Address Map
Hex address Assigned device
000 - 01F DMA controller 1, 8237
020 - 03F Interrupt controller 1, 8259
022 - 024 Reserved
040 - 05F Timer, 8254
060 - 06F Keyboard controller, 8242PE
070 - 07F Real-time clock NMI (non-maskable interrupt)
080 - 09F DMA page register, 74LS612
0A0 - 0BF Interrupt controller 2, 8259
0C0 - 0DF DMA controller 2, 8237
0F0 Clear math coprocessor
0F1 Reset math coprocessor
0F8 - 0FF Math coprocessor
1F0 - 1F8 Primary hard disk interface
1E0 - 1E7 Secondary hard disk interface
200 - 207 Game I/O
278 - 27F Parallel printer port 2
2B0 - 2DF Alternate enhanced graphics adapter
2E1 GPIB (adapter 0)
2E2, 2E3 Data acquisition (adapter 0)
2F8 - 2FF Serial port 2
300 - 31F Prototype card
360 - 363 Available
368 - 36B Available
378 - 37A Parallel printer port 1
380 - 38F Available
390 - 393 Available
3A0 - 3AF Available
3B0 - 3BF Available
3C0 - 3CF VGA adapter
3D0 - 3DF VGA adapter
3F0 - 3F5 Diskette drive controller
3F8 - 3FF Serial port 1
6E2, 6E3 Available
790 - 793 Available
AE2, AE3 Available
B90, B93 Available
EE2, EE3 Available
1390 - 1393 Available
22E1 Available
2390 - 2393 Available
42E1 Available
63E1 Available
82E1 Available
A2E1 Available
C2E1 Available
E2E1 Available

EPSON ActionPC and ActionTower 8600 champpig.fm5 (Left) 2/16/96 2:22pm
8 - ActionPC and ActionTower 8600 2/96
Connector Pin Assignments
*Active LOW logic
Parallel port connector pin assignments (J7)
Pin Signal Pin Signal Pin Signal
1Strobe* 10 ACK * 19 Signal ground
2Data 0 11 Busy 20 Signal ground
3Data 1 12 PE 21 Signal ground
4Data 2 13 Select 22 Signal ground
5Data 3 14 AFD * 23 Signal ground
6Data 4 15 Error * 24 Signal ground
7Data 5 16 Init * 25 Signal ground
8Data 6 17 Selectin * — —
9Data 7 18 Signal ground — —
Serial port connector pin assignments (J5 and J6)
Pin Signal Pin Signal
1 Data carrier detect 6 Data set ready
2Receive data 7 Request to send
3 Transmit data 8 Clear to send
4 Data terminal ready 9 Ring indicator
5Ground — —
Mouse and keyboard connector pin assignments (J1 and J3)
Pin Signal Pin Signal
1Data 4 VCC
2 NC 5 Clock
3Ground 6 NC
VGA port connector pin assignments (J8)
Pin Signal Pin Signal Pin Signal
1Red 6 Red ground 11 NC
2Green 7 Green ground 12 Monitor detect
3Blue 8 Blue ground 13 Horizontal sync
4NC 9 NC 14 Vertical sync
5Ground 10 Ground 15 NC
LED connector pin assignments (J21)
Pin Signal Pin Signal
1NC 11 Power LED (yellow)
2 Turbo LED (yellow) 12 NC
3Turbo LED (white) 13 Power LED (white)
4NC 14 NC
5NC 15 NC
6NC 16 NC
7NC 17 Speaker (red)
8NC 18 NC
9Hardware reset (white) 19 NC
10 Hardware reset (yellow) 20 Speaker (black)
* All odd-numbered pins are grounds
*Active low logic
HDD LED connector pin assignments (J22)
Pin Signal Pin Signal
1Red 2White
Power supply connector pin assignments (PS1)
Pin Signal Pin Signal
1 Power good 7 Ground
2 +5 VDC 8 Ground
3 +12 VDC 9 -5 VDC
4 -12 VDC 10 +5 VDC
5 Ground 11 +5 VDC
6 Ground 12 +5 VDC
Diskette drive connector pin assignments (J13)
Pin* Signal Pin* Signal
2NC 20Step
4 NC 22 Write data
6 NC 24 Write enable
8 Index 26 Track 0
10 Motor A 28 Write protect
12 Drive B 30 Read data
14 Drive A 32 Select header 0
16 Motor B 34 Disk change
18 Direction
IDE drive connector pin assignments (J14 and J15)
Pin Signal Pin Signal Pin Signal
1 RESET* 15 D1 29 NC
2 Ground 16 D14 30 Ground
3D7 17D0 31IRQ14
4 D8 18 D15 32 IOCS16*
5 D6 19 Ground 33 A1
6D9 20NC 34NC
7D5 21NC 35A0
8 D10 22 Ground 36 A2
9 D4 23 IOW* 37 CS0*
10 D11 24 Ground 38 CS1*
11 D3 25 IOR* 39 Active*
12 D12 26 Ground 40 Ground
13 D2 27 IOCHRDY*
14 D13 28 BALE

EPSON ActionPC and ActionTower 8600
2/96 ActionPC and ActionTower 8600 - 9
*Active low logic
Option card riser board connector pin assignments
Pin Signal Pin Signal Pin Signal Pin Signal
A1 +12 VDC A31 SA3 B1 +12 VDC B31 BALE
A2 Ground A32 SA2 B2 +5 VDC B32 +5 VDC
A3 Ground A33 SA1 B3 Ground B33 OSC
A4 IOCHCK* A34 SA0 B4 Ground B34 Ground
A5 SD7 A35 Ground B5 RESETDRV B35 Ground
A6 SD6 A36 Ground B6 +5 VDC B36 +5 VDC
A7 SD5 A37 +5 VDC B7 IRQ9 B37 +5 VDC
A8 SD4 A38 SBHE* B8 5 VDC B38 MEMCS16*
A9 SD3 A39 LA23 B9 DRQ2 B39 IOCS16*
A10 SD2 A40 LA22 B10 12 VDC B40 IRQ10
A11 SD1 A41 LA21 B11 OWS* B41 IRQ11
A12 SD0 A42 LA20 B12 +12 VDC B42 IRQ12
A13 IOCHRDY A43 LA19 B13 Ground B43 IRQ15
A14 AEN A44 LA18 B14 SMEMW* B44 IRQ14
A15 SA19 A45 LA17 B15 SMEMR* B45 DACK0*
A16 SA18 A46 MEMR* B16 IOW* B46 DRQ0
A17 SA17 A47 MEMW* B17 IOR* B47 DACK5*
A18 SA16 A48 SD8 B18 DACK3* B48 DRQ5
A19 SA15 A49 SD9 B19 DRQ3 B49 DACK6*
A20 SA14 A50 SD10 B20 DACK1* B50 DRQ6
A21 SA13 A51 SD11 B21 DRQ1 B51 DACK7*
A22 SA12 A52 SD12 B22 REFRESH* B52 DRQ7
A23 SA11 A53 SD13 B23 SYSCLK B53 +5 VDC
A24 SA10 A54 SD14 B24 IRQ7 B54 MASTER*
A25 SA9 A55 SD15 B25 IRQ6 B55 Ground
A26 SA8 A56 Ground B26 IRQ5 B56 Ground
A27 SA7 A57 Ground B27 IRQ4 B57 Ground
A28 SA6 A58 Ground B28 IRQ3 B58 +5 VDC
A29 SA5 A59 +5 VDC B29 DACK2* B59 +5 VDC
A30 SA4 A60 +5 VDC B30 TC B60 +5 VDC
* Active low logic
* Active low logic
ISA option slot connector pin assignments
Pin Signal Pin Signal Pin Signal Pin Signal
A1 IOCHCK* A26 SA5 B20 SYSCLK C14 SD11
A2 SD7 A27 SA4 B21 IRQ7 C15 SD12
A3 SD6 A28 SA3 B22 IRQ6 C16 SD13
A4 SD5 A29 SA2 B23 IRQ5 C17 SD14
A5 SD4 A30 SA1 B24 IRQ4 C18 SD15
A6 SD3 A31 SA0 B25 IRQ3 D1 Memcs16*
A7 SD2 B1 Ground B26 DACK2* D2 IOCS16*
A8 SD1 B2 RESETDRV B27 T/C D3 IRQ10
A9 SD0 B3 +5 VDC B28 BALE D4 IRQ11
A10 IORDY B4 IRQ9 B29 +5 VDC D5 IRQ12
A11 AEN B5 5 VDC B30 OSC D6 IRQ15
A12 SA19 B6 DRQ2 B31 Ground D7 IRQ14
A13 SA18 B7 12 VDC C1 SBHE* D8 DACK0*
A14 SA17 B8 OWS* C2 SA23 D9 DREQ0
A15 SA16 B9 +12 VDC C3 SA22 D10 DACK5*
A16 SA15 B10 Ground C4 SA21 D11 DREQ5
A17 SA14 B11 SMEMW* C5 SA20 D12 DACK6*
A18 SA13 B12 SMEMR* C6 SA19 D13 DRQ6
A19 SA12 B13 IOW* C7 SA18 D14 DACK7*
A20 SA11 B14 IOR* C8 SA17 D15 DREQ7
A21 SA10 B15 DACK3* C9 MEMR* D16 +5 VDC
A22 SA9 B16 DREQ3 C10 MEMW* D17 MASTER*
A23 SA8 B17 DACK1* C11 SD8 D18 Ground
A24 SA7 B18 DREQ1 C12 SD9
A25 SA6 B19 REF* C13 SD10
SIMM socket connector pin assignments
Pin Signal Pin Signal Pin Signal Pin Signal
1 Ground 19 NC 37 DP1 55 DQ11
2 DQ0 20 DQ4 38 DP3 56 DQ27
3DQ1621DQ2039Ground57DQ12
4 DQ1 22DQ5 40CAS0* 58DQ28
5DQ1723DQ2141CAS2*59VCC
6 DQ2 24DQ6 42CAS3* 60DQ29
7DQ1825DQ2243CAS1*61DQ13
8 DQ3 26DQ7 44RAS0* 62DQ30
9DQ1927DQ2345RAS1*63DQ14
10VCC 28A7 46A10A 64DQ31
11 NC 29 NC 47 WE* 65 DQ15
12 A0 30 VCC 48 A10B 66 NC
13 A1 31 A8 49 DQ8 67 PD1
14 A2 32 A9 50 DQ24 68 PD2
15 A3 33 RAS3* 51 DQ9 69 PD3
16 A4 34 RAS2* 52 DQ25 70 PD4
17 A5 35 DP2 53 DQ10 71 NC
18 A6 36 DP0 54 DQ26 72 Ground

EPSON ActionPC and ActionTower 8600 champpig.fm5 (Left) 2/16/96 2:22pm
10 - ActionPC and ActionTower 8600 2/96
Tested Operating Environments
Although your system will run most software applications,
the following operating environments have been tested for
compatibility with your system.
Microsoft
®
MS-DOS 3.3 and later
Novell NetWare* 3.12 and 4.1
Novell Personal NetWare
IBM
®
OS/2; including version 3.0 (Warp)
SCO
®
UNIX
SCO Open Desktop
Microsoft Windows 3.1 and later
Microsoft Windows 95
Microsoft Windows for WorkGroups
Microsoft Windows NT

; including version 3.5
*Certified as workstation and file server in certain configurations
As new environments become available, these also will be
tested.
Installation/Support Tips
Installing Diskette Drives
❏
Make sure that the drive type has been correctly selected in
the SETUP program.
❏
Make sure jumper JP22 is set to position 1-2 to enable the
diskette drive controller. Also make sure that the Diskette
Controller option is enabled in the BIOS SETUP program.
Installing Hard Disk Drives
❏
If you are installing a drive that cannot use the embedded
IDE interface (such as an ESDI drive), it is recommended
that you use a 16-bit, AT-type hard disk controller and a
PCI hard disk controller for higher performance. If you
install a non-IDE hard disk drive and controller card, you
must disable the built-in IDE hard disk drive interface (use
the Local Bus IDE Adapter option in the BIOS SETUP
program). Also, remove the hard disk drive ribbon
connector from the system board.
❏
When installing an IDE hard disk drive, use the auto-
sensing feature in SETUP to select the correct type for the
drive. If the auto-sensing feature does not produce a match
for the drive, you can define your own drive type by
selecting
User
as the type and entering the drive's
parameters.
Installing Option Cards
If you are installing a video adapter card, make sure you
disable the built-in VGA controller by setting jumper JP21
to 2-3.
Booting Sequence
If you cannot boot the computer from the hard disk, make
sure the booting sequence in SETUP is set to
A: then C:
.
Then boot the computer from a system diskette in drive A.
Password
If you forget your password, you must discharge your CMOS
memory as follows:
1. Turn off the computer and remove the cover.
2. Disable the password by setting jumper JP1 on the system
board to position 1-2.
3. Turn the computer on, leave it on for a few seconds, then
turn it off again.
4. Set jumper JP1 back to the Open position (remove jumper)
to enable the password function.
5. Run SETUP to enter a new password, if desired.
Information Reference List
Engineering Change Notices
None.
Technical Information Bulletins
None.
Product Support Bulletins
None.
Related Documentation
TM- EPSON ActionPC 8600, ActionTower 8600
Service Manual
PL- EPSON ActionPC 8600, ActionTower 8600
Parts Price List
400537700 EPSON ActionPC 8600, ActionTower 8600
Users Guide
